Hyundai Elantra N (2022 year). Manual in english - page 16





-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Check Tire Inflation Pressure
Tire Rotation
Check your tires, including the spare
To equalize tread wear, HYUNDAI
tire, once a month or more.
recommends that the tires
be rotated according to the
How to check
maintenance schedule or sooner if
irregular wear develops.
Use a good quality tire pressure
gauge to check tire pressure. You
During rotation, check the tires for
can not tell if your tires are properly
correct balance.
inflated simply by looking at them.
When rotating tires, check for
Radial tires may look properly
uneven wear and damage. Abnormal
inflated when they are under-
wear is usually caused by incorrect
inflated.
tire pressure, improper wheel
Remove the valve cap from the tire
alignment, out-of-balance wheels,
valve stem. Press the tire gauge
severe braking or severe cornering.
firmly onto the valve to get a
Look for bumps or bulges in the
pressure measurement. If the cold
tread or side of the tire. Replace
tire inflation pressure matches the
the tire if you find any of these
recommended pressure on the tire
conditions. Replace the tire if fabric
label located on the driver’s side
or cord is visible. After rotation, be
center pillar or in this manual. No
sure to bring the front and rear tire
further adjustment is necessary. If
pressures to specification and check
the pressure is low, add air until you
lug nut tightness (proper torque is
reach the recommended pressure.
79~94 lbf·ft [11~13 kgf·m]).
Make sure to put the valve caps
back on the valve stems. Without
the valve cap, dirt or moisture could
get into the valve core and cause
air leakage. If a valve cap is missing,
install a new one as soon as possible.
If you overfill the tire, release air by
pushing on the metal stem in the
center of the tire valve. Recheck the
tire pressure with the tire gauge. Be
sure to put the valve caps back on
the valve stems. Without the valve
cap, dirt or moisture could get into
the valve core and cause air leakage.
If a valve cap is missing, install a new
one as soon as possible.
A cold tire means the vehicle has
been sitting for 3 hours and driven
for less than 1 mile (1.6 km) in that 3
hour period.
Allow the tire to cool before
measuring the inflation pressure.
Always be sure the tire is cold before
inflating to the recommended
pressure.
9-35

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Without a spare tire
Wheel Alignment and Tire
Balance
The wheels on your vehicle were
aligned and balanced carefully at the
factory to give you the longest tire
life and best overall performance.
In most cases, you will not need to
have your wheels aligned again.
However, if you notice unusual tire
wear or your vehicle pulling one way
OHI078078
or the other, the alignment may need
to be reset.
Disc brake pads should be inspected for
If you notice your vehicle vibrating
wear whenever tires are rotated.
when driving on a smooth road, your
wheels may need to be rebalanced.
Information
The outside and inside of the
NOTICE
unsymmetrical tire is distinguishable.
Improper wheel weights can
When installing an unsymmetrical
damage your vehicle’s aluminum
tire, be sure to install the side marked
wheels. Use only approved wheel
“outside” face the outside. If the side
weights.
marked “inside” is installed on the
outside, it will have a negative effect
on vehicle performance.
WARNING
Do not mix bias ply and radial ply tires
under any circumstances. This may
cause unusual handling characteristics
that may cause loss of vehicle control
resulting in an accident.
9-36

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Tire Replacement
WARNING
To reduce the risk of DEATH or
Tread wear indicator
SERIOUS INJURY:
Replace tires that are worn, show
uneven wear, or are damaged.
Worn tires can cause loss of
braking effectiveness, steering
control, and traction.
Always replace tires with the
same size as each tire that was
originally supplied with this
OLMB073027
vehicle. Using tires and wheels
other than the recommended
If the tire is worn evenly, a tread wear
sizes could cause unusual
indicator will appear as a solid band
handling characteristics, poor
across the tread. This shows there is
vehicle control, or negatively
less than 1/16 inch (1.6 mm) of tread
affect your vehicle’s Anti-Lock
left on the tire. Replace the tire when
Brake System (ABS) resulting in a
this happens.
serious accident.
Do not wait for the tread surface to
Tires degrade over time, even
become level with the tread wear
when they are not being used.
indicators before replacing the tire.
Regardless of the remaining
tread, HYUNDAI recommends
that tires be replaced after six (6)
years of normal service.
When replacing tires, it is
recommended to replace the
two front or two rear tires as a
pair. Replacing just one tire can
seriously affect your vehicle’s
handling. If only replacing one
pair of tires, it is recommended
to install the pair of new tires on
the rear axle.
Heat caused by hot climates or
frequent high loading conditions
can accelerate the aging process.
Failure to follow this warning
may cause sudden tire failure,
which could lead to a loss of
vehicle control resulting in an
accident.
9-37

