DTC P1845 ATF PRESSURE SWITCH 5 AT-229 D E F G H I J K L M A B AT Diagnostic Procedure ECS0088Y 1. INPUT SIGNALS With CONSULT-II 1. Start engine. 2. Select “ECU INPUT SIGNALS” or “MAIN SIGNALS” in “DATA 3. Accelerate vehicle in the “D” position (1st Þ 2nd gear), and con- firm the ON/OFF actuation of the “ATF PRES SW 5”. OK or NG OK >> GO TO 4. NG >> GO TO 2. 2. CHECK HARNESS BETWEEN TCM AND A/T UNIT ASSEMBLY HARNESS CONNECTOR 1. Turn ignition switch to “OFF” position. 2. Disconnect TCM connector. 3. Check continuity between A/T unit assembly harness connector 4. If OK, check harness for short to ground and short to power. 5. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors. PCIA0067E Item Connector No. Terminal No. (Wire color) Continuity TCM F103 22 (P/B) Yes A/T unit assembly harness F26 6 (P/B) TCM F104 40 (Y/G) Yes A/T unit assembly harness F26 2 (Y/G) SCIA3101E |
