PCS BCM (BODY CONTROL MODULE) PCS-77 < ECU DIAGNOSIS > [POWER DISTRIBUTION SYSTEM] C D E F G H I J K L B A O P N PUSH SW Push-button ignition switch (push switch) is not pressed Off Push-button ignition switch (push switch) is pressed On IGN RLY2 -F/B Ignition switch in OFF or ACC position Off Ignition switch in ON position On ACC RLY -F/B Ignition switch in OFF position Off Ignition switch in ACC or ON position On CLUCH SW The clutch pedal is not depressed Off The clutch pedal is depressed On BRAKE SW 1 The brake pedal is not depressed On The brake pedal is depressed Off DETE/CANCL SW Selector lever in P position Off Selector lever in any position other than P On SFT PN/N SW Selector lever in any position other than P and N Off Selector lever in P or N position On S/L -LOCK Steering is locked Off Steering is unlocked On S/L -UNLOCK Steering is unlocked Off Steering is locked On S/L RELAY-F/B Ignition switch in OFF or ACC position Off Ignition switch in ON position On UNLK SEN-DR Driver door is unlocked Off Driver door is locked On PUSH SW -IPDM Push-button ignition switch (push-switch) is not pressed Off Push-button ignition switch (push-switch) is pressed On IGN RLY1 -F/B Ignition switch in OFF or ACC position Off Ignition switch in ON position On DETE SW -IPDM Selector lever in P position Off Selector lever in any position other than P On SFT PN -IPDM Selector lever in any position other than P and N Off Selector lever in P or N position On SFT P -MET Selector lever in any position other than P Off Selector lever in P position On SFT N -MET Selector lever in any position other than N Off Selector lever in N position On ENGINE STATE Engine stopped Stop While the engine stalls Stall At engine cranking Crank Engine running Run S/L LOCK-IPDM Steering is locked Off Steering is unlocked On S/L UNLK-IPDM Steering is unlocked Off Steering is locked On S/L RELAY-REQ Ignition switch in OFF or ACC position Off Ignition switch in ON position On Monitor Item Condition Value/Status |