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Wheel Replacement
When replacing the metal wheels
for any reason, make sure the new
wheels are equivalent to the original
factory units in diameter, rim width
and offset.
Tire Traction
Tire traction can be reduced if you
drive on worn tires, tires that are
improperly inflated or on slippery
OLMB073028
road surfaces. Tires should be
replaced when the tread depth is at
1. Manufacturer or brand name
least 2/32 inch (1.6 mm). To reduce
Manufacturer or brand name is
the possibility of losing control, slow
shown.
down whenever there is rain, snow
or ice on the road.
2. Tire size designation
A tire’s sidewall is marked with a
Tire Maintenance
tire size designation. You will need
In addition to proper inflation,
this information when selecting
correct wheel alignment helps to
replacement tires for your car.
decrease tire wear. If you find a tire
The following explains what the
is worn unevenly, have your dealer
letters and numbers in the tire size
check the wheel alignment.
designation mean.
When you have new tires installed,
Example tire size designation:
make sure they are balanced. This
(These numbers are provided as
will increase vehicle ride comfort
an example only; your tire size
and tire life. Additionally, a tire
designator could vary depending on
should always be rebalanced if it is
your vehicle.)
removed from the wheel.
245/35 ZR19 93Y
Tire Sidewall Labeling
245 -Tire width in millimeters.
This information identifies and
describes the fundamental
35 - Aspect ratio. The tire’s section
characteristics of the tire and also
height as a percentage of its
provides the tire identification
width.
number (TIN) for safety standard
ZR - Tire construction code (Radial).
certification. The TIN can be used to
19 - Rim diameter in inches.
identify the tire in case of a recall.
93 - Load Index, a numerical code
associated with the maximum
load the tire can carry.
Y - Speed Rating Symbol. See the
speed rating chart in this section
for additional information.
9-38

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Wheel size designation
3. Checking tire life (TIN : Tire
Identification Number)
Wheels are also marked with
important information that you need
Any tires that are over six years old,
if you ever have to replace one. The
based on the manufacturing date,
following explains what the letters
(including the spare tire) should be
and numbers in the wheel size
replaced by new tires. You can find
designation mean.
the manufacturing date on the tire
Example wheel size designation:
sidewall (possibly on the inside of
the wheel), displaying the DOT Code.
8.0J X 19
The DOT Code is a series of numbers
on a tire consisting of numbers and
8.0 - Rim width in inches.
English letters. The manufacturing
J - Rim contour designation.
date is designated by the last four
digits (characters) of the DOT code.
19 - Rim diameter in inches.
DOT : XXXX XXXX OOOO
Tire speed ratings
The chart below lists many of the
The front part of the DOT shows a
plant code number, tire size and
different speed ratings currently
being used for passenger vehicle
tread pattern and the last four
numbers indicate week and year
tires. The speed rating is part of the
tire size designation on the sidewall
manufactured.
of the tire. This symbol corresponds
For example:
to that tire’s designed maximum safe
DOT XXXX XXXX 1421 represents that
operating speed.
the tire was produced in the 14th
week of 2021.
Speed Rating
Maximum Speed
Symbol
4. Tire ply composition and material
S
112 mph (180 km/h)
The number of layers or plies of
T
118 mph (190 km/h)
rubber-coated fabric in the tire. Tire
H
130 mph (210 km/h)
manufacturers also must indicate the
materials in the tire, which include
V
149 mph (240 km/h)
steel, nylon, polyester, and others.
W
168 mph (270 km/h)
The letter “R” means radial ply
Y
186 mph (300 km/h)
construction; the letter “D” means
diagonal or bias ply construction;
and the letter “B” means belted-bias
ply construction.
9-39

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
5. Maximum permissible inflation
Tread wear
pressure
The tread wear grade is a
This number is the greatest amount
comparative rating based on the
of air pressure that should be put in
wear rate of the tire when tested
the tire. Do not exceed the maximum
under controlled conditions on a
permissible inflation pressure. Refer
specified government test course.
to the Tire and Loading Information
For example, a tire graded 150 would
label for recommended inflation
wear one-and-a-half times (1½) as
pressure.
well on the government course as a
tire graded 100.
6. Maximum load rating
The relative performance of tires
This number indicates the maximum
depends upon the actual conditions
load in kilograms and pounds that
of their use, however, and may
can be carried by the tire. When
depart significantly from the norm
replacing the tires on the vehicle,
due to variations in driving habits,
always use a tire that has the same
service practices and differences in
load rating as the factory installed
road characteristics and climate.
tire.
These grades are molded on the
sidewalls of passenger vehicle tires.
7. Uniform tire quality grading
The tires available as standard or
Quality grades can be found where
optional equipment on your vehicle
may vary with respect to grade.
applicable on the tire sidewall
between tread shoulder and
maximum section width.
Traction AA, A, B & C
For example:
The traction grades, from highest
to lowest, are AA, A, B and C. Those
TREAD WEAR 200
grades represent the tire’s ability to
TRACTION AA
stop on wet pavement as measured
TEMPERATURE A
under controlled conditions on
specified government test surfaces
of asphalt and concrete. A tire
marked C may have poor traction
performance.
WARNING
The traction grade assigned to this
tire is based on straight-ahead
braking traction tests, and does not
include acceleration, cornering,
hydroplaning, or peak traction
characteristics.
9-40

