WW-16 < FUNCTION DIAGNOSIS > DIAGNOSIS SYSTEM (IPDM E/R) DIAGNOSIS SYSTEM (IPDM E/R) Diagnosis Description INFOID:0000000003769970 AUTO ACTIVE TEST Description In auto active test mode, the IPDM E/R sends a drive signal to the following systems to check their operation. Operation Procedure 1. Close the hood and lift the wiper arms from the windshield. (Prevent windshield damage due to wiper 2. Turn ignition switch OFF. 3. Turn the ignition switch ON, and within 20 seconds, press the driver door switch 10 times. Then turn the CAUTION: Close passenger door. 4. Turn the ignition switch ON within 10 seconds. After that the horn sounds once and the auto active test 5. The oil pressure warning lamp starts blinking when the auto active test starts. 6. After a series of the following operations is repeated 3 times, auto active test is completed. NOTE: CAUTION: • If auto active test mode cannot be actuated, check door switch system. Refer to . • Do not start the engine. Inspection in Auto Active Test Mode When auto active test mode is actuated, the following 5 steps are repeated 3 times. JPMIA0950ZZ |
