Seats & Safety System
Seat belts
Front Seats
Always fasten your seat belt before
starting any trip. At all times, passengers
WARNING
should sit upright and be properly
To prevent serious injury or death:
restrained with a seat belt. Infants and
• NEVER attempt to adjust the seat while
small children must be restrained in
the vehicle is moving. The seat could
appropriate Child Restraint Systems.
respond with unexpected movement
Children who have outgrown a booster
and may cause loss of vehicle control
seat and adults must be restrained using
resulting in an accident.
the seat belts.
• Do not place anything under the front
WARNING
seats. Loose objects in the driver's foot
area could interfere with the operation
To prevent serious injury or death:
of the foot pedals, causing an accident.
• NEVER use one seat belt for more than
• Do not allow anything to interfere with
one occupant.
the normal position and proper locking
• Always position the seatback upright
of the seatback.
with the lap portion of the seat belt
• Do not place a cigarette lighter on the
snug and low across the hips.
floor or seat.
• NEVER allow children or small infants,
• Use extreme caution when picking up
or pets to ride on a passenger's lap.
small objects trapped under the seats
• Do not route the seat belt across your
or between the seat and the center
neck, across sharp edges, or reroute
console. Your hands might be cut or
the shoulder strap away from your
injured by the sharp edges of the seat
body.
mechanism.
• Do not allow the seat belt to become
• If there are occupants in the rear seats,
caught or jammed.
be careful while adjusting the front seat
position.
• Make sure that the seat is locked in
place after the adjustment. If not, the
seat might move unexpectedly.
CAUTION
To prevent injury:
• Do not adjust your seat while wearing
your seat belt. Moving the seat cushion
forward may cause strong pressure on
your abdomen.
• Do not allow your hands or fingers to
get caught in the seat mechanisms
while the seat is moving.
3-6
3
Reclining seatback
Manual adjustment
Sitting in a reclined position when the
if equipped
vehicle is in motion can be dangerous.
The front seat can be adjusted by using
Even when buckled up, the protections of
the levers located underneath the front
your restraint system (seat belts and/or
part of the seat or on the outer side of the
airbags) is greatly reduced by reclining
seat.
your seatback.
Seat belts must be snug against your hips
Forward and rearward adjustment
and chest to work properly.
The more the seatback is reclined, the
greater the chance for the passenger's
hips to slide under the lap belt or the
passenger's neck to strike the shoulder
belt.
WARNING
Never ride with a reclined seatback when
the vehicle is moving.
2C_AdjustSeatForwardBackwardmanual
Riding with a reclined seatback increases
To move the seat forward or rearward:
your chance of serious or fatal injuries in
the event of a collision or sudden stop.
1. Pull up the seat slide adjustment lever
and hold it.
Driver and passengers should always sit
well back in their seats, properly belted,
2. Slide the seat to the position desired
and with the seatbacks upright.
position.
Seat belts must be snug against your hips
3. Release the lever and make sure the
and chest to work properly. When the
seat is locked in place. Move forward
seatback is reclined, the shoulder belt
and rearward without using the lever. If
cannot do its job because it will not be
the seat moves, it is not locked
snug against your chest. Instead, it will be
properly.
in front of you. During a collision, you
could be thrown into the seat belt,
causing neck or other injuries.
The more the seatback is reclined, the
greater chance the passenger's hips will
slide under the lap belt or the passenger's
neck will strike the shoulder belt.
3-7
Seats & Safety System
Seatback angle
Lumbar support
if equipped
2C_AdjustSeatBackmanual
To recline the seatback:
2C_AdjustSeatBackCushionManual
1. Lean forward slightly and lift up the
To adjust the lumbar support:
seatback lever.
1. Press the front portion of the switch (1)
2. Carefully lean back on the seat and
to increase support or the rear portion
adjust the seatback to the desired
of the switch (2) to decrease support.
position.
2. Release the switch once the lumbar
3. Release the lever and make sure the
support reaches the desired position.
seatback is locked in place.
NOTICE
Seat height
Do not continue to operate the lumbar
support when the lumbar support
provides its maximum support. Damage
to the lumbar support motor could occur.
2C_AdjustSeatHeightmanual
To change the height of the seat cushion:
• Push down on the lever several times,
to lower the seat cushion.
• Pull up on the lever several times, to
raise the seat cushion.
3-8
3
Power adjustment
Forward and rearward adjustment
if equipped
The front seat can be adjusted by using
the control switches located on the
outside of the seat cushion.
WARNING
NEVER allow children to remain in the
vehicle unattended. The power seats are
operable when the vehicle is turned off.
2C_AdjustSeatForwardBackwardAuto
To move the seat forward or rearward:
NOTICE
1. Push the control switch forward or
To prevent damage to the seats:
rearward.
• Always stop adjusting the seats when
2. Release the switch once the seat
the seat has been adjusted as far
reaches the desired position.
forward or rearward as possible.
Seatback angle adjustment
• Do not adjust the seats longer than
necessary when the vehicle is turned
off. This may result in unnecessary
battery drain.
• Do not operate two or more seats at the
same time. This may result in an
electrical malfunction.
2C_AdjustSeatBackAuto
To recline the seatback:
1. Push the control switch forward or
rearward.
2. Release the switch once the seatback
reaches the desired position.
3-9
Seats & Safety System
Seat cushion tilt/Seat height adjustment
Lumbar support
if equipped
2C_AdjustSeatHeightAuto
• Seat cushion tilt (1)
2C_AdjustSeatBackCushionAuto
To change the angle of the front part of
To adjust the lumbar support:
the seat cushion:
1. Press the front portion of the switch (1)
1. Push the front portion of the control
to increase support or the rear portion
switch up to raise or down to lower the
of the switch (2) to decrease support.
front part of the seat cushion.
2. Release the switch once the lumbar
2. Release the switch once the seat
support reaches the desired position.
reaches the desired position.
NOTICE
• Seat height (2)
To change the height of the seat:
Do not continue to operate the lumbar
support when the lumbar support
1. Push the rear portion of the control
provides its maximum support. Damage
switch up to raise or down to lower the
to the lumbar support motor could occur.
height of the seat.
2. Release the switch once the seat
reaches the desired position.
3-10
3
Seatback pocket
Folding the rear seats
if equipped
The rear seatbacks can be folded to
facilitate carrying long items or to
increase the rear cargo volume in the
vehicle.
WARNING
• Never allow passengers to sit on top of
the folded down seatback while the
vehicle is moving. This is not a proper
seating position and no seat belts are
available for use. This could result in
2C_SeatBackPocket
serious injury or death in a collision or
sudden stop.
The seatback pocket is provided on the
back of the front seatbacks.
• Objects carried on the folded down
seatback should not extend higher than
CAUTION
the top of the front seatbacks. This can
allow cargo to slide forward and cause
Do not put heavy or sharp objects in the
property damage or serious injury or
seatback pockets. In a collision, they can
even death during a collision or sudden
come loose from the pocket and injure
stop.
occupants.
To fold down the rear seatback:
Rear Seats
1. Adjust the front seatback to the upright
position and if necessary, slide the front
Reclining the rear seats
seat forward.
2. Lower the rear head restraints to the
lowest position by pushing and holding
the release button (1) and pushing
down on the head restraint (2).
2C_RearSeatRecline
To recline the seatback:
1. Pull up the seatback folding lever.
2. Hold the lever and adjust the seatback
2C_AdjustRearHeadrestDown
of the seat to the desired position.
3. Release the lever and make sure the
seatback is locked in place.
3-11
Seats & Safety System
3. Route the seat belt webbing to the both
To unfold the rear seatback:
sides of the rear seat to prevent the
1. Lift and push the seatback rearward
belts from being damaged.
while lifting up the front portion of the
folding lever.
2C_RearSeatFoldingStep_2
4. Pull up the seatback folding lever, then
2C_RearSeatFoldingStep_5
fold the seat toward the front of the
2. Push the seatback firmly until it clicks
vehicle.
into place. Make sure the seatback is
locked in place.
3. Return the rear seat belt to the proper
position.
WARNING
Lock the seatback properly. In a collision
or sudden stop, an unlocked seatback
may allow cargo to move forward with
great force and may result in serious
injury or death.
2C_RearSeatFoldingStep_3
WARNING
Cargo should always be secured to
prevent it from moving in a collision and
causing serious injury or death to the
vehicle occupants. Do not place objects
in the rear seats, because they cannot be
properly secured and may hit the front
seat occupants in a collision.
2C_RearSeatFoldingStep_4
3-12
3
Armrest
• Adjust the head restraints so the middle
of the head restraint is at the same
height as the height of the top of the
eyes.
2C_RearArmrestFlip
The armrest is located in the center of the
rear seat. Pull the armrest down from the
2C_HeadrestRightPosition
seatback to use it.
• NEVER adjust the head restraint
position of the driver's seat when the
Head Restraint
vehicle is in motion.
The vehicle's front and rear seats have
• Adjust the head restraint as close to the
adjustable head restraints. The head
passenger's head as possible. Do not
restraints provide comfort for
use a seat cushion that holds the body
passengers, but more importantly they
away from the seatback.
are designed to help protect passengers
• Make sure the head restraint locks into
from whiplash and other neck and spinal
position after adjusting it.
injuries during an accident, especially in a
rear impact collision. When there are no
occupants in the rear seats, adjust the
rear head restraints to the lowest height
to improve the driver's visibility.
WARNING
To help reduce the risk of serious injury or
death in an accident, take the following
precautions when adjusting your head
restraints:
• Always properly adjust the head
restraints for all passengers BEFORE
starting the vehicle.
• NEVER let anyone ride in a seat with the
head restraint removed or reversed.
3-13
Seats & Safety System
Adjusting the height up and down
WARNING
When sitting on the rear center seat, do
not adjust the height of the head restraint
to the lowest position.
2C_AdjustFrontHeadrestUpDown
To raise the head restraint:
1. Pull it up to the desired position (1).
To lower the head restraint:
2C_RearHeadrestCaution
1. Push and hold the release button (2) on
the head restraint support.
Front seat head restraints
2. Lower the head restraint to the desired
position (3).
NOTICE
2C_FrontHeadrestOverview
The driver's and front passenger's seats
are equipped with adjustable head
restraints for the passengers safety and
2C_AdjustHeadrestCaution
comfort.
If you adjust the seatback towards the
front with the head restraint and seat
cushion raised, the head restraint may
come in contact with the sunvisor or
other parts of the vehicle.
3-14
3
Removal/Reinstallation
To reinstall the head restraint:
To remove the head restraint:
Manual adjustment seat
Manual adjustment seat
Power adjustment seat
Power adjustment seat
1. Recline the seat back by pressing
seatback angle lever or switch (3).
1. Recline the seatback (2) with the
seatback angle lever or switch (1).
2. Put the head restraint poles (2) into the
holes while pressing the release button
2. Pull up the head restraint to the upmost
(1).
position and press the release button
(3) to remove the head restraint (4).
3. Adjust the head restraint to the
appropriate height.
WARNING
4. Adjust the seatback angle (4) with the
NEVER allow anyone to travel in a seat
seatback angle lever or switch (3).
with the head restraint removed.
WARNING
Always make sure the head restraint locks
into position after reinstalling and
adjusting it properly.
3-15
Seats & Safety System
Rear seat head restraints
Removal/Reinstallation
To remove the head restraint:
2C_RearHeadrestOverview
The rear seats are equipped with head
2C_AdjustRearHeadrestUp
restraints in all the seating positions for
1. Raise the head restraint as far as it can
the passenger's safety and comfort.
go.
2. Press the head restraint release button
Adjusting the height up and down
(1) while pulling the head restraint up
To raise the head restraint:
(2).
To reinstall the head restraint:
2C_AdjustRearHeadrestUpDown
1. Pull it up to the desired position (1).
2C_AdjustRearHeadrestDown
To lower the head restraint:
1. Put the head restraint poles into the
1. Push and hold the release button (2) on
holes (2) while pressing the release
the head restraint support.
button (1).
2. Lower the head restraint to the desired
2. Adjust the head restraint to the
position (3).
appropriate height.
3-16
3
Seat Warmers
NOTICE
if equipped
To prevent damage to the seat warmers
Seat warmers are provided to warm the
and seats:
seats during cold weather.
• Never use a solvent such as paint
During mild weather or conditions where
thinner, benzene, alcohol or gasoline to
the operation of the seat warmer is not
clean the seats.
needed, keep the seat warmers off.
• Do not place heavy or sharp objects on
seats equipped with seat warmers.
WARNING
• Do not change the seat cover. It may
The seat warmers can cause a serious
damage the seat warmer.
burn, even at low temperatures and
especially if used for long periods of time.
Passengers must be able to feel if the seat
Front seat warmers
is becoming too warm so they can turn it
off, if needed.
Seat warmer consume large amounts of
electricity. Please avoid using seat
warmers while the vehicle is off in order
to prevent battery discharge.
People who cannot detect temperature
change or pain to the skin should use
extreme caution, especially the following
types of passengers:
2C_FrontSeatWarmerSwitch
• Infants, children, elderly or disabled
persons, or hospital outpatients.
While the vehicle is running, press the
switch to warm the driver's seat or front
• People with sensitive skin or who burn
passenger's seat.
easily.
• Pressing the switch each time changes
• Fatigued individuals.
the temperature in turn from high to
• Intoxicated individuals.
medium, low, and off.
• People taking medication that can
• The seat warmer temperature is
cause drowsiness or sleepiness.
lowered automatically and then goes
Never place anything on the seat that
off after a certain time to prevent low
insulates against heat when the seat
temperature burns. If high temperature
warmer is operating, such as a blanket or
is selected again after the seat warmer
seat cushion.
turns off, the temperature is controlled
automatically again.
• The seat warmer defaults to the OFF
position whenever the Start/Stop
button is pressed to the ON position.
3-17
Seats & Safety System
Rear seat warmers
Air Ventilation Seats
if equipped
The air ventilation seats are provided to
cool the front seats by blowing air
through small vent holes on the surface of
the seat cushions and seatbacks.
When the operation of the air ventilation
seat is not needed, keep the air
ventilation seats off.
NOTICE
2C_RearSeatVentilationSwitch
While the vehicle is running, press the
To prevent damage to the air ventilation
seat warmer switch to warm the rear seat.
seats:
• Pressing the switch each time changes
• Never use a solvent such as paint
the temperature in turn from high to
thinner, benzene, alcohol or gasoline to
medium, low, and off.
clean the seats.
• The seat warmer temperature is
• Avoid spilling liquids on the surface of
lowered automatically and then goes
the front seats and seatbacks. This may
off after a certain time to prevent low
cause the air vent holes to block and
temperature burns. If high temperature
not work properly.
is selected again after the seat warmer
• Do not place materials such as plastic
turns off, the temperature is controlled
bags or newspapers under the seats.
automatically again.
They may block the air intake causing
• The seat warmer defaults to the OFF
malfunction of the air vent.
position whenever the Start/Stop
• Do not change the seat covers.
button is pressed to the ON position.
• If the air vents do not operate, restart
the vehicle. If there is no change, have
your vehicle inspected by an authorized
HYUNDAI dealer.
3-18
3
Front air ventilation seats
Seat Belts
This section describes how to use the seat
belts properly. It also describes some of
the things not to do when using seat belts.
Seat Belt Safety Precautions
Always fasten your seat belt and make
sure all passengers have fastened their
seat belts before starting any trip. Airbags
are designed to supplement the seat belt
2C_FrontSeatVentilationSwitch
as an additional safety device, not to
While the vehicle running, press the
replace them. Most states require all
switch to cool the driver's seat or front
occupants of a vehicle to wear seat belts.
passenger's seat.
• Press the button repeatedly to cycle
WARNING
though the airflow speeds from high to
Seat belts must be used by ALL
medium, low, and off.
passengers whenever the vehicle is
• The air ventilation seat defaults to the
moving. To prevent serious injury or
OFF position whenever the Start/Stop
death:
button is pressed to the ON position.
• Children under the age of 13 should be
properly restrained in the rear seats.
• Never allow children to ride in the front
passenger seat, unless the airbag is
deactivated. If a child is seated in the
front passenger seat, move the seat as
far back as possible. And the child must
always be restrained in the seat
properly.
• NEVER allow an infant or child to be
carried on an occupant's lap.
• NEVER ride with the seatback reclined
when the vehicle is moving.
• Do not allow children to share a seat or
seat belt.
• Do not wear the shoulder belt under
your arm or behind your back.
• NEVER wear a seat belt over fragile
objects. If there is a sudden stop or
impact, the seat belt can damage it.
3-19
Seats & Safety System
• Do not use the seat belt if it is twisted. A
Seat Belt Warning Light
twisted seat belt will not protect you
properly in an accident.
Driver's seat belt warning
• Do not use a seat belt if the webbing or
Instrument cluster
hardware is damaged.
• Do not latch the seat belt into the
buckles intended for other seating
positions.
• Never unfasten the seat belt while
driving. This may cause loss of vehicle
control resulting in a collision.
• Make sure there is nothing in the buckle
that could interfere with the seat belt
latch mechanism from fastening
securely.
2C_SeatBeltWarningLampOverview
As a reminder to the driver, the driver's
• Never modify seatbelt or install devices
seat belt warning light illuminates for
that may prevent seatbelt assembly
about 6 seconds each time the Start/Stop
from removing slack.
button is in the ON position regardless of
• Do not use a seat belt if the webbing or
seatbelt fastening.
hardware is damaged. Have the seat
If you continue not to fasten the seat belt
belt replaced by an authorized
or unfasten the seat belt while driving
HYUNDAI dealer.
under 12 mph (20 km/h), the seat belt
warning light illuminates.
If you continue not to fasten the seat belt
WARNING
or unfasten the seat belt while driving 12
Damaged seat belts and seat belt
mph (20 km/h) or faster, the seat belt
assemblies do not operate properly.
warning chime sounds for certain period
Always replace:
of time and the warning light blinks.
• Frayed, contaminated, or damaged
webbing.
Front passenger's seat belt warning
• Damaged hardware.
As a reminder to the front passenger, the
front passenger's seat belt warning light
• The entire seat belt assembly after it
illuminates for about 6 seconds each time
has been worn in an accident, even if
the vehicle is turned on regardless of seat
damage to webbing or assembly is not
belt fastening.
apparent.
If the passenger continues to not fasten
their seat belt or unfasten their seat belt
and you drive under 12 mph (20 km/h), the
seat belt warning light illuminates.
If the passenger continues to not to
fasten their seat belt or unfasten their
seat belt and you drive 12 mph (20 km/h)
or faster, the seat belt warning chime
sounds for certain period of time and the
corresponding warning light blinks.
3-20
3
• If the passenger continues not to fasten
WARNING
their seat belt or unfasten their seat belt
Riding in an improper position may
and you drive 12 mph (20 km/h) or
adversely affect the front passenger's
faster, the seat belt warning chime
seat belt warning system. Instruct the
sounds for certain period of time and
passenger to be seated properly when the
the corresponding warning light blinks.
vehicle is moving.
For rear center seat
As a reminder to the rear passenger, the
rear passenger's seat belt warning
Information
lights illuminate for about 6 seconds
• If the front passenger seat is not
each time the Start/Stop button is in
occupied, the seat belt warning light
the ON position regardless of seat belt
blinks or illuminate for 6 seconds.
fastening.
• The front passenger's seat belt warning
If the seat belt is not fastened when the
may operate when luggage is placed on
Start/Stop button is in the ON position,
the front passenger seat.
the seat belt warning light will
illuminate for certain period of time.
If the passenger continues not to fasten
Rear passenger's seat belt warning
their seat belt or unfasten their seat belt
and you drive under 12 mph (20 km/h),
the corresponding warning light
continues to illuminate for certain
period of time.
If the passenger continues not to fasten
their seat belt or unfasten their seat belt
and you drive over 12 mph (20 km/h),
the seat belt warning chime sounds for
certain period of time and the
corresponding warning light blinks.
2C_RearSeatBeltWarningLamp
If the rear door is opened or closed
under 6 mph (10 km/h), the seat belt
For rear left and right side seat
warning chime and corresponding
• As a reminder to the rear passenger, the
warning light does not work even if you
rear passenger's seat belt warning
drive over 12 mph (20 km/h).
lights illuminate for about 6 seconds
each time the Start/Stop button is in
the ON position regardless of seatbelt
fastening.
• If the passenger continues not to fasten
their seat belt or unfasten their seat belt
and you drive under 12 mph (20 km/h),
the corresponding warning light
continues to illuminate until the seat
belt is fastened.
3-21
Seats & Safety System
Seat Belt Restraint System
Driver's seat belt - 3-point system
with emergency locking retractor
WARNING
To fasten your seat belt:
2C_SeatBeltWearStep_2
2C_SeatBeltWearStep
Improperly positioned seat belts may
Pull the belt out of the retractor and insert
increase the risk of serious injury in an
the metal tab (1) into the buckle (2). An
accident or sudden stop. Take the
audible "click" sounds when the tab locks
following precautions when adjusting the
into the buckle. Make sure the seat belt is
seat belt:
not twisted.
• Position the lap portion of the seat belt
as low as possible across your hips, not
on your waist, so that it fits snugly. This
allows your strong pelvic bones to
absorb the force of the crash, reducing
the chance of internal injuries.
• Position one arm under the shoulder
belt and the other over the belt, as
shown in the illustration.
• Always position the shoulder belt
anchor into the locked position at the
2C_SeatBeltCorrectWear
appropriate height.
Place the lap belt (1) portion across your
• Never position the shoulder belt across
hips and the shoulder belt (2) portion
your neck or face.
across your chest.
The seat belt automatically adjusts to the
proper length after the lap belt portion is
adjusted manually so that it fits snugly
around your hips. If you lean forward in a
slow, easy motion, the belt extends and
moves with you.
If there is a sudden stop or impact, the
belt will lock into position. It will also lock
if you try to lean forward too quickly.
3-22
3
To release your seat belt:
NOTICE
If you cannot smoothly pull the seat belt
out from the retractor, firmly pull the seat
belt out and release it. After release, the
belt may be pulled out smoothly.
Height adjustment
Adjust the height of the shoulder belt so
that it lies across your chest and midway
over your shoulder nearest the door, not
2C_SeatBeltRelease
over your neck.
Press the release button (1) in the locking
To adjust the height of the seat belt
buckle.
anchor:
Once released, the belt should
Front seat
automatically draw back into the
retractor. If this does not happen, check
the belt to be sure it is not twisted, then
try again.
Passenger and rear seat belts -
3-point system with convertible
locking retractor
This type of seat belt combines both an
emergency locking retractor and an
automatic locking retractor. Convertible
2C_AdjustSeatBeltHeight
retractor type seat belts are installed in
• Pull it up (1) to raise the height. To lower
the rear seat positions to help
it, push it down (3) while pressing the
accommodate the installation of child
height adjuster button (2). Release the
restraint systems.
button to lock the anchor in place. Try
pushing the height adjuster down to
A convertible retractor is also installed in
make sure that it is locked in place.
the front passenger seat position.
Children should always be seated in the
rear. Never place any infant/child
restraint system in the front seat.
3-23
Seats & Safety System
To fasten your seat belt:
To release your seat belt:
Pull the seat belt out of the retractor and
insert the metal tab into the buckle. An
audible "click" sounds when the tab locks
into the buckle. Pull the shoulder portion
of the belt to snug the belt across your
hips and remove slack. Make sure the seat
belt is not twisted.
When not securing a child restraint, the
seat belt automatically adjusts to the
proper length only after the lap belt
portion of the seat belt is adjusted
2C_SeatBeltRelease
manually so that it fits snugly across your
Press the release button (1) in the locking
hips.
buckle.
When the seat belt has been fully
The belt should automatically draw back
extended from the retractor to allow for
into the retractor. If this does not happen,
the installation of a child restraint system,
check the belt is not twisted, then try
the seat belt operation changes to allow
again.
the belt to retract, but not to extend
(Automatic Locking Retractor Type).
Information
Refer to the "Child Restraint System
• The emergency locking mode allows
(CRS)" section in this chapter.
seated passengers to move freely in
their seats while keeping some tension
on the belt. During a collision or sudden
stop, the retractor automatically locks
the belt to help restrain the passengers.
• To deactivate the automatic locking
mode, unbuckle the seat belt and allow
the belt to fully retract.
3-24
3
Rear center seat belt (3-point rear
Pretensioner seat belt
center seat belt)
2C_RetractPretensioner
2C_RearCenterSeatBeltWearStep
(1) Retractor Pretensioner
Insert the tongue plate (1) into the buckle
(2) Emergency Fastening Device (EFD)
(2) until an audible "click" is heard,
Your vehicle is equipped with driver's and
indicating the latch is locked. Pull the
front passenger's pretensioner seat belts
shoulder portion of the belt to snug the
(retractor pretensioner and Emergency
belt across your hips and remove slack.
Fastening Device) and rear passengers
Make sure the seat belt is not twisted.
pretensioner seat belts (retractor
When using the rear center seat belt, use
pretensioner). The pretensioner makes
the buckle with the "CENTER" mark.
sure the seat belts fit tightly against your
body in certain frontal or side collision(s).
Information
The pretensioner seat belts may be
activated in some crashes where the
If you cannot pull out the safety belt from
frontal or side collision(s) is severe
the retractor, firmly pull the belt out and
enough, together with the airbags.
release it. After release, pull out the belt
smoothly.
When the vehicle stops suddenly, or if you
try to lean forward too quickly, the seat
belt retractor locks in place.
In some frontal collisions, the
WARNING
pretensioner activates and pulls the seat
Make sure that the seatback is locked in
belt against your body.
place when using the rear center seat
belt.
If not, the seatback may move when there
is a sudden stop or collision, which could
result in serious injury.
3-25
Seats & Safety System
WARNING
To prevent serious injury or death:
• Always wear your seat belt and sit
properly in your seat.
• Do not use the seat belt if it is loose or
twisted.
• Do not place anything near the buckle.
• Always replace your pretensioners after
activation or an accident.
2C_RearRetractorPretensionerOverview
• NEVER inspect, service, repair or
The pretensioner seat belt system
replace the pretensioners by yourself.
consists mainly of the following
Have the pretensioners inspected,
components. Their locations are shown in
serviced, repaired, or replaced by an
the illustration above:
authorized HYUNDAI dealer.
(1) SRS airbag warning light
• Do not hit the seat belt assemblies.
(2) Retractor pretensioner
(3) SRS control module
(4) Emergency Fastening Device (EFD)
(5) Rear retractor pretensioner
WARNING
Do not touch the pretensioner seat belt
NOTICE
assemblies for several minutes after they
The sensor that activates the SRS control
have been activated. When the
module is connected with the
pretensioner seat belt mechanism
pretensioner seat belt. The SRS airbag
deploys during a collision, the
warning light on the instrument cluster
pretensioner can become hot and can
illuminates for about 3-6 seconds after
burn you.
the Start/Stop button is in the ON
position, and then turns off.
If the pretensioner is not working
CAUTION
properly, the warning light illuminates
even if the SRS airbag is not
Body work on the front area of the vehicle
malfunctioning. If the warning light does
may damage the pretensioner seat belt
not illuminate when starting the vehicle
system. Have the system serviced by an
or stays illuminated or illuminates while
authorized HYUNDAI dealer.
driving, have the pretensioner seat belts
and/or SRS control module inspected by
an authorized HYUNDAI dealer as soon as
possible.
3-26
3
Additional Seat Belt Safety
Information
Precautions
Pretensioner seat belts may be
activated in certain frontal or side
collisions or rollover situations.
Seat belt use during pregnancy
When the pretensioner seat belts are
The seat belt should always be used
activated, a loud noise may be heard
during pregnancy. The best way to
and fine dust, which may appear to be
protect your unborn child is to protect
smoke, may be visible in the passenger
yourself by always wearing the seat belt.
compartment. These are normal
Pregnant women should always wear a
operating conditions and are not
lap-shoulder seat belt. Place the shoulder
hazardous.
belt across your chest, routed between
Although it is non-toxic, the fine dust
your breasts and away from your neck.
may cause skin irritation and should not
Place the lap belt below your belly and
be inhaled for prolonged periods. Wash
pull the shoulder portion so that it fits
all exposed skin areas thoroughly after
SNUGLY across your hips and pelvic
an accident in which the pretensioner
bone, under the rounded part of your
seat belts were activated.
belly.
WARNING
• Pregnant women and patients are more
vulnerable to any impacts on the
abdomen during an abrupt stop or
collision. If you are in an accident while
pregnant, consult your doctor.
• To reduce the risk of serious injury or
death to an unborn child during an
accident, pregnant women should
NEVER place the lap portion of the seat
belt above or over the area of the
abdomen where the unborn child is
located.
3-27
Seats & Safety System
Seat belt use and children
Larger children
Children under age 13 and who are too
Infant and small children
large for a booster seat should always
All 50 states have Child Restraint System
occupy the rear seat and use the available
laws that require children to travel in
lap/shoulder belts. A seat belt should be
approved Child Restraint System devices,
snug against the hips and be snug across
including booster seats. The age at which
the shoulder and chest to restrain the
seat belts can be used instead of Child
child safely. A child's squirming could
Restraint System may be different among
move the belt out of position. Adults
states, so you should be aware of the
should frequently check belt fit. In a
specific requirements in your state, and
collision, the safest place for children is in
where you are travelling. Infant and Child
the rear seats, using a Child Restraint
Restraint System must be properly placed
System appropriate for the child.
and installed in a rear seat.
If a larger child over age 13 must be seated
For more information refer to the "Seat
in the front seat, the child must be
Belt Safety Precautions" section in this
securely restrained by the available seat
chapter.
belt and the seat should be placed in the
rearmost position.
WARNING
If the shoulder belt portion slightly
Always properly restrain infants and small
touches the child's neck or face, try
children in a Child Restraint System
placing the child closer to the center of
appropriate for the child's height and
the vehicle. If the shoulder belt still
weight.
touches their face or neck, the child
needs to return to an appropriate booster
To reduce the risk of serious injury or
seat in the rear seat.
death to a child and other passengers,
never hold a child in your lap or arms
WARNING
when the vehicle is moving. Violent forces
during a collision will tear the child from
• Always make sure larger children's seat
your arms and throw the child against the
belts are buckled and properly
interior or to be ejected from the vehicle.
adjusted.
• Never allow the shoulder belt to
contact the child's neck or face.
Small children are best protected from
• Do not allow more than one child to use
injury in an accident when properly
a single seat belt.
restrained in the rear seat by a Child
Restraint System that meets the
requirements of the Federal Motor
Vehicle Safety Standards. Before buying
any Child Restraint System, make sure
that it has a label certifying that it meets
the Federal Motor Vehicle Safety
Standards FMVSS 213.
The Child Restraint System must be
appropriate for your child's height and
weight. Check the label on the Child
Restraint System for this information.
Refer to the "Child Restraint System
(CRS)" section in this chapter.
3-28
3
Seat belt use and injured people
Care of Seat Belts
A seat belt should still be used when an
Seat belt systems should never be
injured person is being transported.
disassembled or modified.
Consult a physician for specific
recommendations.
Periodic inspection
All seat belts should be inspected
One person per belt
periodically for wear or damage of any
When two people (children or adults) are
kind. Any damaged parts should be
sitting together, never attempt to use a
replaced as soon as possible.
single seat belt. This could increase the
severity of injuries in a collision.
Keep belts clean and dry
Seat belts should be kept clean and dry. If
Do not lie down
belts become dirty, they can be cleaned
Sitting in a reclined position when the
by using a mild soap solution and warm
vehicle is moving can be dangerous. Even
water. Bleach, dye, strong detergents, or
when buckled up, the protections of your
abrasives should not be used because
restraint system (seat belts and/or
they may damage and weaken the fabric.
airbags) is greatly reduced by reclining
your seatback.
When to replace seat belts
Seat belts must be snug against your hips
The entire seat belt assembly or
and chest to work properly.
assemblies should be replaced if the
During a collision, you could be thrown
vehicle has been involved in an accident.
into the seat belt, causing neck or other
This should be done even if no damage is
injuries.
visible. Consult an authorized HYUNDAI
The more the seat back is reclined, the
dealer for assistance.
greater the chance for the passenger's
hips to slide under the lap belt or the
passenger's neck to strike the shoulder
belt.
WARNING
• Never ride with a reclined seatback
when the vehicle is moving.
• Riding with a reclined seatback
increases your chance of serious or
fatal injuries in the event of a collision or
sudden stop.
• Driver and passengers should always sit
well back in their seats with the
seatbacks upright and should be belted
properly.
3-29
Seats & Safety System
or by a LATCH system in the rear seats of
Child Restraint System
the vehicle.
(CRS)
Child Restraint System (CRS)
Infants and younger children must be
Children Always in the Rear
restrained in an appropriate
rearward-facing or forward-facing CRS
WARNING
that has first been properly secured to the
Always properly restrain children in the
seat of the vehicle. Read and comply with
rear seats of the vehicle. Children of all
the instructions for installation and use
ages are safer when restrained in the rear
provided by the manufacturer of the Child
seats. A child riding in the front passenger
Restraint System.
seat can be forcefully struck by an
inflating airbag resulting in SERIOUS
WARNING
INJURY or DEATH.
An improperly secured child restraint can
increase the risk of SERIOUS INJURY or
DEATH in an accident. Always take the
Children under age 13 should always ride
following precautions when using a Child
in the rear seats and must always be
Restraint System:
properly restrained to minimize the risk of
injury in an accident, sudden stop or
NEVER install a child or infant restraint
sudden maneuver.
in the front passenger's seat.