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Temperature A, B & C
Tire Terminology and Definitions
The temperature grades are A (the
highest), B and C representing the
Air Pressure
tire’s resistance to the generation
The amount of air inside the tire
of heat and its ability to dissipate
pressing outward on the tire. Air
heat when tested under controlled
pressure is expressed in pounds per
conditions on a specified indoor
square inch (psi) or kilopascal (kPa).
laboratory test wheel.
Sustained high temperature can
Accessory Weight
cause the material of the tire to
This means the combined weight
degenerate and reduce tire life, and
of optional accessories. Some
excessive temperature can lead to
examples of optional accessories
sudden tire failure. Grade C responds
are automatic transmission, power
to a level of performance which
seats, and air conditioning.
all passenger car tires must meet
under the Federal Motor Vehicle
Aspect Ratio
Safety Standard No. 109. Grades
B and A represent higher levels of
The relationship of a tire’s height to
its width.
performance on the laboratory test
wheel than the minimum required
by law.
Belt
A rubber coated layer of cords that
is located between the plies and the
WARNING
tread. Cords may be made from steel
The temperature grade for this
or other reinforcing materials.
tire is established for a tire that
is properly inflated and not
Bead
overloaded. Excessive speed,
The tire bead contains steel wires
under-inflation, over-inflation, or
wrapped by steel cords that hold the
excessive loading, either separately
tire onto the rim.
or in combination, can cause heat
build-up and possible sudden
Bias Ply Tire
tire failure. This may cause loss
of vehicle control resulting in an
A pneumatic tire in which the plies
accident.
are laid at alternate angles less than
90 degrees to the centerline of the
tread.
Cold Tire Pressure
The amount of air pressure in a tire,
measured in pounds per square inch
(psi) or kilopascals (kPa) before a tire
has built up heat from driving.
9-41

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Curb Weight
Kilopascal (kPa)
This means the weight of a motor
The metric unit for air pressure.
vehicle with standard and optional
equipment including the maximum
Light truck (LT) tire
capacity of fuel, oil and coolant, but
A tire designated by its manufacturer
without passengers and cargo.
as primarily intended for use on
lightweight trucks or multipurpose
DOT Markings
passenger vehicles.
A code molded into the sidewall
of a tire signifying that the tire
Load ratings
is in compliance with the U.S.
The maximum load that a tire is rated
Department of Transportation motor
to carry for a given inflation pressure.
vehicle safety standards. The DOT
code includes the Tire Identification
Load Index
Number (TIN), an alphanumeric
designator which can also identify
An assigned number ranging from 1
the tire manufacturer, production
to 279 that corresponds to the load
plant, brand and date of production.
carrying capacity of a tire.
GVWR
Maximum Inflation Pressure
Gross Vehicle Weight Rating
The maximum air pressure to which
a cold tire may be inflated. The
GAWR FRT
maximum air pressure is molded
onto the sidewall.
Gross Axle Weight Rating for the
Front Axle.
Maximum Load Rating
GAWR RR
The load rating for a tire at the
maximum permissible inflation
Gross Axle Weight Rating for the
pressure for that tire.
Rear axle.
Maximum Loaded Vehicle Weight
Intended Outboard Sidewall
The sum of curb weight; accessory
The side of an asymmetrical tire,
weight; vehicle capacity weight; and
that must always face outward when
production options weight.
mounted on a vehicle.
Normal Occupant Weight
The number of occupants a vehicle
is designed to seat multiplied by 150
pounds (68 kg).
9-42

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Occupant Distribution
Pneumatic options weight
Designated seating positions.
The combined weight of installed
regular production options weighing
Outward Facing Sidewall
over 5 lb. (2.3 kg) in excess of the
standard items which they replace,
An asymmetrical tire has a particular
not previously considered in
side that faces outward when
curb weight or accessory weight,
mounted on a vehicle. The outward
including heavy duty breaks, ride
facing sidewall bears white lettering
levelers, roof rack, heavy duty
or bears manufacturer, brand, and/or
battery, and special trim.
model name molding that is higher
or deeper than the same moldings
Recommended Inflation Pressure
on the inner facing sidewall.
Vehicle manufacturer’s
Passenger (P-Metric) tire
recommended tire inflation pressure
as shown on the tire placard.
A tire used on passenger cars
and some light duty trucks and
multipurpose vehicles.
Radial Ply Tire
A pneumatic tire in which the ply
Ply
cords that extend to the beads are
laid at 90 degrees to the centerline
A layer of rubber-coated parallel
cords.
of the tread.
Pneumatic tire
Rim
A mechanical device made of rubber,
A metal support for a tire and upon
chemicals, fabric and steel or other
which the tire beads are seated.
materials, that, when mounted on
an automotive wheel provides the
Sidewall
traction and contains the gas or fluid
The portion of a tire between the
that sustains the load.
tread and the bead.
Speed Rating
An alphanumeric code assigned to a
tire indicating the maximum speed
at which a tire can operate.
Traction
The friction between the tire and
the road surface. The amount of grip
provided.
9-43

