ADP-166 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 72 (R) Ground Room antenna 2 ( − ) (Center console) Output Ignition switch When Intelligent Key is in When Intelligent Key is not 73 (G) Ground Room antenna 2 (+) Output Ignition switch When Intelligent Key is in When Intelligent Key is not 74 (SB) Ground Passenger door an- − ) Output When the pas- When Intelligent Key is in When Intelligent Key is not Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB |
