Hyundai Grand Santa Fe (2016 year). Instruction - part 7
Features of your vehicle
DOOR LOCKS
Operating door locks from
•
Turn the key toward the rear of the
Transmitter/Smart key
outside the vehicle
vehicle to lock and toward the front
•
Doors can be locked and unlocked
of the vehicle to unlock.
Mechanical key
with the transmitter or smart key.
•
If you lock/unlock the driver’s door
■ Type A
•
Doors can be locked and unlocked
with a key, only the driver’s door
pressing the button of the outside
will lock/unlock.
door handle with the smart key in
•
Once the door is unlocked, it may
your possession. (vehicles equipped
be opened by pulling the door han-
with smart key system)
Lock
dle.
•
Once the doors are unlocked, they
Unlock
•
When closing the door, push the
may be opened by pulling the door
door by hand. Make sure that
handle.
doors are closed securely.
•
When closing the door, push the
door by hand. Make sure that
ODM042011
doors are closed securely.
■ Type B
✽ NOTICE
• In cold and wet climates, door lock
Lock
and door mechanisms may not
Unlock
work properly due to freezing con-
ditions.
• If the door is locked/unlocked
multiple times in rapid succession
with either the vehicle key or door
ODMECO2035
lock switch, the system may stop
operating temporarily in order to
protect the circuit and prevent
damage to system components.
4 18
Features of your vehicle
Operating door locks from
•
If the inner door handle of the front
WARNING
inside the vehicle
door is pulled when the door lock
button is in lock position, the button
•
If you don't close the door
With the door lock button
securely, the door may open
is unlocked and door opens.
(Except Europe)
again.
•
Be careful that someone's
•
If the inner door handle of any door
is pulled when the door lock button
body and hands are not
trapped when closing the door.
is in lock position, the button is
unlocked and door opens.
(For
Lock
Europe )
Unlock
•
Front doors cannot be locked if the
ignition key is in the ignition switch
and any front door is opened.
(Except Europe)
•
Doors cannot be locked if the igni-
ODM042013
tion key is in the ignition switch and
•
To unlock a door, push the door
any door is opened. (For Europe)
lock button (1) to the “Unlock” posi-
•
Doors cannot be locked if the
tion. The red mark (2) on the button
will be visible.
smart key is in the vehicle and any
door is opened.
•
To lock a door, push the door lock
button (1) to the “Lock” position. If
the door is locked properly, the red
mark (2) on the door lock button
will not be visible.
•
To open a door, pull the door han-
dle (3) outward.
4 19
Features of your vehicle
With central door lock switch
• If a door is opened, the doors will
not lock when the front portion (1)
WARNING - Doors
Driver’s door
of the central door lock switch is
•
The doors should always be
pressed. (For Europe)
fully closed and locked while
• If the smart key is in the vehicle
the vehicle is in motion to pre-
and a door is opened, the doors
vent accidental opening of the
will not lock when the front portion
door. Locked doors will also
(1) of central door lock switch is
discourage potential intruders
pressed.
when the vehicle stops or
slows down.
•
Be careful when opening
✽ NOTICE
doors and watch for vehicles,
Once the doors are locked with the
motorcycles, bicycles or
ODM042014
transmitter or smart key, the doors
pedestrians approaching the
Operate by depressing the central
cannot be unlocked with the central
vehicle in the path of the door.
door lock switch.
door lock/unlock switch.
Opening a door when some-
• When pushing down on the front
thing is approaching can
portion (1) of the switch, all vehicle
cause damage or injury.
doors will lock.
• When pushing down on the rear
portion (2) of the switch, all vehicle
doors will unlock.