According to accident statistics, children
Always properly secure the child
are safer when properly restrained in the
restraint to a rear seat of the vehicle.
rear seats than in the front seat. Even with
Always follow the child restraint system
airbags, children can be seriously injured
manufacturer's instructions for
or killed. Children too large for a Child
installation and use.
Restraint System must use the seat belts
Always properly restrain your child in
provided.
the child restraint.
All 50 states have child restraint laws
If the vehicle head restraint prevents
which require children to travel in
proper installation of a child seat (as
approved Child Restraint Systems.
described in the child restraint system
The laws governing the age or
manual), the head restraint of the
height/weight restrictions at which seat
respective seating position shall be
belts can be used instead of Child
readjusted or entirely removed.
Restraint System differs among states, so
Do not use an infant carrier or a child
you should be aware of the specific
safety seat that "hooks" over a
requirements in your state, and where
seatback, it may not provide adequate
you are travelling.
protection in an accident.
Child Restraint Systems must be properly
After an accident, have an authorized
placed and installed in the rear seat. You
HYUNDAI dealer check the child
must use a commercially available Child
restraint system, seat belts, tether
Restraint System that meets the
anchors and lower anchors.
requirements of the Federal Motor
Vehicle Safety Standards (FMVSS 213).
Child Restraint Systems are generally
designed to be secured in a vehicle seat
by lap belt portion of a lap/shoulder belt,
3-30
3
Selecting a Child Restraint
Rearward-facing Child Restraint System
System (CRS)
When selecting a Child Restraint System
for your child, always:
• Make sure the Child Restraint System
has a label certifying that it meets
applicable Federal Motor Vehicle
Safety Standards (FMVSS 213).
• Select a Child Restraint System based
on your child's height and weight. The
required label or the instructions for use
2C_ALRSeatBelt
typically provide this information.
A rearward-facing Child Restraint System
• Select a Child Restraint System that fits
provides restraint with the seating
the vehicle seating position where it will
surface against the back of the child. The
be used.
harness system holds the child in place,
and in an accident, acts to keep the child
• Read and comply with the warnings
positioned in the Child Restraint Systems
and instructions for installation and use
and reduce the stress to the fragile neck
provided with the Child Restraint
and spinal cord.
System.
All children under the age of one year
must always ride in a rearward-facing
Child Restraint System types
Child Restraint System. Convertible and
There are three main types of Child
3-in-1 Child Restraint Systems typically
Restraint Systems: rearward-facing,
have higher height and weight limits for
forward-facing and booster Child
the rearward-facing position, allowing
Restraint Systems.
you to keep your child rearward-facing
They are classified according to the
for a longer period of time.
child's age, height and weight.
Keep using Child Restraint Systems in the
rearward-facing position as long as
children fit within the height and weight
limits allowed by the Child Restraint
System's manufacturer. It's the best way
to keep them safe.
Once your child has outgrown the
rearward-facing Child Restraint System,
your child is ready for a forward-facing
Child Restraint System with a harness.
WARNING
NEVER install a child or infant restraint in
the front passenger's seat.
Placing a rearward-facing child restraint
in the front seat can result in SERIOUS
INJURY or DEATH if the child restraint is
struck by an inflating airbag.
3-31
Seats & Safety System
Forward-facing Child Restraint System
Installing a Child Restraint
System (CRS)
WARNING
Before installing your Child Restraint
System always:
Read and follow the instructions provided
by the manufacturer of the Child
Restraint System.
Failure to follow all warnings and
2C_ALRSeatBelt_2
instructions could increase the risk of the
A forward-facing Child Restraint System
SERIOUS INJURY or DEATH if an accident
provides restraint for the child's body
occurs.
with a harness. Keep children in a
forward-facing Child Restraint System
with a harness until they reach the top
WARNING
height or weight limit allowed by your
Child Restraint System's manufacturer.
If the vehicle head restraint prevents
proper installation of a Child Restraint
Once your child outgrows the
System, the head restraint of the
forward-facing Child Restraint System,
respective seating position shall be
your child is ready for a booster seat.
readjusted or entirely removed.
Booster seats
A booster seat is a Child Restraint System
After selecting a proper Child Restraint
designed to improve the fit of the
System for your child and checking that
vehicle's seat belt system. A booster seat
the Child Restraint System fits properly
positions the seat belt so that it fits
on the seating position, there are three
properly over the stronger parts of your
general steps for a proper installation:
child's body. Keep your children in
Properly secure the Child Restraint
booster seats until they are big enough to
System to the vehicle. All Child
fit in a seat belt properly.
Restraint Systems must be secured to
For a seat belt to fit properly, the lap belt
the vehicle with the lap belt or lap part
must lie comfortable across the upper
of a lap/shoulder belt or with the lower
thighs, not the stomach. The shoulder
anchor and/or tether anchor and/or
belt should lie comfortable across the
with the support leg.
shoulder and chest and not across the
Make sure the Child Restraint System
neck or face. Children under age 13 must
is firmly secured. After installing a
always be properly restrained to minimize
Child Restraint System to the vehicle,
the risk of injury in an accident, sudden
push and pull the seat forward and from
stop or sudden maneuver.
side-to-side to verify that it is securely
attached to the seat. A Child Restraint
System secured with a seat belt should
be installed as firmly as possible.
However, some side-to-side
movement can be expected. When
installing a Child Restraint System,
adjust the vehicle seat and seatback
3-32
3
(up and down, forward and rearward)
so that your child fits in the Child
Restraint System in a comfortable
manner.
Secure the child in the Child Restraint
System. Make sure the child is properly
strapped in the Child Restraint System
according to the Child Restraint System
manufacturer's instructions.
CAUTION
2C_ALRSeatBeltLowerAnchorOverview
A Child Restraint System in a closed
LATCH anchors have been provided in the
vehicle can become very hot. To prevent
left and right outboard rear seating
burns, check the seating surface and
positions. Their locations are shown in the
buckles before placing your child in the
illustration. There are no LATCH anchors
Child Restraint System.
provided for the center rear seating
position.
Lower Anchors and Tether for
WARNING
Children (LATCH System)
Do not attempt to install a Child Restraint
The LATCH system holds a Child Restraint
System using LATCH anchors in the rear
System during driving and in an accident.
center seating position. There are no
This system is designed to make
LATCH anchors provided for this seat.
installation of the Child Restraint System
Using the outboard seat anchors can
easier and reduce the possibility of
damage the anchors which may break or
improperly installing your Child Restraint
fail in a collision resulting in serious injury
System. The LATCH system uses anchors
or death.
in the vehicle and attachments on the
Child Restraint System. The LATCH
system eliminates the need to use seat
belts to secure the Child Restraint System
to the rear seats.
Lower anchors are metal bars built into
the vehicle. There are two lower anchors
for each LATCH seating position that will
accommodate a Child Restraint System
with lower attachments.
To use the LATCH system in your vehicle,
you must have a Child Restraint System
with LATCH attachments.
2C_ALRSeatBeltLowerAnchor
[A] Lower Anchor Position Indicator (Ŏ)
The Child Restraint System manufacturer
[B] Lower Anchor
will provide you with instructions on how
The lower anchor position indicator
to use the Child Restraint System with its
symbols are located on the left and right
attachments for the LATCH anchorages.
rear seat backs to identify the position of
the lower anchors in your vehicle (see
arrows in illustration).
3-33
Seats & Safety System
The LATCH anchors are located between
WARNING
the seatback and the seat cushion of the
rear seat left and right outboard seating
Take the following precautions when
positions.
using the LATCH system:
• Read and follow all installation
WARNING
instructions provided with your Child
Before installing the Child Restraint
Restraint System.
System, make sure that there are no
• To prevent the child from reaching and
objects (for example, toy, pen, wire)
taking hold of unretracted seat belts,
around the lower anchor area. Those
buckle all unused rear seat belts and
objects may damage either the seat belt
retract the seat belt webbing behind
system or the Child Restraint System
the child. Children can be strangled if a
during the installment procedure. If
shoulder belt becomes wrapped
necessary, have your vehicle inspected
around their neck and the seat belt
by an authorized HYUNDAI dealer.
tightens.
• NEVER attach more than one Child
Restraint System to a single anchorage.
Securing a Child Restraint System
This could cause the anchor or
with the "LATCH Anchors System"
attachment to come loose or break.
To install a LATCH-compatible Child
• Always have the LATCH system
Restraint System in either of the rear
inspected by your dealer after an
outboard seating positions:
accident. An accident can damage the
1. Move the seat belt buckle away from
LATCH system and may not properly
the lower anchors.
secure the Child Restraint System.
2. Move any other objects away from the
anchorages that could prevent a secure
connection between the Child Restraint
NOTICE
System and the lower anchors.
3. Place the Child Restraint System on the
Make sure that the combined weight of
vehicle seat, then attach the seat to the
the child and the child restraint system is
lower anchors according to the
less than 65 lbs. (30 kg) for each LATCH
instructions provided by the Child
system.
Restraint System manufacturer.
4. Follow the instructions of the Child
Restraint System's manufacturer for
proper installation and connection of
the lower attachments on the Child
Restraint System to the lower anchors.
3-34
3
Securing a Child Restraint System
seat with "Top-tether Anchorage"
system
2C_ALRSeatBeltTetherAnchorInstall
To install the tether anchor:
1. Route the Child Restraint System
2C_ALRSeatBeltTetherAnchor
top-tether strap over the seatback.
First secure the child restraint with the
Route the tether strap under the head
LATCH lower anchors or the seat belt. If
restraint and between the head
the child restraint manufacturer
restraint posts, or route the tether strap
recommends that the top tether strap be
over the top of the vehicle seatback.
attached, attach and tighten the top
Make sure the strap is not twisted.
tether strap to the top tether strap
2. Connect the tether strap hook to the
anchor.
tether anchor, then tighten the
Top tether anchorages are located on the
top-tether strap according to the
rear of the seatbacks.
instructions of your Child Restraint
System's manufacturer to firmly attach
WARNING
the Child Restraint System to the seat.
Take the following precautions when
3. Check that the Child Restraint System
installing the top-tether:
is securely attached to the seat by
pushing and pulling the seat
• Read and follow all installation
forward-and-back and side-to-side.
instructions provided with your Child
Restraint System.
• NEVER attach more than one Child
Restraint System to a single tether
anchor. This could cause the anchorage
or attachment to come loose or break.
• Do not attach the tether strap to
anything other than the correct
top-tether anchor. It may not work
properly if attached to something else.
• Child Restraint System anchors are
designed to withstand only those loads
imposed by correctly fitted Child
Restraint System.
Under no circumstances are the
anchors to be used for adult seat belts
or harnesses or for attaching other
items or equipment to the vehicle.
3-35
Seats & Safety System
Automatic locking mode
WARNING
Take the following precautions when
installing the top-tether:
• Read and follow all installation
instructions provided with your Child
Restraint System.
• NEVER attach more than one Child
Restraint System to a single tether
anchor. This could cause the anchorage
or attachment to come loose or break.
2C_ALRSeatBeltInstall
• Do not attach the tether strap to
Since all passenger seat belts move freely
anything other than the correct
under normal conditions and only lock
top-tether anchor. It may not work
under extreme or emergency conditions
properly if attached to something else.
(emergency locking mode), you must
• Child Restraint System anchors are
manually pull the seat belt all the way out
designed to withstand only those loads
to shift the retractor to the "Automatic
imposed by correctly fitted Child
Locking" mode to secure a Child Restraint
Restraint System.
System.
Under no circumstances are the
The "Automatic Locking" mode will help
anchors to be used for adult seat belts
prevent the normal movement of the
or harnesses or for attaching other
child in the vehicle from causing the seat
items or equipment to the vehicle.
belt to loosen and compromise the Child
Restraint System. To secure a Child
Restraint System, use the following
Securing a Child Restraint system
procedure.
with a lap/shoulder belt
To install a Child Restraint System on the
When not using the LATCH system, all
rear seats, do the following:
Child Restraint Systems must be secured
1. Place the Child Restraint System on a
to a rear seat with the lap part of a
rear seat and route the lap/shoulder
lap/shoulder belt.
belt around or through the Child
Restraint System, following the Child
WARNING
Restraint System manufacturer's
ALWAYS place a rearward-facing Child
instructions. Make sure the seat belt
Restraint System in the rear seat of the
webbing is not twisted.
vehicle.
Placing a rearward-facing child restraint
Information
in the front seat can result in serious injury
When using the rear center seat belt,
or death if the Child Restraint System is
you should also refer to the "Rear
struck by an inflating airbag.
center seat belt (3-point rear center
seat belt)" section in this chapter.
3-36
3
2. Fasten the lap/shoulder belt latch into
4. Slowly allow the shoulder portion of the
the buckle. Listen for the distinct "click"
seat belt to retract and listen for an
sound.
audible "clicking" or "ratcheting"
sound. This indicates that the retractor
is in the "Automatic Locking" mode. If
no distinct sound is heard, repeat steps
3 and 4.
2C_ALRSeatBeltInstall_2
Information
Position the release button so that it is
easy to access in case of an emergency.
2C_ALRSeatBeltInstall_4
5. Remove as much slack from the belt as
possible by pushing down on the Child
3. Pull the shoulder portion of the seat belt
Restraint System while feeding the
all the way out. When the shoulder
shoulder belt back into the retractor.
portion of the seat belt is fully
extended, it will shift the retractor to
the "Automatic Locking" (child
restraint) mode.
2C_ALRSeatBeltInstall_5
6. Push and pull on the Child Restraint
System to confirm that the seat belt is
holding it firmly in place. If it is not,
2C_ALRSeatBeltInstall_3
release the seat belt and repeat steps 2
through 6.
7. Double check that the retractor is in the
"Automatic Locking" mode by
attempting to pull more of the seat belt
out of the retractor. If you cannot, the
retractor is in the "Automatic Locking"
mode.
3-37
Seats & Safety System
If your Child Restraint System
manufacturer instructs or recommends
you to use a tether anchor with the lap/
shoulder belt, refer to the "Installing a
Child Restraint System (CRS)" section in
this chapter.
Information
When the seat belt is allowed to retract to
its fully stowed position, the retractor will
automatically switch from the "Automatic
Locking" mode to the emergency lock
mode for normal adult usage.
WARNING
If the retractor is not in the "Automatic
Locking" mode, the child restraint can
move when your vehicle turns or stops
suddenly. A child can be seriously injured
or killed if the child restraint is not
properly anchored in the car, including
manually pulling the seat belt all the way
out to shift the retractor to the "Automatic
Locking" mode.
To remove the Child Restraint System,
press the release button on the buckle
and then pull the lap/shoulder belt out of
the Child Restraint System and allow the
seat belt to retract fully.
3-38
3
Airbag - Supplemental Restraint System
1C_AirbagOverview
The actual airbags in the vehicle may differ from the illustration.
(1) Driver's front airbag
(2) Passenger's front airbag
(3) Side airbag
(4) Curtain airbag
3-39
Seats & Safety System
Your vehicle is equipped with a Supplemental Airbag System for the driver's seat and
front passenger's seats.
The front airbags are designed to supplement the three-point seat belts. For these
airbags to provide protection, the seat belts must be worn at all times when driving.
You can be severely injured or killed in an accident if you are not wearing a seat belt.
Airbags are designed to supplement seat belts, but do not replace them. Also, airbags are
not designed to deploy in every collision. In some accidents, the seat belts are the only
restraint protecting you.
WARNING
AIRBAG SAFETY PRECAUTIONS
ALWAYS use seat belts and Child Restraint Systems - every trip, every time, everyone!
Even with airbags, you can be seriously injured or killed in a collision if you are improperly
belted or not wearing your seat belt when the airbag inflates.
NEVER place a child in any Child Restraint System or booster seat in the front passenger
seat, unless the airbag is deactivated.
An inflating airbag could forcefully strike the infant or child causing serious or fatal
injuries.
ABC - Always Buckle Children under age 13 in the back seat. It is the safest place for
children of any age to ride. If a child age 13 or older must be seated in the front seat, he
or she must be properly belted and the seat should be moved as far back as possible.
All occupants should sit upright with the seatback in an upright position, centered on the
seat cushion with their seat belt on, legs comfortably extended and their feet on the floor
until the vehicle is parked and the vehicle is turned off. If an occupant is out of position
during an accident, the rapidly deploying airbag may forcefully contact the occupant
causing serious or fatal injuries.
You and your passengers should never sit or lean unnecessarily close to the airbags or
lean against the door or center console.
Move your seat as far back as possible from front airbags, while still maintaining control
of the vehicle. The U.S. National Highway Traffic Safety Administration (NHTSA)
recommends that drivers allow at least 10 in. (25 cm) between the center of the steering
wheel and the chest.