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Tread
All Season Tires
The portion of a tire that comes into
HYUNDAI specifies all season
contact with the road.
tires on some models to provide
good performance for use all year
Treadwear Indicators
round, including snowy and icy
road conditions. All season tires
Narrow bands, sometimes called
are identified by ALL SEASON and/
“wear bars”, that show across the
or M+S (Mud and Snow) on the tire
tread of a tire when only 1/16 inch of
sidewall. Snow tires have better
tread remains.
snow traction than all season tires
and may be more appropriate in
UTQGS
some areas.
Uniform Tire Quality Grading
Standards is a tire information
Summer Tires
system that provides consumers
with ratings for a tire’s traction,
HYUNDAI specifies summer tires on
temperature and treadwear.
some models to provide superior
Ratings are determined by tire
performance on dry roads. Summer
manufacturers using government
tire performance is substantially
testing procedures. The ratings are
reduced in snow and ice. Summer
molded into the sidewall of the tire.
tires do not have the tire traction
rating M+S (Mud and Snow) on
the tire side wall. If you plan to
Vehicle Capacity Weight
operate your vehicle in snowy or icy
The number of designated seating
conditions, HYUNDAI recommends
positions multiplied by 150 lbs. (68
the use of snow tires or all season
kg) plus the rated cargo and luggage
tires on all four wheels.
load.
Snow Tires
Vehicle Maximum Load on the Tire
If you equip your car with snow
Load on an individual tire due to curb
tires, they should be the same size
and accessory weight plus maximum
and have the same load capacity as
occupant and cargo weight.
the original tires. Snow tires should
be installed on all four wheels;
Vehicle Normal Load on the Tire
otherwise, poor handling may result.
Load on an individual tire that is
Snow tires should carry 4 psi (28 kPa)
determined by distributing to each
more air pressure than the pressure
axle its share of the curb weight,
recommended for the standard
accessory weight, and normal
tires on the tire label on the driver’s
occupant weight and dividing by 2.
side of the center pillar, or up to the
maximum pressure shown on the tire
Vehicle Placard
sidewall, whichever is less. Do not
drive faster than 75 mph (120 km/h)
A label permanently attached
when your vehicle is equipped with
to a vehicle showing the
snow tires.
original equipment tire size and
recommended inflation pressure.
9-44

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Radial-Ply Tires
Low Aspect Ratio Tires
Radial-ply tires provide improved
The aspect ratio is lower than 50 on
tread life, road hazard resistance
low aspect ratio tires.
and smoother high speed ride. The
Because low aspect ratio tires are
radial-ply tires used on this vehicle
optimized for handling and braking,
are of belted construction, and are
their sidewall is a little stiffer than
selected to complement the ride
a standard tire. Also low aspect
and handling characteristics of your
ratio tires tend to be wider and
vehicle.
consequently have a greater contact
Radial-ply tires have the same load
patch with the road surface. In some
carrying capacity, as bias-ply or
instances they may generate more
bias belted tires of the same size,
road noise compared with standard
and use the same recommended
tires.
inflation pressure. Mixing of radial-
ply tires with bias-ply or bias belted
tires is not recommended. Any
combinations of radial-ply and bias-
ply or bias belted tires when used
on the same vehicle will seriously
deteriorate vehicle handling. The
best rule to follow is: Identical pairs
of radial-ply tires should always be
used as a set for the front tires and a
set for the rear tires.
Longer wearing tires can be more
susceptible to irregular tread wear.
It is very important to follow the tire
rotation interval in this chapter to
achieve the tread life potential of
these tires. Cuts and punctures in
radial-ply tires are repairable only in
the tread area, because of sidewall
flexing. Consult your tire dealer for
radial-ply tire repairs.
WARNING
Do not mix bias ply and radial ply
tires under any circumstances.
This may cause unusual handling
characteristics that may cause loss
of vehicle control resulting in an
accident.
9-45

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
CAUTION
The side wall of a low aspect ratio
tire is shorter than the normal one.
Thus, the low-aspect wheel and
tire are easily damaged. Follow the
below instructions.
When driving on a rough road or
driving off a road, be careful not
to damage the tires and wheels.
After driving, inspect the tires
and wheels.
When passing over a pothole,
speed bump, manhole, or curb
stone, drive the vehicle slowly so
as not to damage the tires and
wheels.
When there is an impact on a tire,
inspect the tire condition. Or,
you can contact an authorized
HYUNDAI dealer.
Inspect the tire condition and
pressure every 8,000 miles
(13,000 km) to prevent tire
damage.
It is difficult to recognize a tire
damage only with your eyes.
When there is a slight hint of a
tire damage, check and replace
the tire to prevent the damage
caused by air leakage.
When a tire is damaged while
driving on a rough road, off a
road, or over obstacles, such as a
pothole, manhole, or curb stone,
your warranty does not cover the
damage.
The tire information is specified
on the tire side wall.
9-46

