< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

DISPLAY UNIT

9

(B)

Ground

RGB area (YS) signal

Input

Ignition

switch

ON

At RGB image displayed

5 V

At rear view camera image
displayed

11

(BR)

Ground

Communication signal
(CONT

→

DISP)

Input

Ignition

switch

ON

When adjusting display-
brightness.

12

(W)

Ground

Camera image signal

Input

Ignition

switch

ON

At rear view camera image
displayed

13

(B)

Ground

GND

—

Ignition

switch

ON

—

0  V

14

—

Shield

—

—

—

15

(G)

Ground

AUX image signal

Input

Ignition

switch

ON

AUX image

17

(L)

Ground

RGB signal (R: red)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

18

(V)

Ground

RGB signal (B: blue)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

PKIB4948J

PKIB5039J

SKIB2251J

SKIB2251J

SKIB2238J

SKIB2237J

AV

DISPLAY UNIT

AV-433

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

N

A

O

P

Wiring Diagram — BOSE AUDIO WITH NAVIGATION  SYSTEM —

INFOID:0000000000964894

NOTE:

19

(Y)

Ground

RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(W)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

ON

—

21

—

Shield

—

—

—

—

22

(Y)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display-
brightness.

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3603E

SKIB3598E

PKIB5039J

AV-434

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

DISPLAY UNIT

The name MULTIFUNCTION SWITCH indicates the integration of PRESET SWITCH and MULTIFUNCTION
SWITCH virtually.

JCNWA0048GB

AV

DISPLAY UNIT

AV-435

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

N

A

O

P

JCNWA0049GB
