TROUBLE DIAGNOSIS FOR SYMPTOMS AT-269 D E F G H I J K L M A B AT 5. CHECK LINE PRESSURE Check line pressure at idle with selector lever in “D” position. Refer . OK or NG OK >> GO TO 8. NG - 1 >> Line pressure high. GO TO 6. 6. DETECT MALFUNCTIONING ITEM 1. Check control valve assembly. Refer to AT-312, "Control Valve Assembly" 2. Disassemble A/T. Refer to . 3. Check the following items: – Oil pump assembly. Refer to . OK or NG OK >> GO TO 8. NG >> Repair or replace damaged parts. 7. DETECT MALFUNCTIONING ITEM 1. Check control valve assembly. Refer to AT-312, "Control Valve Assembly" 2. Disassemble A/T. Refer to . 3. Check the following items: – Oil pump assembly. Refer to . – Power train system. Refer to – Transmission case. Refer to OK or NG OK >> GO TO 8. NG >> Repair or replace damaged parts. 8. CHECK A/T FLUID CONDITION 1. Remove oil pan. Refer to AT-312, "Control Valve Assembly" 2. Check A/T fluid condition. Refer to . OK or NG OK >> GO TO 9. NG >> GO TO 12. SAT494G SCIA5199E |
