Driving your vehicle
If
the above situation occurs,
System warning
depress the brake pedal and release
CAUTION
EPB by pressing the EPB switch.
•
A click sound may be heard
while operating or releasing
the EPB, but these conditions
WARNING
are normal and indicate that
•
To prevent unintentional
the EPB is functioning proper-
movement when stopped and
ly.
leaving the vehicle, do not use
•
When leaving your keys with a
the shift lever in place of the
parking lot attendant or valet,
parking brake. Set the parking
make sure to inform him/her
brake and make sure the shift
how to operate the EPB.
lever is securely positioned in
•
The EPB may malfunction if
P (Park).
ODMEDR2127/ODMEDR2130
you drive with the EPB
•
Never allow anyone who is
When the conversion from Auto Hold
applied.
unfamiliar with the vehicle to
to EPB is not working properly a
•
When you automatically
touch the parking brake. If the
warning will sound and a message
release EPB by depressing
parking brake is released
will appear.
the accelerator pedal, depress
unintentionally, serious injury
it slowly.
may occur.
CAUTION
•
All vehicles should always
Depress the brake pedal when
have the parking brake fully
the above message appears for
engaged when parking to
the Auto Hold and EPB may not
avoid inadvertent movement
activate.
of the car which can injure
occupants or pedestrians.
5 40
Driving your vehicle
System warning
EPB malfunction indicator
The EPB malfunction indicator may
(if equipped)
illuminate when the ESC indicator
comes on to indicate that the ESC is
■ Type A
■ Type B
not working properly, but it does not
indicate a malfunction of the EPB.
ODMEDR2128/ODMEDR2131
•
If the EPB is applied while Auto
ODMEDR2140
Hold is activated because of ESC
This warning light illuminates if the
(Electronic Stability Control) signal,
engine start/stop button is changed
a warning will sound and a mes-
to the ON position and goes off in
sage will appear.
approximately 3 seconds if the sys-
tem is operation normally.
•
If the driver’s door is opened and
the seatbelt is not fastened while
If the EPB malfunction indicator
Auto Hold is opened, a warning will
remains on, comes on while driving,
sound and a message will appear.
or does not come on when the igni-
tion switch or the engine start/stop
button is changed to the ON position,
this indicates that the EPB may have
malfunctioned.
If this occurs, we recommend that
the system be checked by an author-
ized HYUNDAI dealer.
5
41
Driving your vehicle
Emergency braking
✽ NOTICE
CAUTION
If there is a problem with the brake
During emergency braking by the
•
The EPB warning light may
pedal while driving, emergency brak-
EPB, the parking brake warning
illuminate if the EPB switch
ing is possible by pulling up and
light will illuminate to indicate that
operates abnormally. Shut the
holding the EPB switch. Braking is
the system is operating.
engine off and turn it on again
possible only while you are holding
after a few minutes. The warn-
the EPB switch.
ing light will go off and the
CAUTION
EPB switch will operate nor-
If you continuously notice a
mally. However, if the EPB
WARNING
noise or burning smell when the
warning light is still on, we
EPB is used for emergency
Do not operate the parking
recommend that the system
brake while the vehicle is mov-
braking, we recommend that the
be checked by an authorized
system be checked by an
ing except in an emergency sit-
HYUNDAI dealer.
uation.
authorized HYUNDAI dealer.
•
If the parking brake warning
light does not illuminate or
blinks even though the EPB
switch was pulled up, the EPB
is not applied.
•
If the parking brake warning
light blinks when the EPB
warning light is on, press the
switch, then pull it up. Once
more press it back to its origi-
nal position and pull it back
up. If the EPB warning does
not go off, we recommend that
the system be checked by an
authorized HYUNDAI dealer.
5 42
Driving your vehicle
When the EPB (electric parking
AUTO HOLD (if equipped)
Set up
brake) does not release
The Auto Hold maintains the vehicle
If the EPB does not release normal-
in a standstill even though the brake
White
ly, we recommend that you contact
pedal is not depressed after the driv-
an authorized HYUNDAI dealer by
er brings the vehicle to a complete
loading the vehicle on a flatbed tow
stop by depressing the brake pedal.
truck and have the system checked.
ODM052019
1.With the driver's door, engine hood
and tailgate/trunk closed, fasten
the driver's seat belt or depress the
brake pedal and then press the
Auto Hold button. The white AUTO
HOLD indicator will come on and
the system will be in the standby
position.
5 43
Driving your vehicle
Leaving
Cancel
White
If you press the accelerator pedal
with the shift lever in R (Reverse), D
Light off
(Drive) or sports mode, the Auto
Hold will be released automatically
and the vehicle will start to move.
