ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

JCFWA0071GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

BRC-87

< ECU DIAGNOSIS >

[VDC/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

Fail-Safe

INFOID:0000000001635146

ABS, EBD SYSTEM

In case of electrical malfunctions with the ABS, ABS warning lamp, VDC OFF indicator lamp, SLIP indicator
lamp will turn on. In case of electrical malfunctions with the EBD, brake warning lamp, ABS warning lamp,
VDC OFF indicator lamp and SLIP indicator lamp will turn on. Simultaneously, the VDC/TCS/ABS become one
of the following conditions of the fail-safe function.

JCFWA0072GB

BRC-88

< ECU DIAGNOSIS >

[VDC/TCS/ABS]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

• For malfunction of ABS, only the EBD is activated and the condition of vehicle is the same condition of vehi-

cles without TCS/ABS system.
NOTE:
ABS self-diagnosis sound may be heard. That is a normal condition because a self-diagnosis for “Ignition
switch ON” and “The first starting” are being performed.

• For malfunction of EBD, EBD and ABS become inoperative, and the condition of vehicle is the same as the

condition of vehicles without TCS/ABS, EBD system.

VDC / TCS

In case of malfunction in the VDC/TCS/ABS system, VDC OFF indicator lamp, SLIP indicator lamp are turned
on, and the condition of vehicle is the same as the condition of vehicles without VDC/TCS control.

CAUTION:

If the Fail-Safe function is activated, then perform self-diagnosis for VDC/TCS/ABS control system.

DTC No. Index

INFOID:0000000001635147

DTC

Items (CONSULT screen terms)

Reference

C1101

RR RH SENSOR-1

BRC-31, "DTC Logic"

C1102

RR LH SENSOR-1

C1103

FR RH SENSOR-1

C1104

FR LH SENSOR-1

C1105

RR RH SENSOR-2

BRC-34, "DTC Logic"

C1106

RR LH SENSOR-2

C1107

FR RH SENSOR-2

C1108

FR LH SENSOR-2

C1109

BATTERY VOLTAGE [ABNORMAL]

BRC-37, "DTC Logic"

C1110

CONTROLLER FAILURE

BRC-39, "DTC Logic"

C1111

PUMP MOTOR

BRC-40, "DTC Logic"

C1114

MAIN RELAY

BRC-42, "DTC Logic"

C1115

ABS SENSOR [ABNORMAL SIGNAL]

BRC-44, "DTC Logic"

C1116

STOP LAMP SW

BRC-47, "DTC Logic"

C1120

FR LH IN ABS SOL

BRC-49, "DTC Logic"

C1121

FR LH OUT ABS SOL

BRC-52, "DTC Logic"

C1122

FR RH IN ABS SOL

BRC-49, "DTC Logic"

C1123

FR RH OUT ABS SOL

BRC-52, "DTC Logic"

C1124

RR LH IN ABS SOL

BRC-49, "DTC Logic"

C1125

RR LH OUT ABS SOL

BRC-52, "DTC Logic"

C1126

RR RH IN ABS SOL

BRC-49, "DTC Logic"

C1127

RR RH OUT ABS SOL

BRC-52, "DTC Logic"

C1130

ENGINE SIGNAL 1

BRC-55, "DTC Logic"

C1131

ENGINE SIGNAL 2

C1132

ENGINE SIGNAL 3

C1138

4WAS CIRCUIT

BRC-56, "DTC Logic"

C1142

PRESS SEN CIRCUIT

BRC-57, "DTC Logic"

C1143

ST ANG SEN CIRCUIT

BRC-59, "DTC Logic"

C1144

ST ANG SEN SIGNAL

C1145

YAW RATE SENSOR

BRC-61, "DTC Logic"

C1146

SIDE G-SEN CIRCUIT

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

BRC-89

< ECU DIAGNOSIS >

[VDC/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

C1147

USV LINE [FL-RR]

BRC-64, "DTC Logic"

C1148

USV LINE [FR-RL]

C1149

HSV LINE [FL-RR]

C1150

HSV LINE [FR-RL]

C1153

EMERGENCY BRAKE

BRC-39, "DTC Logic"

C1155

BR FLUID LEVEL LOW

BRC-67, "DTC Logic"

C1170

VARIANT CORDING

BRC-39, "DTC Logic"

C1185

ACC CONT

BRC-69, "DTC Logic"

U1000

CAN COMM CIRCUIT

BRC-70, "DTC Logic"

U1002

SYSTEM COMM

DTC

Items (CONSULT screen terms)

Reference
