FRONT FOG LAMP

FRONT FOG LAMP

Exploded View

INFOID:0000000001604725

The front fog lamp is integrated in the front combination lamp. Refer to

EXL-188, "Exploded View"

.

OPTICAL SENSOR

EXL-193

< ON-VEHICLE REPAIR >

[XENON TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

OPTICAL SENSOR

Exploded View

INFOID:0000000001604726

Removal and Installation

INFOID:0000000001604727

REMOVAL

1.

Insert an appropriate tool between the optical sensor and the instrument upper panel. Pull out the optical
sensor upward.

2.

Disconnect the connector. Remove the optical sensor.

INSTALLATION

Install in the reverse order of removal.

1.

Optical sensor

JPLIA0049ZZ

EXL-194

< ON-VEHICLE REPAIR >

[XENON TYPE]

LIGHTING AND TURN SIGNAL SWITCH

LIGHTING AND TURN SIGNAL SWITCH

Exploded View

INFOID:0000000001604728

Lighting and turn signal switch is integrated in the combination switch.

BCS-80, "Exploded View"

.