3-40
3
SRS Components
1C_AirbagPartsOverview
The SRS consists of the following components:
(1) Driver's front airbag module
(2) Passenger's front airbag module
(3) Side airbag modules
(4) Curtain airbag modules
(5) Retractor pretensioner
(6) Airbag warning light
(7) SRS control module (SRSCM)/Rollover sensor
(8) Front impact sensors
(9) Side impact sensors (acceleration)
(10)Side impact sensors (pressure)
(11) Occupant classification system
(12)Driver's and front passenger's seat belt buckle sensors
(13)Emergency Fastening Device (EFD) system
Information
Front Passenger's airbag OFF indicator is located on the overhead console.
3-41
Seats & Safety System
Where are the Airbags?
ability to control the SRS deployment
based on whether or not the seat belts are
fastened, and how severe the impact is.
Driver's and passenger's front
The SRS offers the ability to control the
airbags
airbag inflation within two levels. A first
Driver's front airbag
stage level is provided for moderate
severity impacts. A second stage level is
provided for more severe impacts.
According to the impact severity and seat
belt usage, the SRS Control Module
(SRSCM) controls the airbag inflation.
Failure to properly wear seat belts may
increase the risk or severity of injury in a
collision.
WARNING
Passenger's front airbag
To reduce the risk of serious injury or
death from inflating front airbags:
Seat belts must be worn at all times to
help keep occupants positioned
properly.
Move your seat as far back as possible
from front airbags, while still
maintaining control of the vehicle.
Never lean against the door or center
console.
Hold the steering wheel at the 9 o'clock
The SRS consists of advanced airbags
and 3 o'clock positions, to minimize the
located in the center of the steering
risk of injuries to your hands and arms.
wheel and the passenger's side front
Do not allow the front passenger to
panel pad above the glove box.
place their feet or legs on the
The airbag locations are embossed with
dashboard.
the letters, "AIRBAG".
Never place any objects (such as
The purpose of the SRS is to provide the
dashboard cover, mobile phone holder,
vehicle's driver and front passenger with
cup holder, perfume or stickers) over or
additional supplemental protection that
near the airbag modules on the steering
the seat belt system does not provide in
wheel, instrument panel, windshield
case of a frontal impact of sufficient
glass, and the front passenger's panel
severity.
above the glove box. Such objects may
The SRS uses sensors to gather
cause harm if the vehicle is in a crash
information about the driver's and front
severe enough to cause the airbags to
passenger's seat belt usage and impact
deploy.
severity.
Do not attach any objects on the front
The seat belt buckle sensors determine if
windshield and inside mirror.
the driver and front passenger's seat belts
are fastened. These sensors provide the
3-42
3
Side airbags
WARNING
Side airbag
To reduce the risk of serious injury or
death from an inflating side airbag:
Seat belts must be worn at all times to
help keep occupants positioned
properly.
Do not allow passengers to lean their
heads or bodies onto doors, put their
arms on the doors, stretch their arms
out of the window, or place objects
between the doors and seats.
Do not use any accessory seat covers. It
may reduce or prevent the
effectiveness of the system.
Do not hang other objects except
clothes. In an accident it may cause
vehicle damage or personal injury
especially when airbag is inflated.
Do not place any objects over the
airbag location or between the airbag
and yourself. Also, do not attach any
2C_SideAirbagDeployment
objects around the area the airbag
inflates such as door, side door glass,
Side airbags are located in each front
and front and rear pillar.
seat.
Do not place any objects between the
The side airbags are designed to deploy
door and the seat. They may become
during certain side impact collisions,
dangerous projectiles if the side airbag
depending on the crash severity, angle,
inflates.
speed and point of impact.
Do not install any accessories on the
For the vehicle equipped with a rollover
side or near the side airbags.
sensor, the side and/or curtain airbags
and pretensioners on both sides of the
Do not cause an impact to the doors
vehicle may deploy if a rollover or
when the Start/Stop button is in the ON
possible rollover is detected.
or START position because the side
airbags can inflate.
The side airbags are not designed to
deploy in all side impact or rollover
If the seat or seat cover is damaged,
situations.
have your vehicle serviced by an
authorized HYUNDAI dealer.
3-43
Seats & Safety System
Curtain airbags
WARNING
To reduce the risk of serious injury or
death from an inflating curtain airbag:
Seat belts must be worn at all times to
help keep occupants positioned
properly.
Properly secure a Child Restraint
System as far away from the door as
possible.
Do not place any objects over the
2C_CurtainAirbagLabel
airbag. Also, do not attach any objects
around the area the airbag inflates such
as door, side door glass, front and rear
pillar, and roof side rail.
Do not hang other objects except
clothes, especially hard or breakable
objects near airbag locations. In an
accident, it may cause vehicle damage
or personal injury.
Do not allow passengers to lean their
heads or bodies onto doors, put their
2C_CurtainAirbagDeployment
arms on the doors, stretch their arms
Curtain airbags are located along both
out of the window, or place objects
sides of the roof rails above the front and
between the doors and seats.
rear doors.
Do not open or repair the side curtain
They are designed to help protect the
airbags yourself. If necessary, have the
heads of the front seat occupants and the
airbag inspected by an authorized
rear outboard seat occupants in certain
HYUNDAI dealer.
side impact collisions.
The curtain airbags are designed to
deploy during certain side impact
collisions, depending on the crash
severity.
For the vehicle equipped with a rollover
sensor, the side and/or curtain airbags
and pretensioners on both sides of the
vehicle may deploy if a rollover or
possible rollover is detected.
The curtain airbags are not designed to
deploy in all side impact or rollover
situations.
3-44
3
The front airbags completely inflate
How does the Airbags System
and deflate in an instant. It is virtually
Operate?
impossible for you to see the airbags
The SRSCM (Supplemental Restraint
inflate during an accident. It is much
System Control Module) continually
more likely that you simply see the
monitors all SRS components while the
deflated airbags hanging out of their
Start/Stop button is ON to determine if a
storage compartments after the
crash impact is severe enough to require
collision.
airbag deployment or pretensioner seat
In addition to inflating in serious side
belt deployment.
collisions, vehicles equipped with a
During a moderate to severe frontal
rollover sensor, side and/or curtain
collision, sensors detect the vehicle's
airbags inflate if the sensing system
rapid deceleration. If the rate of
detects a rollover.
deceleration is high enough, the SRSCM
When a rollover is detected, curtain
inflates the front airbags with the force
airbags remain inflated longer to help
needed.
provide protection from ejection,
The front airbags help protect the driver
especially when used in conjunction
and front passenger by responding to
with the seat belts.
frontal impacts in which seat belts alone
To help provide protection, the airbags
cannot provide adequate restraint. When
must inflate rapidly. The speed of
needed, the side airbags help provide
airbag inflation is a consequence of
protection in the event of a side impact or
extremely short time in which the
rollover by supporting the side upper
airbag inflates between the occupant
body area.
and the vehicle structures before the
• Airbags are activated (able to inflate if
occupant impacts those structures.
necessary) only when the Start/Stop
This speed of inflation reduces the risk
button is in the ON or START position,
of serious or life-threatening injuries
and it may be activated within 3
and is thus a necessary part of airbag
minutes after the vehicle is turned off.
design.
• Airbags inflate in the event of certain
However, the rapid airbag inflation may
frontal or side collisions to help protect
also cause injuries that include facial
the occupants from serious physical
abrasions, bruises, and broken bones
injury.
because the inflation speed also causes
• There is no single speed at which the
the airbags to expand with great force.
airbags will inflate. Generally, airbags
There are even circumstances under
are designed to inflate based upon the
which contact with the airbag may
severity of a collision and its direction.
cause fatal injuries, especially when the
Airbag deployment also depends on a
occupant is positioned excessively
number of other factors including
close to the airbag.
vehicle speed, angles of impact and the
You can take steps to reduce the risk of
density and stiffness of the vehicles or
being injured by an inflating airbag. The
objects which your vehicle impacts
greatest risk is sitting too close to the
during a collision. The determining
airbag. An airbag needs about 10 in. (25
factors are not limited to those
cm) of space to inflate. NHTSA
mentioned above.
recommends that drivers allow at least 10
in. (25 cm) between the center of the
steering wheel and the chest.
3-45
Seats & Safety System
Driver's front airbag (1)
WARNING
To reduce the risk of serious injury or
death from an inflating airbag:
• Never place a child restraint in the front
passenger seat. Always properly
restrain children under age 13 in the
rear seats of the vehicle.
• Adjust the front passenger's and
driver's seats as far to the rear as
possible while allowing you to maintain
full control of the vehicle.
When the SRSCM detects a sufficiently
• Hold the steering wheel with hands at
severe impact to the front of the vehicle,
the 9 o'clock and 3 o'clock positions.
it automatically deploys the front airbags.
• Never place anything or anyone
Driver's front airbag (2)
between the airbag and the seat
occupant.
• Do not allow the front passenger to
place their feet or legs on the
dashboard.
Upon deployment, tear seam in the pad
cover separates from the expansion of
the airbags.
A fully inflated airbag, in combination
with a properly worn seat belt, slows the
driver's or the front passenger's forward
motion, reducing the risk of head and
chest injury.
3-46
3
Driver's front airbag (3)
What to Expect After an
Airbag Inflates
After a frontal or side airbag inflates, it
deflates very quickly. Airbag inflation
does not prevent the driver from seeing
out of the windshield or being able to
steer. Curtain airbags may remain
partially inflated for some time after they
deploy.
WARNING
Passenger's front airbag
After an airbag inflates, take the following
precautions:
• Open your windows and doors as soon
as possible after impact to reduce
prolonged exposure to the powder
released by the inflating airbag.
• Do not touch the airbag storage area's
internal components immediately after
an airbag has inflated. The parts that
come into contact with an inflating
airbag may be very hot.
2C_PassengerAirbagDeployment
• Always wash exposed skin areas
After complete inflation, the airbag
thoroughly with cold water and mild
immediately starts deflating, enabling the
soap.
driver to maintain forward visibility and
steer or operate other controls.
• Have an authorized HYUNDAI dealer
inspect your vehicle and replace
WARNING
components as required before
operating your vehicle again. Airbags
To prevent objects from becoming
are designed to be used only once.
dangerous projectiles when the
passenger's airbag inflates:
• Do not install or place any objects (drink
holder, CD holder, stickers, etc.) on the
front passenger's panel above the glove
box where the passenger's airbag is
located.
• Do not install a container of liquid air
freshener near the instrument cluster or
on the instrument panel surface.
3-47
Seats & Safety System
Noise and smoke from inflating
SRS Warning Light
airbag
When the airbags inflate, they make a
loud noise and may release powder inside
the vehicle. After the airbag inflates, you
=
may feel discomfort while breathing. This
may be due to the impact of the airbag or
the seat belt with your chest and it may
The SRS (Supplemental Restraint System)
also be due to breathing residual powder
airbag warning light on the instrument
in the air and around your vehicle. The
panel displays the airbag symbol in the
powder may aggravate asthma for some
illustration. The light indicates if there is a
people. If you experience breathing
potential problem with your airbag
problems after an airbag deployment,
system, which could include your side
seek medical attention immediately.
and/or curtain airbags used for rollover
protection.
Though the powder is nontoxic, it may
cause irritation to the skin, eyes, nose,
WARNING
throat, etc. If this is the case, wash and
rinse with cold water immediately and
If your SRS malfunctions, the airbags may
seek medical attention if the symptoms
not inflate properly during a collision
persist.
increasing the risk of serious injury or
death.
Your SRS malfunctions in the following
conditions:
• The light does not turn on for about
three to six seconds when the
Start/Stop button is in the ON position.
• The light stays on after illuminating for
about three to six seconds.
• The light comes on while the vehicle is
moving.
• The light blinks when the vehicle is
running.
Have an authorized HYUNDAI dealer
inspect the SRS as soon as possible.
3-48
3
Occupant Classification
Front passenger seat adult occupants
who are properly seated and wearing the
System (OCS)
seat belt properly, should not cause the
passenger airbag to be automatically
turned off. For smaller adults it may turn
off, however, if the occupant does not sit
in the seat properly (for example, by not
sitting upright, by sitting on the edge of
the seat, or by otherwise being out of
position), this could cause the sensor to
turn the airbag off.
You will find the "PASSENGER AIRBAG
OFF" indicator on the overhead console
panel. This system detects the conditions
2C_OCSIndicator
1-4 in the following table and activates or
Your vehicle is equipped with an
deactivates the front passenger airbag
Occupant Classification System (OCS) in
based on these conditions.
the front passenger's seat.
Always be sure that you and all vehicle
occupants are seated properly and
Main components of the Occupant
wearing the seat belt properly for the
Classification System
most effective protection by the airbag
• A detection device located within the
and the seat belt.
front passenger seat cushion.
The OCS may not function properly if the
• Electronic system to help determine
passenger takes actions which can affect
whether the passenger airbag systems
the classification system. These include:
should be activated or deactivated.
• Failing to sit in an upright position.
• An indicator light located on the
• Leaning against the door or center
overhead console which illuminates the
console.
words "PASSENGER AIRBAG OFF"
• Sitting towards the sides of the front of
indicating the front passenger airbag
the seat.
system is deactivated.
• Putting their legs on the dashboard or
• The instrument cluster airbag indicator
resting them on other locations which
light is interconnected with the OCS.
reduce the passenger weight on the
The OCS is designed to help detect the
front seat.
presence of a properly-seated front
• Wearing the seat belt improperly.
passenger and determine if the
• Reclining the seatback.
passenger's front airbag should be
enabled (may inflate) or not.
• Wearing thick clothing like ski wear or
hip protection wear.
The purpose is to help reduce the risk of
injury or death from an inflating airbag to
• Putting an additional thick cushion on
certain front passenger seat occupants,
the seat.
such as children, by requiring the airbag
• Putting electrical devices (for example,
to be automatically turned off.
laptop, satellite radio) on the seat with
For example, if a child restraint of the type
inverter charging.
specified in the regulations is on the seat,
the occupant classification sensor can
detect it and cause the airbag to turn off.
3-49
Seats & Safety System
Condition and operation in the front passenger Occupant Classification System
Indicator/Warning Light
Devices
Condition Detected by the
"PASSENGER
Occupant Classification System
SRS Warning
Front Passenger
AIRBAG OFF"
Light
Airbag
Indicator Light
Adult *1
Off
Off
Activated
Infant *2 or child restraint system
On
Off
Deactivated
with 12 months old *3*4
Unoccupied
On
Off
Deactivated
Malfunction in the system
Off
On
Activated
*1 The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the
system may recognize him/her as a child depending on his/her physique and posture.
*2 Do not allow children to ride in the front passenger seat. When a larger child who has outgrown a child restraint
system sits in the front passenger seat, the system may recognize him/her as an adult depending upon his/her
physique or sitting position.
*3 Never install a child restraint system on the front passenger seat.
*4 The PASSENGER AIRBAG "OFF" indicator may turn on or off when a child above 12 months to 12 years old (with
or without child restraint system) sits in the front passenger seat. This is a normal condition.
3-50
3
• NEVER place your feet or legs on the
WARNING
dashboard.
Riding in an improper position or placing
weight on the front passenger's seat
when it is unoccupied by a passenger
adversely affects the OCS. To reduce the
risk of serious injury or death:
• NEVER put a heavy load in the front
seat or seatback pocket, or hang any
items on the front passenger seat.
2C_OCSWarning_3
• NEVER place your feet on the front
passenger seatback.
2C_OCSWarning
• NEVER sit with your hips shifted
towards the front of the seat.
2C_OCSWarning_4
• NEVER ride with the seatback reclined
when the vehicle is moving.
2C_OCSWarning_2
2C_OCSWarning_5
3-51
Seats & Safety System
• NEVER lean on the door or center
• Do not place electronic devices such as
console or sit on one side of the front
laptops, DVD player, or conductive
passenger seat.
materials such as water bottles on the
passenger seat. Do not use electronic
devices such as laptops and satellite
radios which use inverter chargers.
2C_OCSWarning_6
• Do not sit on the passenger seat
wearing heavily padded clothes such as
ski wear or hip protector.
2C_OCSWarning_8
• If large quantity of liquid has been
spilled on the passenger seat, the
airbag warning light may illuminate or
malfunction. Therefore, make sure the
seat has been completely dried before
driving the vehicle.
2C_OCSWarning_7
• Do not use car seat accessories such as
thick blankets and cushions which
cover up the car seat surface.
2C_OCSWarning_10
• Do not place sharp objects on the front
passenger seat. These may damage the
occupant detection system, if they
puncture the seat cushion.
• Do not place any items under the front
passenger seat.
• When changing or replacing the seat
2C_OCSWarning_9
only use Genuine Hyundai Parts. The
OCS has been developed based on
using original HYUNDAI car seats only.
