Hyundai Genesis (2016 year). Instruction - part 23
Maintenance
Normal maintenance schedule
7,500 miles (12,000 km) or 6 months
15,000 miles (24,000 km) or 12 months
❑ Rotate tires
❑ Rotate tires
❑ Inspect air cleaner filter
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Replace engine oil and filter
❑ Inspect air conditioning refrigerant
(7,500 miles (12,000 km) or 12 months)
❑ Inspect brake hoses and lines
❑ Add fuel additives *1
❑ Inspect drive shafts and boots
(7,500 miles (12,000 km) or 12 months)
❑ Inspect exhaust pipe and muffler
❑ Inspect front brake disc/pad, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pad
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Replace climate control air filter
(for evaporator and blower unit)
❑ Replace engine oil and filter
(15,000 miles (24,000 km) or 24 months)
❑ Add fuel additives *1
(15,000 miles (24,000 km) or 24 months)
7-10
Normal maintenance schedule
22,500 miles (36,000 km) or 18 months
30,000 miles (48,000 km) or 24 months
❑ Rotating tires
❑ Rotate tires
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect air conditioning refrigerant
❑ Replace engine oil and filter
❑ Inspect brake hoses and lines
(22,500 miles (36,000 km) or 36 months)
❑ Inspect drive shafts and boots
❑ Add fuel additives *1
❑ Inspect exhaust pipe and muffler
(22,500 miles (36,000 km) or 36 months)
❑ Inspect front brake disc/pads, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect brake fluid
❑ Inspect fuel filter *2
❑ Inspect fuel lines, fuel hoses and connections
❑ Inspect fuel tank air filter *2
❑ Inspect parking brake
7
❑ Inspect vapor hose and fuel filler cap, fuel tank
❑ Replace climate control air filter
(for evaporator and blower unit)
❑ Replace air cleaner filter
❑ Replace engine oil and filter
(30,000 miles (48,000 km) or 48 months)
❑ Add fuel additives *1
(30,000 miles (48,000 km) or 48 months)
7-11
Maintenance
Normal maintenance schedule
37,500 miles (60,000 km) or 30 months
45,000 miles (72,000 km) or 36 months
❑ Rotate tires
❑ Rotate tires
❑ Inspect air cleaner filter
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect front(AWD)/rear differential oil *3
❑ Inspect air conditioning refrigerant
(Inspect 37,500 miles (60,000km) or 48months)
❑ Inspect brake hoses and lines
❑ Replace engine oil and filter
❑ Inspect drive shafts and boots
(37,500 miles (60,000 km) or 60 months)
❑ Inspect exhaust pipe and muffler
❑ Add fuel additives *1
❑ Inspect front brake disc/pads, calipers
(37,500 miles (60,000 km) or 60 months)
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Replace climate control air filter
(for evaporator and blower unit)
❑ Replace engine oil and filter
(45,000 miles (72,000 km) or 72 months)
❑ Add fuel additives *1
(45,000 miles (72,000 km) or 72 months)
7-12
Normal maintenance schedule
52,500 miles (84,000 km) or 42 months
60,000 miles (96,000 km) or 48 months
❑ Rotating tires
❑ Rotate tires
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect air conditioning refrigerant
❑ Replace engine oil and filter
❑ Inspect brake hoses and lines
(52,500 miles (84,000 km) or 84 months)
❑ Inspect drive shafts and boots
❑ Add fuel additives *1
❑ Inspect exhaust pipe and muffler
(52,500 miles (84,000 km) or 84 months)
❑ Inspect front brake disc/pads, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect brake fluid
❑ Inspect fuel filter *2
❑ Inspect fuel lines, fuel hoses and connections
❑ Inspect fuel tank air filter *2
❑ Inspect parking brake
7
❑ Inspect vapor hose and fuel filler cap, fuel tank
