CHARGING SYSTEM SC-19 C D E F G H I J L M A B SC Trouble Diagnosis with Battery/Starting/Charging System Tester AKS002EH NOTE: 1. Turn off all loads on the vehicle electrical system. 2. Perform battery and starting system test with Battery/Starting/ 3. Press “ENTER” to begin the charging system test. 4. Start engine. 5. Press “ENTER” until “LOADS OFF REV ENGINE 5 SEC” is dis- 6. Raise and hold the engine speed at 1,500 to 2,000 rpm for about NOTE: ● If after 30 seconds an increase in engine idle speed is not ● Some engines may have a higher idle initially after starting, 7. The tester now checks the engine at idle and performs the 8. When complete, the tester will prompt you to turn on the follow- ● Heater fan set to highest speed. Do not run the A/C or wind- ● Headlamp high beam ● Rear window defogger NOTE: 9. Press “ENTER” to continue. SEL417X SEL418X SEL419X SEL420X |