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
FUSES
Ŷ Blade type
If the electrical system does not work,
first check the driver’s side fuse panel.
Before replacing a blown fuse, turn the
engine and all switches off, and then
disconnect the negative battery cable.
Always replace a blown fuse with one of
the same rating.
If the replacement fuse blows, this
indicates an electrical problem.
Normal
Blown
Avoid using the system involved and
immediately consult an authorized
Ŷ Cartridge type
HYUNDAI dealer.
WARNING
NEVER replace a fuse with anything but
another fuse of the same rating.
A higher capacity fuse could cause
damage and possibly cause a fire.
Normal
Blown
Do not install a wire or aluminum
foil instead of the proper fuse -
Ŷ Multi fuse
even as a temporary repair. It may
cause extensive wiring damage and
possibly a fire.
NOTICE
Do not use a screwdriver or any other
metal object to remove fuses because
it may cause a short circuit and damage
the system.
Normal
Blown
OTM078035
A vehicle’s electrical system is protected
from electrical overload damage by
fuses.
This vehicle has 2 (or 3) fuse panels, one
located in the driver’s side panel bolster,
the other in the engine compartment
near the battery.
If any of your vehicle’s lights,
accessories, or controls do not work,
check the appropriate circuit fuse. If a
fuse has blown, the element inside the
fuse will be melted or broken.
9-47

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Instrument Panel Fuse
Replacement
OCN7080018
5. Pull the suspected fuse straight out.
Use the removal tool provided in the
OCN7N091011N
engine compartment fuse panel.
1. Turn the vehicle off.
6. Check the removed fuse; replace it if
2. Turn all other switches OFF.
it is blown. Spare fuses are provided in
3. Open the fuse panel cover.
the engine compartment fuse panel.
4. Refer to the label on the inside of
7. Push in a new fuse of the same
the fuse panel cover to locate the
rating, and make sure it fits tightly in
suspected fuse location.
the clips. If it fits loosely, consult an
authorized HYUNDAI dealer.
In an emergency, if you do not have a
spare fuse, use a fuse of the same rating
from a circuit you may not need for
operating the vehicle.
If the head lamp, turn signal lamp, tail
lamp, interior lamp doesn’t work and
the bulbs are undamaged, consult an
authorized HYUNDAI dealer.
9-48

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Engine Compartment Panel Fuse
Multi fuse (Main fuse)
Replacement
Blade type fuse
OCN7080020
OCN7080021
If the multi fuse is blown, it must be
Cartridge type fuse
removed as follows:
1. Turn off the engine.
2. Disconnect the negative battery
cable.
3. Remove the fuse panel cover by
pressing the tab and pulling it up.
4. Remove the nuts shown in the picture
above.
5. Replace the fuse with a new one of
the same rating.
OCN7080022
6. Reinstall in the reverse order of
1. Turn the engine off.
removal.
2. Turn all other switches OFF.
3. Remove the fuse panel cover by
Information
pressing the tap and pulling up.
If the multi fuse is blown, consult an
4. Check the removed fuse; replace it
authorized HYUNDAI dealer.
if it is blown. To remove or insert the
fuse, use the fuse puller in the engine
compartment fuse panel.
5. Push in a new fuse of the same
rating, and make sure it fits tightly in
the clips. If it fits loosely, consult an
authorized HYUNDAI dealer.
NOTICE
After checking the fuse panel in the
engine compartment, securely install
the fuse panel cover. You may hear a
clicking sound if the cover is securely
latched. If it is not securely latched,
electrical failure may occur from water
contact.
9-49

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Fuse/Relay Panel Description
Information
Instrument panel fuse panel
Not all fuse panel descriptions in this
manual may be applicable to your vehicle;
the information is accurate at the time of
printing. When you inspect the fuse box on
your vehicle, refer to the fuse box label.
OCN7N091012N
Inside the fuse/relay box cover, you can
find the fuse/relay label describing fuse/
relay names and ratings.
OCN7N091025N
9-50

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Driver’s side fuse panel
Fuse Name
Fuse Rating
Circuit Protected
Driver/Passenger Power Outside Mirror, Instrument
MEMORY1
10A
Cluster, A/C Controller, A/C Control Module
AIR BAG2
10A
SRS Control Module
Front View Camera, Crash Pad Switch, IBU, Front Console
MODULE4
10A
Switch, E-LSD Controller, ECS Controller
MODULE7
7.5A
Rear Seat Warmer Control Module, IAU
START
7.5A
PCM/ECM IBU, E/R Junction Block(RLY.5)
CLUSTER
7.5A
Instrument Cluster
IBU2
7.5A
IBU
E/R Junction Block(RLY.13), A/C Control Module, A/C
A/C1
7.5A
Controller, PTC HEATER RLY
TRUNK
10A
Trunk Lid Latch
Front Air Ventilation Seat Control Module, Front Seat
S/HEATER FRT
20A
Warmer Control Module
P/WINDOW
Power Window Main Switch, Passenger Power Window
25A
LH
Switch
MULTIMEDIA
15A
Audio, A/V & Navigation Head Unit
9-51

