DLN-266 < DISASSEMBLY AND ASSEMBLY > [REAR FINAL DRIVE: R200V] DIFFERENTIAL ASSEMBLY SIDE BEARING PRELOAD • Before inspection and adjustment, drain gear oil. 1. Remove rear cover. Refer to 2. Make sure all parts are clean. Also, make sure the bearings are 3. Place the differential case, with side bearings and bearing races 4. Insert left and right original side bearing adjusting washers in 5. Install bearing caps in their correct locations and tighten bearing 6. Turn the carrier several times to seat the bearings. 7. Measure the turning torque of the carrier at the drive gear — (J-8129)]. When the preload is small On pinion bearings: Tighten the drive pinion lock nut. On side bearings: Use thicker side bearing adjusting washers by the same amount to SPD919 SPD924 PDIA0069E Specification : 34.2 – 39.2 N (3.5 – 4.0 kg, SPD194A |
