To increase Smart Cruise
To decrease the Smart Cruise
CAUTION
Control set speed
Control set speed
Check the driving condition
before using the toggle switch.
Driving speed sharply increas-
es, when you push up and hold
the toggle switch.
OPDE056120
OPDE056119
5
Follow either of these procedures:
Follow either of these procedures:
• Push the toggle switch up (RES+),
• Push the toggle switch down (SET-),
and release it immediately. The
and release it immediately. The
cruising speed will increase by 1
cruising speed will decrease by 1
km/h (1 mph) each time you move
km/h (1 mph) each time you move
the toggle switch up in this manner.
the toggle switch down in this man-
ner.
• Push the toggle switch up (RES+),
and hold it. Your vehicle set speed
• Push the toggle switch down (SET-),
will increase by 10 km/h (5 mph).
and hold it. Your vehicle set speed
Release the toggle switch at the
will decrease by 10 km/h (5 mph).
speed you want.
Release the toggle switch at the
speed you want.
• You can set the speed to 180 km/h
(110 mph).
• You can set the speed to 30 km/h
(20 mph).
5-133
Driving your vehicle
To temporarily accelerate with
Smart Cruise Control will be
Cancelled automatically
the Smart Cruise Control on
temporarily canceled when:
•
The driver's door is opened.
If you want to speed up temporarily
•
The shift lever is shifted to N
when the Smart Cruise Control is on,
(Neutral), R (Reverse) or P (Park).
depress the accelerator pedal.
•
The parking brake is applied.
Increased speed will not interfere
•
The vehicle speed is over
190
with Smart Cruise Control operation
km/h (120 mph).
or change the set speed.
•
The ESC
(Electronic Stability
To return to the set speed, take your
Control), TCS
(Traction Control
foot off the accelerator pedal.
System) or ABS is operating.
If you push the toggle switch down
•
The ESC is turned off.
(SET-) at increased speed, the cruis-
•
The sensor or the cover is dirty or
ing speed will be set again pedal.
blocked with foreign matter.
OPDE056121
•
The vehicle is stopped for a certain
i
Information
Cancelled manually
period of time.
Be careful when accelerating tem-
• Depressing the brake pedal.
•
The vehicle stops and goes repeat-
porarily, because the speed is not con-
• Pressing the
button located on
edly for a long period of time.
trolled automatically at this time even
the steering wheel.
•
The accelerator pedal is continu-
if there is a vehicle in front of you.
The Smart Cruise Control turns off
ously depressed for a long period
temporarily when the Set Speed and
of time.
Vehicle-to-Vehicle Distance indicator
•
The engine performance is abnor-
on the LCD display turns off.
mal.
The cruise (
) indicator is
•
The driver starts driving by pushing
illuminated continuously.
the toggle switch up (RES+)/down
(SET-) or depressing the accelera-
tor pedal, approximately 3 minutes
after the vehicle is stopped by the
Smart Cruise Control System with
no other vehicle ahead.
5-134
• The driver starts driving by pushing
To resume Smart Cruise Control
the toggle switch up (RES+)/down
set speed
(SET-) or depressing the accelera-
If any method other than the cruise
tor pedal, after stopping the vehicle
toggle switch was used to cancel
with a vehicle stopped far away in
cruising speed and the system is still
front.
activated, the cruising speed will
• The AEB is activated.
automatically resume when you
Each of these actions will cancel the
push the toggle switch up (RES+) or
Smart Cruise Control operation. The
down (SET-).
Set Speed and Vehicle-to-Vehicle
If you push the toggle switch up
Distance on the LCD display will go
(RES+), the speed will resume to the
OAE056165L
off.
recently set speed. However, if vehi-
In a condition the Smart Cruise
Smart Cruise Control cancelled
cle speed drops below
30 km/h (20
Control is cancelled automatically,
If the system is cancelled, the warn-
mph), it will resume when there is a
5
the Smart Cruise Control will not
ing chime will sound and a message
vehicle in front of your vehicle.
resume even though the RES+ or
will appear for a few seconds.
SET- toggle switch is pushed.
i
Information
You must adjust the vehicle speed by
depressing the accelerator or brake
Always check the road conditions
i
Information
pedal according to the road condition
when you push the toggle switch up
ahead and driving condition.
(RES+) to resume speed.
If the Smart Cruise Control is can-
celled by other than the reasons men-
Always check the road conditions.
tioned, we recommend that the system
Do not rely on the warning chime.
be checked by an authorized
HYUNDAI dealer.
