What to do in an emergency
Distributing the sealant
Checking the tire inflation pres-
CAUTION - Tire pressure
sure
11. Immediately drive approximately
Do not attempt to drive your
1.After driving approximately
4
4~6miles
(7~10km or, about
vehicle if the tire pressure is
~6miles(7~10km or about 10min),
10min) to evenly distribute the
below
29 PSI(200kpa). This
stop at a safety location.
sealant in the tire.
could result in an accident due
Do not exceed a speed of 50 mph
2.Connect connection hose (9) of the
to sudden tire failure.
(80 km/h). If possible, do not fall
compressor directly to the tire
below a speed of 12 mph (20 km/h).
valve.
9. Switch off the compressor.
While driving, if you experience any
3.Plug the compressor power cord
unusual vibration, ride disturbance or
into the vehicle power outlet.
10. Detach the hoses from the
noise, reduce your speed and drive
4.Adjust the tire inflation pressure to
sealant bottle connector and
with caution until you can safely pull
the recommended tire inflation.
from the tire valve.
off of the side of the road.
Return the Tire Mobility Kit to its stor-
With the ignition switched on, pro-
Call for road side service or towing.
ceed as follows.
age location in the vehicle.
When you use the Tire Mobility Kit,
- To increase the inflation pres-
the tire pressure sensors and wheel
sure : Switch on the compressor,
WARNING - Carbon
may be damaged by sealant, remove
position I. To check the current
monoxide
the sealant stained with tire pressure
inflation pressure setting, briefly
Do not leave your vehicle run-
sensors and wheel and inspect in
switch off the compressor.
ning in a poorly ventilated area
authorized dealer.
for extended periods of time.
Carbon monoxide poisoning
and suffocation can occur.
6 22
What to do in an emergency
✽ NOTICE
CAUTION - Tire pressure
The pressure gauge may show high-
sensor
er than actual reading when the
We recommend that you use the
compressor is running. To get an
sealant of Tire Mobility Kit from
accurate tire pressure, the compres-
an authorized HYUNDAI dealer.
sor needs to be turned off.
The sealant on the tire pressure
sensor and wheel should be
- To reduce the inflation pres-
removed when you replace the
sure: Loosen the screw cap (8)
tire with a new one and inspect
on the compressor hose.
the tire pressure sensors in
authorized dealer.
6 23
What to do in an emergency
IF YOU HAVE A FLAT TIRE (WITH TIREMOBILITYKIT, IF EQUIPPED) (TYPE B)
■ Type B
Air pressure loss in the tire may
adversely affect tire performance.
For this reason, you should avoid
abrupt steering or other driving
maneuvers, especially if the vehicle is
heavily loaded or if a trailer is in use.
The TireMobilityKit is not designed or
intended as a permanent tire repair
method and is to be used for one tire
only.
This instruction shows you step by
OJC064010
OGDE064101
step how to temporarily seal the
puncture simply and reliably.
Please read the instructions before
Introduction
Read the section "Notes on the safe
using the TireMobilityKit.
With the TireMobilityKit you stay mobile
use of the TireMobilityKit".
(1) Compressor
even after experiencing a tire puncture.
(2) Sealant bottle
The system of compressor and seal-
WARNING
ing compound effectively and comfort-
ably seals most punctures in a pas-
Do not use the TireMobilityKit if
a tire is severely damaged by
senger car tire caused by nails or sim-
ilar objects and reinflates the tire.
driving run flat or with insuffi-
cient air pressure.
After you ensured that the tire is prop-
erly sealed you can drive cautiously
Only punctured areas located
on the tire (up to 200 km (120 miles))
within the tread region of the
at a max. speed of 80 km/h (50 mph)
tire can be sealed using the
in order to reach a vehicle or tire deal-
TireMobilityKit.
er to have the tire replaced.
Damage to the sidewall must
It is possible that some tires, especially
not be repaired due to safety rea-
with larger punctures or damage to the
sons.
sidewall, cannot be sealed completely.
6 24
What to do in an emergency
7. Pressure gauge for displaying the
tire inflation pressure
8. Button for reducing tire inflation
pressure
Connectors, cable and connection
hose are stored in the compressor
housing.
