8 CHECK RADIATOR CAP Apply pressure to cap with a tester and check radiator cap relief pressure. SLC755A Radiator cap relief pressure: 59 - 98 kPa (0.6 - 1.0 kg/cm 2 , 9 - 14 psi) OK or NG OK © GO TO 9. NG © Replace radiator cap. 9 CHECK THERMOSTAT 1. Remove thermostat. It should seat tightly. 3. Check valve opening temperature and valve lift. SLC343 Valve opening temperature: 82°C (180°F) [standard] Valve lift: More than 8 mm/95°C (0.31 in/203°F) 4. Check if valve is closed at 5°C (9°F) below valve opening temperature. For details, refer to LC-12, “Thermostat”. OK or NG OK © GO TO 10. NG © Replace thermostat GI MA EM LC FE CL MT AT AX SU BR ST RS BT HA SC EL IDX DTC P1217 ENGINE OVER TEMPERATURE (OVERHEAT) Diagnostic Procedure (A/T Models) (Cont’d) EC-471 |