❑ Inspect drive belts *5
(First, 60,000 miles (96,000 km) or 72 months
after every 15,000 miles (24,000 km) or 24 months)
❑ Inspect valve clearance (Lambda Engine) *4
(Every 60,000 miles (96,000 km) or 72 months)
(Continued)
7-13
Maintenance
Normal maintenance schedule
(Continued)
67,500 miles (108,000 km) or 54 months
❑ Replace climate control air filter
❑ Rotating tires
(for evaporator and blower unit)
❑ Inspect air cleaner filter
❑ Replace air cleaner filter
❑ Inspect vacuum hose
❑ Replace engine oil and filter
❑ Replace engine oil and filter
(60,000 miles (96,000 km) or 96 months)
(67,500 miles (108,000 km) or 108 months)
❑ Add fuel additives *1
❑ Add fuel additives *1
(60,000 miles (96,000 km) or 96 months)
(67,500 miles (108,000 km) or 108 months)
7-14
Normal maintenance schedule
75,000 miles (120,000 km) or 60 months
82,500 miles (132,000 km) or 66 months
❑ Rotate tires
❑ Rotating tires
❑ Inspect air cleaner filter
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect air conditioning refrigerant
❑ Replace engine oil and filter
❑ Inspect brake hoses and lines
(82,500 miles (132,000 km) or 132 months)
❑ Inspect drive shafts and boots
❑ Add fuel additives *1
❑ Inspect exhaust pipe and muffler
(82,500 miles (132,000 km) or 132 months)
❑ Inspect front brake disc/pads, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect drive belts *5
(First, 60,000 miles (96,000 km) or 72 months
after every 15,000 miles (24,000 km) or 24 months)
❑ Inspect front(AWD)/rear differential oil *3
7
(Inspect 75,000 miles (120,000km) or 96months)
❑ Replace climate control air filter
(for evaporator and blower unit)
❑ Replace engine oil and filter
(75,000 miles (120,000 km) or 120 months)
❑ Add fuel additives *1
(75,000 miles (120,000 km) or 120 months)
7-15
Maintenance
Normal maintenance schedule
90,000 miles (144,000 km) or 72 months
(Continued)
❑ Rotate tires
❑ Replace air cleaner filter
❑ Inspect vacuum hose
❑ Replace engine oil and filter
❑ Inspect air conditioning refrigerant
(90,000 miles (144,000 km) or 144 months)
❑ Inspect brake hoses and lines
❑ Add fuel additives *1
❑ Inspect drive shafts and boots
(90,000 miles (144,000 km) or 144 months)
❑ Inspect exhaust pipe and muffler
❑ Inspect front brake disc/pads, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect brake fluid
❑ Inspect fuel filter *2
❑ Inspect fuel lines, fuel hoses and connections
❑ Inspect fuel tank air filter *2
❑ Inspect parking brake
❑ Inspect vapor hose and fuel filler cap, fuel tank
❑ Inspect drive belts *5
(First, 60,000 miles (96,000 km) or 72 months
after every 15,000 miles (24,000 km) or 24 months)
❑ Replace climate control air filter
(for evaporator and blower unit)
(Continued)
7-16
Normal maintenance schedule
97,500 miles (156,000 km) or 78 months
105,000 miles (168,000 km) or 84 months
❑ Rotating tires
❑ Rotate tires
❑ Inspect air cleaner filter
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Replace engine oil and filter
❑ Inspect air conditioning refrigerant
(97,500 miles (156,000 km) or 156 months)
❑ Inspect brake hoses and lines
❑ Replace spark plugs (iridium coated)
❑ Inspect drive shafts and boots
❑ Add fuel additives *1
❑ Inspect exhaust pipe and muffler
(97,500 miles (156,000 km) or 156 months)
❑ Inspect front brake disc/pads, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect drive belts *5
(First, 60,000 miles (96,000 km) or 72 months
after every 15,000 miles (24,000 km) or 24 months)
❑ Replace climate control air filter
7
(for evaporator and blower unit)
❑ Replace engine oil and filter
