BCS BCM (BODY CONTROL MODULE) BCS-67 < ECU DIAGNOSIS > C D E F G H I J K L B A O P N 124 (LG) Ground Passenger door Input Passenger door OFF (Door close) 11.8 V ON (Door open) 0 V 132 (V) Ground Power window switch Input/ Output Ignition switch ON 10.2 V Ignition switch OFF or ACC Battery voltage 133 Ground Push-button ignition Output Push-button igni- ON (Tail lamps OFF) 9.5 V ON (Tail lamps ON) NOTE: OFF 0 V 134 (GR) Ground LOCK indicator lamp Output LOCK indicator OFF Battery voltage ON 0 V 137 (O) Ground Receiver and sensor Input Ignition switch ON 0 V 138 (Y) Ground Sensor power supply Output Ignition switch OFF 0 V ACC or ON 5.0 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0011GB JPMIA0013GB JPMIA0159GB |