WARNING
Before using the TireMobilityKit,
follow the instructions on the
sealant bottle.
Remove the label with the speed
restriction from the sealant bottle
and apply it to the steering wheel.
Please note the expiry date on the
sealant bottle.
OGDE064102
Components of the TireMobilityKit
0. Speed restriction label
3. Connectors and cable for the
power outlet direct connection
1. Sealant bottle and label with
speed restriction
4. Holder for the sealant bottle
2. Filling hose from sealant bottle to
5. Compressor
wheel
6. On/off switch
6 25
What to do in an emergency
Using the TireMobilityKit
1. Filling the sealant
Strictly follow the specified sequence,
otherwise the sealant may escape
under high pressure.
1) Shake the sealant bottle.
OHY015012
OGDE064101
6) Ensure that the compressor is
switched off, position 0.
CAUTION
Securely install the sealant fill-
7) Connect between compressor
ing hose to the valve. If not,
and the vehicle power outlet using
sealant may flow backward, pos-
the cable and connectors.
sibly clogging the filling hose.
OGDE064100
✽ NOTICE
2) Connect the filling hose 2 onto the
Only use the front passenger side
connector of the sealant bottle (1).
5) Insert the sealant bottle into the
power outlet.
3) Ensure that button 6 on the com-
housing of the compressor so that
pressor is not pressed.
the bottle is upright (2).
8) With the ignition switched on:
4) Unscrew the valve cap from the
Switch on the compressor and let it
valve of the defective wheel and
run for approximately 3 minutes to fill
screw filling hose 2 of the sealant
the sealant. The inflation pressure of
bottle onto the valve.
the tire after filling is unimportant.
9) Switch off the compressor.
6 26
What to do in an emergency
10) Detach the hose from the
(Continued)
sealant bottle connector and
WARNING
Call for road side service or tow-
from the tire valve.
Do not let the compressor run for
ing.
Return the TireMobilityKit to its stor-
more than 10 minutes, otherwise
age location in the vehicle.
the device will overheat and may
be damaged.
Producing the tire inflation pres-
WARNING
sure
Carbon monoxide poisoning
1) After driving approximately 3 km (2
- To reduce the inflation pres-
and suffocation is possible if the
miles), stop at a suitable location.
sure: Press the button 8 on the
compressor.
engine is left running in a poorly
2) Connect the filling hose 2 of the
ventilated or unventilated loca-
compressor
(clip mounted side)
tion (such as inside a building).
directly and then connect the filling
CAUTION
hose 2 (opposite side) to the tire
If the inflation pressure is not
Distributing the sealant
valve.
maintained, drive the vehicle a
3) Connect between compressor and
second time, refer to Distributing
Immediately drive approximately 3 km
the sealant. Then repeat steps 1
(2 miles) to evenly distribute the
the vehicle power outlet using the
cable and connectors.
to 4.
sealant in the tire.
Use of the TireMobilityKit may
4) Adjust the tire inflation pressure to
CAUTION
220 kPa (32 psi). With the ignition
be ineffectual for tire damage
Do not exceed a speed of 80 km/h
switched on, proceed as follows.
larger than approximately 4 mm
(50 mph). If possible, do not fall
(0.16 in).
- To increase the inflation pres-
below a speed of 20 km/h (12 mph).
We recommend that you contact
sure: Switch on the compressor,
While driving, if you experience
position I. To check the current
the nearest HYUNDAI A/S center,
any unusual vibration, ride dis-
inflation pressure setting, briefly
or a workshop that works accord-
turbance or noise, reduce your
switch off the compressor.
ing to HYUNDAI repair proce-
speed and drive with caution
dures with correspondingly
until you can safely pull off of the
trained personnel if the tire can-
side of the road.
not be made roadworthy with the
TireMobilityKit.
(Continued)
6
27
What to do in an emergency
•
Provided the car is outdoors, leave
❈ Sealing compound and spare
WARNING
the engine running. Otherwise
parts can be obtained and
The tire inflation pressure must
operating the compressor may
replaced at an authorized vehicle
be at least 200 kPa (29 psi). If it is
eventually drain the car battery.
or tire dealer. Empty sealing com-
not, do not continue driving. Call
pound bottles may be disposed of
•
Never leave the TireMobilityKit
for road side service or towing.
at home. Liquid residue from the
unattended while it is being used.
sealing compound should be dis-
•
Do not leave the compressor run-
posed of by your vehicle or tire
ning for more than 10 min. at a time
Notes on the safe use of the
dealer or in accordance with local
or it may overheat.