Altering or changing the authentic parts
may result in system malfunction and
increase risk of injury when in collision.
Any of the above could interfere with
3-52
3
the proper operation of the OCS sensor
NOTICE
thereby increasing the risk of an injury
in an accident.
The "PASSENGER AIRBAG OFF" indicator
generally illuminates for about 4 seconds
after the Start/Stop button is in the ON or
Proper seated position for OCS
START position. But, if the Start/Stop
button is pressed to the ON or START
position within 3 minutes after the vehicle
is turned OFF, the indicator does not
illuminate. If the front passenger seat is
occupied, the OCS will then classify the
front passenger after several more
seconds.
Do not install a Child Restraint
System on the Front Passenger's
2C_HowToUseOCS
Seat
If the "PASSENGER AIRBAG OFF"
indicator is on when an adult is seated in
the front passenger seat, place the
Start/Stop button in the OFF position and
ask the passenger to sit properly (sitting
upright with the seat back in an upright
position, centered on the seat cushion
with their seat belt on, legs comfortably
extended and their feet on the floor).
Restart the vehicle and have the person
remain in that position. This will allow the
system to detect the person and to enable
2C_AirbagPartsWarning
the passenger airbag. If the "PASSENGER
Even though your vehicle is equipped
AIRBAG OFF" indicator is still on, ask the
with the OCS, never install a child
passenger to move to the rear seat.
restraint in the front passenger's seat. An
inflating airbag can forcefully strike a
WARNING
child or child restraint resulting in serious
NEVER allow an adult passenger to ride in
or fatal injury.
the front passenger seat when the
"PASSENGER AIRBAG OFF" indicator is
WARNING
illuminated. During a collision, the airbag
NEVER use a rearward facing Child
will not inflate if the indicator is
Restraint on a seat protected by an
illuminated. Have your passenger
ACTIVE AIRBAG in front of it, DEATH or
reposition themselves in the seat. If the
SERIOUS INJURY to the CHILD can occur.
"PASSENGER AIRBAG OFF" indicator
remains illuminated after the passenger
repositions themselves properly and the
vehicle is restarted, have the passenger
move to the rear seat because the airbag
will not inflate.
3-53
Seats & Safety System
Why didn't My Airbag Go Off in
a Collision?
There are certain types of accidents in
which the airbag would not be expected
to provide additional protection. These
include rear impacts, second or third
collisions in multiple impact accidents, as
well as low speed impacts. Damage to the
vehicle indicates collision energy
absorption, and is not an indicator of
whether or not an airbag should have
inflated.
Airbag collision sensors
WARNING
To reduce the risk of an airbag deploying
unexpectedly and causing serious injury
or death:
• Do not hit or allow any objects to
impact the locations where airbags or
sensors are installed.
• Do not perform maintenance on or
around the airbag sensors. If the
location or angle of the sensors is
altered, the airbags may deploy when
they should not or may not deploy
when they should.
• Installing bumper guards with
non-genuine Hyundai parts may
adversely affect the collision and airbag
deployment performance.
To ensure correct function of the airbag
system, have the bumper replaced with
genuine Hyundai part specified for your
vehicle.
• Press the Start/Stop button to the OFF
or ACC position and wait for 3 minutes
when the vehicle is being towed to
prevent inadvertent airbag
deployment.
• Have all airbag repairs conducted by an
authorized HYUNDAI dealer.
3-54
3
1C_AirbagSensorOverview
(1) SRS control module/Rollover sensor
(2) Front impact sensor
(3) Side impact sensor (Pressure)
(4) Side impact sensor (Acceleration)
3-55
Seats & Safety System
Airbag inflation conditions
Although the driver's and front
passenger's airbags are designed to
Front airbags
inflate in frontal collisions, they also may
inflate in other types of collisions if the
front impact sensors detect a sufficient
impact. Side and curtain airbags are
designed to inflate in side impact
collisions, but they may inflate in other
collisions if the side impact sensors
detect a sufficient impact.
Also, the side and curtain airbags are
designed to inflate when a rollover is
detected by a rollover sensor.
2C_AirbagOperatingConditionFrontAirbag
If the vehicle chassis is impacted by
Front airbags are designed to inflate in a
bumps or objects on unimproved roads,
frontal collision depending on the
the airbags may deploy. Drive carefully on
severity of impact of the front collision.
unimproved roads or on surfaces not
designed for vehicle traffic to prevent
Side and curtain airbags
unintended airbag deployment.
Airbag non-inflation conditions
2C_AirbagOperatingConditionSideAirbag
2C_AirbagNonOperatingConditionMinorCrash
In certain low-speed collisions the
airbags may not deploy. The airbags are
designed not to deploy in such cases
because they may not provide benefits
beyond the protection of the seat belts.
2C_SideCurtainAirbagDeployment
Side and curtain airbags are designed to
inflate when an impact is detected by side
collision sensors depending on the
severity of impact resulting from a side
collision.
3-56
3
2C_AirbagNonOperatingConditionRearCrash
Front airbags are not designed to inflate
2C_AirbagNonOperatingConditionSidlingCrash
in rear collisions, because occupants are
In an angled collision, the force of impact
moved backward by the force of the
may direct the occupants in a direction
impact. In this case, inflated airbags
where the airbags would not be able to
would not provide any additional benefit.
provide any additional benefit, and thus
the sensors may not deploy any airbags.
2C_AirbagNonOperatingConditionSideCrash
Front airbags may not inflate in side
2C_AirbagNonOperatingConditionTruckCrash
impact collisions, because occupants
Just before impact, drivers often brake
move in the direction of the collision, and
heavily. Such heavy braking lowers the
thus in side impacts, front airbag
front portion of the vehicle causing it to
deployment would not provide additional
"ride" under a vehicle with a higher
occupant protection.
ground clearance. Airbags may not inflate
in this "underride" situation because
However, side and curtain airbags may
deceleration forces that are detected by
inflate depending on the severity of
sensors may be significantly reduced by
impact.
such "underride" collisions.
3-57
Seats & Safety System
SRS Care
The SRS is virtually maintenance-free and
there are no parts you can safely service
by yourself. If the SRS airbag warning
light does not illuminate when the
Start/Stop button is in the ON position, or
continuously remains on, have the
system be immediately inspected by an
authorized HYUNDAI dealer.
Any work on the SRS system, such as
2C_AirbagNonOperatingConditionTurnoverCrash
removing, installing, repairing, or any
Front airbags may not inflate in rollover
work on the steering wheel, the front
accidents because front airbag
passenger's panel, front seats and roof
deployment would not provide additional
rails be performed by an authorized
occupant protection.
HYUNDAI dealer. Improper handling of
The side and curtain airbags may inflate in
the SRS system may result in serious
a rollover situation, when it is detected by
personal injury.
the rollover sensor.
WARNING
To reduce the risk of serious injury or
death take the following precautions:
• Do not attempt to modify or disconnect
the SRS components or wiring,
including the addition of any kind of
badges to the pad covers or
modifications to the body structure.
• Do not place objects over or near the
airbag modules on the steering wheel,
2C_AirbagNonOperatingConditionPollCrash
instrument panel, and the front
Airbags may not inflate if the vehicle
passenger's panel above the glove box.
collides with objects such as utility poles
• Clean the airbag pad covers with a soft
or trees, where the point of impact is
cloth moistened with plain water.
concentrated and the collision energy is
Solvents or cleaners could adversely
absorbed by the vehicle structure.
affect the airbag covers and proper
deployment of the system.
• Have the inflated airbags replaced by
an authorized HYUNDAI dealer.
• If components of the airbag system
must be discarded, or if the vehicle
must be scrapped, certain safety
precautions must be observed. Consult
an authorized HYUNDAI dealer for the
necessary information. Failure to follow
these precautions could increase the
risk of personal injury.
3-58
3
Additional Safety Precautions
Adding equipment to or modifying
your airbag equipped vehicle
Passengers should not move out of or
change seats while the vehicle is
If you modify your vehicle by changing
moving. A passenger who is not wearing
your vehicle's frame, bumper system,
a seat belt during a crash or emergency
front end or side sheet metal or ride
stop can be thrown against the inside of
height, this may affect the operation of
the vehicle, against other occupants, or
your vehicle's airbag system.
be ejected from the vehicle.
Do not use any accessories on seat belts.
Airbag Warning Labels
Devices claiming to improve occupant
comfort or reposition the seat belt can
reduce the protection provided by the
seat belt and increase the chance of
serious injury in a crash.
Do not modify the front seats.
Modification of the front seats could
interfere with the operation of the
supplemental restraint system sensing
components or side airbags.
Do not place items under the front seats.
Placing items under the front seats could
2C_AirbagWarningLabelPosition
interfere with the operation of the
Airbag warning labels, required by the
supplemental restraint system sensing
U.S. National Highway Traffic Safety
components and wiring harnesses.
Administration (NHTSA), are attached to
Do not cause impact to the doors.
alert the driver and passengers of
Impact to the doors when the Start/Stop
potential risks of the airbag system. Be
button is in the ON or START position may
sure to read all of the information about
cause the airbags to inflate.
the airbags that are installed on your
vehicle in this Owners Manual.
Modifications to accommodate
disabilities. If you require modification to
your vehicle to accommodate a disability,
contact the HYUNDAI Customer Connect
Center at 800-633-5151.
3-59
4. Instrument Cluster
Instrument Cluster
4-2
Instrument Cluster Control
4-3
Gauges and Meters
4-4
Power/Charge Gauge
4-4
State of Charge (SOC) Gauge for High Voltage Battery
4-5
Gear Shift Indicator
4-7
Warning and Indicator Lights
4-7
Cluster Display Messages
4-19
Cluster Display
4-23
Cluster Display Control
4-23
4
View Modes
4-23
Vehicle Settings (Infotainment System)
4-26
Setting Your Vehicle
4-26
Instrument Cluster
Instrument Cluster
Type A
Type B
The actual cluster in the vehicle may differ from the illustration. For more information, refer to the "Gauges and
Meters" section in this chapter.
(1) Speedometer
(2) Power/Charge gauge
(3) Odometer
(4) Distance to empty
(5) Battery SOC (State of Charge) gauge
(6) Warning and indicator lights
(7) Cluster display
4-2
4
Instrument Cluster Control
Infotainment system
You can adjust the brightness of the
instrument panel illumination from the
Instrument panel illumination
infotainment system. Press theŲ
button, and then select Cluster >
Control switch
Illumination
Information
The infotainment system may change
after software updates. For more
information, refer to the manual provided
in the infotainment system and the quick
reference guide.
2C_IlluminationControlSwitch
WARNING
When the vehicle's parking lights or
Never adjust the instrument cluster while
headlights are on, press the illumination
driving. This could result in loss of control
control switch to adjust the brightness of
and lead to an accident that may cause
the instrument panel illumination.
death, serious injury, or vehicle damage.
When pressing the illumination control
switch, the interior switch illumination
intensity is also adjusted.
WARNING
Never adjust the instrument panel
illumination while driving to prevent
death, serious injury, or vehicle damage.
• The brightness of the instrument panel
illumination is displayed.
• When the brightness setting reaches
either the minimum or maximum level,
a chime sounds.
4-3
Instrument Cluster
Gauges and Meters
Power/Charge Gauge
Type A
Speedometer
Type A
2C_PowerChargeGauge
Type B
2C_Speedmeter
Type B
The Power/Charge gauge shows the
energy consumption rate of the vehicle
2C_Speedmeter_2
and the charge/discharge status of the
The speedometer indicates the speed of
regenerative brakes.
the vehicle and is calibrated in mi. per
hour (MPH).
• POWER: It shows the energy
consumption rate of the vehicle when
driving uphill or accelerating. The more
electric energy is used, the higher the
gauge level.
• CHARGE: It shows the charging status
of the battery when it is being charged
by the regenerative brakes
(decelerating or driving on a downhill
road). The more electric energy is
charged, the lower the gauge level.
4-4
4
State of Charge (SOC) Gauge
Outside temperature gauge
for High Voltage Battery
2C_OutsideTemp
2C_BatteryLevelGauge
The temperature reads in Fahrenheit or
• The SOC gauge shows the charging
Celsius depending on the units selected
status of the high voltage battery.
from the infotainment system. The
temperature indicated on the instrument
• The low percentage number on the
cluster may not change as quickly as the
indicator indicates that there is not
outside temperature.
enough energy in the high voltage
battery. 100 % indicates that the high
Press theŲ button, and then select
voltage battery is fully charged.
General > Units > Temperature Unit.
• When driving on highways, make sure
Both the temperature unit on the
to check in advance if the high voltage
instrument cluster and climate control
battery is charged enough.
screen is changed.
1. When the remaining battery is lower
Information
than 10 % on the SOC gauge, the High
Voltage Battery Level (ª) warning light
The infotainment system may change
Illuminates, to alert you of the battery
after software updates. For more
level.
information, refer to the user's manual
provided in the infotainment system and
2. When the High Voltage Battery Level
the quick reference guide.
(ª) warning light Illuminates, the
vehicle can drive an additional 18-25 mi.
(30-40 km) depending on the driving
speed, heater/air conditioner, weather,
driving style, and other factors.
Charging is required.
NOTICE
When the high voltage battery level is
low, the Power Down (®) indicator light
illuminates and the vehicle power is
limited.
Charge the battery immediately since
your vehicle may not be driven, or may
roll back on a slope with the indicator light
illuminated.
4-5
Instrument Cluster
Odometer
• The distance to empty differs
depending on which drive mode
(ECO/NORMAL/SPORT/SNOW) is
selected.
For more information, refer to the
"Factors affecting the distance to empty"
section in chapter 1.
Information
• The distance to empty may differ from
the actual driving distance because it is
2C_Odometer
only an estimate as it is an estimate of
The odometer indicates the total distance
the available driving distance.
that the vehicle has been driven and
• The distance to empty may differ
should be used to determine when
significantly based on driving
periodic maintenance is required.
conditions, driving habits, and
condition of the vehicle.
Distance to empty
• If the vehicle is not on level ground or
Type A
the battery power has been
interrupted, the distance to empty
function may not operate correctly.
Type B
The distance to empty is the estimated
distance the vehicle can be driven with
the remaining electric energy.
4-6
4
Gear Shift Indicator
Warning and Indicator Lights
Information
Make sure that all warning lights are OFF
after starting the vehicle. If any light is still
ON, this indicates a situation that needs
attention.
Ready Indicator Light
2C_ShiftPosition
The Gear Shift Indicator indicates the
current gear or P (Park).
¢
Regenerative braking level indicator
This indicator illuminates:
When the vehicle is ready to be driven.
• ON: Normal driving is possible.
• OFF: Normal driving is not possible, or a
problem has occurred.
• Blinking: Emergency driving.
When the¢ indicator goes off or blinks,
there is a problem with the system. In this
case, have your vehicle inspected by an
2C_RegenerationBrakeLevel
authorized HYUNDAI dealer.
The regenerative brake indicates the level
of the regenerative braking that you set.
And it also indicates Smart regenerative
system's operation status.
For more information, refer to the
"Regenerative Braking System" section in
chapter 6.
4-7
Instrument Cluster
Service Warning Light
Power Down Indicator Light
«
®
This warning light illuminates:
This indicator light illuminates:
• When the Start/Stop button is in the ON
When the power is limited for the safety
position. The Service warning light
of the high-powered parts of an electric
illuminates for 3 seconds and then goes
vehicle. The power is limited for the
off.
following reasons:
• When there is a problem with related
• The high voltage battery level is too low
parts of the electric vehicle control
or voltage is decreasing
system, such as sensors, etc.
• The temperature of the high voltage
When the warning light illuminates while
battery is too high or too low
driving, or does not go off after starting
• The temperature of the motor is high
the vehicle, have your vehicle inspected
by an authorized HYUNDAI dealer.
NOTICE
• Do not accelerate or start the vehicle
suddenly when the power down
indicator light is illuminated.
• When the power is limited for the safety
of high-powered parts of an electric
vehicle, the power down indicator light
illuminates. Your vehicle may not be
driven, or may roll back on a slope with
the indicator light illuminated due to
the limitation of vehicle power.
Information
Unless both the Service Warning Light
and Power Down Indicator Light
illuminate at the same time, it is not a
failure.
4-8
4
Charging Connector Indicator Light
Airbag Warning Light
¥
=
This warning light indicates the
This warning light illuminates:
connection status of the charging
connector. When the charging connector
• When the Start/Stop button is in the ON
is connected to the vehicle, the green
position. The Airbag warning light
light illuminates for about 1 minute.
illuminates for 3-6 seconds and then
goes off.
High Voltage Battery Level Warning
• When there is a malfunction with the
Light
Safety Restraint System (SRS).
If the Airbag warning light remains
illuminated while driving, have your
vehicle inspected by an authorized
HYUNDAI dealer.
ª
Regenerative Brake Warning Light
This warning light illuminates:
When the high voltage battery level is
low.
