AUTO ANTI-DAZZLING INSIDE MIRROR CIRCUIT
MIR-79
< COMPONENT DIAGNOSIS >
[WITHOUT ADP]
C
D
E
F
G
H
I
J
K
M
A
B
MIR
N
O
P
AUTO ANTI-DAZZLING INSIDE MIRROR CIRCUIT
Description
INFOID:0000000000962368
It automatically changes according to the brightness of the light that is reflected from the headlight of the vehi-
cle to the rear.
Component Function Check
INFOID:0000000000962369
1.
CHECK AUTO ANTI-DAZZLING INSIDE MIRROR FUNCTION
Check that glare-proof mirror can operate when mirror sensor is illuminated.
Is the inspection result normal?
YES
>> Auto anti-dazzling inside mirror function is OK.
NO
>> Refer to
.
Diagnosis Procedure
INFOID:0000000000962370
1.
CHECK POWER SUPPLY CIRCUIT
Check voltage between auto anti-dazzling inside mirror connector and ground.
Is the inspection result normal?
YES
>> GO TO 2.
NO
>> Repair or replace harness.
2.
CHECK GROUND CIRCUIT
1.
Disconnect auto anti-dazzling inside mirror connector.
2.
Check continuity between auto anti-dazzling inside mirror connector and ground.
Is the inspection result normal?
YES
>> GO TO 3.
NO
>> Repair or replace harness.
3.
CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to
GI-39, "Intermittent Incident"
.
Is the inspection result normal?
YES
>> Replace auto anti-dazzling inside mirror. Refer to
MIR-66, "Removal and Installation"
.
NO
>> Repair or replace the malfunctioning parts.
(+)
(-)
Condition of ignition switch
Voltage (V)
(Approx.)
Auto anti-dazzling inside mirror
connector
Terminal
Ground
R3
6
ON or START
Battery voltage
10
OFF
Battery voltage
Auto anti-dazzling inside mirror connector
Terminal
Ground
Continuity
R3
8
Existed