• If the key is in the ignition switch
and a front door is opened, the
doors will not lock when the front
portion
(1) of central door lock
switch is pressed. (Except Europe)
4 20
Features of your vehicle
Door lock/unlock features
WARNING - Unlocked
WARNING - Unattended
Impact sensing door unlock sys-
vehicles
children
tem
Leaving your vehicle unlocked
An enclosed vehicle can
All doors will automatically unlock
can invite theft or possible harm
become extremely hot, causing
when an impact causes the air bags
to you or others from someone
death or severe injury to unat-
to deploy.
hiding in your vehicle while you
tended children or animals who
are gone. Always remove the
cannot escape the vehicle.
Speed sensing door lock system
ignition key, engage the parking
Furthermore, children might
(if equipped)
brake, close all windows and
operate features of the vehicle
lock all doors when leaving
that could injure them, or they
All doors will automatically lock after
your vehicle unattended.
could encounter other harm,
the vehicle speed exceeds 15 km/h.
possibly from someone gaining
entry to the vehicle. Never leave
You can activate or deactivate the
children or animals unattended
auto door lock/unlock features in the
in your vehicle.
vehicle. Refer to "User setting" in this
section.
4 21
Features of your vehicle
Child-protector rear door lock
3. Close the rear door.
To open the rear door, pull the out-
side door handle.
Even though the doors may be
unlocked, the rear door will not open
by pulling the inner door handle until
rear door child safety lock is unlocked.
WARNING - Rear door
locks
If children accidentally open the
rear doors while the vehicle is
ONCNCO2015
in motion, they could fall out
The child safety lock is provided to
and be severely injured or
help prevent children from acciden-
killed. To prevent children from
tally opening the rear doors from
opening the rear doors from the
inside the vehicle. The rear door
inside, the rear door safety
safety locks should be used whenev-
locks should be used whenever
er children are in the vehicle.
children are in the vehicle.
1. Open the rear door.
2. Insert a key (or screwdriver) into
the hole
(1) and turn it to the
“lock(
)” position. When the child
safety lock is in the lock position,
the rear door will not open even
though the inner door handle is
pulled inside the vehicle.
4 22
Features of your vehicle
TAILGATE
Non-powered tailgate
• If unlocked, the tailgate can be
opened by pressing the handle and
WARNING
Opening the tailgate
pulling it up.
The tailgate swings upward.
• Once the tailgate is opened and
Make sure no objects or people
then closed, the tailgate locks
are near the rear of the vehicle
automatically. (All doors must be
when opening the tailgate.
locked.)
✽ NOTICE
CAUTION
In cold and wet climates, door lock
Make certain that you close the
and door mechanisms may not work
tailgate before driving your
properly due to freezing conditions.
vehicle. Possible damage may
occur to the tailgate lift cylin-
ONCNCO2002
ders and attaching hardware if
the tailgate is not closed prior to
•
The tailgate is locked or unlocked
driving.
when all doors are locked or
unlocked with the key, transmitter,
smart key or central door
lock/unlock switch.
•
Only the tailgate is unlocked if the
tailgate unlock button on the trans-
mitter or smart key is pressed for
approximately 1 second, or the tail-
gate handle button is pressed
when the smart key is detected.
4 23
Features of your vehicle
Closing the tailgate
WARNING
WARNING - Exhaust
Make sure your hands, feet and
fumes
other parts of your body are
If you drive with the tailgate
safely out of the way before
opened, you will draw dangerous
closing the tailgate.
exhaust fumes into your vehicle
which can cause serious injury
or death to vehicle occupants.
CAUTION
If you must drive with the tail-
Make sure nothing is near the
gate opened, keep the air vents
and all windows open so that
tailgate latch and striker while
closing the tailgate. It may dam-
additional outside air comes
into the vehicle.
ONCNCO2003
age the tailgate's latch.
Lower and push down the tailgate
firmly. Make sure that the tailgate is
WARNING - Rear cargo
securely latched.
area
Occupants should never ride in
the rear cargo area where no
restraints are available. To avoid
injury in the event of an acci-
dent or sudden stops, occu-
pants should always be proper-
ly restrained.
