SB-10

< SERVICE INFORMATION >

TOP TETHER STRAP CHILD RESTRAINT

TOP TETHER STRAP CHILD RESTRAINT

Removal and Installation

INFOID:0000000001327739

CAUTION:

Replace anchor bolts if they are deformed or worn out.

REMOVAL

1.

Remove the roof rear garnish assembly. Refer to

EI-45, "Com-

ponent Parts Location"

.

2.

Remove the top tether strap child restraint.

INSTALLATION

Install in the reverse order of removal.

PHIA0345E

SC-1

ELECTRICAL

C

D

E

F

G

H

I

J

L

M

SECTION

SC

A

B

SC

N

O

P

CONTENTS

STARTING & CHARGING SYSTEM

SERVICE INFORMATION  ............................

2

PRECAUTIONS ...................................................

2

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................

2

PREPARATION ...................................................

3

Special Service Tools ................................................

3

Commercial Service Tools  ........................................

3

BATTERY ............................................................

4

How to Handle Battery  ..............................................

4

Trouble Diagnosis with Battery Service Center .........

6

Removal and Installation ...........................................

6

STARTING SYSTEM  ...........................................

8

System Description  ...................................................

8

Wiring Diagram - START -  ........................................

9

Trouble Diagnosis with Starting/Charging System
Tester (Starting)  ......................................................

10

Removal and Installation (VK45DE Engine Mod-
els) ..........................................................................

13

Removal and Installation [VQ35DE Engine Mod-
els (2WD)] ................................................................

14

Removal and Installation [VQ35DE Engine Mod-
els (AWD)]  ...............................................................

15

Disassembly and Assembly .....................................

15

Inspection After Disassembly  ..................................

18

CHARGING SYSTEM  .......................................

19

System Description ..................................................

19

Wiring Diagram - CHARGE -  ...................................

20

Trouble Diagnosis with Starting/Charging System
Tester (Charging)  ....................................................

21

Removal and Installation (VK45DE Engine Mod-
els) ...........................................................................

25

Removal and Installation (VQ35DE Engine Mod-
els) ...........................................................................

27

Disassembly and Assembly .....................................

28

SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................

30

Battery .....................................................................

30

Starter ......................................................................

30

Alternator .................................................................

30

SC-2

< SERVICE INFORMATION >

PRECAUTIONS

SERVICE INFORMATION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000001612927

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SUPPLEMENTAL RESTRAINT SYS-
TEM” and “SEAT BELTS” of this Service Manual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SUPPLEMENTAL RESTRAINT SYSTEM”.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.

PREPARATION

SC-3

< SERVICE INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

SC

N

O

P

PREPARATION

Special Service Tools

INFOID:0000000001328241

Commercial Service Tools

INFOID:0000000001328242

Tool number
(Kent-Moore No.)
Tool name

Description

—

(J-48087)
Battery Service Center

Tests battery.
For operating instructions, refer to Technical
Service Bulletin and Battery Service Center
User Guide.

—

(J-44373 Model MCR620)
Starting/Charging System Tester

Tests starting and charging system.
For operating instructions, refer to Technical
Service Bulletin.

WKIA5280E

SEL403X

Tool number
Tool name

Description

Power tool

Loosening bolts and nuts

PBIC0190E