TireMobilityKit
waste disposal regulations.
•
Do not use the TireMobilityKit if the
•
Park your car at the side of the
ambient temperature is below -30°C
road so that you can work with the
(-22°F).
TireMobilityKit away from moving
traffic. Place your warning triangle
•
Do not use the sealing compound
in a prominent place to make pass-
after its expiration date which can
ing vehicles aware of your location.
be found on the label of the bottle.
•
To be sure your vehicle won't
•
Keep away from children.
move, even when you're on fairly
level ground, always set your park-
ing brake.
•
Only use the TireMobilityKit for
sealing/inflation passenger car
tires. Do not use on motorcycles,
bicycles or any other type of tires.
•
Do not remove any foreign objects-
such as nails or screws -that have
penetrated the tire.
•
Before using the TireMobilityKit,
read the precautionary advice
printed on the sealant bottle!
6 28
What to do in an emergency
TIRE PRESSURE MONITORING SYSTEM (TPMS) (TYPE A) (IF EQUIPPED)
As an added safety feature, your
Your vehicle has also been equipped
vehicle has been equipped with a tire
with a TPMS malfunction indicator to
pressure monitoring system (TPMS)
indicate when the system is not oper-
that illuminates a low tire pressure
ating properly. The TPMS malfunction
telltale when one or more of your
indicator is combined with the low tire
tires is significantly under-inflated.
pressure telltale. When the system
Accordingly, when the low tire pres-
detects a malfunction, the telltale will
sure telltale illuminates, you should
flash for approximately one minute
stop and check your tires as soon as
and then remain continuously illumi-
possible, and inflate them to the
nated. This sequence will continue
proper pressure. Driving on a signifi-
upon subsequent vehicle start-ups as
cantly under-inflated tire causes the
long as the malfunction exists. When
OJC063013
tire to overheat and can lead to tire
the malfunction indicator is illuminat-
Low tire pressure telltale /
failure. Under-inflation also reduces
ed, the system may not be able to
TPMS malfunction indicator
fuel efficiency and tire tread life, and
detect or signal low tire pressure as
may affect the vehicle’s handling and
intended. TPMS malfunctions may
Each tire, including the spare (if pro-
stopping ability.
occur for a variety of reasons, includ-
vided), should be checked monthly
ing the installation of replacement or
when cold and inflated to the inflation
alternate tires or wheels on the vehi-
Please note that the TPMS is not a
pressure recommended by the vehi-
cle that prevent the TPMS from func-
substitute for proper tire mainte-
cle manufacturer on the vehicle plac-
tioning properly. Always check the
nance, and it is the driver’s responsi-
ard or tire inflation pressure label. (If
TPMS malfunction telltale after
bility to maintain correct tire pres-
your vehicle has tires of a different
replacing one or more tires or wheels
sure, even if under-inflation has not
size than the size indicated on the
on your vehicle to ensure that the
reached the level to trigger illumina-
vehicle placard or tire inflation pres-
replacement or alternate tires and
tion of the TPMS low tire pressure
sure label, you should determine the
wheels allow the TPMS to continue to
telltale.
proper tire inflation pressure for
function properly.
those tires.)
6 29
What to do in an emergency
✽ NOTICE
Low tire pressure tell-
tale
CAUTION
If the TPMS indicator does not illu-
In winter or cold weather, the
minate for 3 seconds when the igni-
low tire pressure telltale may be
tion switch is turned to the ON posi-
When the tire pressure monitoring
illuminated if the tire pressure
tion or engine is running, or if it
system warning indicator is illuminat-
was adjusted to the recom-
comes on after blinking for approxi-
ed, one or more of your tires is sig-
mended tire inflation pressure
mately one minute, we recommend
nificantly under-inflated.
in warm weather. It does not
that you contact an authorized
If the telltale illuminates, immediately
mean your TPMS is malfunction-
HYUNDAI dealer.
reduce your speed, avoid hard cor-
ing because the decreased tem-
nering and anticipate increased stop-
perature leads to a proportional
ping distances. You should stop and
lowering of tire pressure.
check your tires as soon as possible.
