SERVICE DATA AND SPECIFICATIONS (SDS) EM-143 < SERVICE DATA AND SPECIFICATIONS (SDS) C D E F G H I J K L M A EM N P O * 2 : Total indicator reading VALVE LIFTER Unit: mm (in) VALVE CLEARANCE Unit: mm (in) *: Approximately 80 ° C (176 ° F) AVAILABLE VALVE LIFTER Unit: mm (in) Items Standard Valve lifter outer diameter 33.980 - 33.990 (1.3378 - 1.3382) Valve lifter hole diameter 34.000 - 34.016 (1.3386 - 1.3392) Valve lifter clearance 0.010 - 0.036 (0.0004 - 0.0014) Items Cold Hot* (reference data) Intake 0.26 - 0.34 (0.010 - 0.013) 0.304 - 0.416 (0.012 - 0.016) Exhaust 0.29 - 0.37 (0.011 - 0.015) 0.308 - 0.432 (0.012 - 0.017) Identification (stamped) mark Thickness 788T 7.88 (0.3102) 790T 7.90 (0.3110) 792T 7.92 (0.3118) 794T 7.94 (0.3126) 796T 7.96 (0.3134) 798T 7.98 (0.3142) 800T 8.00 (0.3150) 802T 8.02 (0.3157) 804T 8.04 (0.3165) 806T 8.06 (0.3173) 808T 8.08 (0.3181) 810T 8.10 (0.3189) 812T 8.12 (0.3197) 814T 8.14 (0.3205) 816T 8.16 (0.3213) 818T 8.18 (0.3220) 820T 8.20 (0.3228) 822T 8.22 (0.3236) 824T 8.24 (0.3244) 826T 8.26 (0.3252) 828T 8.28 (0.3260) 830T 8.30 (0.3268) 832T 8.32 (0.3276) 834T 8.34 (0.3283) 836T 8.36 (0.3291) 838T 8.38 (0.3299) |