4 24
Features of your vehicle
Power tailgate (if equipped)
WARNING
■ Type A
Never leave children or animals
unattended in your vehicle.
Children or animals might oper-
ate the power tailgate that could
result in injury to themselves or
others, or damage the vehicle.
WARNING
ONCDCO3045
ONCNCO2005
Make sure there are no people
■ Type B
or objects around the tailgate
before operating the power tail-
gate. Wait until the tailgate is
opened fully and stopped before
loading or unloading cargo or
passengers from the vehicle.
CAUTION
ONCDCO3044
ONCNCO2006
Do not close or open the power
tailgate manually. This may
(1) Power tailgate open/close button
✽ NOTICE
cause damage to the power tail-
(2) Power tailgate handle switch
The power tailgate operates when the
gate. If it is necessary to close
(3) Power tailgate close button
automatic shift lever is in P (Park).
or open the power tailgate man-
ually when the battery is dis-
charged or disconnected, do
not apply excessive force.
4 25
Features of your vehicle
Opening the tailgate
■ Type A
■ Type A
ONCDCO3045
■ Type B
ONCNCO3044
ONCNCO2005
■ Type B
• Press the tailgate handle switch
carrying the smart key with you.
ONCDCO3044
• Press the power tailgate open but-
ONCNCO3045
ton for approximately one second.
The power tailgate will open automat-
For emergency stop while operating,
ically by doing one of the following:
press the power tailgate open button
• Press the tailgate unlock button on
shortly.
the transmitter or smart key for
approximately one second.
4 26
Features of your vehicle
Closing the tailgate
Power tailgate non-opening
conditions
■ Type A
The power tailgate will not open or
close automatically, when the vehicle
is moving more than 3km/h (2mph).
WARNING
The chime will sound continu-
ously if you drive over 3km/h
(2mph) with the tailgate opened.
ONCDCO3045
ONCNCO2006
Stop your vehicle immediately
■ Type B
at a safe place and check if your
• Press the power tailgate close but-
tailgate is opened.
ton for approximately one second
when the tailgate is opened.
The tailgate will close and lock
CAUTION
automatically.
Operating the power tailgate
more than 5 times continuously
WARNING
could cause damages to the
The chime will sound and the
operating motor. In this case,
ONCDCO3044
hazard warning flasher will blink
the system enters into a thermal
• Press the power tailgate close but-
10 times if you drive with the
protection mode. In thermal pro-
ton for approximately one second
tailgate closed but not locked.
tection mode, the power tailgate
when the tailgate is opened.
can not operate and the chime
Stop your vehicle immediately
The tailgate will close and lock
at a safe place and check if your
will sound for 3 times by any
switch inputs. Leave your power
automatically.
tailgate is securely locked.
tailgate system for rest about 1
For emergency stop while operating,
minute and then operate.
press the power tailgate close button
shortly.
4
27
Features of your vehicle
✽ NOTICE
Automatic reversal
However, if the resistance is weak
such as from an object that is thin or
•
The power tailgate can be operat-
soft, or the tailgate is near the latched
ed when the engine is not running.
position, the automatic stop and rever-
However the power tailgate opera-
sal may not detect the resistance.
tion consumes large amounts of
vehicle electric power. To prevent
If the automatic reversal feature
the battery from being discharged,
operates continuously more than
do not operate it excessively e.g.:
twice during opening or closing oper-
more than approximately 10 times
ation, the power tailgate may stop at
repeatedly.
that position. At this time, close the
•
To prevent the battery from being
tailgate manually and operate the
discharged, do not leave the power
tailgate automatically again.
tailgate in the open position for a
ONCNCO2007
long lime.
