✽ NOTICE

HID lamps have superior perform-

ance vs. halogen bulbs. HID lamps

are estimated by the manufacturer to

last twice as long or longer than halo-

gen bulbs depending on their fre-

quency of use. They will probably

require replacement at some point in

the life of the vehicle. Cycling the

headlamps on and off more than typ-

ical use will shorten HID lamps life.

HID lamps do not fail in the same

OBK072056

OBK072057

manner as halogen incandescent

Front fog light bulb replacement

6. Remove the socket from the

lamps. If a headlamp goes out after a

(if equipped)

assembly by turning the socket

period of operation but will immedi-

counterclockwise until the tabs on

1. Turn the steering wheel fully. (If

ately relight when the headlamp

the socket align with the slots on

you want to replace driver side fog

switch is cycled it is likely the HID

the assembly

lamp, turn the steering wheel to

lamp needs to be replaced. HID light-

the front passenger side.)

7. Pull the bulb out of the socket.

ing components are more complex

than conventional halogen bulbs thus

2. Open the hood.

8. Insert a new bulb into the socket.

have higher replacement cost.

3. Disconnect the negative battery

9. Install the socket in the assembly

cable.

by aligning the tabs on the socket

If the light bulb is not operating, have

with the slots in the assembly.

4. Loosen the retaining bolt on the

the vehicle checked by an authorized

Push the socket into the assembly

service cover. And then pull down

HYUNDAI dealer.

and turn the socket clockwise.

the service cover.

10. Install the fog light bulb cover by

5. Remove the fog light bulb cover by

turning it clockwise. And then

turning it counter clockwise.

assemble the service cover.

7 71

Maintenance

8. Install the socket in the assembly

Back up light

Turn signal

by aligning the tabs on the socket

5. Remove the socket from the

with the slots in the assembly.

assembly by turning the socket

Push the socket into the assembly

counterclockwise until the tabs on

and turn the socket clockwise.

the socket align with the slots on

the assembly.

6. Remove the bulb by pulling it out.

7. Inset a new bulb by inserting it into

Back up

the socket.

8. Install the socket in the assembly

OBK072063

by aligning the tabs on the socket

with the slots in the assembly.

Turn signal light

Push the socket into the assembly

5. Remove the socket from the

and turn the socket clockwise.

assembly by turning the socket

counterclockwise until the tabs on

Tail light, Stop and tail light (LED),

the socket align with the slots on

Side marker (LED)

the assembly.

If the light is not operating, we rec-

6. Remove the bulb from the socket

ommend that you checked an

by pressing it in and rotating it

authorized HYUNDAI dealer.

counterclockwise until the tabs on

the bulb align with the slots in the

socket. Pull the bulb out of the

socket.

7. Insert a new bulb by inserting it

into the socket and rotating it until

it locks into place.

7 73

Maintenance

■ Type A

OBK079031

■ Type B

OBK049023

OFD067030

Side repeater light bulb

License plate light bulb

replacement (if equipped)

replacement

If the light bulb is not operating, have

1. Remove the lens by pressing the

the vehicle checked by an authorized

tabs.

HYUNDAI dealer.

2. Remove the socket by turning the

socket counter clockwise.

3. Remove the bulb by pulling it

OBK072031

straight out.

High mounted stop light

4. Install a new bulb in the socket

and install the socket to the lens.

replacement

5. Reinstall the lens securely.

If the light is not operating, have the

vehicle checked by an authorized

HYUNDAI dealer.

7 74

Maintenance

Luggage lamp

Glove box lamp

Interior light bulb replacement

1. Using a flat-blade screwdriver,

gently pry the lens (map lamp) or

lamp

(luggage lamp, glove box

lamp and sunvisor lamp) from the

interior light housing.

2. Remove the bulb by pulling it

straight out.

WARNING

Prior to working on the Interior

Sunvisor lamp

Map lamp

Lights, ensure that the “OFF”

button is depressed to avoid

burning your fingers or receiv-

ing an electric shock.

3. Install a new bulb in the socket.

4. Align the lens tabs with the interior

light housing notches and snap

the lens into place.

CAUTION

OBK079033/OTD079035/OBK079032/OBK079049

Use care not to dirty or damage

lens, lens tab, and plastic hous-

ings.

