Infiniti G35 (V35) Sedan. Manual - part 253





BRC-86

< ECU DIAGNOSIS >

[VDC/TCS/ABS]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

Fail-Safe

INFOID:0000000000958624

ABS, EBD SYSTEM

In case of electrical malfunctions with the ABS, ABS warning lamp, VDC OFF indicator lamp, SLIP indicator
lamp will turn on. In case of electrical malfunctions with the EBD, brake warning lamp, ABS warning lamp,
VDC OFF indicator lamp and SLIP indicator lamp will turn on. Simultaneously, the VDC/TCS/ABS become one
of the following conditions of the fail-safe function.

JCFWA0005GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

BRC-87

< ECU DIAGNOSIS >

[VDC/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

• For malfunction of ABS, only the EBD is activated and the condition of vehicle is the same condition of vehi-

cles without TCS/ABS system.
NOTE:
ABS self-diagnosis sound may be heard. That is a normal condition because a self-diagnosis for “Ignition
switch ON” and “The first starting” are being performed.

• For malfunction of EBD, EBD and ABS become inoperative, and the condition of vehicle is the same as the

condition of vehicles without TCS/ABS, EBD system.

VDC / TCS

In case of malfunction in the VDC/TCS/ABS system, VDC OFF indicator lamp, SLIP indicator lamp are turned
on, and the condition of vehicle is the same as the condition of vehicles without VDC/TCS control.

CAUTION:

If the Fail-Safe function is activated, then perform self-diagnosis for VDC/TCS/ABS control system.

DTC No. Index

INFOID:0000000000958625

DTC

Items (CONSULT screen terms)

Reference

C1101

RR RH SENSOR-1

BRC-30, "Description"

C1102

RR LH SENSOR-1

C1103

FR RH SENSOR-1

C1104

FR LH SENSOR-1

C1105

RR RH SENSOR-2

BRC-33, "Description"

C1106

RR LH SENSOR-2

C1107

FR RH SENSOR-2

C1108

FR LH SENSOR-2

C1109

BATTERY VOLTAGE [ABNORMAL]

BRC-36, "Description"

C1110

CONTROLLER FAILURE

BRC-38, "DTC Logic"

C1111

PUMP MOTOR

BRC-39, "Description"

C1114

MAIN RELAY

BRC-41, "Description"

C1115

ABS SENSOR [ABNORMAL SIGNAL]

BRC-43, "Description"

C1116

STOP LAMP SW

BRC-46, "Description"

C1120

FR LH IN ABS SOL

BRC-48, "Description"

C1121

FR LH OUT ABS SOL

BRC-51, "Description"

C1122

FR RH IN ABS SOL

BRC-48, "Description"

C1123

FR RH OUT ABS SOL

BRC-51, "Description"

C1124

RR LH IN ABS SOL

BRC-48, "Description"

C1125

RR LH OUT ABS SOL

BRC-51, "Description"

C1126

RR RH IN ABS SOL

BRC-48, "Description"

C1127

RR RH OUT ABS SOL

BRC-51, "Description"

C1130

ENGINE SIGNAL 1

BRC-54, "Description"

C1131

ENGINE SIGNAL 2

C1132

ENGINE SIGNAL 3

C1138

4WAS CIRCUIT

BRC-55, "Description"

C1142

PRESS SEN CIRCUIT

BRC-56, "Description"

C1143

ST ANG SEN CIRCUIT

BRC-58, "Description"

C1144

ST ANG SEN SIGNAL

C1145

YAW RATE SENSOR

BRC-60, "Description"

C1146

SIDE G-SEN CIRCUIT

BRC-88

< ECU DIAGNOSIS >

[VDC/TCS/ABS]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

C1147

USV LINE [FL-RR]

BRC-63, "Description"

C1148

USV LINE [FR-RL]

C1149

HSV LINE [FL-RR]

C1150

HSV LINE [FR-RL]

C1153

EMERGENCY BRAKE

BRC-38, "DTC Logic"

C1155

BR FLUID LEVEL LOW

BRC-66, "Description"

C1170

VARIANT CORDING

BRC-38, "DTC Logic"

U1000

CAN COMM CIRCUIT

BRC-68, "Description"

U1002

SYSTEM COMM

DTC

Items (CONSULT screen terms)

Reference

VDC/TCS/ABS

BRC-89

< SYMPTOM DIAGNOSIS >

[VDC/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

SYMPTOM DIAGNOSIS

VDC/TCS/ABS

Symptom Table

INFOID:0000000000958626

If ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp turn ON, perform self-diagnosis.

NOTE:

• 1: The ABS does not operate when the speed is 10 km/h (6 MPH) or less.

• 2: Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed (just place a foot on it).

However, this is normal.

- When shifting gears

- When driving on slippery road

- During cornering at high speed

- When passing over bumps or grooves [at approximately 50 mm (1.97 in) or more]

- When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]

Symptom

Check item

Reference

Excessive ABS function operation fre-
quency

Brake force distribution

BRC-90, "Diagno-

sis Procedure"

Looseness of front and rear axle

Wheel sensor and rotor system

Unexpected pedal reaction

Brake pedal stroke

BRC-91, "Diagno-

sis Procedure"

Make sure the braking force is sufficient when the ABS is not operating.

The braking distance is long

Check stopping distance when the ABS is not operating.

BRC-92, "Diagno-

sis Procedure"

ABS function does not operate (Note 1)

ABS actuator and electric unit (control unit)

BRC-93, "Diagno-

sis Procedure"

Pedal vibration or ABS operation sound
occurs (Note 2)

Brake pedal

BRC-94, "Diagno-

sis Procedure"

ABS actuator and electric unit (control unit)

Vehicle jerks during VDC/TCS/ABS con-
trol

ABS actuator and electric unit (control unit)

BRC-95, "Diagno-

sis Procedure"

TCM

ECM
