Infiniti G35 (V35) Sedan. Manual - part 1356

TM-116

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

DIAGNOSIS SYSTEM (TCM)

• *1: Refer to

TM-110, "Diagnosis Description"

.

• *2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL.

DATA MONITOR

Display Items List

 X: Standard, —: Not applicable,

: Option

Monitored item (Unit)

Monitor Item Selection

Remarks

TCM IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

VHCL/S SE-A/T (km/h)

X

X

Revolution sensor

VHCL/S SE-MTR (km/h)

X

—

—

ACCELE POSI (0.0/8)

X

—

Accelerator pedal position signal

THROTTLE POSI (0.0/8)

X

X

Degree of opening for accelerator recognized by
the TCM.
For fail-safe operation, the specific value used
for control is displayed.

CLSD THL POS (ON/OFF)

X

—

Signal input with CAN communications.

W/O THL POS (ON/OFF)

X

—

BRAKE SW (ON/OFF)

X

—

Stop lamp switch

GEAR

—

X

Gear position recognized by the TCM updated
after gear-shifting.

ENGINE SPEED (rpm)

X

X

—

TURBINE REV (rpm)

X

X

—

OUTPUT REV (rpm)

X

X

—

GEAR RATIO

—

X

—

TC SLIP SPEED (rpm)

—

X

Difference between engine speed and torque
converter input shaft speed.

F SUN GR REV (rpm)

—

—

—

F CARR GR REV (rpm)

—

—

—

ATF TEMP SE 1 (V)

X

—

—

ATF TEMP SE 2 (V)

X

—

—

ATF TEMP 1 (

°

C)

—

X

—

ATF TEMP 2 (

°

C)

—

X

—

BATTERY VOLT (V)

X

—

—

ATF PRES SW 1 (ON/OFF)

X

X

—

ATF PRES SW 2 (ON/OFF)

X

X

(for LC/B solenoid)

ATF PRES SW 3 (ON/OFF)

X

X

—

ATF PRES SW 5 (ON/OFF)

X

X

—

ATF PRES SW 6 (ON/OFF)

X

X

—

PNP SW 1 (ON/OFF)

X

—

—

PNP SW 2 (ON/OFF)

X

—

—

PNP SW 3 (ON/OFF)

X

—

—

DIAGNOSIS SYSTEM (TCM)

TM-117

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

PNP SW 4 (ON/OFF)

X

—

—

1 POSITION SW (ON/OFF)

X

—

—

SLCT LVR POSI

—

X

Selector lever position is recognized by the TCM.
For fail-safe operation, the specific value used
for control is displayed.

OD CONT SW (ON/OFF)

X

—

Not mounted but displayed.

POWERSHIFT SW (ON/OFF)

X

—

HOLD SW (ON/OFF)

X

—

DS RANGE (ON/OFF)

X

—

—

MANU MODE SW (ON/OFF)

X

—

—

NON M-MODE SW (ON/OFF)

X

—

—

UP SW LEVER (ON/OFF)

X

—

—

DOWN SW LEVER (ON/OFF)

X

—

—

SFT UP ST SW (ON/OFF)

—

—

—

SFT DWN ST SW (ON/OFF)

—

—

—

ASCD-OD CUT (ON/OFF)

—

—

—

ASCD-CRUISE (ON/OFF)

—

—

—

ABS SIGNAL (ON/OFF)

—

—

—

ACC OD CUT (ON/OFF)

—

—

Intelligent cruise control (ICC) system

ACC SIGNAL (ON/OFF)

—

—

TCS GR/P KEEP (ON/OFF)

—

—

—

TCS SIGNAL 2 (ON/OFF)

—

—

—

TCS SIGNAL 1 (ON/OFF)

—

—

—

TCC SOLENOID (A)

—

X

—

LINE PRES SOL (A)

—

X

—

I/C SOLENOID (A)

—

X

—

FR/B SOLENOID (A)

—

X

—

D/C SOLENOID (A)

—

X

—

HLR/C SOL (A)

—

X

—

ON OFF SOL (ON/OFF)