5-135
Driving your vehicle
To turn Cruise Control off
Smart Cruise Control Vehicle-
i
Information
to-Vehicle Distance
The mode changes, as below, whenev-
To set Vehicle-to-Vehicle
er the
button is pressed.
Distance
System off
Smart Cruise Control
Speed Limit Control
OPDE056118
•
Press the
button (the cruise
(
) indicator light will go
OPDE056124
off).
•
Press the
button
(The
When the Smart Cruise Control
(
) indicator light will go
System is ON, you can set and main-
off.). (if equipped with Speed Limit
tain the distance from the vehicle
Control)
ahead of you without pressing the
accelerator or brake pedal.
- With the Smart Cruise Control
on, pressing the button once will
Each time the button is pressed, the
turn Off the Smart Cruise Control
vehicle to vehicle distance changes
and turn on the Speed Limit
as follows:
Control.
Distance 4
Distance 3
Distance 2
- With the Smart Cruise Control off
and Speed Limit Control on,
pressing the button will turn off
Distance 1
both system.
5-136
For example, if you drive at 90 km/h
When the lane ahead is clear:
When there is a vehicle ahead
(56 mph), the distance maintain as
of you in your lane:
follows:
Distance 4 - approximately 52.5 m
Distance 3 - approximately 40 m
Distance 2 - approximately 32.5 m
Distance 4
Distance 3
Distance 1 - approximately 25 m
i
Information
The distance is set to the last set dis-
OPD056084
tance when the system is used for the
Distance 2
Distance 1
first time after starting the engine.
5
The vehicle speed will maintain the
OPD056085/OPD056086/OPD056087/OPD056088
set speed.
• Your vehicle speed will slow down
or speed up to maintain the select-
ed distance.
• If the vehicle ahead speeds up,
your vehicle will travel at a steady
cruising speed after accelerating to
the set speed.
5-137
Driving your vehicle
WARNING
(Continued)
CAUTION
• Even if the warning chime is
not activated, always pay
attention to the driving condi-
tions to prevent dangerous
situations from occurring.
• Playing the vehicle audio sys-
tem at high volume may offset
the system warning sounds.
OPD056089
OPDE056090
When using the Smart Cruise
If the vehicle ahead
(vehicle
Control System:
speed: less than 30km/h) disap-
pears to the next lane, the warn-
• The warning chime sounds
and the Vehicle-to Vehicle
ing chime will sound and a mes-
sage "Watch for surrounding
Distance indicator blinks if
the vehicle is unable to main-
vehicles" will appear. Adjust
your vehicle speed for vehicles
tain the selected distance
from the vehicle ahead.
or objects that can suddenly
appear in front of you by
• If the warning chime sounds,
depressing the brake pedal.
depress the brake pedal or
use the steering wheel toggle
Always pay attention to the road
switch to actively adjust the
condition ahead.
vehicle speed, and the dis-
tance to the vehicle ahead.
(Continued)
5-138
In traffic situation
• If you push the advanced smart
Sensor to detect distance to
cruise control toggle switch (RES+
the vehicle ahead
or SET-) while Auto Hold and
advanced smart cruise control is
operating the Auto Hold will be
released regardless of accelerator
pedal operation and the vehicle will
start to move. The AUTO HOLD
indicator changes from green to
white.
(if equipped with EPB
(Electronic Parking Brake))
OPDE056091
OPDE056039
5
Use switch or pedal to accelerate
• In traffic, your vehicle will stop if the
The Smart Cruise Control uses a
vehicle ahead of you stops. Also, if
sensor to detect distance to the vehi-
the vehicle ahead of you starts
cle ahead.
moving, your vehicle will start as
well. However, if the vehicle stops
for more than 3 seconds, you must
depress the accelerator pedal or
push up the toggle switch
(RES+)
or push down the toggle switch
(SET-) to start driving.
5-139
Driving your vehicle
Warning message
i
Information
(Continued)
For the SCC operation is temporarily
•
Be careful not to apply unnec-
stopped if the radar is blocked, but you
essary force on the radar sen-
wish to use cruise control mode (speed
sor or sensor cover. If the sen-
control function), you must convert to
sor is forcibly moved out of
the cruise control mode (refer to “To
proper alignment, the Smart
convert to Cruise Control mode” in
Cruise Control System may
the following page.
not operate correctly. In this
case, a warning message may
not be displayed. Have the
CAUTION
vehicle inspected by an
authorized HYUNDAI dealer.
