AV-472

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

BOSE AMP.

JCNWA0065GB

AV

CAMERA CONTROL UNIT

AV-473

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

N

A

O

P

CAMERA CONTROL UNIT

Reference Value

INFOID:0000000000964897

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0007ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

5

—

Shield

—

—

—

—

6

(B)

Ground

Camera image signal

Input

Ignition

switch

ON

At rear view camera image
displayed

7

(W)

Ground

GND

—

Ignition

switch

ON

—

0  V

8

(R)

Ground

Camera ON signal

Output

Ignition

switch

ON

R position

6 V

Other than R position

0 V

11

—

Shield

—

— —

—

12

(W)

Ground

Camera image signal

Output

Ignition

switch

ON

At rear view camera image
displayed

13

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

14

(W)

Ground

Camera-connection recog-
nition signal

—

Ignition

switch

ON

Connected to camera con-
trol unit connector

0 V

Not connected to camera
control unit connector

5 V

17

(BR)

—

AV communication signal
(L)

Input/

Output

—

—

—

SKIB2251J

SKIB2251J

AV-474

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

CAMERA CONTROL UNIT

18

(Y)

—

AV communication signal
(H)

Input/

Output

—

—

—

19

(R)

—

AV communication signal
(L)

Input/

Output

—

—

—

20

(G)

—

AV communication signal
(H)

Input/

Output

—

—

—

22

(GR)

Ground

Reverse signal

Input

Ignition

switch

ON

R position

12 V

Other than R position

0 V

23

(L)

Ground

Sensor signal 1

Input

Ignition

switch

ON

Turn the steering to the
right

A: Sensor signal 1
B: Sensor signal 2

Turn the steering to the left

A: Sensor signal 1
B: Sensor signal 2

24

(R)

Ground

Sensor signal 2

Input

Ignition

switch

ON

Turn the steering to the
right

A: Sensor signal 1
B: Sensor signal 2

Turn the steering to the left

A: Sensor signal 1
B: Sensor signal 2

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3827E

SKIB3828E

SKIB3827E

SKIB3828E

AV

CAMERA CONTROL UNIT

AV-475

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

N

A

O

P

Wiring Diagram — BOSE AUDIO WITH NAVIGATION  SYSTEM —

INFOID:0000000000964898

NOTE:

25

(O)

Ground

Sensor signal 3

Input

Ignition

switch

ON

Turn the steering around
the neutral position

A: Sensor signal 3
B: Sensor signal 1

26

(V)

Ground

Vehicle speed signal
(8-pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

29

(SB)

Ground

Ignition signal

Input

Ignition

switch

ON

—

Battery voltage

30

(LG)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

31

(B)

Ground

GND

—

Ignition

switch

ON

—

0  V

32

(L)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3829E