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Driver’s side fuse panel
Fuse Name
Fuse Rating
Circuit Protected
MDPS1
7.5A
MDPS Unit
MODULE6
7.5A
IBU
S/HEATER RR
20A
Rear Seat Warmer Control Module
SAFETY P/
25A
Driver Safety Power Window Module
WINDOW DRV
P/WINDOW
Power Window Main Switch, Passenger Power Window
25A
RH
Switch
BRAKE
10A
Stop Lamp Switch, IBU
SWITCH
IBU1
15A
IBU
E/R Junction Block(RLY.2), Power Outside Mirror Switch,
MODULE2
10A
AMP, IBU, Audio, A/V & Navigation Head Unit, IAU
AIR BAG1
15A
SRS Control Module, ODS(Occupant Detection System)
Front Wirelesscharger, Crash Pad Switch, Electro Chromic
Mirror, A/C Controller, A/C Control Module, Audio, A/V &
Navigation Head Unit, Data Link Connector, AMP, Rear
MODULE5
10A
Seat Warmer Control Module, Front Air Ventilation Seat
Control Module, Front Seat Warmer Control Module, Head
Lamp Leveling Device LH/RH, TGS Indicator
AMP
25A
AMP
HEATED
Driver/Passenger Power Outside Mirror, A/C Control
10A
MIRROR
Module, A/C Controller
9-52

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Driver’s side fuse panel
Fuse Name
Fuse Rating
Circuit Protected
DOOR LOCK
20A
Door Lock/Unlock Actuator
MODULE3
7.5A
Sport Mode Switch, Stop Lamp Switch, M/F Switch, IAU
AIR BAG IND
7.5A
Instrument Cluster, Air bag Indicator
WASHER
15A
Multifunction Switch
WIPER
10A
PCM/ECM, IBU
Driver/Passenger Smart Key Outside Handle, Sport Mode
MODULE1
10A
Switch, Data Link Connector, Hazard Switch, Crash Pad
Switch
SUNROOF
20A
Sunroof Motor
USB CHARGER
15A
Front USB Charger
IG1
25A
PCB Block (Fuse - F10/12/16), Fuse - F14
9-53

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Engine compartment fuse panel
Information
Not all fuse panel descriptions in this
manual may be applicable to your vehicle;
the information is accurate at the time of
printing. When you inspect the fuse panel
in your vehicle, refer to the fuse panel
label.
ODN8089017
Inside the fuse/relay box cover, you can
find the fuse/relay label describing fuse/
relay names and ratings.
OCN7N091013N
9-54

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Engine compartment fuse panel
Type
Fuse Name
Fuse Rating
Circuit Protected
[G4FM/G4FG/G4NA] Alternator, (Fuse - F33, F34,
ALT
180A
F35, F37)
MIDI
[G4FP] Alternator, (Fuse - F33, F34, F35, F37)
FUSE-3
MDPS1
100A
MDPS Unit
COOLING
80A
[G4FP] Cooling Fan Controller
FAN2
MIDI
FUSE-2
EOP
60A
Electronic Oil Pump
RR HTD
50A
Rear Glass Heated
PCB Block (Engine Control Relay, Fuse - F1, F2,
B+5
60A
F3, F4, F6)
B+1
60A
ICU Junction Block (IPS2/IPS5/IPS6/IPS7/IPS14)
ICU Junction Block (IPS1/IPS4/IPS8/IPS9/IPS10/
B+2
60A
IPS13)
ICU Junction Block (Fuse - F13, F14, F22, F23,
B+3
50A
MIDI
F32,F40, F41, Long Term Load Latch Relay)
FUSE-1
BLOWER
40A
BLOWER Motor, Multipurpose Check Connector
IG1
40A
E/R Junction Block (RLY.4/6), Ignition Switch
IG2
40A
E/R Junction Block (RLY.3/5), Ignition Switch
DCT1
60A
TCU
PTC
50A
PTC HEATER
HEATER
9-55