•
Do not apply license plate
OAE056166L
•
If the front bumper becomes
molding or foreign objects
damaged in the area around
Smart Cruise Control disabled.
such as a bumper sticker or a
Radar blocked
the radar sensor, the Smart
bumper guard near the radar
Cruise Control System may
When the sensor lens cover is
sensor. Doing so may adverse-
not operate properly. We rec-
blocked with dirt, snow, or debris, the
ly affect the sensing perform-
ommend you to have the vehi-
Smart Cruise Control System opera-
ance of the radar.
cle inspected by an author-
tion may stop temporarily. If this
•
Always keep the radar sensor
ized HYUNDAI dealer.
occurs, a warning message will
and lens cover clean and free
•
Use only genuine HYUNDAI
appear on the LCD display. Remove
of dirt and debris.
any dirt, snow, or debris and clean
parts to repair or replace a
•
Use only a soft cloth to wash
damaged sensor or sensor
the radar sensor lens cover before
the vehicle. Do not spray pres-
operating the Smart Cruise Control
cover. Do not apply paint to
surized water directly on the
the sensor cover.
System. The Smart Cruise Control
sensor or sensor cover.
system may not properly activate, if
(Continued)
the radar is totally contaminated, or if
any substance is not detected after
turning ON the engine (e.g. in an open
terrain).
5-140
To adjust the sensitivity of
To convert to Cruise Control
Smart Cruise Control
mode
The sensitivity of vehicle speed
The driver may choose to only use
when following the front vehicle to
the Cruise Control mode (speed con-
maintain the set distance can be
trol function) by doing as follows:
adjusted. Go to the 'User Settings
1. Turn the Smart Cruise Control
Driving Assist
Smart Cruise
System on (the cruise indicator
Control Speed Slow/Normal/Fast'
light will be on but the system will
on the LCD display. You may select
not be activated).
one of the three stages you prefer.
2. Push and hold the Vehicle-to-
- Slow:
OAE056167L
Vehicle Distance button for more
Vehicle speed following the front
than 2 seconds.
Check Smart Cruise Control System
vehicle to maintain the set distance
3. Choose between "Smart Cruise
The message will appear when the
is slower than normal speed.
5
Control" and "Cruise Control".
vehicle to vehicle distance control
- Normal:
When the system is canceled using
system is not functioning normally.
Vehicle speed following the front
the
button or the
button is
We recommend that you take your
vehicle to maintain the set distance
used after the engine is turned on,
vehicle to an authorized HYUNDAI
is normal.
the Smart Cruise Control mode will
dealer and have the system checked.
turn on.
- Fast:
Vehicle speed following the front
vehicle to maintain the set distance
is faster than normal speed.
i
Information
The last selected speed sensitivity of
the smart cruise control is remained in
the system.
5-141
Driving your vehicle
Limitations of the system
WARNING
The Smart Cruise Control System
may have limits to its ability to detect
When using the Cruise Control
mode, you must manually
distance to the vehicle ahead due to
road and traffic conditions.
adjust the distance to other
vehicles by depressing the
accelerator or brake pedal. The
On curves
system does not automatically
adjust the distance to vehicles
in front of you.
OAE056101
Your vehicle speed can be reduced
due to a vehicle in the adjacent lane.
Apply the accelerator pedal and
select the appropriate set speed.
Check to be sure that the road con-
ditions permit safe operation of the
Smart Cruise Control.
OAE056100
•
The Smart Cruise Control System
may not detect a moving vehicle in
your lane, and then your vehicle
could accelerate to the set speed.
Also, the vehicle speed will
decrease when the vehicle ahead
is recognized suddenly.
•
Select the appropriate set speed
on curves and apply the brakes or
accelerator pedal if necessary.
5-142
On inclines
Lane changing
Vehicle recognition
OAE056102
OAE056103
OAE056104
5
•
During uphill or downhill driving,
•
A vehicle which moves into your
Some vehicles in your lane cannot
the Smart Cruise Control System
lane from an adjacent lane cannot
be recognized by the sensor:
may not detect a moving vehicle in
be recognized by the sensor until it
- Narrow vehicles such as motorcy-
your lane, and cause your vehicle
is in the sensor's detection range.
cles or bicycles
to accelerate to the set speed.
