Infiniti M45 (Y34). Manual - part 580





POWER WINDOW SYSTEM

GW-31

C

D

E

F

G

H

J

K

L

M

A

B

GW

Terminals and Reference Value for Passenger, Rear LH, RH Door Control Unit

AIS001MX

(): Passenger door control unit

TERMI-

NAL

WIRE

COLOR

ITEM

CONDITION

Voltage (V)

(Approx.)

(1)

PU

Limit switch signal

Passenger side door window is in a position
between fully-open and just before fully-closed
position (ON)

0

Passenger side door window is in a position
between just before fully-closed position and
fully-closed position (OFF)

5

3

L/W

Power window motor
DOWN signal

When power window motor DOWN operates

Battery voltage

(4)

W

Encoder power supply

When ignition switch ON or power window timer
operates

10

10

(W/R)

Y/B

BAT power supply

Battery voltage

11

B

Ground

0

(12)

G

Encoder pulse signal

When power window motor operates

14

L/R

Power window motor
UP signal

When power window motor UP operates

Battery voltage

15

L/Y

Local data line

When ignition switch ON or power window timer
operates

OCC3383D

SIIA0591J

GW-32

POWER WINDOW SYSTEM

Trouble Diagnosis Symptom Chart

AIS001MY

Check that other systems using the signal of the following systems operate normally.

Symptom

Diagnostic procedure.

Refer to page

None of the power windows can be operated using any switch

Check the following.

40A fusible link (letter H, located in fuse and fus-
ible link box)

Harness for open and short between fuse and
driver control unit (LCU01).

Harness for open and short between BCM and
driver door control unit (LCU01).
Refer to

BL-76, "COMMUNICATION DIAGNO-

SIS"

 .

Driver door control unit (LCU01)

Driver door control unit power and ground circuit
check.

BCM

One or more power windows cannot be operated using front
power window main switch

1. Driver door control unit circuit check

GW-43

2. Communication signal circuit check

GW-33

Driver side power window cannot be operated but other win-
dows can be operated

1. Driver door control unit circuit check

GW-43

2. Front power window regulator (driver side) cir-
cuit check

GW-34

Passenger side power window cannot be operated

1. Passenger door control unit circuit check

GW-43

2. Communication signal circuit check

GW-33

3. Front power window regulator (passenger side)
check

GW-35

Rear LH or RH power window cannot be operated

1. Rear door control unit (LH or RH) circuit check

GW-44

2. Communication signal circuit check

GW-33

3. Rear power window regulator LH or RH check

GW-36

Anti-pinch system does not operate normally. (driver side)

1. Limit switch is adjusted

GW-48

2. Limit switch check (driver side)

GW-37

3. Encoder switch check (driver side)

GW-39

4. Door window sliding part malfunction.

A foreign material adheres to window glass or
glass run rubber.

Glass run rubber wear or deformation.

Sash is tilted too much, or not enough.

5. Replace driver door control unit

EI-31

Anti-pinch system does not operate normally. (passenger side)

1. Limit switch is adjusted

GW-48

2. Limit switch check (passenger side)

GW-38

3. Encoder switch check (passenger side)

GW-41

4. Door window sliding part malfunction.

A foreign material adheres to window glass or
glass run rubber.

Glass run rubber wear or deformation.

Sash is tilted too much, or not enough.

5. Replace passenger door control unit

EI-31

POWER WINDOW SYSTEM

GW-33

C

D

E

F

G

H

J

K

L

M

A

B

GW

Communication Signal Circuit Check

AIS001MZ

1.

CHECK COMMUNICATION SIGNAL

1.

Turn ignition switch OFF.

2.

Check the signal between malfunctioning door control unit connector and ground with oscilloscope.

OK or NG

OK

>> Communication signal is OK.

NG

>> GO TO 2.

Power window timer function does not operate properly

1. Door switch check

GW-45

2. Communication signal circuit check

GW-33

Check the following

harness for open and short between BCM and
driver door control unit (LCU01).
Refer to

BL-76, "COMMUNICATION DIAGNO-

SIS"

BCM

Key switch check

Does not operate by the key cylinder switch.

1. Door key cylinder switch circuit check.

GW-45

2. Driver door control unit circuit check

GW-43

3. Replace driver door control unit

EI-31

Symptom

Diagnostic procedure.

Refer to page

Connector

Terminals (Wire color)

signal

(+)

(–)

D38 (passenger)

D58 (rear LH)

D78 (rear RH)

15 (L/Y)

Ground

PIIA2681E

SIIA0591J

GW-34

POWER WINDOW SYSTEM

2.

CHECK COMMUNICATION CIRCUIT

1.

Disconnect driver door control unit (LCU01) and malfunctioning door control unit connector.

2.

Check continuity between driver door control unit (LCU01) and malfunctioning door control unit connector.

Driver door control unit (LCU01) connector D8 terminal 5 and
passenger door control unit connector D38 terminal 15.

Driver door control unit (LCU01) connector D8 terminal 5 and
rear LH door control unit connector D58 terminal 15.

Driver door control unit (LCU01) connector D8 terminal 5 and
rear RH door control unit connector D78 terminal 15.

3.

Check continuity between driver door control unit (LCU01) connector D8 terminal 5 and body ground.

OK or NG

OK

>> Replace driver door control unit (LCU01).

NG

>> Repair or replace harness between driver door control unit (LCU01) and malfunctioning door con-

trol unit.

Front Power Window Regulator Circuit Check (Driver Side)

AIS001N0

1.

CHECK DRIVER DOOR CONTROL UNIT OUTPUT SIGNAL

1.

Turn ignition switch OFF.

2.

Disconnect front power window regulator (driver side) connector.

3.

Turn ignition switch ON.

4.

Check voltage between front power window regulator (driver side) connector and ground.

OK or NG

OK

>> Replace front power window regulator (driver side).

NG

>> GO TO 2.

5 (L/Y) – 15 (L/Y)

: Continuity should exist.

5 (L/Y) – 15 (L/Y)

: Continuity should exist.

5 (L/Y) – 15 (L/Y)

: Continuity should exist.

 5 (L/Y) – Ground

: Continuity should not exist.

PIIA2682E

Connector

Terminals (Wirer color)

Condition

Voltage (V)

(Approx.)

(+)

(–)

D7

1 (L/R)

Ground

Closing

Battery voltage

Opening

2 (L/W)

Closing

0

Opening

Battery voltage

PIIA2705E