(105,000 miles (168,000 km) or 168 months)
❑ Add fuel additives *1
(105,000 miles (168,000 km) or 168 months)
7-17
Maintenance
Normal maintenance schedule
112,500 miles (180,000 km) or 90 months
120,000 miles (192,000 km) or 96 months
❑ Rotating tires
❑ Rotate tires
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect air conditioning refrigerant
❑ Inspect front(AWD)/rear differential oil *3
❑ Inspect brake hoses and lines
(112,500 miles (180,000km) or 144months)
❑ Inspect drive shafts and boots
❑ Replace engine oil and filter
❑ Inspect exhaust pipe and muffler
(112,500 miles (180,000 km) or 180 months)
❑ Inspect front brake disc/pads, calipers
❑ Add fuel additives *1
❑ Inspect propeller shaft
(112,500 miles (180,000 km) or 180 months)
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect brake fluid
❑ Inspect fuel filter *2
❑ Inspect fuel lines, fuel hoses and connections
❑ Inspect fuel tank air filter *2
❑ Inspect parking brake
❑ Inspect vapor hose and fuel filler cap, fuel tank
❑ Inspect drive belts *5
(First, 60,000 miles (96,000 km) or 72 months
after every 15,000 miles (24,000 km) or 24 months)
❑ Inspect valve clearance (Lambda Engine) *4
(Every 60,000 miles (96,000 km) or 72 months)
(Continued)
7-18
Normal maintenance schedule
(Continued)
127,500 miles (204,000 km) or 102 months
❑ Replace climate control air filter
❑ Rotating tires
(for evaporator and blower unit)
❑ Inspect air cleaner filter
❑ Replace air cleaner filter
❑ Inspect vacuum hose
❑ Replace engine oil and filter
❑ Replace engine oil and filter
(120,000 miles (192,000 km) or 192 months)
(127,500 miles (204,000 km) or 204 months)
❑ Replace coolant
❑ Add fuel additives *1
(First, 120,000 miles (210,000 km) or 120 months
(127,500 miles (204,000 km) or 204 months)
after every 30,000 miles (48,000 km) or 24 months)
❑ Add fuel additives *1
(120,000 miles (192,000 km) or 192 months)
7
7-19
Maintenance
Normal maintenance schedule
135,000 miles (216,000 km) or 108 months
142,500 miles (228,000 km) or 114 months
❑ Rotate tires
❑ Rotating tires
❑ Inspect air cleaner filter
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect air conditioning refrigerant
❑ Replace engine oil and filter
❑ Inspect brake hoses and lines
(142,500 miles (228,000 km) or 228 months)
❑ Inspect drive shafts and boots
❑ Add fuel additives *1
❑ Inspect exhaust pipe and muffler
(142,500 miles (228,000 km) or 228 months)
❑ Inspect front brake disc/pads, calipers
❑ Inspect propeller shaft
❑ Inspect rear brake disc/pads
❑ Inspect steering gear box, linkage & boots/lower arm ball
joint, upper arm ball joint
❑ Inspect suspension mounting bolts
❑ Inspect drive belts *5
(First, 60,000 miles (96,000 km) or 72 months
after every 15,000 miles (24,000 km) or 24 months)
❑ Replace climate control air filter
(for evaporator and blower unit)
❑ Replace engine oil and filter
(135,000 miles (216,000 km) or 216 months)
❑ Add fuel additives *1
(135,000 miles (216,000 km) or 216 months)
7-20
Normal maintenance schedule
150,000 miles (240,000 km) or 120 months
(Continued)
❑ Rotate tires
❑ Inspect front(AWD)/rear differential oil *3
❑ Inspect vacuum hose
(150,000 miles (240,000km) or 192months)
❑ Inspect air conditioning refrigerant
❑ Replace climate control air filter
❑ Inspect brake hoses and lines
(for evaporator and blower unit)
❑ Inspect drive shafts and boots
❑ Replace air cleaner filter
❑ Inspect exhaust pipe and muffler
❑ Replace engine oil and filter
❑ Inspect front brake disc/pads, calipers
(150,000 miles (240,000 km) or 240 months)
