AUDIO

AV-33

C

D

E

F

G

H

I

J

L

M

A

B

AV

Terminals and Reference Value for BOSE Speaker Amp.

NKS001HU

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

3 (W)

4 (R/L)

Microphone signal

Input

ON

When inputting some
sounds (voice, etc.) toward
the microphone

5 (LG)

Ground

Communication
signal (+)

Input/

Output

ON

6 (PU)

Ground

Communication
signal (–)

Input/

Output

ON

7

Shield

11 (Y)

Ground

Battery power supply

Input

OFF

Battery voltage

13 (P)

29 (L/Y)

Audio signal front door
speaker RH

Output

ON

Receive audio signal

15

Shield

16 (R/G)

17 (R/W)

Audio signal rear door
speaker LH

Output

ON

Receive audio signal

18 (G/R)

19 (G/W)

Audio signal instru-
ment speaker LH

Output

ON

Receive audio signal

PKIA2104E

SKIB7378E

SKIB7379E

SKIB3609E

SKIB3609E

SKIB3609E

AV-34

AUDIO

21 (Y)

20 (L)

Audio signal instru-
ment speaker center

Output

ON

Receive audio signal

23 (G)

22 (R)

Audio signal instru-
ment speaker RH

Output

ON

Receive audio signal

25 (P)

24 (PU)

Audio signal rear door
speaker RH

Output

ON

Receive audio signal

27 (B)

Ground

Ground

ON

Approx. 0 V

28

(BR/W)

12

(BR)

Audio signal woofer

Output

ON

Receive audio signal

30 (L/B)

14 (L/W)

Audio signal front door
speaker  LH

Output

ON

Receive audio signal

31

Shield

32

Shield

34 (OR/L)

Ground

ACC power supply

Input

ACC

Battery voltage

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AUDIO

AV-35

C

D

E

F

G

H

I

J

L

M

A

B

AV

40 (L/G)

39 (L/Y)

Audio signal LH

Input

ON

Receive audio signal

41 (Y/R)

38 (Y/B)

Audio signal RH

Input

ON

Receive audio signal

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

SKIB3609E

SKIB3609E

AV-36

AUDIO

Terminals and Reference Value for CD Auto Changer

NKS001HV

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

2 (L/R)

1 (L/Y)

Audio signal LH

Output

ON

Play back CD on CD auto
changer

4 (G)

3 (OR)

Audio signal RH

Output

ON

Play back CD on CD auto
changer

5

Shield

6

Shield

8 (Y)

Ground

Communication signal
REQ (CHG-AUDIO)

Output

ON

When setting to CD auto
changer mode

9 (L)

Ground

Communication signal
Tx (CHG-AUDIO)

Output

ON

When setting to CD auto
changer mode

10 (G)

Ground

Communication signal
Rx (AUDIO-CHG)

Input

ON

When setting to CD auto
changer mode

12

(PU/W)

Ground

Battery power supply

Input

OFF

Battery voltage

13 (SB)

Ground

Illumination control
signal

ON

illumination control switch is
operated by lighting switch
in ON position

Changes between approx. 0 and
approx. 12 V

14 (R/L)

13 (SB)

Illumination signal

Input

ON

illumination control switch is
operated by lighting switch
in ON position

Changes between approx. 0 and
approx. 12 V

Lighting switch OFF

Approx. 0 V

15 (B)

Ground

Ground

ON

Approx. 0 V

16 (L/OR)

Ground

ACC power supply

Input

ACC

Battery voltage

SKIB3609E

SKIB3609E

SKIB7338E

SKIB7337E

SKIB7336E