During power opening and closing if
WARNING
•
Do not modify or repair any part
of the power tailgate by yourself.
the power tailgate is blocked by an
Never intentionally place any
We recommend that you contact
object or part of the body, the power
object or part of your body in
an authorized HYUNDAI dealer.
tailgate will detect the resistance.
the path of the power tailgate to
•
When jacking up the vehicle to
• If the resistance is detected while
make sure the automatic rever-
change a tire or repair the vehicle,
opening the tailgate, it will stop and
sal operates.
do not operate the power tailgate.
move in the opposite direction.
This could cause the power tail-
• If the resistance is detected while
gate to operate improperly.
closing the tailgate, it will stop and
CAUTION
•
In cold and wet climates, the
move in the opposite direction.
Do not put heavy stuffs on the
power tailgate may not work prop-
power tailgate before you oper-
erly due to freezing conditions.
ate the power tailgate.
Additional weight on tailgate
could cause damages to the
system.
4 28
Features of your vehicle
How to reset the power tailgate
Power tailgate opening height
user setting
WARNING - Exhaust
If the battery has been discharged or
disconnected, or if the related fuse has
fumes
been replaced or disconnected, for the
If you drive with the tailgate
power tailgate to operate normally,
opened, you will draw dangerous
reset the power tailgate as follow:
exhaust fumes into your vehicle
which can cause serious injury
1. Put the shift lever in P (Park).
or death to vehicle occupants.
2. While pressing the tailgate close
If you must drive with the tail-
button, press the tailgate handle
switch for more than 3 seconds.
gate opened, keep the air vents
and all windows open so that
(the chime will sound)
additional outside air comes
3. Close the tailgate manually.
into the vehicle.
ONCNCO2006
If the power tailgate does not work
properly after the above procedure,
The driver may set the height of a
WARNING - Rear cargo
we recommend that the system be
fully opened tailgate by following the
area
checked by an authorized HYUNDAI
below instruction.
Occupants should never ride in
dealer.
1. Position the tailgate manually to
the rear cargo area where no
the height you prefer.
restraints are available. To avoid
2. Press the tailgate close button for
✽ NOTICE
injury in the event of an accident
more than 3 seconds.
If the power tailgate does not oper-
or sudden stops, occupants
ate normally, first check the follow-
3. Close the tailgate manually after
should always be properly
ing condition before using the power
hearing the buzzer sound.
restrained.
tailgate.
Check if the shift lever is in P (Park)
The tailgate will open to the height
for automatic transaxle vehicles.
the driver has set up.
4 29
Features of your vehicle
Smart tailgate (if equipped)
How to use the Smart Tailgate
1. Setting
The tailgate can be opened with no-
To activate the Smart Tailgate, go to
touch activation satisfying all the
User Settings Mode and select
conditions below.
Smart Tailgate on the LCD display.
• After
15 seconds when all doors
are closed and locked
❈ For more details, refer to "LCD
• Positioned in the detecting area for
Display" in this chapter.
more than 3 seconds.
✽ NOTICE
• The Smart Tailgate does not oper-
ate when:
ONC045077
- The smart key is detected within
15 seconds after the doors are
On the vehicle equipped with a smart
closed and locked, and is contin-
key, the tailgate can be opened with
uously detected.
no-touch activation using the Smart
- The smart key is detected within
tailgate system.
15 seconds after the doors are
closed and locked, and
1.5 m
(60 in.) from the front door han-
dles. (for vehicles equipped with
Welcome Light)
- A door is not locked or closed.
- The smart key is in the vehicle.
4 30
Features of your vehicle
WARNING
•
Make certain that you close
the tailgate before driving
your vehicle.
•
Make sure there are no people
or objects around the tailgate
before opening or closing the
tailgate.
•
Make sure objects in the rear
cargo area do not come out
ONC045078
ONC045079
when opening the tailgate on
2. Detect and Alert
3. Automatic opening
the slope way. It may cause
If you are positioned in the detecting
The hazard warning lights will blink
serious injury.
area (50 ~100 cm (20 ~ 40 in.) behind
and chime will sound 2 times and
•
Make sure to deactivate the
the vehicle) carrying a smart key, the
then the tailgate will slowly open.