When you drive your vehicle
Inflate the tires to the proper pres-
from a warm area to a cold area
sure as indicated on the vehicle’s
or from a cold area to a warm
placard or tire inflation pressure label
area, or the outside temperature
located on the driver’s side center pil-
is greatly higher or lower, you
lar outer panel. If you cannot reach a
should check the tire inflation
service station or if the tire cannot
pressure and adjust the tires to
hold the newly added air, replace the
the recommended tire inflation
low pressure tire with the spare tire.
pressure.
Then the Low Tire Pressure telltale
may flash for approximately one
minute and then remain continuously
illuminated after restarting and about
20 minutes of continuous driving
before you have the low pressure tire
repaired and replaced on the vehicle.
6 30
What to do in an emergency
TPMS (Tire Pressure
WARNING - Low pressure
Monitoring System)
CAUTION
damage
malfunction indicator
•
The TPMS malfunction indica-
Significantly low tire pressure
tor may be illuminated if the
makes the vehicle unstable and
vehicle is moving around elec-
The TPMS malfunction indicator will
can contribute to loss of vehicle
tric power supply cables or
illuminate after it blinks for approxi-
control and increased braking
radios transmitter such as at
mately one minute when there is a
distances.
police stations, government
problem with the Tire Pressure
and public offices, broadcast-
Continued driving on low pres-
Monitoring System. If the system is
ing stations, military installa-
sure tires can cause the tires to
able to correctly detect an under infla-
tions, airports, or transmitting
overheat and fail.
tion warning at the same time as sys-
towers, etc. This can interfere
tem failure then it will illuminate the
with normal operation of the
TPMS malfunction indicator.
Tire Pressure Monitoring
We recommend that the system be
System (TPMS).
checked by an authorized HYUNDAI
•
The TPMS malfunction indica-
dealer.
tor may illuminate if snow
chains or some separately
purchased devices such as
notebook computers, mobile
charger, remote starter, navi-
gation etc. are used in the
vehicle. This can interfere with
normal operation of the Tire
Pressure Monitoring System
(TPMS).
6 31
What to do in an emergency
Changing a tire with TPMS
Each wheel is equipped with a tire
If the indicator is not extinguished
pressure sensor mounted inside the
after a few minutes of driving, We
If you have a flat tire, the Low Tire
tire behind the valve stem. You must
recommend that the system be
Pressure will come on. We recom-
use TPMS specific wheels. It is rec-
checked by an authorized HYUNDAI
mend that the flat tire be checked by
ommended that you have your tires
dealer.
an authorized HYUNDAI dealer.
serviced by an authorized HYUNDAI
dealer.
CAUTION
CAUTION
Even if you replace the low pressure
If original mounted tire is
We recommend that you use a
tire with the spare tire, the Low Tire
replaced with the spare tire, the
puncture-repairing
agent
Pressure Telltale will blink or remain
TPMS sensor on the replaced
approved by HYUNDAI.
on until the low pressure tire is
spare wheel should be initiated
The sealant on the tire pressure
repaired and placed on the vehicle.
and we recommend that the
sensor and wheel shall be elim-
After you replace the low pressure
TPMS sensor on the original
inated when you replace the tire
tire with the spare tire, the Low Tire
mounted wheel be deactivated
with a new one.
Pressure Telltale may blink or illumi-
by a HYUNDAI dealer. If the
nate after a few minutes because the
TPMS sensor on the original
TPMS sensor mounted on the spare
mounted wheel located in the
wheel is not initiated.
spare tire carrier still activates,
Once the low pressure tire is reinflat-
the tire pressure monitoring
ed to the recommended pressure
system may not operate proper-
and installed on the vehicle or we
ly. We recommend that the sys-
recommend that the TPMS sensor
tem be serviced by an author-
mounted on the replaced spare
ized HYUNDAI dealer.
wheel be initiated by an authorized
HYUNDAI dealer, the TPMS mal-
function indicator and the low tire
pressure telltale will extinguish within
a few minutes of driving.
