DOOR MIRROR DOES NOT OPERATE MIR-39 < SYMPTOM DIAGNOSIS > [WITH ADP] C D E F G H I J K M A B MIR N O P SYMPTOM DIAGNOSIS DOOR MIRROR DOES NOT OPERATE Diagnosis Procedure INFOID:0000000001696833 1. CHECK AUTOMATIC DRIVE POSITIONER SYSTEM Check door mirror operate with automatic drive positioner system. Is the inspection result normal? YES >> GO TO 2. NO >> Check automatic drive positioner system operation. Refer to POSITIONER SYSTEM : System Diagram" 2. CHECK MIRROR SWITCH Check mirror switch. MIR-10, "Component Function Check" Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace the malfunctioning parts. 3. CHECK CHANGEOVER SWITCH Check changeover switch. MIR-13, "Component Function Check" Is the inspection result normal? YES >> GO TO 4. NO >> Repair or replace the malfunctioning parts. 4. CONFIRM THE OPERATION Confirm the operation again. YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident" NO >> GO TO 1. |