Charge the high voltage battery as soon
"
as possible.
This warning light illuminates:
Seat Belt Warning Light
When the regenerative brake does not
operate and the brake does not perform
well. This causes the Brake Warning light
(red) and Regenerative Brake Warning
!
Light (yellow) to illuminate
simultaneously.
This warning light informs the driver that
In this case, drive safely and have your
the seat belt is not fastened.
vehicle inspected by an authorized
HYUNDAI dealer.
For more information, refer to the "Seat
Belts" section in chapter 3.
The operation of the brake pedal may be
more difficult than normal and the
braking distance can increase.
4-9
Instrument Cluster
Parking Brake and Brake Fluid
Dual-diagonal braking system
Warning Light
Your vehicle is equipped with the
dual-diagonal braking system. This
means you still have braking on two
wheels even if one of the dual systems
fails.
?
With only one of the dual systems
working, more than normal pedal travel
and greater pedal force are required to
This warning light illuminates:
stop the vehicle.
• When the Start/Stop button is in the ON
Also, the vehicle does not stop in a short
position. The Parking Brake warning
distance if only a portion of the braking
light illuminates for about 3 seconds
system is working.
and then goes off once the parking
brake is released.
WARNING
• Whenever the parking brake is applied.
If the Parking Brake and Brake Fluid
• Whenever the brake fluid level in the
warning light illuminates with the parking
reservoir is low.
brake released, it indicates that the brake
- If the warning light illuminates with
fluid level is low.
the parking brake released, it
Have your vehicle inspected by an
indicates the brake fluid level in the
authorized HYUNDAI dealer.
reservoir is low.
If the brake fluid level in the reservoir is
Anti-lock Brake System (ABS)
low:
Warning Light
1. Drive carefully to the nearest safe
location and stop your vehicle.
2. With the motor stopped, check the
brake fluid level immediately and add
B
fluid as required (For more information,
refer to the "Brake Fluid" section in
chapter 9). After adding brake fluid,
check all brake components for fluid
This warning light illuminates:
leaks. If a brake fluid leak is found, or if
• When the Start/Stop button is in the ON
the warning light remains on, or if the
position. The ABS warning light
brakes do not operate properly, do not
illuminates for about 3 seconds and
drive the vehicle. Have your vehicle
then goes off.
inspected by an authorized HYUNDAI
• Whenever there is a malfunction with
dealer.
the ABS.
The hydraulic braking system still
operates even if there is a malfunction
with the ABS.
If the ABS warning light remains
illuminated while driving, have your
vehicle inspected by an authorized
HYUNDAI dealer.
4-10
4
Electronic Brake Force Distribution
Motor Driven Power Steering
(EBD) System Warning Light
(MDPS) Warning Light
A
E
These two warning lights illuminate at the
This warning light illuminates:
same time while driving:
• When the Start/Stop button is in the ON
When the ABS warning and Parking Brake
position. The Motor Driven Power
warning lights are on simultaneously, it
Steering warning light illuminates for
may indicate a problem with the
about 3 seconds and then goes off.
Electronic Brake Force Distribution
• Whenever there is a malfunction with
system.
Motor Driven Power Steering.
If both the ABS warning light and the
If the MDPS warning light remains
Parking Brake warning light remain
illuminated while driving, have your
illuminated while driving, have your
vehicle inspected by an authorized
vehicle inspected by an authorized
HYUNDAI dealer.
HYUNDAI dealer.
WARNING
Master Warning Light
When both ABS and Parking Brake and
Brake Fluid warning lights are on, the
braking system does not work normally
and you may experience an unexpected
X
and dangerous situation during sudden
braking. Avoid high speed driving and
abrupt braking.
This warning light illuminates:
Have your vehicle inspected by an
If a malfunction is detected in any of the
authorized HYUNDAI dealer as soon as
following:
possible.
• Forward Collision-Avoidance Assist
malfunction
• Forward Collision-Avoidance Assist
Information
radar blocked
When the ABS warning light is on or both
• Blind-Spot Collision-Avoidance Assist
ABS and Parking Brake and Brake Fluid
malfunction
warning lights are on, the speedometer,
• Blind-Spot Collision-Avoidance Assist
odometer, or tripmeter may not work.
radar blocked
Also, the MDPS warning light may
• Rear Cross-Traffic Collision-Avoidance
illuminate and the steering effort may
Assist malfunction
increase or decrease.
• Rear Cross-Traffic Collision-Avoidance
Assist radar blocked
• Exterior light malfunction
• LED headlight malfunction
4-11
Instrument Cluster
• High Beam Assist malfunction
Low Tire Pressure Warning Light
• Smart Cruise Control malfunction
• Smart Cruise Control radar blocked
• Lane Following Assist malfunction
L
• Low washer fluid (if equipped)
• Tire Pressure Monitoring System
(TPMS) malfunction
This warning light illuminates:
If the issue is resolved, the Master
• When the Start/Stop button is in the ON
Warning Light turns off.
position. The low tire pressure warning
light illuminates for about 3 seconds
Electronic Parking Brake (EPB)
and then goes off.
Warning Light
• When one or more tires are significantly
underinflated. (The location of the
underinflated tire appears on the
instrument cluster.)
M
For more information, refer to the "Tire
Pressure Monitoring System (TPMS)"
section in chapter 8.
This warning light illuminates:
This warning light remains ON after
• When the Start/Stop button is in the ON
blinking for about 60 seconds, or
position. The EPB warning light
repeatedly blinks ON and OFF in 3 second
illuminates for about 3 seconds and
intervals:
then goes off.
When there is a malfunction with the
• Whenever there is a malfunction with
TPMS.
EPB.
If this occurs, have your vehicle inspected
If the EPB warning light remains
by an authorized HYUNDAI dealer as soon
illuminated while driving, have your
as possible.
vehicle inspected by an authorized
For more information, refer to the "Tire
HYUNDAI dealer.
Pressure Monitoring System (TPMS)"
section in chapter 8.
Information
The Electronic Parking Brake (EPB)
WARNING
warning light may illuminate when the
• The TPMS cannot alert you to severe
Electronic Stability Control (ESC)
and sudden tire damage caused by
indicator light comes on to indicate that
external factors.
ESC is not working properly. This does not
indicate malfunction of EPB.
• If you notice any vehicle instability,
immediately take your foot off the
accelerator pedal, apply the brakes
gradually with light force, and slowly
move to a safe position off the road.
4-12
4
Inattentive Driving Warning Light
Forward Safety Warning Light
W
O
This warning light illuminates:
This warning light illuminates:
• When the Start/Stop button is in the ON
• When the Start/Stop button is in the ON
position. It illuminates for about 3
position. The Forward Safety warning
seconds and then goes off.
light illuminates for about 3 seconds
and then goes off.
• Yellow: When Driver Attention Warning
is disabled or a malfunction is detected.
• Yellow: When Forward Safety of
Forward Collision-Avoidance Assist is
If the yellow indicator light remains on
deselected, disabled, or a malfunction
after the front view camera has been
is detected.
uncovered or unblocked, have your
vehicle inspected by an authorized
If the yellow warning light remains on
HYUNDAI dealer.
after the sensor has been uncovered or
unblocked when the Forward Safety is
This indicator light blinks:
set, have your vehicle inspected by an
authorized HYUNDAI dealer.
• Yellow: Driver Attention Warning
recommends to take a break.
If the yellow warning light is still on even
after removing foreign material from the
For more information, refer to the "Driver
front of the sensors after Forward Safety
Attention Warning (DAW)" section in
select in settings, have your vehicle
chapter 7
inspected by an authorized HYUNDAI
dealer as soon as possible.
This warning light blinks:
• Red: When Forward Safety function is
operating.
For more information, refer to the
"Forward Collision-Avoidance Assist
(FCA)" section in chapter 7.
4-13
Instrument Cluster
Lane Following Assist indicator light
Lane Safety Indicator Light
º
S
This indicator light illuminates:
This indicator light illuminates:
• When the Start/Stop button is in the ON
• When the Start/Stop button is in the ON
position. It illuminates for about 3
position. It illuminates for about 3
seconds and then goes off.
seconds and then goes off.
• Green: When Lane Following Assist is
• Gray: When Lane Keeping Assist
operating.
operating conditions are not satisfied.
• Gray: When Lane Following Assist
• Green: When Lane Keeping Assist
operating conditions are not satisfied.
operating conditions are satisfied.
• Yellow: When Lane Safety is
This indicator light blinks:
deselected, disabled, or a malfunction
• White: When the steering wheel assist
is detected.
is cancelled.
If the yellow warning light remains on
For more information, refer to the "Lane
after the sensor has been uncovered or
Following Assist (LFA)" section in chapter
unblocked when Lane Safety is set, have
7.
your vehicle inspected by an authorized
HYUNDAI dealer as soon as possible.
This indicator light blinks:
• Green: When Lane Keeping Assist is
operating.
For more information, refer to the "Lane
Keeping Assist (LKA)" section in chapter 7.
4-14
4
LED Headlight Warning Light
Door Open Indicator Light
Y
l
This warning light illuminates:
This indicator light illuminates:
• When the Start/Stop button is in the ON
When any door or liftgate is left open.
position. The LED headlight warning
light illuminates for about 3 seconds
WARNING
and then goes off.
Before driving the vehicle, confirm the
• Whenever there is a malfunction with
door and liftgate are fully closed.
the LED headlight.
If the LED headlight warning light
remains illuminated while driving, have
CAUTION
your vehicle inspected by an authorized
HYUNDAI dealer.
The 12 V battery may discharge if you
leave the vehicle with the Door Open
This warning light blinks:
indicator light illuminated.
Whenever there is a malfunction with a
LED headlight related part.
Electronic Stability Control (ESC)
If this occurs, have your vehicle inspected
Indicator Light
by an authorized HYUNDAI dealer.
NOTICE
Driving with the LED headlight warning
a
light on or blinking may reduce LED
headlight life.
This indicator light illuminates:
• When the Start/Stop button is in the ON
position. The Electronic Stability
Control indicator light illuminates for
about 3 seconds and then goes off.
• Whenever there is a malfunction with
ESC system.
If this occurs, have your vehicle
inspected by an authorized HYUNDAI
dealer.
This indicator light blinks:
While ESC is operating.
For more information, refer to the
"Electronic Stability Control (ESC)"
section in chapter 6.
4-15
Instrument Cluster
Electronic Stability Control (ESC)
If this occurs, have your vehicle inspected
OFF Indicator Light
by an authorized HYUNDAI dealer.
This indicator light blinks:
Whenever there is a malfunction with the
immobilizer system.
b
If this occurs, have your vehicle inspected
by an authorized HYUNDAI dealer.
This indicator light illuminates:
• When the Start/Stop button is in the ON
Turn Signal Indicator Light
position. The Electronic Stability
Control indicator light illuminates for
about 3 seconds and then goes off.
• When you deactivate ESC system by
`
pressing the ESC OFF button.
For more information, refer to the
"Electronic Stability Control (ESC)"
This indicator light blinks:
section in chapter 6.
When you operate the turn signal lever.
If any of the following occur, there may be
Immobilizer Indicator Light
a malfunction with the turn signal system.
• The turn signal indicator light
illuminates but does not blink.
• The turn signal indicator light blinks
j
rapidly.
• The turn signal indicator light does not
illuminate at all.
This indicator light illuminates for up to 30
If any of these occur, have your vehicle
seconds:
inspected by an authorized HYUNDAI
When the vehicle detects the smart key in
dealer.
the vehicle with the Start/Stop button in
the ACC or ON position.
• At this time, you can start the vehicle.
• The indicator light goes off after
starting the vehicle.
This indicator light blinks for a few
seconds:
When the smart key is not in the vehicle,
you cannot start the vehicle.
This indicator light illuminates for a few
seconds and goes off:
If the smart key is in the vehicle and the
Start/Stop button is ON, but the vehicle
cannot detect the smart key.
4-16
4
Low Beam Indicator Light
High Beam Assist Indicator Light
if equipped
Z
^
This indicator light illuminates:
This indicator light illuminates:
When the high beam is on with the light
When the headlights are on.
switch in the AUTO position.
• White: When High Beam Assist is ready
to operate.
High Beam Indicator Light
• Green: When High Beam Assist is
operating.
If your vehicle detects oncoming vehicles
in front of you, High Beam Assist switches
]
the high beam to low beam automatically.
For more information, refer to the "High
This indicator light illuminates:
Beam Assist (HBA)" section in chapter 5.
• When the headlights are on and in the
high beam position.
AUTO HOLD Indicator Light
• When the turn signal lever is pulled into
the Flash-to-Pass position.
N
Light ON Indicator Light
This indicator light illuminates:
• White: When you activate Auto Hold by
_
pressing the AUTO HOLD switch.
• Green: When you stop the vehicle
This indicator light illuminates:
completely by depressing the brake
pedal with Auto Hold activated.
When the Parking lights or headlights are
on.
• Yellow: Whenever a malfunction with
the Auto Hold is detected.
If the AUTO HOLD indicator light
remains yellow while driving, have your
vehicle inspected by an authorized
HYUNDAI dealer.
For more information, refer to the
"Electronic Parking Brake (EPB)" section
in chapter 6.
4-17
Instrument Cluster
Smart Cruise indicator light
Intelligent Speed Limit Assist
indicator light
Ü
y
This indicator light illuminates:
This indicator light illuminates:
When the smart cruise control system is
enabled.
• When the Start/Stop button is in the ON
position. It illuminates for about 3
For more information, refer to the "Smart
seconds and then goes off.
Cruise Control (SCC)" in chapter 7.
• Yellow: When Intelligent Speed Limit
Assist is disabled, the front view camera
Speed Limiter indicator light
is blocked, or a malfunction is detected.
If the yellow indicator light remains on
after the front view camera has been
uncovered or unblocked, have your
Ý
vehicle inspected by an authorized
HYUNDAI dealer.
For more information, refer to the
This indicator light illuminates:
"Intelligent Speed Limit Assist (ISLA)"
When the speed limiter is enabled.
section in chapter 7.
For more information, refer to the
"Manual Speed Limit Assist (MSLA)" in
chapter 7.
4-18
4
Cluster Display Messages
Key not in vehicle
This message appears if the smart key is
not in the vehicle when you have left the
Shift to P
vehicle with the Start/Stop button in the
This message appears if the Start/Stop
ON or Start position.
button is pressed to the OFF position
Always turn off the vehicle before leaving
without the gear in the P (Park) position.
your vehicle.
If this occurs, the Start/Stop button goes
to the ACC position.
Press START button again
If you cannot start the vehicle after the
Vehicle is in N. Press START button,
Start/Stop button is pressed, attempt to
shift to P and turn vehicle Off
start the vehicle by pressing the
This message appears if you try to turn off
Start/Stop button again.
the vehicle with the gear in N (Neutral).
If the warning message appears each
To turn off the vehicle:
time you press the Start/Stop button,
1. Press the Start/Stop button. The
have your vehicle inspected by an
Start/Stop button moves to the ON
authorized HYUNDAI dealer.
position.
2. Shift the gear to P (Park).
Press START button with key
3. Press the Start/Stop button again, then
This message appears if the smart key is
the vehicle turns off.
not detected when you press the
Start/Stop button after accessing with
the smart key.
Low key battery
When the Start/Stop button is pressed to
the OFF position, a message may appear,
Check BRAKE SWITCH fuse
indicating the internal battery of the
This message appears if the brake switch
smart key is low.
fuse is disconnected. Replace the fuse
Replace the smart key battery.
before starting the vehicle.
If that is not possible, start the vehicle by
pressing the Start/Stop button for 10
Press brake pedal to start vehicle
seconds in the ACC position.
This message appears if the Start/Stop
button is pressed repeatedly without
depressing the brake pedal.
Shift to P to start vehicle
Start the vehicle by depressing the brake
This message appears if you try to start
pedal and then pressing the Start/Stop
the vehicle in any other position except P
button.
(Park).
Information
For your safety, start the vehicle with the
gear shifted to P (Park).
4-19
Instrument Cluster
Battery discharging due to external
Sunroof open indicator
electrical devices
if equipped
if equipped
This message appears if the vehicle 12 V
battery voltage is low or if a current draw
is detected that could drain the vehicle
battery.
Do not connect any external electronic
devices to the battery system or battery
discharge may occur.
If this message appears on the cluster and
there are no other external electronic
devices connected to the vehicle, have
2C_SunroofOpenWarning
your vehicle inspected by an authorized
This warning appears if you turn off the
HYUNDAI dealer.
vehicle when the sunroof is open.
Close the sunroof securely before leaving
your vehicle.
Door, Hood, Liftgate open indicator
Low tire pressure
2C_DoorOpenWarning
This warning appears if any door or hood
or liftgate is left open. The warning
2C_TireLowPressureWarning
indicates which door is open on the
This warning message appears if the tire
cluster display.
pressure is low. The corresponding tire on
the vehicle is illuminated.