•
The radar may not detect immedi-
- Vehicles offset to one side
Also, the vehicle speed will rapidly
ately when a vehicle cuts in sud-
decrease when the vehicle ahead
- Slow-moving vehicles or sudden-
denly. Always pay attention to the
is recognized suddenly.
decelerating vehicles
traffic, road and driving conditions.
•
Select the appropriate set speed
- Stopped vehicles
•
If a slower vehicle moves into your
on inclines and apply the brake or
- Vehicles with small rear profile
lane, your speed may decrease to
accelerator pedal if necessary.
such as trailers with no loads
maintain the distance to the vehicle
ahead.
•
If a faster vehicle which moves into
your lane, your vehicle will acceler-
ate to the set speed.
5-143
Driving your vehicle
A vehicle ahead cannot be recog-
nized correctly by the sensor if any of
following occurs:
- When the vehicle is pointing
upwards due to overloading in the
luggage compartment
- While the steering wheel is operat-
ing
- When driving to one side of the
lane
- When driving on narrow lanes or
OAE056108
OAE056109
on curves
•
Your vehicle may accelerate when
•
When driving in stop-and-go traffic,
Apply the brake or accelerator pedal
a vehicle ahead of you disappears.
and a stopped vehicle in front of
if necessary.
you merges out of the lane, the
•
When you are warned that the
vehicle ahead of you is not detect-
system may not immediately
detect the new vehicle that is now
ed, drive with caution.
in front of you. In this case, you
must maintain a safe braking dis-
tance, and if necessary, depress
the brake pedal to reduce your
driving speed in order to maintain a
safe distance.
5-144
WARNING
When using the Smart Cruise
Control take the following pre-
cautions:
•
If an emergency stop is nec-
essary, you must apply the
brakes. The vehicle cannot be
stopped at every emergency
situation by using the Smart
Cruise Control System.
OAE056110
OPD056040
•
Keep a safe distance accord-
•
Always look out for pedestrians
•
Always be cautious for vehicles
ing to road conditions and
when your vehicle is maintaining a
with higher height or vehicles car-
vehicle speed. If the vehicle to
5
distance with the vehicle ahead.
rying loads that sticks out from the
vehicle distance is too close
back of the vehicle.
during a high-speed driving, a
serious collision may result.
•
Always maintain sufficient
braking distance and deceler-
ate your vehicle by applying
the brakes if necessary.
•
The Smart Cruise Control
System cannot recognize a
stopped vehicle, pedestrians
or an oncoming vehicle.
Always look ahead cautiously
to prevent unexpected and
sudden situations from occur-
ring.
(Continued)
5-145
Driving your vehicle
NOTICE
(Continued)
•
Vehicles moving in front of you
The Smart Cruise Control System
with a frequent lane change
may not operate temporarily due
may cause a delay in the sys-
to:
tem's reaction or may cause
•
Electrical interference
the system to react to a vehicle
•
Modifying the suspension
actually in an adjacent lane.
Always drive cautiously to pre-
•
Differences of tire abrasion or
vent unexpected and sudden
tire pressure
situations from occurring.
•
Installing different type of tires
•
Always be aware of the select-
ed speed and vehicle to vehi-
cle distance. The driver
should not solely rely on the
system but always pay atten-
tion to driving conditions and
control your vehicle speed.
•
The Smart Cruise Control
System may not recognize
complex driving situations so
always pay attention to driv-
ing conditions and control
your vehicle speed.
5-146
SPECIAL DRIVING CONDITIONS
Hazardous driving conditions
Rocking the vehicle
WARNING
When hazardous driving elements
If it is necessary to rock the vehicle
are encountered such as water,
to free it from snow, sand, or mud,
If the vehicle is stuck and
snow, ice, mud and sand, take the
first turn the steering wheel right and
excessive wheel spin occurs,
bellow suggestions:
left to clear the area around your
the temperature in the tires can
• Drive cautiously and keep a longer
front wheels. Then, shift back and
increase very quickly. If the tires
forth between R (Reverse) and a for-
braking distance.
become damaged, a tire blow
ward gear.
out or tire explosion can occur.
• Avoid abrupt braking or steering.