7 75

Maintenance

APPEARANCE CARE

Exterior care

Finish maintenance

CAUTION

Exterior general caution

Washing

•

Do not use strong soap, chem-

To help protect your vehicle’s finish

It is very important to follow the label

ical detergents or hot water,

directions when using any chemical

from rust and deterioration, wash it

and do not wash the vehicle in

thoroughly and frequently at least

cleaner or polish. Read all warning

direct sunlight or when the

and caution statements that appear

once a month with lukewarm or cold

body of the vehicle is warm.

water.

on the label.

•

Do not wash the side windows

If you use your vehicle for off-road

too close with high pressure

driving, you should wash it after each

High-pressure washing

water. Water may leak through

off-road trip. Pay special attention to

the windows and wet the inte-

•

When using high-pressure wash-

the removal of any accumulation of

rior.

ers, make sure to maintain suffi-

salt, dirt, mud, and other foreign

cient distance from the vehicle.

materials. Make sure the drain holes

•

To prevent damage to the

in the lower edges of the doors and

plastic parts and lamps, do

Insufficient clearance or excessive

pressure can lead to component

rocker panels are kept clear and

not clean with chemical sol-

clean.

vents or strong detergents.

damage or water penetration.

•

Do not spray the camera, sensors

Insects, tar, tree sap, bird droppings,

or its surrounding area directly with

industrial pollution and similar

a high pressure washer. Shock

deposits can damage your vehicle’s

WARNING - Wet brakes

applied from high pressure water

finish if not removed immediately.

After washing the vehicle, test

may cause the device to not oper-

Even prompt washing with plain

the brakes while driving slowly

ate normally.

water may not completely remove all

to see if they have been affected

•

Do not bring the nozzle tip close to

these deposits. A mild soap, safe for

by water. If braking performance

boots (rubber or plastic covers) or

use on painted surfaces, may be

is impaired, dry the brakes by

connectors as they may be dam-

used.

applying them lightly while

aged if they come into contact with

After washing, rinse the vehicle thor-

maintaining a slow forward

high pressure water.

oughly with lukewarm or cold water.

speed.

Do not allow soap to dry on the fin-

ish.

7 76

Maintenance

Waxing

CAUTION

A good coat of wax is a barrier

between your paint and contaminate.

•

Wiping dust or dirt off the

Keeping a good coat of wax on your

body with a dry cloth will

vehicle will help protect it.

scratch the finish.

Wax the vehicle when water will no

•

Do not use steel wool, abra-

longer bead on the paint.

sive cleaners, or strong deter-

gents containing highly alka-

Always wash and dry the vehicle

line or caustic agents on

before waxing. Use a good quality

chrome-plated or anodized

liquid or paste wax, and follow the

aluminum parts. This may

manufacturer’s instructions. Wax all

OJB037800

result in damage to the protec-

metal trim to protect it and to main-

tive coating and cause discol-

tain its luster.

oration or paint deterioration.

CAUTION

Removing oil, tar, and similar materi-

•

Water washing in the engine

als with a spot remover will usually

compartment including high

strip the wax from the finish. Be sure to

pressure water washing may

re-wax these areas even if the rest of

cause the failure of electrical

the vehicle does not yet need waxing.

circuits or engine and related

part located in the engine

compartment.

•

Never allow water or other liq-

uids to come in contact with

electrical/electronic compo-

nents inside the vehicle as

this may damage them.

7 77

Maintenance

Finish damage repair

Bright-metal maintenance

Underbody maintenance

Deep scratches or stone chips in the

•

To remove road tar and insects,

Corrosive materials used for ice and

painted surface must be repaired

use a tar remover, not a scraper or

snow removal and dust control may

promptly. Exposed metal will quickly

other sharp object.

collect on the underbody. If these

rust and may develop into a major

materials are not removed, acceler-

•

To protect the surfaces of bright-

repair expense.

ated rusting can occur on underbody

metal parts from corrosion, apply a

parts such as the fuel lines, frame,

coating of wax or chrome preser-

floor pan and exhaust system, even

vative and rub to a high luster.

✽ NOTICE

though they have been treated with

•

During winter weather or in coastal

If your vehicle is damaged and

rust protection.

areas, cover the bright metal parts

requires any metal repair or

Thoroughly flush the vehicle under-

with a heavier coating of wax or

replacement, be sure the body shop

preservative. If necessary, coat the

body and wheel openings with luke-

applies anti-corrosion materials to

warm or cold water once a month,

parts with non-corrosive petroleum

the parts repaired or replaced.

jelly or other protective compound.

after off-road driving and at the end of

each winter. Pay special attention to

these areas because it is difficult to

see all the mud and dirt. It will do

more harm than good to wet down the

road grime without removing it. The

lower edges of doors, rocker panels,

and frame members have drain holes

that should not be allowed to clog with

dirt; trapped water in these areas can

cause rusting.

