WCS-60

< ECU DIAGNOSIS >

UNIFIED METER AND A/C AMP.

Fail Safe

INFOID:0000000001677402

FAIL SAFE

The unified meter and A/C amp. activates the fail-safe control if CAN communication with each unit is malfunc-
tioning.

JCNWA0445GB

WCS

UNIFIED METER AND A/C AMP.

WCS-61

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DTC Index

INFOID:0000000001677403

NOTE:
The details of TIME display are as follows.
• CRNT: The malfunctions that are detected now.
• PAST: The malfunctions was detected in the past. IGN counter is displayed on FFD (Freeze Frame data).

Function

Specifications

Speedometer

Reset to zero by suspending communication.

Tachometer

Fuel gauge

Indicates fuel level

Water temperature gauge

Reset to zero by suspending communication.

Illumination control

When suspending communication, change to nighttime mode.

Information display

The display turns off by suspending communication.

Buzzer

The buzzer turns off by suspending communication.

Warning lamp/indicator
lamp

ABS warning lamp

The lamp turns on by suspending communication.

VDC OFF indicator lamp

SLIP indicator lamp

Brake warning lamp

CRUISE warning lamp

Master warning lamp

Low tire pressure warning lamp

The lamp turns ON after flashing for 1 minute.

AFS OFF indicator lamp

The lamp blinking caused by communication malfunction

High beam indicator

The lamp turns off by suspending communication.

4WAS warning lamp

Turn signal indicator lamp

Front fog indicator lamp

Oil pressure warning lamp

Malfunction indicator lamp

A/T CHECK warning lamp

Key warning lamp

Display contents of CONSULT-III

Time

Diagnostic item is detected when...

Refer to

U1000: CAN COMM CIRCUIT

CRNT

PAST

When unified meter and A/C amp. is not transmitting or receiving
CAN communication signal for 2 seconds or more.

MWI-41

U1010: CONTROL UNIT (CAN)

CRNT

PAST

When detecting error during the initial diagnosis of CAN control-
ler of unified meter and A/C amp.

MWI-42

B2201: COMM ERROR 1

CRNT

PAST

If a communication error is present in the communication line
between unified meter and A/C amp. and combination meter for
2 seconds or more.

MWI-43

B2202: COMM ERROR 2

CRNT

PAST

If a communication error is present in the communication line
between unified meter and A/C amp. and combination meter for
2 seconds or more.

MWI-45

B2205: VEHICLE SPEED

CRNT

PAST

The abnormal vehicle speed signal is input from ABS actuator
and electric unit (control unit) for 2 seconds or more.

MWI-47

B2267: ENGINE SPEED

CRNT

PAST

If ECM continuously transmits abnormal engine speed signals
for 2 seconds or more.

MWI-48

B2268: WATER TEMP

CRNT

PAST

If ECM continuously transmits abnormal engine coolant temper-
ature signals for 60 seconds or more.

MWI-49

WCS-62

< ECU DIAGNOSIS >

UNIFIED METER AND A/C AMP.

- 1 - 39: The number is indicated when it is normal at present and a malfunction was detected in the past. It

increases like 0

→

 1

→

 2 ··· 38

→

 39 after returning to the normal condition whenever IGN OFF

→

 ON. It is

fixed to 39 until the self-diagnosis results are erased if it is over 39. It returns to 0 when a malfunction is
detected again in the process.

WCS

BCM (BODY CONTROL MODULE)

WCS-63

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BCM (BODY CONTROL MODULE)

Reference Value

INFOID:0000000001889423

VALUES ON THE DIAGNOSIS TOOL

CONSULT-III MONITOR ITEM

Monitor Item

Condition

Value/Status

FR WIPER HI

Other than front wiper switch HI

Off

Front wiper switch HI

On

FR WIPER LOW

Other than front wiper switch LO

Off

Front wiper switch LO

On

FR WASHER SW

Front washer switch OFF

Off

Front washer switch ON

On

FR WIPER INT

Other than front wiper switch INT

Off

Front wiper switch INT

On

FR WIPER STOP

Front wiper is not in STOP position

Off

Front wiper is in STOP position

On

INT VOLUME

Wiper intermittent dial is in a dial position 1 - 7

Wiper intermittent dial position

TURN SIGNAL R

Other than turn signal switch RH

Off

Turn signal switch RH

On

TURN SIGNAL L

Other than turn signal switch LH

Off

Turn signal switch LH

On

TAIL LAMP SW

Other than lighting switch 1ST and 2ND

Off

Lighting switch 1ST or 2ND

On

HI BEAM SW

Other than lighting switch HI

Off

Lighting switch HI

On

HEAD LAMP SW 1

Other than lighting switch 2ND

Off

Lighting switch 2ND

On

HEAD LAMP SW 2

Other than lighting switch 2ND

Off

Lighting switch 2ND

On

PASSING SW

Other than lighting switch PASS

Off

Lighting switch PASS

On

AUTO LIGHT SW

Other than lighting switch AUTO

Off

Lighting switch AUTO

On

FR FOG SW

Front fog lamp switch OFF

Off

Front fog lamp switch ON

On

RR FOG SW

NOTE:
The item is indicated, but not monitored.

Off

DOOR SW-DR

Driver door closed

Off

Driver door opened

On

DOOR SW-AS

Passenger door closed

Off

Passenger door opened

On

DOOR SW-RR

NOTE:
The item is indicated, but not monitored.

Off

DOOR SW-RL

NOTE:
The item is indicated, but not monitored.

Off
