REMOTE KEYLESS ENTRY SYSTEM

BL-101

C

D

E

F

G

H

J

K

L

M

A

B

BL

5.

Touch “IVMS”.
If “IVMS” is not indicated, go to

GI-38, "CONSULT-II Data Link

Connector (DLC) Circuit"

 .

6.

Check the model specification, touch either “WITH SUNROOF”
or “WITHOUT SUNROOF”.

7.

Touch “OK”. If the selection is wrong, touch “CANCEL”.

8.

Touch “MULTI-REMOTE CONT SYS”.

9.

Touch “WORK SUPPORT”.

10. The item shown on the figure at right can be set up.

●

“REMO CONT ID CONFIR”
Use this mode to confirm if a electronic key ID code is registered
or not.

●

“REMO CONT ID REG”
Use this mode to register a electronic key ID code.

NOTE:
Register the ID code when electronic key or BCM is replaced, or
when additional electronic key is required.

●

“REMO CONT ID ERASUR”
Use this mode to erase a electronic key ID code.

PIIA0183E

PIIA0184E

PIIA0373E

SEL274W

BL-102

REMOTE KEYLESS ENTRY SYSTEM

Removal and Installation of Remote Keyless Entry Receiver

AIS001Q7

REMOVAL

1.

Remove the rear pillar finisher upper (LH). Refer to

EI-34, "BODY SIDE TRIM"

 .

2.

Disconnect the remote keyless entry receiver connector, mount-
ing screw and remove the remote keyless entry receiver.

INSTALLATION

Install in the reverse order of removal.

PIIA3440E

DOOR

BL-103

C

D

E

F

G

H

J

K

L

M

A

B

BL

DOOR

PFP:80100

Fitting Adjustment

AIS001E9

FRONT DOOR
Longitudinal Clearance and Surface Height Adjustment at Front End

1.

Accessing from inside the fender, loosen the hinge mounting bolts. Raise the front door at rear end to
adjust.

REAR DOOR
Longitudinal Clearance and Surface Height Adjustment at Front End

1.

Remove the center pillar upper garnish and center pillar lower garnish. Refer to

EI-34, "BODY SIDE

TRIM"

 .

2.

Accessing from inside the vehicle, loosen the mounting bolts and nuts. Open the rear door, and raise the
rear door at rear end to adjust.

STRIKER ADJUSTMENT

1.

Remove the striker cover.

PIIA3061E

SIIA0886E

BL-104

DOOR

2.

Adjust the striker so that it becomes parallel with the lock inser-
tion direction.

Removal and Installation of Front Door

AIS001EA

REMOVAL

CAUTION:

●

When removing and installing the front door assembly, support the door with a jack and cloth to
protect the door and body.

●

When removing and installing front door assembly, be sure to carry out the fitting adjustment
Refer to

BL-103, "Fitting Adjustment"

 .

●

Operate with two workers, because of its heavy weight.

●

Check the hinge rotating part for poor lubrication. If necessary, apply “body grease”.

●

After installing, check operation.

1.

Pull the lever and remove the front door harness connector
while removing tabs of door harness connector.

2.

Remove the mounting bolts of the check link on the vehicle.

3.

Remove the door-side hinge mounting nuts, and remove the
door assembly.

SIIA0338E

PIIA2514E

PIIA2515E

PIIA3057E