6 32
What to do in an emergency
You may not be able to identify a low
tire by simply looking at it. Always
WARNING - TPMS
WARNING - For EUROPE
use a good quality tire pressure
•
The TPMS cannot alert you to
•
Do not modify the vehicle, it
gauge to measure the tire's inflation
severe and sudden tire dam-
may interfere with the TPMS
pressure. Please note that a tire that
age caused by external fac-
function.
is hot (from being driven) will have a
tors such as nails or road
•
The wheels on the market do
higher pressure measurement than a
debris.
not have a TPMS sensor.
tire that is cold.
•
If you feel any vehicle instabil-
For your safety, we recom-
A cold tire means the vehicle has
ity, immediately take your foot
mend that you use parts for
been sitting for 3 hours and driven for
off the accelerator, apply the
replacement from an author-
less than 1 mile (1.6 km) in that 3
brakes gradually and with
ized HYUNDAI dealer.
hour period.
light force, and slowly move to
•
If you use the wheels on the
Allow the tire to cool before measur-
a safe position off the road.
market, use a TPMS sensor
ing the inflation pressure. Always be
approved by a HYUNDAI deal-
sure the tire is cold before inflating to
er. If your vehicle is not
the recommended pressure.
WARNING - Protecting
equipped with a TPMS sensor
TPMS
or TPMS does not work prop-
CAUTION
Tampering with, modifying, or
erly, you may fail the periodic
disabling the Tire Pressure
We recommend that you use the
vehicle inspection conducted
tire
sealant approved by
Monitoring System (TPMS) com-
in your country.
ponents may interfere with the
HYUNDAI if your vehicle is
❈All vehicles sold in the
system's ability to warn the driv-
equipped with a Tire Pressure
EUROPE market during below
er of low tire pressure condi-
Monitoring System. The liquid
period must be equipped with
tions and/or TPMS malfunctions.
sealant can damage the tire
TPMS.
Tampering with, modifying, or
pressure sensors.
- New model vehicle : Nov. 1,
disabling the Tire Pressure
Monitoring System (TPMS) com-
2012 ~
ponents may void the warranty
- Current model vehicle : Nov.
for that portion of the vehicle.
1, 2014~ (Based on vehicle
registrations)
6 33
What to do in an emergency
TIRE PRESSURE MONITORING SYSTEM (TPMS) (TYPE B) (IF EQUIPPED)
As an added safety feature, your
Your vehicle has also been equipped
vehicle has been equipped with a tire
with a TPMS malfunction indicator to
pressure monitoring system (TPMS)
indicate when the system is not
that illuminates a low tire pressure
operating properly. The TPMS mal-
telltale when one or more of your
function indicator is combined with
tires is significantly under-inflated.
the low tire pressure telltale. When
Accordingly, when the low tire pres-
the system detects a malfunction,
sure telltale illuminates, you should
the telltale will flash for approximate-
stop and check your tires as soon as
ly 1 minute and then remain continu-
possible, and inflate them to the
ously illuminated. This sequence will
proper pressure. Driving on a signifi-
continue upon subsequent vehicle
cantly under-inflated tire causes the
start-ups as long as the malfunction
OJC060013
tire to overheat and can lead to tire
exists. When the TPMS malfunction
(1) Low tire pressure telltale /
failure. Under-inflation also reduces
indicator remains illuminated after
TPMS malfunction indicator
fuel efficiency and tire tread life, and
blinking for approximately 1 minute,
(2) Low tire pressure position telltale
may affect the vehicle’s handling and
the system may not be able to detect
(Shown on the LCD display)
stopping ability.
or signal low tire pressure as intend-
ed. TPMS malfunctions may occur
Each tire, including the spare (if pro-
for a variety of reasons, including the
Please note that the TPMS is not a
vided), should be checked monthly
installation of replacement or alter-
substitute for proper tire mainte-
when cold and inflated to the inflation
nate tires or wheels on the vehicle
nance, and it is the driver’s responsi-
pressure recommended by the vehi-
that prevent the TPMS from function-
bility to maintain correct tire pres-
cle manufacturer on the vehicle plac-
ing properly. Always check the
sure, even if under-inflation has not
ard or tire inflation pressure label. (If
TPMS malfunction telltale after
reached the level to trigger illumina-
your vehicle has tires of a different
replacing one or more tires or wheels
tion of the TPMS low tire pressure
size than the size indicated on the
on your vehicle to ensure that the
telltale.
vehicle placard or tire inflation pres-
replacement or alternate tires and
sure label, you should determine the
wheels allow the TPMS to continue
proper tire inflation pressure for
to function properly.
those tires.)