CAUTION
For more information, refer to the "Tire
Before driving the vehicle, confirm the
Pressure Monitoring System (TPMS)"
door, hood, and liftgate are fully closed.
section in chapter 8.
4-20
4
Lights
Wiper
Front
2C_LightMode
This indicator displays which exterior light
Rear
is selected using the lighting control.
You can activate or deactivate
Wiper/Lights display function from the
infotainment system. Press theŲ
button, and then select Cluster > Content
Selection > Wiper/Lights Display.
This indicator displays which wiper speed
is selected using the wiper control.
You can activate or deactivate
Wiper/Lights display function in the
infotainment system. Press theŲ
button, and then select Cluster >
Wiper/Lights Display.
Information
The infotainment system may change
after software updates. For more
information, refer to the user's manual
provided in the infotainment system and
the quick reference guide.
4-21
Instrument Cluster
Low washer fluid
if equipped
This message appears if the washer fluid
level in the reservoir is nearly empty.
Have the washer fluid reservoir refilled.
Check turn signal
if equipped
This message appears if the turn signal
lights are not operating properly.
Replace the burned out bulb with a new
one with the same wattage rating.
Check headlight LED
This message appears if there is a
problem with the LED headlight. Have
your vehicle inspected by an authorized
HYUNDAI dealer.
Check Active Air Flap system
This warning message appears in the
following situations:
• There is a malfunction with the actuator
flap.
• There is a malfunction with the actuator
air flap controller.
• The air flap does not open.
When all of the above conditions are
fixed, the warning disappears.
4-22
4
Cluster Display
Cluster Display Control
2C_ClusterMenuSwitch
Switch
Function
ô
MODE button for changing View Modes
ñ, ò
MOVE switch for changing items
OK
SELECT/RESET button for setting or resetting the selected item
View Modes
View modes
Explanation
This mode displays Driver Assistance system such as Lane Keeping
Driving Assist
Assist, Smart Cruise Control, and Lane Following Assist etc.
Turn by Turn
This mode displays the navigation guidance.
This mode displays driving information such as the trip distance,
Utility
electric energy economy, etc.
The information provided may differ depending on which features are available to your
vehicle.
4-23
Instrument Cluster
Driving Assist view
Current Trip
2C_DrivingAssistMode
2C_DrivingInfo
Trip distance, total driving time, average
LKA/SCC/LFA/HDA
energy consumption, and instant energy
Displays the state of Lane Keeping Assist,
consumption are displayed.
Manual Speed Limit Assist, Smart Cruise
The information is combined for each
Control, Lane Following Assist, and
ignition cycle. However, when the vehicle
Highway Driving Assist. For more
has been OFF for 3 minutes or longer the
information, refer to each system
Current Trip screen is reset.
information in Chapter 7.
To reset manually, press the OK button on
the steering wheel for more than 1 second
Turn By Turn (TBT) view
when "Current Trip" appears.
After Recharging
2C_TurnByTurnMode
Turn-by-turn navigation, distance/time to
2C_InfoAfterCharging
destination information is displayed when
Trip distance, total driving time, average
Turn by Turn view is selected.
energy consumption, and instant energy
consumption after the vehicle has been
Utility view
recharged are displayed. To reset
In the Utility view, using the ñ, ò (UP,
manually, press the OK button on the
DOWN) switch, you may change through
steering wheel for more than 1 second
items in the following order.
when "After Recharging" appears.
4-24
4
Since Last Reset
Additional information display
Driver Assistance
2C_AccumulatedInfo
Accumulated trip distance, total driving
time, and average energy economy are
2C_ADASInfo
displayed.
The current operation condition of
Manual Speed Limit Assist, Smart Cruise
The information is accumulated starting
Control, Lane Following Assist, etc.
from the last reset.
appears.
To reset manually, press the OK button on
the steering wheel for more than 1 second
when "Since Last Reset" appears.
Tire pressure
The tire pressure of each tire is displayed.
For more information, refer to the "Tire
Pressure Monitoring System (TPMS)"
section in chapter 8.
4-25
Instrument Cluster
Vehicle Settings
Setting Your Vehicle
(Infotainment System)
Vehicle Settings in the infotainment
system provides user options for the
settings including door lock/unlock
features, convenience features, driver
assistance settings, etc.
Vehicle Setup menu
• Driver Assistance
• Drive Mode
• Climate
1. Press theŲ button on the main
• Seat
keyboard.
• Lights
2. Select Vehicle to change the settings
for features.
• Door
• Convenience
Information
The information provided may differ
The infotainment system may change
depending on which functions are
after software updates. For more
available to your vehicle.
information, refer to the user's manual
provided in the infotainment system and
WARNING
the quick reference guide.
Do not adjust the Vehicle Settings while
driving. You may be distracted from the
driving task and could crash.
4-26
5. Convenience Features
Accessing Your Vehicle
5-5
Smart Key
5-5
Immobilizer System
5-12
Hyundai Digital Key 2 Touch
5-13
Digital Key (Smartphone)
5-13
Digital key (card key)
5-18
Used Vehicle/Digital Key Maintenance
5-21
Limitations of the System
5-22
Door Locks
5-22
Operating Door Unlocks from Outside the Vehicle
5-22
Operating Door Lock/Unlock from Inside the Vehicle
5-23
Automatic Door Lock and Unlock Features
5-25
Child-Protector Rear Door Locks
5-26
Vehicle Auto-Shut Off Function
5-26
5
Theft-Alarm System
5-27
Rear Occupant Alert (ROA)
5-28
Steering Wheel
5-29
Motor Driven Power Steering (MDPS)
5-29
Tilt/Telescopic Steering
5-29
Steering Wheel Heater
5-30
Horn
5-31
Haptic Warning/Steering Wheel Vibration Warning
5-31
Mirrors
5-32
Inside Rearview Mirror
5-32
Side View Mirrors
5-42
Reverse Parking Aid
5-43
Windows
5-45
Power Windows
5-46
Wide Sunroof
5-49
Power Sunshade
5-49
Tilt Open/Close
5-50
Slide Open/Close
5-50
Automatic Reversal
5-51
Resetting the Sunroof
5-52
Sunroof Open Warning
5-52
Hood
5-53
Opening the Hood
5-53
Closing the Hood
5-53
Front Trunk
5-54
Opening the Front Trunk
5-54
Closing the Front Trunk
5-54
Liftgate
5-55
Opening the Liftgate
5-55
Closing the Liftgate
5-55
Emergency Liftgate Safety Release
5-56
Power Liftgate
5-56
Power Liftgate Operating Conditions
5-56
Operating the Power Liftgate
5-58
5
Setting the Power Liftage
5-59
Resetting the Power Liftgate
5-60
Emergency Liftgate Safety Release
5-61
Smart Liftgate
5-61
Using Smart Liftgate
5-61
Deactivating Smart Liftgate
5-62
Detecting Area
5-63
Electric Charging Door
5-63
Opening the Electric Charging Door
5-63
Closing the Electric Charging Door
5-64
Over-The-Air Software Update
5-64
Downloading Software
5-64
Approving Software Update
5-64
Preparing Software Update
5-65
Updating Software
5-65
Exterior Lights
5-67
Lighting Control
5-67
High Beam Operation
5-68
Turn Signals and Lane Change Signals
5-69
Headlight Delay Function
5-69
Interior Button Lights
5-70
Daytime Running Light (DRL)
5-70
Welcome System
5-70
5. Convenience Features
High Beam Assist (HBA)
5-72
High Beam Assist Settings
5-72
High Beam Assist Operation
5-73
High Beam Assist Malfunction and Limitations
5-73
Interior Lights
5-75
Interior Light AUTO cut
5-75
Front Lamps
5-75
Rear Lamps
5-76
Vanity Mirror Lamp
5-76
Glove Box Lamp
5-77
Ambient Light
5-77
Cargo Area Lamp
5-77
Front Trunk Lamp
5-77
Wipers and Washers
5-78
5
Front Windshield Wipers
5-78
Front Windshield Washers
5-79
Rear Windshield Wipers
5-80
Rear Windshield Washers
5-80
Automatic Climate Control System
5-81
Automatic Heating and Air Conditioning
5-82
Manual Heating and Air Conditioning
5-83
System Operation
5-88
System Maintenance
5-89
Windshield Defrosting and Defogging
5-91
Automatic Climate Control System
5-91
Defogging Logic
5-92
Windshield Defrosting (Heater)
5-92
Rear Window Defroster
5-92
Climate Control Additional Features
5-93
Air Conditioner Auto-Dry
5-93
Auto Defogging System
5-94
Auto Dehumidify
5-95
Recirculating Air When Washer Fluid is Used
5-95
Recirculating Air When Entering a Tunnel
5-96
Link to Climate Settings for Auto-Adjustment
5-96
Storage Compartment
5-97
Center Console Storage
5-97
Removable Partition
5-97
Glove Box
5-98
Passenger Seat Open Tray
5-98
Interior Features
5-98
Cup Holder
5-98
Sunvisor
5-99
Power Outlet
5-99
USB Charger
5-100
Wireless Smartphone Charging System
5-101
Clock
5-103
Coat Hook
5-103
Floor Mat Anchor(s)
5-104
Cargo Net Holder
5-104
5
Cargo Area Cover
5-105
Cargo Tray
5-106
Exterior Features
5-107
Roof Side Rails
5-107
Hitch Mounted Accessories
5-108
Infotainment System
5-108
USB Port
5-108
Antenna
5-109
Steering Wheel Remote Controls
5-109
Infotainment System
5-110
Voice Recognition
5-110
Bluetooth® Wireless Technology
5-111
5
(1) Door lock
Accessing Your Vehicle
(2) Door unlock
(3) Liftgate open/close
Smart Key
(4) Panic
Type A
(5) Remote start
(6) Remote Smart Parking Assist
(Forward/Backward)
Locking your vehicle (1)
Button type
Type B
2C_OutsideDoorHandleButton
To lock your vehicle using the door handle
button or the smart key:
1. Close all doors, hood, and liftgate.
2. Have the smart key with you.
2C_SmartKeyOverview
3. Press the door handle button or press
Type C
the Door Lock button (1) on the smart
key. The hazard warning lights blink.
4. Make sure the doors are locked by
pulling the outside door handle.
2C_SmartKeyOverview_2
Your electric vehicle uses a smart key that
can be used to lock or unlock the doors,
liftgate, and start the vehicle.
5-5
Convenience Features
Touch sensor type
Information
if equipped
Before you leave your vehicle with the
smart key, verify that your vehicle is
locked. When using the touch sensor on
the front door handle, listen to hear that
the lock has actuated, and then pull the
handle within 3 seconds to confirm the
doors are locked.
(If it has been longer than 3 seconds,
verify the doors are locked by pressing
the lock button on the smart key. You can
hear a single beep.)
2C_OutsideDoorHandleTouch_3
To lock your vehicle using the door handle
touch sensor or the smart key:
WARNING
1. Close all doors, hood, and liftgate.
Do not leave the smart key in your vehicle
2. Have the smart key with you.
with children that are unattended or
3. Touch the door handle touch sensor to
unsupervised.
activate the door lock or press the Door
Children could unintentionally press the
lock button (1) on the smart key.
Start/Stop button or could operate the
4. Make sure the doors are locked by
power windows or other vehicle controls
pulling the outside door handle.
or even cause the vehicle to move. This
may result in serious injury or death.
Information
• The door handle button only operates
when the smart key is within 40 in. (1 m)
from the outside door handle.
• If you lock the doors using the door
handle button, the doors are not locked
under the following circumstances:
- The smart key is in the vehicle.
- The Start/Stop button is in the ACC or
ON position.
- Any door is open.
If this occurs, a chime sounds for a few
seconds. Check the vehicle before
attempting to lock the vehicle again.
5-6
5
Unlocking your vehicle (2)
• If you unlock the doors using the
passenger side door handle, all the
Button type
doors are unlocked. If you unlock the
doors using the driver side door
handle, either the driver's side door is
unlocked or all the doors are
unlocked depending on the setting
for the Two Press Unlock feature.
Change the Driver Door unlock mode
by referring to "Setting the Two Press
Unlock feature". If you dip your hand
twice inside the door handle, all
doors will unlock.
2C_OutsideDoorHandleButton
Information
To unlock your vehicle using the door
handle button or the smart key:
The door handle button or touch sensor
only operates when the smart key is
1. Have the smart key with you.
within 40 in. (1 m) from the outside door
2. Press the door handle button or press
handle.
the Door unlock button (2) on the smart
After unlocking the doors, the doors are
key. The hazard warning lights blink.
locked automatically after 30 seconds
unless a door is opened.
Touch sensor type
The infotainment system may change
if equipped
after software updates. For more
information, refer to the manual
provided in the infotainment system
and the quick reference guide.
If the handle inner sensor is covered
and the outside handle is pressed at the
same time, the door may not lock or
unlock for about 2 seconds. Be sure to
only touch the inner sensor to unlock or
the outer sensor to lock, not both at
once unless intentionally setting the
2C_OutsideDoorHandleTouch_2
lock/unlock prevention feature.
1. Have the smart key with you.
2. Grab the door handle to activate the
door unlock touch sensor or press the
Door unlock button (2) on the smart
key. The hazard warning lights blink two
times.
5-7
Convenience Features
Setting the Two Press Unlock feature
Smart key reminder
You can activate or deactivate the Two
If the smart key is in the vehicle, and the
Press Unlock feature from the
door is locked with the central door
infotainment system. Press theŲ
lock/unlock button in the vehicle with a
button, and then select Vehicle > Door >
door open, the doors are not locked but
2 Press Unlock.
unlocked again.
Information
Unlocking/Opening the liftgate (3)
The infotainment system may change
if equipped
after software updates. For more
To open the liftgate:
information, refer to the user's manual
provided in the infotainment system and
1. Have the smart key with you.
the quick reference guide.
2. Press the liftgate open button on the
vehicle or press and hold the Liftgate
open/close button (3) on the smart key
Setting the door lock/unlock prevention
for more than 1 second. The hazard
feature
warning lights blinks 2 times and the
The doors may lock or unlock if the touch
liftgate unlocks or open.
sensor of the outer door handle is
To close the liftgate:
recognized while washing your car or due
Press and hold the Liftgate open/close
to heavy rain.
button (3) on the smart key to close the
To prevent unintentional door lock or
opened liftgate. If you release the button
unlock, press the lock button on the smart
while the liftgate is being closed, it stops
key and immediately press the unlock
working and the chime sounds for about 5
button along with the lock button for
seconds. (available with power liftgate)
more than 4 seconds. The hazard warning
lights blink four times.
Information
At this time, the doors are not lock or
The liftgate open/close button only
unlock even though the touch sensor is
operates when the smart key is within 40
touched on the outside door handle.
in. (1 m) from the liftgate.
To deactivate the function, press the door
lock or unlock button on the smart key.
Using panic alarm (4)
Information
The horn sounds and the hazard warning
• During a car wash or rain, in order to
lights blink for about 30 seconds if this
minimize unintentional operation of the
button (4) is pressed for more than 1
touch sensor, the touch sensor may
second. To stop the horn and lights, press
become insensitive. This is not a
any button on the smart key.
malfunction.
• The doors may not lock or unlock in the
following situations.
- If the touch sensor is touched with
gloves on
- If the door is suddenly approached
5-8
5
Remotely starting vehicle (5)
Forwarding and reversing (6)
1. Press the door lock button on the smart
if equipped
key within about 32 ft. (10 m) from the
Press the forward or reverse button on
vehicle.
the smart key to remotely move the
2. Press the Remote start button (5) on the
vehicle forward or backward. This feature
smart key within 2 seconds from when
is available only if the remote smart
you have pressed the door lock button.
parking assist system is equipped.
The vehicle starts.
For more information, refer to the
3. To turn off the vehicle, press the
"Remote Smart Parking Assist (RSPA)"
Remote Start button (5) once.
section in chapter 7.
Information
CAUTION
The vehicle must be in P (Park) for the
The smart key may not work in conditions
remote start function to start.
as follows.
The vehicle displays "Smart key must
• When out of the operating range
be present to keep the vehicle
(around 32 ft. (10 m))
running" if you get on the vehicle
• When the battery of the smart key is
without a registered smart key.
low
The vehicle turns off if you do not get in
• When radio waves are blocked by other
the vehicle within 10 minutes after
cars or objects
remotely starting the vehicle.
• When the weather is very cold
The Remote start button (5) may not
operate if the smart key is not within 32
ft. (10 m) from the vehicle.
Starting the vehicle
The vehicle does not remotely start if
Your vehicle is equipped with a Start/Stop
the hood or liftgate is open.
button instead of a key cylinder. You can
leave your smart key in your pocket or
purse when you start your vehicle.
