2003 Q45 – Quick Reference – Electrical

7

2003 Q45 – Htr & A/C

PERFORMANCE TEST CONDITIONS

  Vehicle indoors or in the shade

 Doors

closed

 Windows

open

 Hood

open

  Temperature on "Max" setting

  Discharge air on "Face Vent"

  Recirculation switch on "Recirc"

  Fan speed on "High"

  A/C switch "On" and verify A/C Clutch engagement

  Engine speed at idle

  Operate the A/C system for 10 minutes before taking measurements

Precautions:

1. When removing the compressor, store it in the same position as it is mounted in the vehicle.

Failure to do so may cause lubricant to enter the low pressure chamber and cause compressor
damage.

2. Allow components stored in cool areas to warm to area temperatures before removing seals.

This prevents condensation from forming inside A/C components.

2003 Q45 – Quick Reference – Electrical

8

2003 Q45 – Suspension

WHEEL ALIGNMENT (UNLADEN)

Suspension Inspection

Ball Joint End Play
Vertical End Play

0 in (0 mm)

Front Wheel Bearing
Axial End Play

0.0 in (0.0 mm)

Rear Wheel Bearing

Axial End Play

0.0 in (0.0 mm)

Wheel Runout

Max. Lateral / Radial Runout:
0.012 in (0.3 mm) or less

Wheel arch Height (Unladen)

Front Height (Hf)

Rear Height (Hr)

255/55 R17

28.74 in (730 mm)

27.72 in (704 mm)

225/55 R17 Run Flat

28.90 in (734 mm)

27.83 in (707 mm)

245/55 R18

28.58 in (726 mm)

27.60 in (700 mm)

Front Wheel Alignment

Toe-in

Range

Nominal

Total toe-in

0.08 - 0.0 in (2 - 0 mm)

0.04 in (1 mm)

Front Wheel Turning Angle (full turn)

In/Wheel Range

41.75

°

 - 45.75

°

  (41

°

45’ - 45

°

45’)

In/Wheel Nominal

42.75

°

 (42

°

45’)

Out/Wheel Nominal

33.83

°

 (33

°

50’)

Camber
Range

-1.50

°

 - 0.0

°

 (-1

°

30’ - 0

°

0’)

Nominal

-0.75

°

 (-0

°

45’)

Lt/Rt Difference

1.00

°

 (1

°

) or less

Caster
Range

5.42

°

 - 6.92

°

 (5

°

25’ - 6

°

55’)

Nominal

6.17

°

 (6

°

10’)

Lt/Rt Difference

1.00

°

(1

°

) or less

Kingpin Inclination
Range

13.25

°

 - 14.75

°

 (13

°

15’ - 14

°

45’)

Nominal

14.0

°

 (14

°

0’)

Rear Wheel Alignment

Toe-in

17 in Wheel

18 in Wheel

Total toe-in Range

-0.079 to 0.142 in

-0.063 to 0.157 in

(-2.0 to 3.6 mm)

(-1.6 to 4.0 mm)

Nominal

0.031 in (0.8 mm)

0.047 in (1.2 mm)

Camber
Range

-0.92

°

 to 0.08

°

-1.08

°

 to 0.08

°

(-0

°

55’ to 0

°

05’)

(-1

°

05’ to 0

°

05’)

Nominal

-0.42

°

 (-0

°

25’)

-0.58

°

 (-0

°

35’)

W/Lug Nut Torque

72-87 ft/lb (10-12 kg/m)

Mark Actual

To Confirm

Notes

2003 Q45 – Quick Reference – Electrical

9

2003 Q45 – Suspension

PRELIMINARY INSPECTION

  Check tires for wear and proper inflation

  Check wheel runout

  Check front wheel bearings excessive play

  Check front suspension for excessive play

  Check steering linkage for excessive play

  Check struts for leakage and condition

  Check vehicle for proper ride height

Precautions

1. When installing rubber parts, final tightening must be carried out under unladen conditions with

the tires on the ground.

2. Recheck alignment after installing removed suspension components.

2003 Q45 – Quick Reference – Electrical

10

2003 Q45 – Brakes

BRAKE SYSTEM

Brake Model Code

Front Disc Brake

Rear Disc Brake

CLZ31VA AD14VD

Brake Fluid

DOT 3 (Recommended)

Master Cyl. Bore Dia.

1 in (25.4 mm)

Cylinder Bore Dia. 1.687 in (42.86 mm)x2       1.727 in (43.8 mm)

Brake Pad Dimensions
Length

5.0 in (127.0 mm)

3.835 in (97.4 mm)

Width

2.2 in (56.0 mm)

1.335 in (33.9 mm)

Thickness

0.374 in (9.5 mm)

0.39 in (10.0 mm)

Brake Pad Wear Limit
Min. Thickness

0.079 in (2.0 mm)

0.079 in (2.0 mm)

Brake Rotor Dimensions
Standard Thickness

1.10 in (28 mm)

0.63 in (16 mm)

Brake Rotor Repair/Wear Limits
Max. Runout

0.0028 in (0.07 mm)

0.0039 in (0.1 mm)

Min. Thickness

1.024 in (26.0 mm)

0.55 in (14 mm)

Max. Thk. Variation

0.0006 in (0.015 mm)

0.0006 in (0.015 mm)

Brake Pedal Dimen.
Free Height 'H'

7.57 - 7.97 in
(192.4 - 202.4 mm)

Depressed Height 'D'

3.54 in (90 mm) or more

Pedal Free Play 'A'

0.12 - 0.43 in (3.0 - 11.0 mm)

Switch Clearance 'C'

0.0291 - 0.0772 in (0.74 - 1.96 mm)

Brake Booster

Model M215T

Input Rod Length

4.92 in (125 mm)

Parking Drum Brake

DS17HF

Inside Diameter

6.77 in (172 mm)

Brake Shoe Dimension
Thickness

0.126 in (3.2 mm)

Parking Drum Brake Repair/Wear Limit
Max Inside Diameter

6.81 in (173.0 mm)

Shoe Minimum Thk.

0.059 in (1.5 mm)

Parking Brake Control

Number of Notches 4 - 5

Wheel Lug Nut

72-87 ft lb (10-12 kg-m)

Mark Actual

To Confirm

Notes