Try to avoid spinning the wheels, and
This condition is dangerous -
• When your vehicle is stuck in snow,
do not race the engine.
you and others may be injured.
mud, or sand, use the second
Do not attempt this procedure if
To prevent transmission wear, wait
gear. Accelerate slowly to avoid
people or objects are anywhere
unnecessary wheel spinning.
until the wheels stop spinning before
near the vehicle.
shifting gears. Release the accelera-
• Put sand, rock salt, tire chains or
tor pedal while shifting, and press
If you attempt to free the vehi-
5
other non-slip materials under the
lightly on the accelerator pedal while
cle, the vehicle can overheat
wheels to provide additional trac-
the transmission is in gear. Slowly
quickly, possibly causing an
tion while being stuck in ice, snow,
spinning the wheels in forward and
engine compartment fire or
or mud.
reverse directions causes a rocking
other damage. Try to avoid spin-
motion that may free the vehicle.
ning the wheels as much as
WARNING
possible to prevent overheating
of either the tires or the engine.
Downshifting with an automatic
DO NOT allow the vehicle to
transmission while driving on
spin the wheels above 56 km/h
slippery surfaces can cause an
(35 mph).
accident. The sudden change in
tire speed could cause the tires
to skid. Be careful when down-
shifting on slippery surfaces.
5-147
Driving your vehicle
Smooth cornering
Driving in the rain
i
Information
Avoid braking or gear changing in
Rain and wet roads can make driving
The ESC system (if equipped) must be
corners, especially when roads are
dangerous. Here are a few things to
turned OFF before rocking the vehi-
wet. Ideally, corners should always
consider when driving in the rain or
cle.
be taken under gentle acceleration.
on slick pavement:
NOTICE
•
Slow down and allow extra follow-
ing distance. A heavy rainfall
Driving at night
If you are still stuck after rocking
makes it harder to see and increas-
the vehicle a few times, have the
Night driving presents more hazards
es the distance needed to stop
vehicle pulled out by a tow vehicle
than driving in the daylight. Here are
your vehicle.
to avoid engine overheating, pos-
some important tips to remember:
•
Turn OFF your Cruise Control. (if
sible damage to the transmission,
•
Slow down and keep more dis-
equipped)
and tire damage. See "Towing" in
tance between you and other vehi-
•
Replace your windshield wiper
chapter 6.
cles, as it may be more difficult to
blades when they show signs of
see at night, especially in areas
streaking or missing areas on the
where there may not be any street
windshield.
lights.
•
Be sure your tires have enough
•
Adjust your mirrors to reduce the
tread. If your tires do not have
glare from other driver's head-
enough tread, making a quick stop
lamps.
on wet pavement can cause a skid
•
Keep your headlamps clean and
and possibly lead to an accident.
properly aimed. Dirty or improperly
See "Tire Tread" in chapter 7.
aimed headlamps will make it
•
Turn on your headlamps to make it
much more difficult to see at night.
easier for others to see you.
•
Avoid staring directly at the head-
•
Driving too fast through large pud-
lamps of oncoming vehicles. You
dles can affect your brakes. If you
could be temporarily blinded, and it
must go through puddles, try to
will take several seconds for your
drive through them slowly.
eyes to readjust to the darkness.
5-148
• If you believe your brakes may be
Driving in flooded areas
Fuel, engine coolant and engine
wet, apply them lightly while driv-
oil
Avoid driving through flooded areas
ing until normal braking operation
unless you are sure the water is no
Driving at higher speeds on the high-
returns.
higher than the bottom of the wheel
way consumes more fuel and is less
hub. Drive through any water slowly.
efficient than driving at a slower,
Hydroplaning
Allow adequate stopping distance
more moderate speed. Maintain a
because brake performance may be
moderate speed in order to conserve
If the road is wet enough and you are
reduced.
fuel when driving on the highway.
going fast enough, your vehicle may
have little or no contact with the road
After driving through water, dry the
Be sure to check both the engine
surface and actually ride on the
brakes by gently applying them sev-
coolant level and the engine oil
water. The best advice is SLOW
eral times while the vehicle is moving
before driving.
DOWN when the road is wet.
slowly.
Drive belt
The risk of hydroplaning increas-
5
Highway driving
A loose or damaged drive belt may
es as the depth of tire tread
overheat the engine.
decreases, refer to "Tire Tread" in
Tires
chapter 7.
Adjust the tire inflation, as specified.
Under-inflation may overheat or
damage the tires.
Do not install worn-out or damaged
tires, which may reduce traction or
fail the braking operation.
i
Information
Never over-inflate your tires above the
maximum inflation pressure, as speci-
fied on your tires.
5-149