❑ Inspect propeller shaft
❑ Replace coolant
❑ Inspect rear brake disc/pads
(First, 120,000 miles (192,000 km) or 120 months
❑ Inspect steering gear box, linkage & boots/lower arm ball
after every 30,000 miles (48,000 km) or 24 months)
joint, upper arm ball joint
❑ Add fuel additives *1
❑ Inspect suspension mounting bolts
(150,000 miles (240,000 km) or 240 months)
❑ Inspect brake fluid
❑ Inspect fuel filter *2
❑ Inspect fuel lines, fuel hoses and connections
No check, No service required
❑ Inspect fuel tank air filter *2
❑ Automatic transmission fluid
❑ Inspect parking brake
7
❑ Inspect vapor hose and fuel filler cap, fuel tank
❑ Inspect drive belts *5
✽ NOTICE
(First, 60,000 miles (96,000 km) or 72 months
After 120 months or 150,000 miles (240,000 km) contin-
after every 15,000 miles (24,000 km) or 24 months)
ue to follow the prescribed maintenance intervals.
(Continued)
7-21
Maintenance
Maintenance under severe usage conditions
The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer
to the chart below for the appropriate maintenance intervals.
R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary
MAINTENANCE
DRIVING
MAINTENANCE ITEM
MAINTENANCE INTERVALS
OPERATION
CONDITION
Every 3,750 miles (6,000 km) or
A, B, C, D, E, F, G,
Engine oil and filter
R
6 months
H, I, J, K
Air cleaner filter
I
More frequently
C, E
Spark plugs
R
More frequently
A, B, H, I, K
Automatic transmission fluid
R
Every 60,000 miles (96,000 km)
A, C, D, E, F, G, H, I
Front brake disc/pads, calipers
I
More frequently
C, D, G, H
Rear brake disc /pads
I
More frequently
C, D, G, H
Parking brake
I
More frequently
C, D, G, H
7-22
MAINTENANCE
DRIVING
MAINTENANCE ITEM
MAINTENANCE INTERVALS
OPERATION
CONDITION
Steering gear box, linkage & boots/
I
More frequently
C, D, E, F, G, H, I
Lower arm ball joint, upper arm ball joint
Every 7,500 miles (12,000 km) or
Drive shafts and boots
I
C, D, E, F, G, H, I, J
6 months
Front(AWD)/rear differential oil
R
Every 75,000 miles (120,000 km)
C, G, H, I, J
Climate control air filter
R
More frequently
C, E
(for evaporator and blower unit)
Every 7,500 miles (12,000 km) or
Propeller shaft
I
C, E
6 months
Severe driving conditions
A-Repeatedly driving short distance of less than 5 miles (8 km)
F-Driving in heavy traffic area over 90°F (32°C)
in normal temperature or less than 10 miles (16 km) in freez-
G-Driving on uphill, downhill, or mountain road
ing temperature
H-Towing a Trailer, or using a camper, or roof rack
B-Extensive engine idling or low speed driving for long dis-
I
- Driving as a patrol car, taxi, other commercial use or vehicle
tances
7
towing
C-Driving on rough, dusty, muddy, unpaved, graveled or salt-
J-Driving over 106 mph (170 km/h)
spread roads
K-Frequently driving in stop-and-go conditions
D-Driving in areas using salt or other corrosive materials or in
very cold weather
E-Driving in sandy areas
7-23
Maintenance
EXPLANATION OF SCHEDULED MAINTENANCE ITEMS
Engine oil and filter
Fuel filter
Vapor hose and fuel filler cap
The engine oil and filter should be
A clogged filter can limit the speed at
The vapor hose and fuel filler cap
changed at the intervals specified in
which the vehicle may be driven,
should be inspected at those inter-
the maintenance schedule. If the car
damage the emission system and
vals specified in the maintenance
is being driven in severe conditions,
cause multiple issues such as hard
schedule. Make sure a new vapor
more frequent oil and filter changes
starting. If an excessive amount of
hose or fuel filler cap is correctly
are required.