The indicator changes from green to
Green
white.
WARNING
When driving off from Auto
ODM052020
Hold by depressing the acceler-
2.When you stop the vehicle com-
ODM052021
ator pedal, always check the
pletely by depressing the brake
surrounding area near your
To cancel the Auto Hold operation,
pedal, the AUTO HOLD indicator
vehicle.
press the Auto Hold switch. The
changes from white to green.
Slowly depress the accelerator
AUTO HOLD indicator will go out.
3.The vehicle will remain stationary
pedal for a smooth launch.
To cancel the Auto Hold operation
even if you release the brake
when the vehicle is at a standstill,
pedal.
press the Auto Hold switch while
4.If EPB is applied, Auto Hold will be
depressing the brake pedal.
released.
5 44
Driving your vehicle
✽ NOTICE
(Continued)
In these cases, the brake warning
WARNING
•
The Auto Hold does not operate
light comes on, the AUTO HOLD
•
Press the accelerator pedal
when:
indicator changes from green to
slowly when you start the
- The driver's seat belt is unfas-
white, and a warning sounds and a
vehicle.
tened and driver's door is opened
message will appear to inform you
- The engine hood is opened when
•
For your safety, cancel the
that EPB has been automatically
the gear is in D [Drive]
Auto Hold when you drive
engaged. Before driving off again,
- The tailgate/trunk is opened
downhill or back up the vehi-
press foot brake pedal, check the
when the gear is in R [Reverse]
cle or park the vehicle.
surrounding area near your vehi-
- The shift lever is in P (Park)
cle and release parking brake
- The EPB is applied
manually with the EPB switch.
•
For your safety, the Auto Hold
•
If the AUTO HOLD indicator
automatically switches to EPB in
lights up yellow, the Auto Hold is
such cases:
not working properly. We recom-
- The driver's seat belt is unfas-
mend that you contact an author-
tened and driver's door is opened
ized HYUNDAI dealer.
- The engine hood is opened when
•
While operating Auto Hold, you
the gear is in D [Drive]
may hear mechanical noise.
- The tailgate/trunk is opened
However, it is normal operating
when the gear is in R [Reverse]
noise.
- The vehicle is in a standstill for
more than 10 minutes
- The vehicle is standing on a steep
slope
- The vehicle moved several times
(Continued)
5 45
Driving your vehicle
Anti-lock brake system (ABS)
(Continued)
CAUTION
• On roads where the road sur-
If there is a malfunction with the
WARNING
face is pitted or has different
driver’s door, engine hood or
ABS (or ESC) will not prevent
surface height.
tailgate/ trunk open detection
accidents due to improper or
system, the Auto Hold may not
The safety features of an ABS
work properly.
dangerous driving maneuvers.
(or ESC) equipped vehicle
Even though vehicle control is
should not be tested by high
We recommend that you contact
improved during emergency
speed driving or cornering. This
an authorized HYUNDAI dealer.
braking, always maintain a safe
could endanger the safety of
distance between you and
yourself or others.
objects ahead. Vehicle speeds
should always be reduced dur-
ing extreme road conditions.
The braking distance for vehicle
equipped with an anti-lock brak-
ing system
(or Electronic
Stability Control System) may
be longer than for those without
it in the following road condi-
tions.
During these conditions the
vehicle should be driven at
reduced speeds:
• Rough, gravel or snow-cov-
ered roads.
• With tire chains installed.
(Continued)
5 46
Driving your vehicle
The ABS continuously senses the
✽ NOTICE
speed of the wheels. If the wheels
A click sound may be heard in the
are going to lock, the ABS system
engine compartment when the vehi-
repeatedly modulates the hydraulic
cle begins to move after the engine is
brake pressure to the wheels.
started. These conditions are normal
When you apply your brakes under
and indicate that the anti-lock brake
conditions which may lock the
system is functioning properly.
wheels, you may hear a
“tik-tik’’
sound from the brakes, or feel a cor-
•
Even with the anti-lock brake sys-
responding sensation in the brake
tem, your vehicle still requires suf-
pedal. This is normal and it means
ficient stopping distance. Always
your ABS is active.
maintain a safe distance from the
W-78
In order to obtain the maximum ben-
vehicle in front of you.
efit from your ABS in an emergency
•
Always slow down when cornering.
CAUTION
situation, do not attempt to modulate
The anti-lock brake system cannot
•
If the ABS warning light is on
your brake pressure and do not try to
prevent accidents resulting from
and stays on, you may have a
pump your brakes. Press your brake
excessive speeds.
problem with the ABS. In this
pedal as hard as possible or as hard
•
On loose or uneven road surfaces,
case, however, your regular
as the situation warrants and allow
operation of the anti-lock brake
brakes will work normally.
the ABS to control the force being
system may result in a longer stop-
delivered to the brakes.
