HEADLAMP (FOR USA) - CONVENTIONAL TYPE -

LT-17

C

D

E

F

G

H

I

J

L

M

A

B

LT

TKWT5061E

LT-18

HEADLAMP (FOR USA) - CONVENTIONAL TYPE -

TKWT5274E

HEADLAMP (FOR USA) - CONVENTIONAL TYPE -

LT-19

C

D

E

F

G

H

I

J

L

M

A

B

LT

Terminals and Reference Values for BCM

NKS003O4

CAUTION:

●

Check combination switch system terminal waveform under the loaded condition with lighting
switch, turn signal switch and wiper switch OFF not to be fluctuated by overloaded.

●

Turn wiper dial position to 4 except when checking waveform or voltage of wiper dial position.
Wiper dial position can be confirmed on CONSULT-II. Refer to

LT-238, "DATA MONITOR"

 .

Termi-

nal No.

Wire

color

Signal name

Measuring condition

Reference value

Ignition

switch

Operation or condition

2

L/R

Combination

switch input 5

ON

Lighting, turn, wiper
switch
(Wiper dial position 4)

Lighting switch HI beam
(Operates only HI beam
switch)

Approx. 1.0 V

Lighting switch 2ND

Approx. 2.0 V

OFF

Approx. 0 V

3

O/L

Combination

switch input 4

ON

Lighting, turn, wiper
switch
(Wiper dial position 4)

Any of several con-
ditions below

●

Lighting switch 2ND

●

Lighting switch
PASSING (Operates
only PASSING switch)

Approx. 1.0 V

OFF

Approx. 0 V

11

V

Ignition switch

(ACC)

ACC

—

Battery voltage

PKIB4957J

PKIB4953J

PKIB4957J

LT-20

HEADLAMP (FOR USA) - CONVENTIONAL TYPE -

34

L

Combination

switch output 3

ON

Lighting, turn, wiper
switch
(Wiper dial position 4)

Any of several con-
ditions below

●

Lighting switch 2ND

●

Lighting switch HI
beam
(Operates only HI
beam switch)

Approx. 1.2 V

OFF

Approx. 7.0 - 7.5 V

35

SB

Combination

switch output 2

ON

Lighting, turn, wiper
switch
(Wiper dial position 4)

Any of several con-
ditions below

●

Lighting switch 2ND

●

Lighting switch
PASSING (Operates
only PASSING switch)

Approx. 1.2 V

OFF

Approx. 7.0 - 7.5 V

37

LG

Key switch signal

OFF

Intelligent Key is inserted into key slot.

Battery voltage

Intelligent Key is removed from key slot.

Approx. 0 V

38

W

Ignition switch

(ON)

ON

—

Battery voltage

39

L

CAN

−



H

—

—

—

40

P

CAN

−



L

—

—

—

42

P

Battery power

supply

OFF

—

Battery voltage

52

B

Ground

ON

—

Approx. 0 V

55

W

Battery power

supply

OFF

—

Battery voltage

Termi-

nal No.

Wire

color

Signal name

Measuring condition

Reference value

Ignition

switch

Operation or condition

PKIB4958J

PKIB4960J

PKIB4958J

PKIB4960J
