AV

IPOD ADAPTER

AV-817

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

JCNWM0811GB

AV-818

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

IPOD ADAPTER

JCNWM0812GB

AV

IPOD ADAPTER

AV-819

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

JCNWM0813GB

AV-820

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

CAMERA CONTROL UNIT

CAMERA CONTROL UNIT

Reference Value

INFOID:0000000003160750

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0007ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

5

—

Shield

—

—

—

—

6

(W)

Ground

Camera image signal

Input

Ignition

switch

ON

At rear view camera image
display

7

(B)

Ground

Camera ground

—

Ignition

switch

ON

—

0  V

8

(R)

Ground

Camera power supply

Output

Ignition

switch

ON

R position

6.0 V

Other than R position

0 V

11

—

Shield

—

—

—

—

12

(W)

Ground

Camera image signal

Output

Ignition

switch

ON

At rear view camera image
display

14

(W)

Ground

Camera-connection recog-
nition signal

—

Ignition

switch

ON

Connected to camera con-
trol unit connector

0 V

Not connected to camera
control unit connector

5.0 V

17

(V)

—

AV communication signal
(L)

Input/

Output

—

—

—

18

(LG)

—

AV communication signal
(H)

Input/

Output

—

—

—

19

(R)

—

AV communication signal
(L)

Input/

Output

—

—

—

SKIB2251J
