AV
WOOFER AMP.
AV-533
< ECU DIAGNOSIS >
[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
M
B
A
O
P
WOOFER AMP.
Reference Value
INFOID:0000000001678441
TERMINAL LAYOUT
PHYSICAL VALUES
JPNIA0513ZZ
Terminal
(Wire color)
Description
Condition
Reference value
(Approx.)
+
–
Signal name
Input/
Output
1
(G)
2
(R)
Sound signal rear woofer
RH
Output
Ignition
switch
ON
Voice output
3
(GR)
Ground
Woofer amp. ON signal
Input
Ignition
switch
ON
Voice output
10 V
5
(W)
4
(B)
Sound signal rear woofer
LH
Output
Ignition
switch
ON
Voice output
7
(Y)
Ground
Battery power supply
Input
Ignition
switch
OFF
—
Battery voltage
8
(SB)
9
(V)
Sound signal rear woofer
Input
Ignition
switch
ON
Voice output
10
(B)
Ground
GND
—
Ignition
switch
ON
—
0 V
