EC-58 < FUNCTION DIAGNOSIS > [VQ35HR] AUTOMATIC SPEED CONTROL DEVICE (ASCD) Component Parts Location INFOID:0000000003738634 1. Battery current sensor 2. IPDM E/R 3. Cooling fan relay 4. Mass air flow sensor (with intake air 5. Refrigerant pressure sensor 6. Cooling fan motor-2 7. Intake valve timing control solenoid 8. Exhaust valve timing control magnet 9. Cooling fan control module 10. Cooling fan motor-1 11. Mass air flow sensor (with intake air 12. ICC brake hold relay (ICC models) 13. Ignition coil (with power transistor) and spark plug (bank 2) 14. Electric throttle control actuator (bank 2) 15. A/F sensor 1 (bank 2) 16. Fuel injector (bank 2) 17. Camshaft position sensor (PHASE) 18. Engine coolant temperature sensor 19. Knock sensor 20. Exhaust valve timing control position sensor 21. EVAP canister purge volume control solenoid valve 22. Fuel injector (bank 1) 23. Ignition coil (with power transistor) and spark plug (bank 1) 24. EVAP service port 25. A/F sensor 1 (bank 1) 26. Crankshaft position sensor (POS) 27. Electric throttle control actuator (bank 1) JMBIA0002ZZ |