Smart tailgate function when
hazard warning lights will blink and
washing your vehicle.
chime will sound for about 3 seconds
Otherwise, the tailgate may
to alert you the smart key has been
open inadvertently.
detected and the tailgate will open.
•
The key should be kept out of
reach of children. Children
✽ NOTICE
may inadvertently open the
Do not approach the detecting area
Smart Tailgate while playing
if you do not want the tailgate to
around the rear area of the
open. If you have unintentionally
vehicle.
entered the detecting area and the
hazard warning lights and chime
starts to operate, leave the detecting
area with the smart key. The tailgate
will stay closed.
4
31
Features of your vehicle
How to deactivate the Smart
✽ NOTICE
Detecting area
Tailgate function using the smart
•
If you press the door unlock but-
key
ton (2), the Smart Tailgate func-
tion will be deactivated temporar-
■ Smart key
ily. But, if you do not open any
door for 30 seconds, the Smart
Tailgate function will be activated
again.
•
If you press the tailgate open but-
ton (3) for more than 1 second, the
tailgate opens.
•
If you press the door lock button
(1) or tailgate open button
(3)
ONC045080
when the Smart Tailgate function
is not in the Detect and Alert stage,
•
The Smart Tailgate operates with a
ODMECO3030
the Smart Tailgate function will
welcome alert if the smart key is
1. Door lock
not be deactivated.
detected within 50 ~ 100 cm (20 ~
•
In case you have deactivated the
40 in.) from the tailgate.
2. Door unlock
Smart Tailgate function by press-
•
The alert stops at once if the smart
3. Tailgate open
ing the smart key button and
key is positioned outside the
opened a door, the Smart Tailgate
detecting area during the Detect
If you press any button of the smart
function can be activated again by
and Alert stage.
key during the Detect and Alert
closing and locking all doors.
stage, the Smart Tailgate function
will be deactivated.
Make sure to be aware of how to
deactivate the Smart Tailgate func-
tion for emergency situations.
4 32
Features of your vehicle
✽ NOTICE
Emergency tailgate safety
release
WARNING
•
The Smart Tailgate function will
not work if any of the following
•
For emergencies, be fully
occurs:
aware of the location of the
- The smart key is close to a radio
emergency tailgate safety
transmitter such as a radio sta-
release lever in the vehicle
tion or an airport which can
and how to open the tailgate if
interfere with normal operation
you are accidentally locked in
of the transmitter.
the luggage compartment.
- The smart key is near a mobile
•
No one should be allowed to
two way radio system or a cellu-
occupy the luggage compart-
lar phone.
ment of the vehicle at any time.
- Another vehicle's smart key is
The luggage compartment is a
being operated close to your
very dangerous location in the
ONCNCO2004
vehicle.
event of a crash.
•
The detecting range may decrease
Your vehicle is equipped with the
•
Use the release lever for
or increase when :
emergency tailgate safety release
emergencies only. Use with
- One side of the tire is raised to
lever located on the bottom of the
extreme caution, especially
replace a tire or to inspect the
tailgate. When someone is inadver-
while the vehicle is in motion.
vehicle.
tently locked in the luggage compart-
- The vehicle is slantingly parked
ment. The tailgate can be opened by
on a slope or unpaved road, etc.
doing as follows:
1. Remove the cover.
2. Push the release lever to the right.
3. Push up the tailgate.
4 33
Features of your vehicle
WINDOWS
(1) Driver’s door power window
switch
(2) Front passenger’s door power
window switch
(3) Rear door (left) power window
switch
(4) Rear door (right) power window
switch
(5) Window opening and closing
(6) Automatic power window
up*/down*
(7) Power window lock switch
*: if equipped
✽ NOTICE
In cold and wet climates, power win-
dows may not work properly due to
freezing conditions.
OANNCO43005
4 34