•
The ABS warning light will
ping distance than for vehicles
stay on for approximately
3
equipped with a conventional
seconds after the ignition
brake system.
switch is ON. During that time,
the ABS will go through self-
diagnosis and the light will go
off if everything is normal.
(Continued)
5 47
Driving your vehicle
(Continued)
✽ NOTICE
CAUTION
If the light stays on, you may
When you jump start your vehicle
•
When you drive on a road hav-
have a problem with your
because of a drained battery, the
ing poor traction, such as an
ABS. We recommend that you
engine may not run as smoothly and
icy road, and operate your
contact
an
authorized
the ABS warning light may turn on
brakes continuously, the ABS
HYUNDAI dealer .
at the same time. This happens
will be active continuously
because of the low battery voltage. It
and the ABS warning light
does not mean your ABS is malfunc-
may illuminate. Pull your vehi-
tioning.
cle over to a safe place and
• Do not pump your brakes!
stop the engine.
• Have the battery recharged before
•
Restart the engine. If the ABS
driving the vehicle.
warning light is off, then your
ABS system is normal.
Otherwise, you may have a
problem with the ABS. We rec-
ommend that you contact an
authorized HYUNDAI dealer.
5 48
Driving your vehicle
Electronic stability control
The Electronic Stability Control
(ESC) (if equipped)
WARNING
(ESC) system is an electronic sys-
tem designed to help the driver main-
Never drive too fast for the road
conditions or too quickly when
tain vehicle control under adverse
conditions. It is not a substitute for
cornering. Electronic stability
control (ESC) will not prevent
safe driving practices. Factors includ-
ing speed, road conditions and driv-
accidents. Excessive speed in
turns, abrupt maneuvers and
er steering input can all affect
whether ESC will be effective in pre-
hydroplaning on wet surfaces
can still result in serious acci-
venting a loss of control. It is still your
responsibility to drive and corner at
dents. Only a safe and attentive
driver can prevent accidents by
reasonable speeds and to leave a
sufficient margin of safety.
avoiding maneuvers that cause
the vehicle to lose traction.
When you apply your brakes under
ODM052046
Even with ESC installed, always
conditions which may lock the
follow all the normal precau-
wheels, you may hear a
“tik-tik’’
The Electronic Stability Control
tions for driving - including driv-
sound from the brakes, or feel a cor-
(ESC) system is designed to stabi-
ing at safe speeds for the condi-
responding sensation in the brake
lize the vehicle during cornering
tions.
pedal. This is normal and it means
maneuvers.
your ESC is active.
ESC checks where you are steering
and where the vehicle is actually
✽ NOTICE
going.
A click sound may be heard in the
ESC applies the brakes at individual
engine compartment when the vehi-
wheels and intervenes with engine
cle begins to move after the engine is
management system to stabilize the
started. These conditions are normal
vehicle.
and indicate that the Electronic
Stability Control
(ESC) System is
functioning properly.
5 49
Driving your vehicle
ESC operation
When operating
ESC operation off
ESC ON condition
When the ESC is in opera-
ESC OFF state
• When the ignition is turned
tion, ESC indicator light
This car has 2 kinds of ESC
ON, ESC and ESC OFF
blinks.
off states.
-
indicator lights illuminate
• When the Electronic
If the engine stops when
for approximately
3 sec-
Stability Control is operating
ESC is off, ESC remains off.
onds, then ESC is turned
properly, you can feel a
Upon restarting the engine,
on.
slight pulsation in the vehi-
the ESC will automatically
• Press the ESC OFF but-
cle. This is only the effect of
turn on again.
ton for at least half a sec-
brake control and indicates
ond after turning the igni-
nothing unusual.
• ESC off state 1
tion ON to turn ESC off.
• When moving out of the
To cancel ESC operation,
(ESC OFF indicator will
mud or slippery road, the
press the ESC OFF button
illuminate). To turn the
engine rpm (revolution per
(ESC OFF
) shortly (ESC
ESC on, press the ESC
minute) may not increase
OFF indicator light
(ESC
OFF button
(ESC OFF
even if you press the
OFF
) illuminates). At this
indicator light will go off).
accelerator pedal deeply.
state, the engine control
• When starting the engine,
This is to maintain the sta-
function does not operate. It
you may hear a slight tick-
bility and traction of the
means the traction control
ing sound. This is the ESC
vehicle and does not indi-
function does not operate.
performing an automatic
cate a problem.