foreign matter accumulates in the
replaced.
fuel tank, the filter may require
Drive belts
replacement more frequently. After
Air cleaner filter
installing a new filter, run the engine
Inspect all drive belts for evidence of
A genuine HYUNDAI air cleaner filter
for several minutes, and check for
cuts, cracks, excessive wear or oil
is recommended when the filter is
leaks at the connections. Fuel filters
saturation and replace if necessary.
replaced.
should be installed by an authorized
Drive belts should be checked peri-
HYUNDAI dealer.
odically for proper tension and
Spark plugs
adjusted as necessary.
Fuel lines, fuel hoses and con-
Make sure to install new spark plugs
nections
of the correct heat range.
Check the fuel lines, fuel hoses and
connections for leakage and dam-
age. Have an authorized HYUNDAI
dealer replace any damaged or leak-
ing parts immediately.
7-24
Valve clearance
Automatic transmission fluid
CAUTION
(Lambda engine)
Automatic transmission fluid should
Inspect for excessive valve noise
not be checked under normal usage
The use of a non-specified fluid
and/or engine vibration and adjust if
conditions. But in severe conditions,
could result in transmission
necessary. Have an authorized
the fluid should be changed at an
malfunction and failure. Use
HYUNDAI dealer perform the opera-
authorized HYUNDAI dealer in
only the specified automatic
tion.
accordance to the scheduled mainte-
transmission fluid
(refer to
nance at the beginning of this chap-
“Recommended Lubricants and
ter.
Capacities” in chapter 8).
Cooling system
Check cooling system components,
✽ NOTICE
such as radiator, coolant reservoir,
Automatic transmission fluid color
hoses and connections for leakage
is basically red.
and damage. Replace any damaged
As the vehicle is driven, the auto-
parts.
matic transmission fluid will begin
to look darker. This is a normal con-
dition and you should not judge the
Engine coolant
need to replace the fluid based upon
The coolant should be changed at
the changed color.
the intervals specified in the mainte-
nance schedule.
7
7-25
Maintenance
Brake hoses and lines
Brake discs, pads, calipers
Steering gear box, linkage &
and rotors
boots/lower arm ball joint
Visually check for proper installation,
chafing, cracks, deterioration and
Check the pads for excessive wear,
With the vehicle stopped and the
any leakage. Replace any deteriorat-
discs for run out and wear, and
engine off, check for excessive free-
ed or damaged parts immediately.
calipers for fluid leakage.
play in the steering wheel. Check the
linkage for bends or damage. Check
the dust boots and ball joints for
Brake fluid
Exhaust pipe and muffler
deterioration, cracks, or damage.
Check brake fluid level in the brake
Visually inspect the exhaust pipes,
Replace any damaged parts.
fluid reservoir. The level should be
muffler and hangers for cracks, dete-
between the MIN and the MAX
rioration, or damage. Start the
marks on the side of the reservoir.
engine and listen carefully for any
Drive shafts and boots
Use only hydraulic brake fluid con-
exhaust gas leakage. Tighten con-
Check the drive shafts, boots and
forming to DOT 3 or DOT 4 specifi-
nections or replace parts as neces-
clamps for cracks, deterioration, or
cation.
sary.
damage. Replace any damaged
parts and, if necessary, repack the
grease.
Parking brake
Suspension mounting bolts
Inspect the parking brake system
Check the suspension connections
including the parking brake pedal
for looseness or damage. Retighten
Air conditioning refrigerant
and cables.
to the specified torque.
Check the air conditioning lines and
connections for leakage and dam-
age.
7-26