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Engine compartment fuse panel
Type
Fuse Name
Fuse Rating
Circuit Protected
POWER
20A
Front Power Outlet
OUTLET2
POWER
20A
Cigarette Lighter
OUTLET3
VACUUM
20A
VACUUM PUMP, ESC
PUMP1
VACUUM
10A
Electronic Vacuum Pump
PUMP2
ECS
15A
ECS Unit
E-LSD
20A
LSD Control Module
E-CVVT3
20A
ECM
E-CVVT2
20A
ECM
E-CVVT1
40A
E/R Junction Block (RLY.14)
FUSE
DCT2
10A
[G4FP] TCM
ICU Junction Block (Fuse - F2, F25, F26, F34,
B+4
40A
F43, F35 (IAU), F44, Power Window Relay)
AMS
10A
Battery Sensor
TCU1
10A
[M/T] Ignition Lock & Clutch Switch
FUEL PUMP
20A
FUEL PUMP Motor
ABS1
40A
ABS Control Module, ESP Control Module
ABS Control Module, ESP Control Module,
ABS2
30A
Multipurpose Check Connector
POWER
40A
E/R Junction Block (RLY.2)
OUTLET1
WIPER
25A
Wiper Motor
9-56

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Engine compartment fuse panel (PCB block) (Smartstream 2.5 GDI)
Type
Fuse Name
Fuse Rating
Circuit Protected
ECS (15A)
15A
ECS Unit
A/C
10A
[G4FM] A/C Compressor
HORN
15A
Horn, Horn Switch
[G4FM/G4NA/G4FP] Ignition Coil #1~#4
IGN COIL
20A
[G4FG] Ignition Coil #1~#4
ECU3
10A
PCM/ECM, [MT] IGN LOCK CLUTCH SW
SENSOR3
10A
E/R Junction Block (RLY.8)
ECU2
15A
PCM/ECM
[G4FM] Oil Control Valve (Intake/Exhaust),
Variable Intake Solenoid Valve, Purge Control
Solenoid Valve, E/R Junction Block (RLY.1/11),
A/C Relay
[G4FG] Oil Control Valve (Intake/Exhaust),
Variable Intake Solenoid Valve, Purge Control
Solenoid Valve, E/R Junction Block (RLY.1/11)
FUSE
[G4NA] Oil Control Valve (Intake/Exhaust),
Variable Intake Solenoid Valve, Purge Control
Solenoid Valve, Oil Pump Solenoid Valve, E/R
SENSOR2
10A
Junction Block (RLY.1/11)
[G4FP] Oil Control Valve (Intake/Exhaust),
Variable Intake Solenoid Valve, Purge Control
Solenoid Valve, RCV Control Solenoid Valve,
Cooling Fan Controller
[Theta 2 T-GDI] Oil Control Valve(Exhaust),
Electronic Water Pump, RCV, Cooling Fan, Purge
Control Solenoid Valve, A/C Comp RLY, Oil Level
Sensor, Canister Closing Valve, Active Exhaust
Valve
SENSOR1
15A
Oxygen Sensor (UP/DOWN)
ABS Control Module, ESP Control Module,
ABS3
10A
Multipurpose Check Connector
ECU1
20A
PCM/ECM
9-57

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
LIGHT BULBS
Consult an authorized HYUNDAI dealer
Information - Headlamp
to replace most vehicle light bulbs. It is
difficult to replace vehicle light bulbs
desiccant (if equipped)
because other parts of the vehicle must
This vehicle is equipped with desiccant to
be removed before you can get to the
reduce fogging inside the headlamp due
bulb. This is especially true for removing
to moisture. The desiccant is consumable
the headlamp assembly to get to the
and its performance may change based on
bulb(s).
the used period or environment. If fogging
Removing/installing the headlamp
inside the headlamp due to moisture
assembly can result in damage to the
continues for a long time, consult an
vehicle.
authorized HYUNDAI dealer.
WARNING
Information
Prior to working on a light, depress
The headlamp and tail lamp lenses could
the foot brake, shift to P (Park), apply
appear frosty if the vehicle is washed after
the parking brake, press the Engine
driving or the vehicle is driven at night in
Start/Stop button to the OFF position
wet weather. This condition is caused by
and take the key with you when
temperature difference between the lamp
leaving the vehicle to avoid sudden
inside and outside and, it does not indicate
movement of the vehicle and to
a problem with your vehicle. When
prevent possible electric shock.
moisture condenses in the lamp, it will be
removed after driving with the headlamp
Be aware the bulbs may be hot and
on. The removable level may differ
may burn your fingers.
depending on lamp size, lamp position
and environmental condition. However, if
NOTICE
moisture is not removed, have your vehicle
Be sure to replace the burned-out bulb
inspected by an authorized HYUNDAI
with one of the same wattage rating.
dealer.
Otherwise, it may cause damage to the
fuse or electrical wiring system.
NOTICE
To prevent damage, do not clean the
headlamp lens with chemical solvents
or strong detergents.
9-58