Brake control function only
system self-check and
operates.
does not indicate a prob-
lem.
5 50
Driving your vehicle
• ESC off state 2
Indicator light
CAUTION
To cancel ESC operation,
press the ESC OFF button
■ ESC indicator light
Driving with varying tire or
(ESC OFF
) for more than 3
wheel sizes may cause the ESC
seconds. ESC OFF indicator
system to malfunction. When
light (ESC OFF
) illuminates
replacing tires, make sure they
and ESC OFF warning chime
are the same size as your origi-
will sound. At this state, the
■ ESC OFF indicator light
nal tires.
engine control function and
brake control function do not
operate. It means the car sta-
WARNING
bility control function does not
operate any more.
The Electronic Stability Control
When ignition switch is turned to ON,
system is only a driving aid; use
the indicator light illuminates, then
precautions for safe driving by
goes off if the ESC system is operat-
slowing down on curved,
ing normally.
snowy, or icy roads. Drive slow-
ly and don’t attempt to acceler-
The ESC indicator light blinks when-
ate whenever the ESC indicator
ever ESC is operating or illuminates
light is blinking, or when the
when ESC fails to operate.
road surface is slippery.
ESC OFF indicator light comes on
when the ESC is turned off with the
button.
5 51
Driving your vehicle
ESC OFF usage
✽ NOTICE
Vehicle stability management
When driving
•
When operating the vehicle on a
(VSM) (if equipped)
• ESC should be turned on for daily
dynamometer, ensure that the
This system provides further
driving whenever possible.
ESC is turned off (ESC OFF light
enhancements to vehicle stability
illuminated). If the ESC is left on,
and steering responses when a vehi-
• To turn ESC off while driving, press
it may prevent the vehicle speed
cle is driving on a slippery road or a
the ESC OFF button while driving
from increasing, and result in false
vehicle detected changes in coeffi-
on a flat road surface.
diagnosis.
cient of friction between right wheels
•
Turning the ESC off does not
and left wheels when braking.
affect ABS or brake system opera-
WARNING
tion.
Never press the ESC OFF but-
VSM operation
ton while ESC is operating (ESC
When the VSM is operating:
indicator light blinks).
• ESC (Electronic Stability Control)
If ESC is turned off while ESC is
(
) light will blink.
operating, the vehicle may slip
• The steering wheel may be con-
out of control.
trolled.
When the vehicle stability manage-
ment is operating properly, you can
feel a slight pulsation in the vehicle.
This is only the effect of brake control
and indicates nothing unusual.
5 52
Driving your vehicle
The VSM does not operate when:
Malfunction indicator
WARNING
• Driving on bank road such as gra-
The VSM can be deactivated even if
dient or incline
you don’t cancel the VSM operation
•
The
Vehicle
Stability
by pressing the ESC OFF button. It
Management system is not a
• Driving rearward
indicates that a malfunction has
substitute for safe driving
• ESC OFF indicator light
(
)
been detected somewhere in the
practices but a supplemen-
remains on the instrument
EPS (Electronic Power Steering)
tary function only. It is the
cluster
system or VSM system. If the ESC
responsibility of the driver to
• EPS (Electronic Power Steering)
indicator light (
) or EPS warning
always check the speed and
indicator light remains on the
light remains on, we recommend that
the distance to the vehicle
instrument cluster
you contact an authorized HYUNDAI
ahead. Always hold the steer-
dealer.
ing wheel firmly while driving.
VSM operation off
•
Your vehicle is designed to
activate according to the dri-
If you press the ESC OFF button to
✽ NOTICE
ver’s intention, even with the
turn off the ESC, the VSM will also
• The VSM is designed to function
VSM installed. Always follow
cancel and the ESC OFF indicator
above approximately 15 km/h (9
all the normal precautions for
light (
) illuminates.
mph) on curves.
driving at safe speeds for the
To turn on the VSM, press the button
• The VSM is designed to function
conditions - including driving
again. The ESC OFF indicator light
above approximately 30 km/h (18
in inclement weather and on a
goes out.
mph) when a vehicle is braking on
slippery road.
a split-mu road. The split-mu road
•
Driving with varying tire or
is made of surfaces which have dif-
wheel sizes may cause the
ferent friction forces.
VSM system to malfunction.
When replacing tires, make
sure they are the same size as
your original tires.