7 78

Maintenance

Aluminum wheel maintenance

Corrosion protection

WARNING

The aluminum wheels are coated

Protecting your vehicle from corro-

•

After washing the vehicle, test

with a clear protective finish.

sion

the brakes while driving slow-

•

Do not use any abrasive cleaner,

By using the most advanced design

ly to see if they have been

polishing compound, solvent, or

and construction practices to combat

affected by water. If braking

wire brushes on aluminum wheels.

corrosion, we produces cars of the

performance is impaired, dry

They may scratch or damage the

highest quality. However, this is only

the brakes by applying them

finish.

part of the job. To achieve the long-

lightly while maintaining a

term corrosion resistance your vehi-

•

Clean the wheel when it has

slow forward speed.

cooled.

cle can deliver, the owner's coopera-

•

If the underbody of you vehi-

tion and assistance is also required.

•

Use only a mild soap or neutral

cle is sprayed with coating

detergent, and rinse thoroughly

substances, the high-speed

with water. Also, be sure to clean

Common causes of corrosion

drive system parts such as

the wheels after driving on salted

the drive shaft or propeller

The most common causes of corro-

roads. This helps prevent corro-

shaft will be out of balance

sion on your car are:

sion.

and make noise or vibrate.

• Road salt, dirt and moisture that is

Moreover, the high-speed

•

Avoid washing the wheels with

allowed to accumulate underneath

drive system parts may be

high-speed car wash brushes.

the car.

damaged.

•

Do not use any alkaline or acid

• Removal of paint or protective

detergent. It may damage and cor-

coatings by stones, gravel, abra-

rode the aluminum wheels coated

sion or minor scrapes and dents

with a clear protective finish.

which leave unprotected metal

exposed to corrosion.

7 79

Maintenance

High-corrosion areas

Moisture breeds corrosion

To help prevent corrosion

If you live in an area where your car

Moisture creates the conditions in

You can help prevent corrosion from

is regularly exposed to corrosive

which corrosion is most likely to

getting started by observing the fol-

materials, corrosion protection is

occur. For example, corrosion is

lowing:

particularly important. Some of the

accelerated by high humidity, partic-

common causes of accelerated cor-

ularly when temperatures are just

rosion are road salts, dust control

above freezing. In such conditions,

chemicals, ocean air and industrial

the corrosive material is kept in con-

pollution.

tact with the car surfaces by moisture

that is slow to evaporate.

Mud is particularly corrosive

because it is slow to dry and holds

moisture in contact with the vehicle.

Although the mud appears to be dry,

it can still retain the moisture and

promote corrosion.

High temperatures can also acceler-

ate corrosion of parts that are not

properly ventilated so the moisture

can be dispersed. For all these rea-

sons, it is particularly important to

keep your car clean and free of mud

or accumulations of other materials.

This applies not only to the visible

surfaces but particularly to the

underside of the car.

7 80

Maintenance

Keep your car clean

• When cleaning lower door panels,

Keep paint and trim in good con-

rocker panels and frame members,

dition

The best way to prevent corrosion is

be sure that drain holes are kept

to keep your car clean and free of

Scratches or chips in the finish

open so that moisture can escape

corrosive materials. Attention to the

should be covered with "touch-up"

and not be trapped inside to accel-

underside of the car is particularly

paint as soon as possible to reduce

erate corrosion.

important.

the possibility of corrosion. If bare

metal is showing through, the atten-

tion of a qualified body and paint

• If you live in a high-corrosion area

Keep your garage dry

shop is recommended.

— where road salts are used, near

Don't park your car in a damp, poor-

the ocean, areas with industrial

ly ventilated garage. This creates a

pollution, acid rain, etc.—, you

favorable environment for corrosion.

Bird droppings : Bird droppings are

should take extra care to prevent

This is particularly true if you wash

highly corrosive and may damage

corrosion. In winter, hose off the

your car in the garage or drive it into

painted surfaces in just a few hours.

underside of your car at least once

the garage when it is still wet or cov-

Always remove bird droppings as

a month and be sure to clean the

ered with snow, ice or mud. Even a

soon as possible.

underside thoroughly when winter

heated garage can contribute to cor-

is over.

rosion unless it is well ventilated so

Don't neglect the interior

moisture is dispersed.

