Infiniti FX35 / FX45. Manual - part 327

ON BOARD DIAGNOSTIC (OBD) SYSTEM

EC-69

< SERVICE INFORMATION >

[VQ35DE]

FUEL
SYSTEM

81H

Fuel injection system function
(Bank 1)

P0171 or P0172

80H

2FH

Long term fuel trim

P0171 or P0172

81H

24H

The number of lambda control
clamped

82H

Fuel injection system function
(Bank 2)

P0174 or P0175

80H

2FH

Long term fuel trim

P0174 or P0175

81H

24H

The number of lambda control
clamped

MISFIRE

A1H

Multiple Cylinder Misfire

P0301

80H

24H

Misfiring counter at 1000rev of the
first cylinder

P0302

81H

24H

Misfiring counter at 1000rev of the
second cylinder

P0303

82H

24H

Misfiring counter at 1000rev of the
third cylinder

P0304

83H

24H

Misfiring counter at 1000rev of the
fourth cylinder

P0305

84H

24H

Misfiring counter at 1000rev of the
fifth cylinder

P0306

85H

24H

Misfiring counter at 1000rev of the
sixth cylinder

P0307

86H

24H

Misfiring counter at 1000rev of the
seventh cylinder

P0308

87H

24H

Misfiring counter at 1000rev of the
eighth cylinder

P0300

88H

24H

Misfiring counter at 1000rev of the
multiple cylinders

P0301

89H

24H

Misfiring counter at 200rev of the
first cylinder

P0302

8AH

24H

Misfiring counter at 200rev of the
second cylinder

P0303

8BH

24H

Misfiring counter at 200rev of the
third cylinder

P0304

8CH

24H

Misfiring counter at 200rev of the
fourth cylinder

P0305

8DH

24H

Misfiring counter at 200rev of the
fifth cylinder

P0306

8EH

24H

Misfiring counter at 200rev of the
fifth cylinder

P0307

8FH

24H

Misfiring counter at 200rev of the
fifth cylinder

P0308

90H

24H

Misfiring counter at 200rev of the
fifth cylinder

P0300

91H

24H

Misfiring counter at 1000rev of the
single cylinder

P0300

92H

24H

Misfiring counter at 200rev of the
single cylinder

P0300

93H

24H

Misfiring counter at 200rev of the
multiple cylinders

Item

OBD-

MID

Self-diagnostic test item

DTC

Test value and Test

limit

(GST display)

Description

TID

Unit and

Scaling

EC-70

< SERVICE INFORMATION >

[VQ35DE]

ON BOARD DIAGNOSTIC (OBD) SYSTEM

HOW TO ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION

How to Erase DTC

With CONSULT-III

The emission related diagnostic information in the ECM can be erased by selecting “ALL Erace” in the
“Description” of “FINAL CHEK” mode with CONSULT-III.

With GST

The emission related diagnostic information in the ECM can be erased by selecting Service $04 with GST.
NOTE:
If the DTC is not for A/T related items (see

EC-17

), skip step 2.

MISFIRE

A2H

No.1 Cylinder Misfire

P0301

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0301

0CH

24H

Misfire counts for last/current driv-
ing cycles

A3H

No.2 Cylinder Misfire

P0302

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0302

0CH

24H

Misfire counts for last/current driv-
ing cycles

A4H

No.3 Cylinder Misfire

P0303

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0303

0CH

24H

Misfire counts for last/current driv-
ing cycles

A5H

No.4 Cylinder Misfire

P0304

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0304

0CH

24H

Misfire counts for last/current driv-
ing cycles

A6H

No.5 Cylinder Misfire

P0305

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0305

0CH

24H

Misfire counts for last/current driv-
ing cycles

A7H

No.6 Cylinder Misfire

P0306

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0306

0CH

24H

Misfire counts for last/current driv-
ing cycles

A8H

No.7 Cylinder Misfire

P0307

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0307

0CH

24H

Misfire counts for last/current driv-
ing cycles

A9H

No.8 Cylinder Misfire

P0308

0BH

24H

EWMA (Exponential Weighted
Moving Average) misfire counts
for last 10 driving cycles

P0308

0CH

24H

Misfire counts for last/current driv-
ing cycles

Item

OBD-

MID

Self-diagnostic test item

DTC

Test value and Test

limit

(GST display)

Description

TID

Unit and

Scaling

ON BOARD DIAGNOSTIC (OBD) SYSTEM

EC-71

< SERVICE INFORMATION >

[VQ35DE]

If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.