For more information, refer to the
"Start/Stop Button" section in chapter 6.
Information
If the smart key is not moved for some
time, the detection function for smart key
operation will pause. Lift the smart key to
activate the detection again.
5-9
Convenience Features
Key cylinder (Driver door)
NOTICE
A key cylinder is located on the driver side
To prevent damaging the smart key:
door handle hidden behind a plastic
• Keep the smart key in a cool, dry place
cover.
to avoid damage or malfunction.
For more information, refer to the "Using
Exposure to moisture or high
the mechanical key" section in this
temperature may cause the internal
chapter on opening the door with the
circuit of the smart key to malfunction
mechanical key.
which may not be covered under
warranty.
Loss of a smart key
• Avoid dropping or throwing the smart
A maximum of two smart keys can be
key.
registered to a single vehicle. If you
• Protect the smart key from extreme
happen to lose your smart key, you should
temperatures.
immediately take the vehicle and
remaining key to your authorized
HYUNDAI dealer or tow the vehicle, if
Mechanical key
necessary.
If the smart key does not operate
normally, you can lock or unlock the
Smart key precautions
driver's door by using the mechanical key.
The smart key may not work if any of the
following occur:
• The smart key may not work if any of
the following occur:
- The smart key is close to a radio
transmitter such as radio station or
airport that may interfere with normal
operation of the transmitter.
- The smart key is near a mobile two
way radio system or a mobile phone.
2C_Mechanicalkey
- Another vehicle's smart key is being
Turn the knob (2) of the mechanical key
operated close to your vehicle.
after removing the key protector (1).
- The smart key is near any normal
After using the mechanical key, turn the
electronic devices or credit cards.
key knob (2) and insert the key protector
- The vehicle battery is discharged.
(1).
- Connecting an external device to the
power outlet and placing the smart
key near the external device.
If the smart key does not work
correctly, open and close the door with
the mechanical key. To start the
vehicle, press the Start/Stop button
directly with the smart key. If you have
5-10
5
a problem with the smart key, contact
NOTICE
an authorized HYUNDAI dealer.
If the smart key is in close proximity to
• Keep the smart key away from
your mobile phone, the signal could be
electromagnetic materials that blocks
blocked by your mobile phone's normal
electromagnetic waves to the key
operational signals. This is specifically
surface.
relevant when the phone is active such
• Always have the smart key with you
as making and receiving calls, text
when leaving the vehicle. If the smart
messaging, and/or sending/receiving
key is left near the vehicle, the vehicle
emails. When possible, avoid keeping
battery may be discharged.
the smart key and your smartphone in
the same location such as a pants or
jacket pocket to avoid interference
Battery replacement
between the two devices.
If the smart key is not working properly,
• If your windows are tinted, especially
try replacing the battery with a new one.
with metallic window tint, it may cause
Battery Type: CR2450
frequency interference, reducing the
To replace the battery:
smart key operating range.
1. Insert a slim tool into the slot (1) and
Information
gently open the rear cover.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment. If the
keyless entry system is inoperative due to
changes or modifications not expressly
approved by the party responsible for
compliance, it will not be covered by your
manufacturer's vehicle warranty.
2C_RemoveSmartKeyCover
Information
2. Remove the old battery and insert a
This device complies with Part 15 of the
new battery. Make sure the battery
FCC rules.
position is correct.
Operation is subject to the following three
conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause undesired
operation.
3. Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the device.
5-11
Convenience Features
3. Reinstall the rear cover of the smart
Immobilizer System
key.
The immobilizer system helps protect
your vehicle from theft. If an improperly
coded key (or other device) is used, the
vehicle is disabled.
When the Start/Stop button is in the ON
position, the immobilizer system
indicator should come on briefly, then go
off. If the indicator starts to blink, the
system does not recognize the coding of
the key.
Press the Start/Stop button to the OFF
2C_ReplaceSmartKeyBattery
position, then to the ON position again.
If you suspect your smart key might have
sustained some damage or you feel your
The system may not recognize your key's
smart key is not working correctly,
coding if another immobilizer key or other
contact an authorized HYUNDAI dealer.
metal object (e.g. key chain) is near the
key. The vehicle may not start because
the metal may interrupt the transponder
WARNING
signal from transmitting normally.
This product contains a button battery.
If the system repeatedly does not
If swallowed, a lithium button battery can
recognize the coding of the key, contact
cause severe or fatal injuries within 2
an authorized HYUNDAI dealer.
hours. Keep batteries out of reach of
Do not attempt to modify this system or
children.
add other devices to it. Electrical
If you think batteries may have been
problems may occur making your vehicle
swallowed or placed inside any part of the
inoperable.
body, seek immediate medical attention.
WARNING
To prevent theft of your vehicle, do not
Information
leave spare keys anywhere in your
vehicle. Your immobilizer password is a
customer unique password and should be
kept confidential.
Ġ
An inappropriately disposed battery can
be harmful to the environment and
human health. Dispose of the battery
according to your local law(s) or
regulations.
5-12
5
NOTICE
Hyundai Digital Key 2
Avoid exposing the key to moisture, static
Touch
electricity, and rough handling. The
if equipped
Immobilizer system may malfunction.
Hyundai digital key provides convenience
to the driver, which the driver can use to
lock or unlock the driver and passenger
Information
doors and turn on the vehicle.
This device complies with Part 15 of the
FCC rules.
Digital Key (Smartphone)
Operation is subject to the following three
conditions:
Information
1. This device may not cause harmful
• Hyundai Digital Key 2 Touch is only
interference.
available on smartphone that support
2. This device must accept any
digital key functions, and digital key
interference received, including
functions of smartphones are provide
interference that may cause undesired
by smartphone manufacturers.
operation.
• Available smartphone brands and
3. Changes or modifications not expressly
models can be found on smartphone
approved by the party responsible for
manufactures' website or HYUNDAI
compliance could void the user's
website.
authority to operate the device
• Depending on the availability of service
on the vehicle, some functions may not
operated.
Setting your smartphone
To use the digital key (smartphone),
download the Bluelink App and sign up
Hyundai account and service.
For more information about Bluelink,
refer to the infotainment system guide.
5-13
Convenience Features
Registering your digital key
• The NFC Antenna position on Apple
(smartphone)
iPhone is located at the top of the
rear [A] and Apple WATCH is located
1. Turn on the vehicle with a smart key
at the center of the screen [B].
and have your smart key with you in the
vehicle.
2. After selecting Digital Key > Set Up
Digital Key from the Bluelink App in the
smartphone, register the digital key
according to the guidance in the
smartphone screen.
• Place your smartphone on the vehicle
authentication pad (wireless
charging pad) with the screen facing
up.
2C_SmartPhoneSample
• Ensure that the NFC Antenna position
on the smartphone is in contact with
the vehicle authentication pad
(wireless charging pad).
• The location of the NFC Antenna on
the smartphone may vary by phone
model, so please contact the
smartphone manufacturer for
details.
2C_WirelessChargingPad
• NFC communication may not work
[A] Vehicle authentication pad (Wireless charging
for some smartphones depending on
pad)
the internal structure of the
• When the digital key (smartphone) is
smartphone. Move the smartphone
saved, a message appears on the
to the left or right of the indoor
infotainment system.
authentication pad (wireless
charging pad) to operate.
Information
• The NFC Antenna position on
Samsung device can be found in the
following path: Settings >
Connections > NFC and contactless
payments.
• The NFC Antenna position on Google
Pixel phone can be found in the
following path: Settings >
Connected devices > Connection
preference > NFC.
5-14
5
To register the digiatal key (smartphone)
• The registering process does not start if
from the infotainment system
a smart key is not in the vehicle.
• Some smartphones may not start the
registering process depending on the
internal structure. Move the
smartphone to the left or right on the
vehicle authentication pad (wireless
charger pad) and try registering the
smartphone.
Using the digital key (smartphone)
2C_AVNRegisterSmartPhone
The driver can lock or unlock the door by
If you cannot register the digital key
placing the smartphone on the outside
(smartphone) with the Bluelink App, try
door handle, and the vehicle can be
registering from the infotainment system.
started by placing the smartphone on the
vehicle authentication pad (wireless
1. Turn off the vehicle, and then turn on
charging pad).
the vehicle with a smart key and have
your smart key with you in the vehicle.
Samsung & Google Pixel smartphone
2. Put the gear in P (Park), press theŲ
button, and then select Vehicle >
Digital key > Smartphone key > Save.
3. Place your smartphone on the vehicle
authentication pad (wireless charging
pad) with the screen facing up.
• When the digital key (smartphone) is
saved, a message appears on the
infotainment system.
2C_OutsideDoorHandleTouchBySmartPhone
Information
[A] Door handle authentication pad
[B] NFC Antenna
• If you want to register a different digital
Apple iPhone
key (smartphone), refer to "Deleting
your digital key (smartphone)" and
delete the digital key (smartphone)
before re-registering. An active Digital
Key can be shared through the Bluelink
App with a different smartphone.
• During the digital key saving process,
the process may cancel when:
- The smartphone is removed from the
vehicle authentication pad (wireless
2C_OutsideDoorHandleTouchBySmartPhone_2
charging pad)
[A] Door handle authentication pad
- The infotainment system is changed
[B] NFC Antenna
- The vehicle is turned off
- The gear is shifted
5-15
Convenience Features
• If the smartphone digital key does not
Information
operate, try again after moving the
• The location of the NFC Antenna on the
smartphone away from the door handle
smartphone may vary by phone model,
authentication pad (more than 4 in. (0.1
so please contact the smartphone
m)).
manufacturer for details.
Information
• The NFC Antenna position on Samsung
device can be found in the following
You cannot lock your vehicle using the
path: Settings > Connections > NFC
digital key (smartphone) if any of the
and contactless payments.
following occurs:
• The NFC Antenna position on Google
• The smart key is in the vehicle.
Pixel phone can be found in the
• The Start/Stop button is in the ACC or
following path: Settings > Connected
ON position.
devices > Connection preference >
• Any of the doors, hood, or liftgate are
NFC.
open.
• The NFC Antenna position on Apple
iPhone is located at the top of the rear
[A] and Apple WATCH is located at the
Starting the vehicle
center of the screen [B].
After placing your registered digital key
(smartphone) on the vehicle
authentication pad (wireless charging
pad), depress the brake pedal and press
the Start/Stop button.
After starting the vehicle, the digital key
(smartphone) may be removed from the
vehicle authentication pad (wireless
charging pad).
For more details on the basic way to start
the vehicle, refer to the "Start/Stop
2C_SmartPhoneSample
Button" section in chapter 6.
• Touch the Door handle NFC Antenna
position with the back of your
Information
smartphone.
If a shared digital key (smartphone) is
used for the first time, the activating time
Locking/Unlocking the doors
may take longer.
• If the driver places the digital key
• Place the shared digital key
(smartphone) NFC antenna to the
(smartphone) on the door handle
driver's or passenger's door handle
authentication pad until the vehicle
authentication pad for more than 2
door lock/unlock activates.
seconds, the door locks or unlocks.
• If a shared digital key (smartphone) is
• After unlocking the doors, the doors are
first used on the vehicle authentication
automatically re-lock after 30 seconds
pad (wireless charger pad), the initial
unless a door is opened.
start of the vehicle may fail.
5-16
5
• If the door lock/unlock is activated
Deleting my registered digital key
once with the shared digital key
(smartphone)
(smartphone) or the vehicle is started
with the digital key (smartphone) on the
vehicle authentication pad, the digital
key (smartphone) is registered in the
vehicle.
WARNING
The vehicle can be started when the
registered smartphone is placed on the
2C_AVNDeleteMySmartPhone
vehicle authentication pad (wireless
To delete only my registered digital key
charging pad). Therefore, do not leave
(smartphone), press theŲ button,
unsupervised children or people who are
and then select Vehicle > Digital Keys >
not aware of the system since it can result
Smartphone key > My Smartphone Key >
in serious injury or death. In addition,
Delete in the infotainment system.
always have the registered smartphone
with you to prevent vehicle theft when
If a shared digital key (smartphone) is
leaving the vehicle.
registered, it cannot be deleted.
A new smartphone can be registered
after deleting the existing digital key
Deleting your digital key
(smartphone) from "My Smartphone
(smartphone)
Key" menu.
Turn on the vehicle with a smart key. Have
your smart key with you in the vehicle.
Information
If the registered digital key
Deleting all registered digital key
(smartphone) is deleted, the digital key
(smartphone)
saved in the smartphone is also
deleted.
If the digital key is deleted from the
smartphone, the digital key
(smartphone) registered in the vehicle
is also deleted.
The shared digital key registered in the
vehicle cannot be deleted individually.
Even though the Bluelink App is deleted
from the smartphone, the digital key
saved in the smartphone is not deleted.
2C_AVNDeleteDegitalKey
To delete all the registered digital key
Management of the digital key saved in
(smartphone), press theŲ button,
the smartphone is available from the
and then select Vehicle > Digital Keys >
Digital Key App provided by the
Smartphone key > Delete All in the
smartphone manufacturer.
infotainment system.
• The "Delete All" button is disabled if
there is no registered digital key
(smartphone).
5-17
Convenience Features
Digital key (card key)
Information
• When there is a digital key (card key)
How to register Digital key (Card
already registered in the vehicle, a new
Key)
digital key (card key) cannot be
To use the card key as a digital key, follow
registered. Re-register a new digital key
the following procedure.
(card key) after deleting the exiting
digital key (card key).
• To register a digital key (card key), both
of your smart keys must be in the
vehicle.
• A registered digital key (card key)
cannot be registered in other vehicles.
Using the digital key (card key)
The driver can lock or unlock the door by
2C_AVNRegisterCardKey
placing the card key on the outside door
handle, and the vehicle can be started by
placing the card key on the vehicle
authentication pad (wireless charging
pad).
2C_WirelessChargingPad
[A] Vehicle authentication pad (Wireless charging
pad)
1. Have both of your smart keys with you
in the vehicle.
2C_CardKey
2. Press theŲ button, and then select
[A] Door handle authentication pad
Vehicle > Digital Keys > NFC Card Key,
[B] Card key NFC Antenna
and check whether "Use" is selected in
Locking/Unlocking the doors
the infotainment system.
- If the driver places the digital key
3. Place your card key on the vehicle
(card key) to the driver's or
authentication pad (wireless charging
passenger's door handle
pad) while the vehicle is on.
authentication pad for more than 2
4. Register your card key by pressing the
seconds, the door locks or unlocks.
Ų button, and then selecting
- After unlocking the doors, the doors
Vehicle > Digital Keys > NFC Card Key
are automatically re-lock after 30
> Save in the infotainment system.
seconds unless a door is opened.
5-18
5
Information
NOTICE
You cannot lock your vehicle using the
The digital key (card key) may not work
digital key (card key) if any of the
under the following conditions:
following occurs:
- The digital key (card key) is not
• The smart key is in the vehicle.
placed on the door handle
authentication pad or vehicle
• The Start/Stop button is in the ACC or
authentication pad (wireless
ON position.
charging pad) correctly.
• Any of the doors, hood, or liftgate are
- The digital key (card key) is near
open.
NFC-enabled cards such as credit
cards or smartphones.
Starting the vehicle
If the digital key (card key) does not
work, try again after moving the
After placing your registered digital key
digital key (card key) away from the
(card key) on the vehicle authentication
door handle authentication pad
pad (wireless charging pad), depress
(more than (4 in. (0.1 m)).
the brake pedal and press the
Start/Stop button.
The digital key (card key) can be
damaged by impacts. If the digital key
For more details on the basic way to
(card key) is damaged, replace the
start the vehicle, refer to the
digital key (card key) with a new one
"Start/Stop Button" section in chapter
and register it again.
6.
Long-time exposure to high
WARNING
temperature may cause the digital key
(card key) to malfunction. Be careful
The vehicle can be started when the
not to expose the digital key (card key)
registered card key is placed on the
to direct sunlight or high temperature.
vehicle authentication pad (wireless
charging pad). Therefore, do not leave
Leaving the digital key (card key) on the
unsupervised children or people who are
in-vehicle authentication pad (wireless
not aware of the system since it can result
charging pad) while driving may cause
in serious injury or death. In addition,
the digital key (card key) to
always have the registered card key with
malfunction. Remove the digital key
you to prevent vehicle theft when leaving
(card key) from the in-vehicle
the vehicle.
authentication pad (wireless charging
pad) after starting the vehicle.
Remove the digital key (card key) from
the smartphone before charging the
smartphone. If the digital key (card key)
is placed between the smartphone and
the in-vehicle authentication pad
(wireless charging pad) while the
smartphone is being charged, the
digital key (card key) may malfunction.
For example, when charging
smartphone while the digital key (card
key) is attached to the back of the
smartphone case.
5-19















Content      ..      1      2      3      ..