—

—

LC/B solenoid

TCC SOL MON (A)

—

—

—

L/P SOL MON (A)

—

—

—

I/C SL MON (A)

—

—

—

FR/B SOL MON (A)

—

—

—

D/C SOL MON (A)

—

—

—

HLR/C SOL MON (A)

—

—

—

Monitored item (Unit)

Monitor Item Selection

Remarks

TCM IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

TM-118

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

DIAGNOSIS SYSTEM (TCM)

ON OFF SOL MON (ON/OFF)

—

—

LC/B solenoid

P POSI IND (ON/OFF)

—

—

—

R POSI IND (ON/OFF)

—

—

—

N POSI IND (ON/OFF)

—

—

—

D POSI IND (ON/OFF)

—

—

—

4TH POSI IND (ON/OFF)

—

—

—

3RD POSI IND (ON/OFF)

—

—

—

2ND POSI IND (ON/OFF)

—

—

—

1ST POSI IND (ON/OFF)

—

—

—

MANU MODE IND (ON/OFF)

—

—

—

POWER M LAMP (ON/OFF)

—

—

—

F-SAFE IND/L (ON/OFF)

—

—

—

ATF WARN LAMP (ON/OFF)

—

—

Not mounted but displayed.

BACK-UP LAMP (ON/OFF)

—

—

—

STARTER RELAY (ON/OFF)

—

—

—

PNP SW3 MON (ON/OFF)

—

—

—

C/V CLB ID1

—

—

—

C/V CLB ID2

—

—

—

C/V CLB ID3

—

—

—

UNIT CLB ID1

—

—

—

UNIT CLB ID2

—

—

—

UNIT CLB ID3

—

—

—

TRGT GR RATIO

—

—

—

TRGT PRES TCC (kPa)

—

—

—

TRGT PRES L/P (kPa)

—

—

—

TRGT PRES I/C (kPa)

—

—

—

TRGT PRE FR/B (kPa)

—

—

—

TRGT PRES D/C (kPa)

—

—

—

TRG PRE HLR/C (kPa)

—

—

—

SHIFT PATTERN

—

—

—

DRV CST JUDGE

—

—

—

START RLY MON

—

—

—

NEXT GR POSI

—

—

—

SHIFT MODE

—

—

—

MANU GR POSI

—

—

—

Monitored item (Unit)

Monitor Item Selection

Remarks

TCM IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

DIAGNOSIS SYSTEM (TCM)

TM-119

< FUNCTION DIAGNOSIS >

[5AT: RE5R05A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

DTC WORK SUPPORT

Display Items List

VEHICLE SPEED (km/h)

—

X

Vehicle speed recognized by the TCM.

Voltage (V)

—

—

Displays the value measured by the voltage
probe.

Frequency (Hz)

—

—

The value measured by the pulse probe is dis-
played.

DUTY-HI (high) (%)

—

—

DUTY-LOW (low) (%)

—

—

PLS WIDTH-HI (ms)

—

—

PLS WIDTH-LOW (ms)

—

—

Monitored item (Unit)

Monitor Item Selection

Remarks

TCM IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

DTC work support item

Description

Check item

1ST GR FUNCTN P0731

Following items for “1st gear function” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed or not)
• Self-diagnostic results (OK or NG)

• Input clutch solenoid

valve

• Front brake solenoid

valve

• Direct clutch solenoid

valve

• High and low reverse

clutch solenoid valve

• Each clutch
• Hydraulic control cir-

cuit

2ND GR FUNCTN P0732

Following items for “2nd gear function” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed or not)
• Self-diagnostic results (OK or NG)

3RD GR FUNCTN P0733

Following items for “3rd gear function” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed or not)
• Self-diagnostic results (OK or NG)

4TH GR FUNCTN P0734

Following items for “4th gear function” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed or not)
• Self-diagnostic results (OK or NG)

5TH GR FUNCTN P0735

Following items for “5th gear function” can be confirmed.
• Self-diagnosis status (whether the diagnosis is being performed or not)
• Self-diagnostic results (OK or NG)