Perform

AT-38, "OBD-II Diagnostic Trouble Code (DTC)"

. (The DTC in TCM will be erased.)

Select Service $04 with GST (Generic Scan Tool).

No Tools

NOTE:
If the DTC is not for A/T related items (see

EC-17

), skip step 2.

If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once.
Wait at least 10 seconds and then turn it ON (engine stopped) again.

Perform

AT-38, "OBD-II Diagnostic Trouble Code (DTC)"

. (The DTC in TCM will be erased.)

Change the diagnostic test mode from Mode II to Mode I by depressing the accelerator pedal. Refer to

EC-71, "Malfunction Indicator Lamp (MIL)"

• If the battery is disconnected, the emission-related diagnostic information will be lost within 24

hours.

• The following data are cleared when the ECM memory is erased.
- Diagnostic trouble codes
- 1st trip diagnostic trouble codes
- Freeze frame data
- 1st trip freeze frame data
- System readiness test (SRT) codes
- Test values
Actual work procedures are explained using a DTC as an example. Be careful so that not only the DTC, but all
of the data listed above, are cleared from the ECM memory during work procedures.

Malfunction Indicator Lamp (MIL)

INFOID:0000000001325917

DESCRIPTION

The MIL is located on the instrument panel.

The MIL will light up when the ignition switch is turned ON with-
out the engine running. This is a bulb check.
If the MIL does not light up, refer to

DI-34

or see

EC-591

When the engine is started, the MIL should go off.
If the MIL remains on, the on board diagnostic system has
detected an engine system malfunction.

ON BOARD DIAGNOSTIC SYSTEM FUNCTION

The on board diagnostic system has the following three functions.

SEF217U

EC-72

< SERVICE INFORMATION >

[VQ35DE]

ON BOARD DIAGNOSTIC (OBD) SYSTEM

When there is an open circuit on MIL circuit, the ECM cannot warn the driver by lighting up MIL when there is
malfunction on engine control system.
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected and demands the
driver to repair the malfunction.

MIL Flashing Without DTC

When any SRT codes are not set, MIL may flash without DTC. For the details, refer to

EC-55, "Emission-

Related Diagnostic Information"

HOW TO SWITCH DIAGNOSTIC TEST MODE

NOTE:
• It is better to count the time accurately with a clock.
• It is impossible to switch the diagnostic mode when an accelerator pedal position sensor circuit has

a malfunction.

• Always ECM returns to Diagnostic Test Mode I after ignition switch is turned OFF.

How to Set Diagnostic Test Mode II (Self-Diagnostic Results)

Confirm that accelerator pedal is fully released, turn ignition switch ON and wait 3 seconds.

Repeat the following procedure quickly 5 times within 5 seconds.

Fully depress the accelerator pedal.

Fully release the accelerator pedal.

Wait 7 seconds, fully depress the accelerator pedal and keep it for approx. 10 seconds until the MIL starts
blinking.
NOTE:

Diagnostic Test
Mode

KEY and ENG.
Status

Function

Explanation of Function

Mode I

Ignition switch in
ON position

Engine stopped

BULB CHECK

This function checks the MIL bulb for damage (blown, open
circuit, etc.).
If the MIL does not come on, check MIL circuit.

Engine running

MALFUNCTION
WARNING

This is a usual driving condition. When a malfunction is de-
tected twice in two consecutive driving cycles (two trip de-
tection logic), the MIL will light up to inform the driver that a
malfunction has been detected.
The following malfunctions will light up or blink the MIL in
the 1st trip.
• Misfire (Possible three way catalyst damage)
• One trip detection diagnoses

Mode II

Ignition switch in
ON position

Engine stopped

SELF-DIAGNOSTIC
RESULTS

This function allows DTCs and 1st trip DTCs to be read.

Engine operating condition in fail-safe mode

Engine speed will not rise more than 2,500 rpm due to the fuel cut
