CHG-28
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Alternator
INFOID:0000000001666073
*: Adjustment range of power generation voltage variable control is 11.4 - 15.6 V.
Type
A3TJ1991
MITSUBISHI make
Nominal rating
[V - A]
12 -150
Ground polarity
Negative
Minimum revolution under no-load (When 13.5 V is ap-
plied)
[rpm]
Less than 1,300
Hot output current (When 13.5 V is applied)
[A/rpm]
More than 31/1,300
More than 122/2,500
More than 144/5,000
Regulated output voltage
[V]
14.1 - 14.7
*
Minimum length of brush
[mm (in)]
More than 5.00 (0.197)
Brush spring pressure
[N (g, oz)]
4.1 - 5.3 (418 - 541, 14.7 - 19.1)
Slip ring minimum outer diameter
[mm (in)]
More than 22.1 (0.870)
Rotor (Field coil) resistance
[
Ω
]
1.7 - 2.0