6 34
What to do in an emergency
✽ NOTICE
Low tire pressure tell-
Then the TPMS malfunction indicator
tale
may blink for approximately 1 minute
We recommend that the system be
and then remain continuously illumi-
checked by an authorized
nated and the low tire pressure posi-
HYUNDAI dealer if any of the
Low tire pressure posi-
tion telltale will remain on after
below happens:
tion telltale
restarting and about 20 minutes of
1.The low tire pressure telltale/
continuous driving before you have
TPMS malfunction indicator do
When the tire pressure monitoring
the low pressure tire repaired and
not illuminate for 3 seconds when
system warning indicators are illumi-
replaced on the vehicle.
the ignition switch is turned to the
ON position or engine is running.
nated, one or more of your tires is
2.The TPMS malfunction indicator
significantly under-inflated. The low
CAUTION
remains illuminated after blinking
tire pressure position telltale light will
In winter or cold weather, the
indicate which tire is significantly
for approximately 1 minute.
low tire pressure telltale may
3.The Low tire pressure position
under-inflated by illuminating the cor-
illuminate if the tire pressure
responding position light.
telltale remains illuminated.
was adjusted to the recom-
If either telltale illuminates, immedi-
mended tire inflation pressure
ately reduce your speed, avoid hard
in warm weather. It does not
cornering and anticipate increased
mean your TPMS is malfunction-
stopping distances. You should stop
ing because the decreased tem-
and check your tires as soon as pos-
perature leads to a proportional
sible. Inflate the tires to the proper
lowering of tire pressure.
pressure as indicated on the vehi-
When you drive your vehicle
cle’s placard or tire inflation pressure
from a warm area to a cold area
label located on the driver’s side cen-
or from a cold area to a warm
ter pillar outer panel. If you cannot
area, or the outside temperature
reach a service station or if the tire
is greatly higher or lower, you
cannot hold the newly added air,
should check the tire inflation
replace the low pressure tire with a
pressure and adjust the tires to
spare tire.
the recommended tire inflation
pressure.
6 35
What to do in an emergency
TPMS (Tire Pressure
WARNING - Low pressure
Monitoring System)
CAUTION
damage
malfunction indicator
•
The TPMS malfunction indica-
Significantly low tire pressure
tor may blink for approximate-
makes the vehicle unstable and
ly 1 minute and then remain
The TPMS malfunction indicator will
can contribute to loss of vehicle
continuously illuminated if the
illuminate after it blinks for approxi-
control and increased braking
vehicle is moving around elec-
mately one minute when there is a
distances.
tric power supply cables or
problem with the Tire Pressure
radios transmitter such as at
Continued driving on low pres-
Monitoring System. If the system is
police stations, government
sure tires can cause the tires to
able to correctly detect an underinfla-
and public offices, broadcast-
overheat and fail.
tion warning at the same time as sys-
ing stations, military installa-
tem failure then the TPMS malfunc-
tions, airports, or transmitting
tion indicator remains illuminated
towers, etc. This can interfere
after blinking for approximately
1
with normal operation of the
minute and the low tire pressure posi-
Tire Pressure Monitoring
tion telltale will illuminate e.g. if Front
System (TPMS).
Left sensor fails, the TPMS malfunc-
•
The TPMS malfunction indica-
tion indicator remains illuminated
tor may blink for approximate-
after blinking for approximately
1
ly 1 minute and then remain
minute, but if the Front Right, Rear
continuously illuminated if
Left, or Rear Right tire is under-inflat-
snow chains are used or some
ed, the low tire pressure position tell-
separate electronic devices
tales may illuminate together with the
such as notebook computer,
TPMS malfunction indicator.
mobile charger, remote starter
We recommend that the system be
or navigation etc., are used in
checked by an authorized HYUNDAI
the vehicle. This can interfere
dealer.
with normal operation of the
Tire Pressure Monitoring
System (TPMS).