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Headlamp, Position Lamp,
Turn Signal Lamp and Daytime
Running Light Bulb Replacement
OCN7080043
Turn signal lamp
1. Open the hood.
OCN7N091028N
2. Disconnect the negative battery
cable.
(1) Headlamp (Low)
3. Remove the socket from
(2) Headlamp (High)
the assembly by turning the
(3) Position lamp / Daytime running
socketcounterclockwise until the
lamp (DRL)
tabs on the socket align with the slots
(4) Turn signal lamp
onthe assembly.
(5) Side marker
4. Remove the bulb from the socket
by pressing it in and rotating
Headlamp/Daytime running light (DRL) /
itcounterclockwise until the tabs on
Position lamp (LED type)
the bulb align with the slots in the
socket. Pull the bulb out of the socket.
If the LED lamp does not operate, have
the system inspected by an authorized
5. Insert a new bulb by inserting it into
HYUNDAI dealer.
the socket and rotating it until it locks
into place.
The LED lamps cannot be replaced as
a single unit because it is an integrated
6. Install the socket in the assembly by
unit. The LED lamps has to be replaced
aligning the tabs on the socket with
with the unit.
the slots in the assembly.
A skilled technician should check or
7. Push the socket into the assembly and
repair the LED lamp, for it may damage
turn the socket clockwise.
related parts of the vehicle.
Lamps
If the LED lamp does not operate, have
the vehicle checked by an authorized
HYUNDAI dealer.
9-59

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Side Repeater Lamp
Rear Combination Lamp Bulb
Replacement
Replacement
OCN7N091029L
OCN7N091030N
(1) Stop lamp (LED)
If the LED lamp (1) does not operate,
have the vehicle checked by an
(2) Tail lamp (LED )
authorized HYUNDAI dealer.
(3) Turn signal lamp
(4) Reverse lamp
(5) Side marker (LED)
Tail/Stop lamp
If the tail/stop lamp do not operate, have
the vehicle checked by an authorized
HYUNDAI dealer.
9-60

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
Turn signal lamp (Outer lamp) (Bulb
type)
1. Open the trunk lid.
OCN7N091034L
[1] : Turn signal lamp
5. Remove the socket from the
assembly by turning the socket
OCN7080045
counterclockwise until the tabs on
the socket align with the slots on the
2. Remove the service cover by pulling
assembly.
out the service cover.
6. Remove the bulb from the socket
by pressing it in and rotating it
counterclockwise until the tabs on the
bulb align with the slots in the socket.
Pull the bulb out of the socket.
7. Insert a new bulb by inserting it into
the socket and rotating it until it locks
into place.
8. Install the socket in the assembly by
aligning the tabs on the socket with
the slots in the assembly. Push the
socket into the assembly and turn the
OCN7080046
socket clockwise.
3. Loosen the assembly retaining nuts.
OCN7080047
4. Remove the rear combination light
assembly from the body of the
vehicle.
9-61

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Reverse lamp (Inner lamp) (Bulb
High Mounted Stop Lamp
type)
Replacement
1. Disconnect the connector and then
remove the nuts by turning the nuts
counter clockwise.
2. Take the light assembly out.
OCN7N091031N
OCN7080053
3. Remove the socket from the
assembly by turning the socket
counterclockwise until the tabs on
the socket align with the slots on the
assembly.
4. Remove the bulb by pulling it out.
OAD075042
5. Insert a new bulb by inserting it into
[A] : High mounted stop lamp
the socket.
1. Open the trunk.
6. Install the light assembly to the trunk.
2. Remove the socket by turning it
7. Reinstall the trunk lid cover by
counterclockwise until the tabs on the
pushing in the screw.
socket align with the slots.
3. Remove the bulb from the socket
Fog lamp (if equipped)
by pressing it in and rotating it
If the lamp does not operate, have
counterclockwise until the tabs on the
the vehicle checked by an authorized
bulb align with the slots in the socket.
HYUNDAI dealer.
Pull the bulb out of the socket.
4. Insert a new bulb by inserting it into
the socket and rotating it until it locks
into place.
5. Install the socket in the assembly by
aligning the tabs on the socket with
the slots in the assembly.
Push the socket into the assembly and
turn the socket clockwise.
9-62

-------------------------------------------------------------------------------------------------------------------------------------------------------------

09
License Plate Light Bulb
Interior Light Bulb Replacement
Replacement
Map lamp
OCN7080033
OCN7N091015N
Room lamp
1. Using a flat-blade screwdriver gently
pry the lens cover from the lamp
housing.
2. Remove the bulb by pulling it straight
out.
3. Install a new bulb.
4. Reinstall in the reverse order.
OCN7080034
9-63

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
Sunvisor lamp
OCN7050058
Trunk room lamp
OCN7N091035N
1. Using a flat-blade screwdriver, gently
pry the lens from the interior light
housing.
2. Remove the bulb by pulling it straight
out.
WARNING
Prior to working on the Interior Lights,
ensure that the “OFF” button is
depressed to avoid burning your fingers
or receiving an electric shock.
3. Install a new bulb in the socket.
4. Align the lens tabs with the interior
light housing notches and snap the
lens into place.
NOTICE
Use care not to dirty or damage lens,
lens tab, and plastic housings.
9-64















Content      ..     14      15      16      17     ..
