DEF-40 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 111 (Y) Ground Steering lock unit Input/ Output Steering lock LOCK status Battery voltage LOCK or UNLOCK For 15 seconds after UN- Battery voltage 15 seconds or later after 0 V 113 (P) Ground Optical sensor signal Input Ignition switch When bright outside of the Close to 5 V When dark outside of the Close to 0 V 114 (R) Ground Clutch interlock Input Clutch interlock OFF (Clutch pedal is not 0 V ON (Clutch pedal is de- Battery voltage 116 (SB) Ground Stop lamp switch 1 Input — Battery voltage 118 (BR) Ground Stop lamp switch 2 Input Stop lamp switch OFF (Brake pedal is not 0 V ON (Brake pedal is de- Battery voltage ICC brake hold OFF 0 V ON Battery voltage 119 (SB) Ground Front door lock as- Input Driver door LOCK status 11.8 V UNLOCK status 0 V 121 (SB) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot 0 V 122 (P) Ground ACC feedback signal Input Ignition switch OFF 0 V ACC or ON Battery voltage 123 Ground IGN feedback signal Input Ignition switch OFF or ACC 0 V ON Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0066GB JPMIA0011GB |
