Infiniti I30 (A33). Manual

QUICK REFERENCE CHART: I30

2001

Engine model

VQ30DE

Firing order

1-2-3-4-5-6

Idle speed

rpm

A/T
(in “N” position)

700±50

Ignition timing (degree BTDC at idle speed)

A/T: 15°±2°

CO% at idle

Idle mixture screw is preset and

sealed at factory.

Drive belt deflection adjustment (Cold)

mm (in)

Used belt

Deflection of

new belt

Alternator

Limit

Deflection

after

adjustment

With air conditioner compressor

7 (0.28)

4.2 - 4.6

(0.165 - 0.181)

3.7 - 4.1

(0.146 - 0.161)

Without air conditioner compressor

10 (0.39)

6.3 - 6.9

(0.248 - 0.272)

5.6 - 6.0

(0.220 - 0.236)

Power steering oil pump

11 (0.43)

7.3 - 8

(0.287 - 0.315)

6.5 - 7.2

(0.256 - 0.283)

Applied pushing force

N (kg, lb)

98 (10, 22)

Drive belt tension adjustment (Cold)

N (kg, lb)

Used belt

New belt

Limit

After adjust-

ment

Alternator

With air conditioner compressor

294 (30, 66)

730 - 818

(74.5 - 83.5,

164 - 184)

838 - 926

(85.5 - 94.5,

188 - 208)

Without air conditioner compressor

294 (30, 66)

730 - 818

(74.5 - 83.5,

164 - 184)

838 - 926

(85.5 - 94.5,

188 - 208)

Power steering oil pump

196 (20, 44)

495 - 583

(50.5 - 59.5,

111 - 131)

603 - 691

(61.5 - 70.5,

136 - 155)

Applied pushing force

—

Radiator cap relief pressure

kPa (kg/cm

, psi)

78 - 98 (0.8 - 1.0, 11 - 14)

Cooling system leakage testing pressure

kPa (kg/cm

, psi)

157 (1.6, 23)

Compression pressure

kPa (kg/cm

, psi)/rpm

Standard

1,275 (13.0, 185)/300

Minimum

981 (10.0, 142)/300

High tension cable resistance

Ω

—

Spark plug

Type

Standard

PFR5G-11

Hot

PFR4G-11

Cold

PFR6G-11

Gap (Nominal) mm (in)

1.1 (0.043)

Tire size

225/50R17

215/55R16

Camber

Degree minute

(Decimal degree)

Minimum

−1°00

′

(−1.00°)

Nominal

−0°15

′

(−0.25°)

Maximum

0°30

′

(0.50°)

Left and right difference

′

(0.75°) or less

Caster

Degree minute

(Decimal degree)

Minimum

2°00

′

(2.00°)

Nominal

2°45

′

(2.75°)

Maximum

3°30

′

(3.50°)

Left and right difference

′

(0.75°) or less

Total toe-in

Minimum

0 (0)

Distance (A − B)

mm (in)

Nominal

1 (0.04)

Maximum

2 (0.08)

Angle (left plus right)

Degree minute

(Decimal degree)

Minimum

′

(0)

Nominal

′

(0.10°)

Maximum

′

(0.20°)

Wheel turning angle (Full turn)

Minimum

29°30

′

(29.50°)

36°00

′

(36.00°)

Inside

Degree minute

(Decimal degree)

Nominal

33°00

′

(33.00°)

39°30

′

(39.50°)

Maximum

34°00

′

(34.00°)

40°30

′

(40.50°)

Outside

Degree minute

(Decimal degree)

Nominal

28°30

′

(28.50°)

32°00

′

(32.00°)

* Fuel, radiator coolant and engine oil full.

Spare tire, jack, hand tools and mats in designated positions.

Camber

Degree minute

(Decimal degree)

Minimum

−1°45

′

(−1.75°)

Nominal

−1°00

′

(−1.00°)

Maximum

−0°15

′

(−0.25°)

Total toe-in

Minimum

−3 (−0.12)

Distance (A − B)

mm (in)

Nominal

1 (0.04)

Maximum

5 (0.20)

Angle (left plus right)

Degree minute

(Decimal degree)

Minimum

−16

′

(−0.27°)

Nominal

′

″

(0.09°)

Maximum

′

(0.43°)

* Fuel, radiator coolant and engine oil full.

Spare tire, jack, hand tools and mats in designated positions.

Unit: mm (in)

Front brake

Pad wear limit

2.0 (0.079)

Rotor repair limit

24.0 (0.945)

Rear brake

Pad wear limit

1.5 (0.059)

Rotor repair limit

8.0 (0.315)

Pedal free height

167 - 174 (6.57 - 6.85)

Pedal depressed height*1

82.5 (3.248)

Parking brake

Number of notches*2

3 - 4

*1 Under force of 490 N (50 kg, 110 lb) with engine running
*2 At pulling force: 196 N (20 kg, 44 lb)

Unit

Liter

US measure

Coolant with reservoir

7.7

8-1/8 qt

Engine*

Drain and refill

With oil filter

4.0

4-1/4 qt

Without oil filter

3.7

3-7/8 qt

Dry engine (engine overhaul)

4.8

5-1/8 qt

Transaxle

A/T

RE4F04B/W

9.4

10 qt

Power steering system

1.1

1-1/8 qt

Air conditioning system

Refrigerant

0.60 - 0.70 kg

1.32 - 1.54 lb

Compressor oil

0.2

6.8 fl oz

* For further details, see “Changing Engine Oil” in MA section.

Infiniti I30 (A33). Manual - part 495
