Infiniti EX35. Manual - part 296
BCS
DIAGNOSIS SYSTEM (BCM)
BCS-31
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
ACTIVE TEST
*: Each lamp switch is in ON position.
TRUNK
TRUNK : CONSULT-III Function (BCM - TRUNK)
INFOID:0000000003743937
BCM CONSULT-III FUNCTION
CONSULT-III performs the following functions via CAN communication with BCM.
DATA MONITOR
*: With back door opener system
ACTIVE TEST
THEFT ALM
KEY CYL UN-SW
[On/Off]
Unlock switch status received from key cylinder switch by power window switch serial
link
TRNK/HAT MNTR
[On/Off]
The switch status input from trunk room lamp switch
RKE-LOCK
[On/Off]
Lock signal status received from remote keyless entry receiver
RKE-UNLOCK
[On/Off]
Unlock signal status received from remote keyless entry receiver
Monitor item
[Unit]
Description
Test item
Operation
Description
BATTERY SAVER
Off
Cuts the interior room lamp power supply to turn interior room lamp OFF.
On
Outputs the interior room lamp power supply to turn interior room lamp ON.*
Diagnosis mode
Function Description
DATA MONITOR
The BCM input/output signals are displayed.
ACTIVE TEST
The signals used to activate each device are forcibly supplied from BCM.
Monitor Item
Contents
PUSH SW
Indicates [ON/OFF] condition of push-button ignition switch.
UNLK SEN -DR
NOTE:
This item is displayed, but cannot be monitored.
VEH SPEED 1
Indicates [Km/h] condition of vehicle speed signal from combination meter.
KEY CYL SW-TR
NOTE:
This item is displayed, but cannot be monitored.
TR CANCEL SW
NOTE:
This item is displayed, but cannot be monitored.
TR/BD OPEN SW
Indicates [ON/OFF] condition of back door opener switch.
TRNK/HAT MNTR
NOTE:
This item is displayed, but cannot be monitored.
RKE-TR/BD*
NOTE:
This item is displayed, but cannot be monitored.
Test item
Description
TRUNK/GLASS HATCH
This test is able to check back door opener actuator open operation.
This actuator opens when “”