5 53
Driving your vehicle
Trailer stability assist (TSA)
Trailer stability assist system contin-
Hill-start assist control (HAC)
(if equipped)
uously analyzes the vehicle and trail-
(if equipped)
er instability. When the Trailer stabili-
Trailer stability assist is operated as
A vehicle has the tendency to slip
ty assist system detects some sway,
vehicle stability control system.
back on a steep hill when it starts to
the brakes are applied automatically
Trailer stability assist system has an
go after stopping. The Hill-start
to stabilize the vehicle on the front
effort to stabilize the vehicle and trail-
Assist Control
(HAC) prevents the
wheel. However, if it is not enough to
er when the trailer sways or oscil-
vehicle from slipping back by operat-
stabilize, the brakes are applied on
lates. There are various reasons
ing the brakes automatically for
all wheels automatically and engine
making vehicle sway and oscillate.
about
2 seconds. The brakes are
power is properly reduced. When the
Almost case it happens at high
released when the accelerator pedal
vehicle is stable from swaying, trailer
speed however, if the trailer is affect-
is depressed or after about 2 sec-
stability assist system does not oper-
ed by crosswinds, buffeting, and
onds.
ate.
improper overloading, it may be a
risk of swaying.
WARNING
The HAC is activated only for
Factors of swaying such as:
about 2 seconds, so when the
- High speed
vehicle is starting off always
- Strong crosswinds
depress the accelerator pedal.
- Improper overloading
- Sudden controlling of steering
wheel
✽ NOTICE
- Uneven road
• The HAC does not operate when
the transaxle shift lever is in the P
(Park) or N (Neutral) position.
• The HAC activates even though
the ESC is off but it does not acti-
vate when the ESC has malfunc-
tioned.
5 54
Driving your vehicle
Emergency Stop Signal (ESS)
Downhill brake control (DBC)
CAUTION
(if equipped)
(if equipped)
The Emergency Stop Signal
The Emergency Stop Signal system
(ESS) system will not work if the
alerts the driver behind by blinking
hazard warning flasher is
the stop light when the vehicle is
already on.
braked rapidly and severely.
The system is activated when:
• The vehicle suddenly stops (vehi-
cle speed is over 55km/h and the
vehicle deceleration at greater
than 7 m/s2)
• The ABS is activating
When the vehicle speed is under 40
ODM052047
km/h and the ABS deactivates or the
sudden stop situation is over, the
❈ The actual feature in the vehicle may
stop light blinking will stop. Instead,
differ from the illustration.
the hazard warning flasher will turn
on automatically.
The Downhill Brake Control (DBC)
The hazard warning flasher will turn
supports the driver come down a
off when vehicle speed is over
steep hill without the driver depress-
10km/h after the vehicle has
ing the brake pedal. It slows down
stopped. Also, it will turn off when the
the vehicle under 10 km/h (6.3 mph)
vehicle is driven at low speed for
and lets the driver concentrate on
some time. You can turn it off manu-
steering the vehicle.
ally by pushing the hazard warning
flasher switch.
DBC defaults to the OFF position
whenever the ignition is turned on.
The DBC can be turned on or off by
pushing the button.
5 55
Driving your vehicle
Indicator
✽ NOTICE
Mode
Description
light
•
The DBC does not turn ON in the
Press the DBC button when the vehicle speed is under
P (Park) position.
•
The DBC may not activate if the
40 km/h (25 mph). The DBC system will turn ON and enter the
Green light
Standby
standby mode.
ESC (or BAS) is activated.
illuminated
•
Noise or vibration may occur from
The system maintains the standby mode when vehicle speed is
under 60km/h.
the brakes when the DBC is acti-
vated.
In the standby mode, DBC will activate automatically under
•
The rear stop light comes on when
Green light
the following conditions:
Activated
the DBC is activated.
blink
• The incline is over a certain degree.
•
On a very steep hill even though
• The brake pedal or accelerator pedal is not depressed.
the brake pedal or accelerator
pedal is depressed the DBC may
The DBC will turn OFF under the following conditions:
Green light
not deactivate.
OFF
• The DBC button is pressed again.
OFF
•
Always turn OFF the DBC on nor-
• The vehicle speed is over 60 km/h (38 mph).
mal roads. The DBC might acti-
vate from the standby mode dur-
In the activated mode, the DBC will temporarily deactivate
ing abrupt corning or driving over
under the following conditions:
speed bumps.
Temporarily
Green light
• The hill is not steep enough.
deactivated
illuminated
• The brake pedal or accelerator pedal is depressed.
If the above conditions are gone, the DBC will automatically
activate again.
WARNING
If the DBC yellow indicator light illuminates, the system has over-
heated or there is an operational problem. The DBC will not activate.
If the DBC yellow indicator light illuminates even though the DBC sys-
tem has been cooled, we recommend that the system be checked by
an authorized HYUNDAI dealer.
5 56
