AUTOMATIC DRIVE POSITIONER CONTROL UNIT
ADP-33
< ECU DIAGNOSIS INFORMATION >
C
D
E
F
G
H
I
K
L
M
A
B
ADP
N
O
P
10
(L/O)
Ground
Door mirror motor (pas-
senger side) up output
signal
Output
Door mirror RH
Operate
(up)
12
Other than the
above
0
11
(Y/B)
Ground
Door mirror motor (pas-
senger side) left output
signal
Output
Door mirror RH
Operate
(left)
12
Other than the
above
0
12
(SB)
Ground
Door mirror motor (driver
side) down/right output
signal
Output
Door mirror (LH)
Operate
(down/right)
12
Other than the
above
0
13
(LG)
Ground
Tilt switch down signal
Input
Tilt switch
Operate
(down)
0
Other than the
above
5
14
(BR)
Ground
Changeover switch LH
signal
Input
Changeover
switch position
LH
0
Neutral or RH
5
15
(O/L)
Ground
Mirror switch down sig-
nal
Input
Mirror switch
Operate
(down)
0
Other than the
above
5
16
(V/W)
Ground
Mirror switch right signal
Input
Mirror switch
Operate
(right)
0
Other than the
above
5
17
(L/R)
Ground
Door mirror sensor (pas-
senger side) left/right
signal
Input
Door mirror RH position
Change between 3.4 (close to
left edge) 0.6 (close to right
edge)
18
(G/W)
Ground
Door mirror sensor (driv-
er side) left/right signal
Input
Door mirror LH position
Change between 0.6 (close to
left edge) 3.4 (close to right
edge)
19
(G)
Ground
Telescopic switch back-
ward signal
Input
Telescopic
switch
Operate
(backward)
0
Other than the
above
5
20
(Y)
Ground
Sensor ground
—
—
0
21
(W/L)
Ground
Door mirror motor sen-
sor power supply
Input
—
5
22
(V)
Ground
Door mirror motor (pas-
senger side) down/right
output signal
Output
Door mirror (RH)
Operate
(down/right)
12
Other than the
above
0
23
(L/W)
Ground
Door mirror motor (driver
side) up output signal
Output
Door mirror (LH)
Operate
(up)
12
Other than the
above
0
Terminal No.
(wire color)
Description
Condition
Voltage (V)
(Approx.)
+
-
Signal name
Input/
Output
