VEHICLE INFORMATION AND INTEGRATED SWITCH SYSTEM /WITH NAVIGA-
TION SYSTEM
DI-139
C
D
E
F
G
H
I
J
L
M
A
B
DI
WARNING INDICATIONS
When combination meter receives warning signal from some control units or sensors, then combination meter
warning lamp is illuminated.
Then combination meter sends warning signal to AV and NAVI control unit to display warning indications on
the screen.
Warning indicators
Warning lamps in
instrument panel
Warning detection and cancel conditions
Cases of malfunction
MALFUNCTION
SERVICE
ENGINE
SOON
Detection condition
Warning lamp ON signal is detected
while engine is running.
ECM malfunction
Cancel condition
Warning lamp OFF signal is
detected.
ENGINE OIL PRES-
SURE
Engine oil
pressure
Detection condition
Warning lamp ON signal is detected
for at least approx. 5 seconds while
engine is running.
[Engine oil pressure: MAX. approx.
29kPa (0.3 kg/cm
2
, 4psi)]
Engine oil pressure
decreases
Cancel condition
Warning lamp OFF signal is
detected. [Engine oil pressure: MIN.
approx. 29kPa (0.3kg/cm
2
, 4psi)]
SUPPLEMENTAL AIR
BAG
Air bag
Detection condition
Warning lamp ON signal is detected
for at least approx. 10 seconds after
ignition switch is turned ON.
SRS air bag system
malfunction
Cancel condition
Warning lamp OFF signal is
detected.
LOW BRAKE FLUID
Brake
Detection condition
Warning lamp ON signal (fluid level)
is detected.
Low brake fluid level
Cancel condition
Warning lamp OFF signal is
detected.
OVERHEATING
–
Detection condition
Engine coolant temperature as
being approx. 119
°
C (246
°
F) min.
Engine cooling system
malfunction
Cancel condition
Engine coolant temperature as
being approx. 105
°
C (221
°
F) max.
CHARGE
Charge
Detection condition
Warning lamp ON signal is detected
while engine is running. Charging
system malfunction
Charging system mal-
function
Cancel condition
Warning lamp OFF signal is
detected.
LOW WASHER FLUID
–
Detection condition
Washer liquid level falls below
approx. 0.4
.(7/8USqt, 3/4 Imp pt)
Low washer liquid level
Cancel condition
Except above condition.
LOW FUEL
Fuel level
Detection condition
After warning lamp ON signal is
detected, vehicle is driven for over
specified distance. (Fuel level:
Approx. 14.0
(14
−
3/4 USqt,12
−
3/
8 Imp pt)
Low fuel level
Cancel condition
Warning lamp OFF signal is
detected.
PARKING BRAKE
Brake
Detection condition
Parking brake ON signal is detected
while vehicle is running [approx. 5
km/h (3MPH) or faster].
Parking brake remains
engaged.
Cancel condition
Vehicle is stopped, or parking brake
OFF signal is detected.