6 36
What to do in an emergency
Changing a tire with TPMS
After you replace the low pressure
tire with the spare tire, the TPMS
CAUTION
If you have a flat tire, the low Tire
malfunction indicator may blink for
If original mounted tire is
Pressure and Position telltales will
approximately
1 minute and then
replaced with the spare tire, the
come on. We recommend that the
remain continuously illuminated
TPMS sensor on the replaced
system be checked by an authorized
because the TPMS sensor mounted
spare wheel should be initiated
HYUNDAI dealer.
on the spare wheel is not initiated.
and we recommend that the
TPMS sensor on the original
Once the low pressure tire is reinflat-
CAUTION
mounted wheel be deactivated
ed to the recommended pressure
We recommend that you use a
by a HYUNDAI dealer. If the
and installed on the vehicle or the
puncture-repairing
agent
TPMS sensor on the original
TPMS sensor mounted on the
approved by HYUNDAI. The
mounted wheel located in the
replaced spare wheel is initiated by
sealant on the tire pressure sen-
spare tire carrier still activates,
an authorized HYUNDAI dealer, the
sor and wheel shall be eliminat-
the tire pressure monitoring
TPMS malfunction indicator and the
ed when you replace the tire
system may not operate proper-
low tire pressure and position tell-
with a new one.
ly. We recommend that the sys-
tales will extinguish within a few min-
tem be serviced by an author-
utes of driving.
ized HYUNDAI dealer.
Each wheel is equipped with a tire
If the indicator is not extinguished
pressure sensor mounted inside the
after a few minutes of driving, we
tire behind the valve stem. You must
recommend that the system be
use TPMS specific wheels. It is rec-
checked by an authorized HYUNDAI
ommended that you have your tires
dealer.
serviced by an authorized HYUNDAI
dealer.
6 37
What to do in an emergency
You may not be able identify a low
tire by simply looking at it. Always
WARNING - TPMS
WARNING - For EUROPE
use a good quality tire pressure
• The TPMS cannot alert you to
•
Do not modify the vehicle, it
gauge to measure the tire's inflation
severe and sudden tire dam-
may interfere with the TPMS
pressure. Please note that a tire that
age caused by external fac-
function.
is hot (from being driven) will have a
tors such as nails or road
•
The wheels on the market do
higher pressure measurement than a
debris.
not have a TPMS sensor.
tire that is cold (from sitting station-
• If you feel any vehicle instabil-
For your safety, we recom-
ary for at least 3 hours and driven
ity, immediately take your foot
mend that you use parts for
less than 1 mile (1.6 km) during that
off the accelerator, apply the
replacement from an author-
3 hour period).
brakes gradually and with
ized HYUNDAI dealer.
Allow the tire to cool before measur-
light force, and slowly move to
•
If you use the wheels on the
ing the inflation pressure. Always be
a safe position off the road.
market, use a TPMS sensor
sure the tire is cold before inflating to
approved by a HYUNDAI deal-
the recommended pressure.
er. If your vehicle is not
A cold tire means the vehicle has
WARNING - Protecting
equipped with a TPMS sensor
been sitting for 3 hours and driven for
TPMS
or TPMS does not work prop-
less than 1 mile (1.6 km) in that 3
Tampering with, modifying, or
erly, you may fail the periodic
hour period.
disabling the Tire Pressure
vehicle inspection conducted
Monitoring System
(TPMS)
in your country.
components may interfere with
CAUTION
❈All vehicles sold in the
the system's ability to warn the
We recommend that you use the
EUROPE market during below
driver of low tire pressure con-
tire
sealant approved by
period must be equipped with
ditions and/or TPMS malfunc-
HYUNDAI if your vehicle is
TPMS.
tions. Tampering with, modify-
equipped with a Tire Pressure
ing, or disabling the Tire
- New model vehicle : Nov. 1,
Monitoring System. The liquid
Pressure Monitoring System
2012 ~
sealant can damage the tire
(TPMS) components may void
- Current model vehicle : Nov.
pressure sensors.
the warranty for that portion of
1, 2014~ (Based on vehicle
the vehicle.
registrations)
6 38
