SRC-164 < COMPONENT DIAGNOSIS > B1150 CURTAIN MODULE LH >> GO TO 3. 3. DTC CODE If DTC is detected. Refer to >> END DTC CONFIRMATION PROCEDURE (Without CONSULT-lll) NOTE: 1. IGNITION SWITCH Turn ignition switch ON. >> GO TO 2. 2. USER MODE-DIAG MODE After air bag warning lamp illuminates for 7 seconds, turn ignition switch OFF within 1 second. >> GO TO 3. 3. USER MODE-DIAG MODE Wait more than 3 seconds. >> GO TO 4. 4. USER MODE-DIAG MODE Repeat step 1 to 3 twice. (Perform three times in all.) >> GO TO 5. 5. DIAG MODE Turn ignition switch ON. (SRS is now in diagnosis mode.) >> GO TO 6. 6. DIAG MODE (AIR BAG WARNING LAMP) Malfunctioning portion is indicated according to blinking times of air bag warning lamp. Refer to >> END Diagnosis Procedure (Component diagnosis) INFOID:0000000000959743 |
