BCM (BODY CONTROL MODULE) SEC-153 < ECU DIAGNOSIS > [INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B SEC N O P 108 (R) Ground Combination switch Input Combination All switch OFF 1.4 V Lighting switch AUTO 1.3 V Lighting switch 1ST 1.3 V Any of the conditions below 1.3 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0041GB JPMIA0038GB JPMIA0036GB JPMIA0039GB |