•

When cleaning underneath the car,

Moisture can collect under the floor

give particular attention to the

mats and carpeting to cause corro-

components under the fenders and

sion. Check under the mats periodi-

other areas that are hidden from

cally to be sure the carpeting is dry.

view. Do a thorough job; just damp-

Use particular care if you carry fertil-

ening the accumulated mud rather

izers, cleaning materials or chemi-

than washing it away will acceler-

cals in the car.

ate corrosion rather than prevent it.

Water under high pressure and

These should be carried only in

steam are particularly effective in

proper containers and any spills or

removing accumulated mud and

leaks should be cleaned up, flushed

corrosive materials.

with clean water and thoroughly

dried.

7 81

Maintenance

Interior care

Cleaning the upholstery and inte-

Cleaning the lap/shoulder belt

rior trim

webbing

Interior general precautions

Vinyl

Clean the belt webbing with any mild

Prevent chemicals such as perfume,

soap solution recommended for

cosmetic oil, sun cream, hand cleaner,

Remove dust and loose dirt from

cleaning upholstery or carpet. Follow

and air freshener from contacting the

vinyl with a whisk broom or vacuum

the instructions provided with the

interior parts because they may cause

cleaner. Clean vinyl surfaces with a

soap. Do not bleach or re-dye the

damage or discoloration. If they do

vinyl cleaner.

webbing because this may weaken it.

contact the interior parts, wipe them off

immediately. See the instructions that

Fabric

follow for the proper way to clean vinyl.

Cleaning the interior window

Remove dust and loose dirt from fab-

glass

ric with a whisk broom or vacuum

CAUTION

If the interior glass surfaces of the

cleaner. Clean with a mild soap solu-

Never allow water or other liq-

tion recommended for upholstery or

vehicle become fogged (that is, cov-

uids to come in contact with

carpets. Remove fresh spots immedi-

ered with an oily, greasy or waxy

electrical/electronic

compo-

ately with a fabric spot cleaner. If

film), they should be cleaned with

nents inside the vehicle as this

fresh spots do not receive immediate

glass cleaner. Follow the directions

may damage them.

attention, the fabric can be stained

on the glass cleaner container.

and its color can be affected. Also, its

fire-resistant properties can be

CAUTION

reduced if the material is not properly

CAUTION

Do not scrape or scratch the

maintained.

When cleaning leather products

inside of the rear window. This

(steering wheel, seats etc.), use

may result in damage to the rear

CAUTION

neutral detergents or low alco-

window defroster grid.

hol content solutions. If you use

Using anything but recommend-

high alcohol content solutions

ed cleaners and procedures

or acid/alkaline detergents, the

may affect the fabric’s appear-

color of the leather may fade or

ance and fire-resistant proper-

the surface may get stripped off.

ties.

7 82

Maintenance

EMISSION CONTROL SYSTEM

The emission control system of your

Caution for the Inspection and

1. Crankcase emission control

vehicle is covered by a written limited

Maintenance Test (With Electronic

system

warranty. Please see the warranty

Stability Control (ESC) system)

The positive crankcase ventilation

information contained in the Owner’s

•

To prevent the vehicle from mis-

system is employed to prevent air

Handbook & Warranty Information

firing during dynamometer test-

pollution caused by blow-by gases

booklet in your vehicle.

ing, turn the Electronic Stability

being emitted from the crankcase.

Your vehicle is equipped with an

Control

(ESC) system off by

This system supplies fresh filtered air

emission control system to meet all

pressing the ESC switch.

to the crankcase through the air

applicable emission regulations.

•

After dynamometer testing is

intake hose. Inside the crankcase,

There are three emission control

completed, turn the ESC system

the fresh air mixes with blow-by

systems, as follows.

back on by pressing the ESC

gases, which then pass through the

switch again.

PCV valve into the induction system.

(1) Crankcase emission control sys-

tem

2. Evaporative emission con-

(2) Evaporative emission control sys-

trol (including ORVR:

tem

Onboard Refueling Vapor

Recovery) system

(3) Exhaust emission control system

The Evaporative Emission Control

System is designed to prevent fuel

In order to assure the proper function

vapors from escaping into the atmos-

of the emission control systems, it is

phere.

recommended that you have your

(The ORVR system is designed to

car inspected and maintained by an

authorized HYUNDAI dealer in

allow the vapors from the fuel tank to

be loaded into a canister while refu-

accordance with the maintenance

schedule in this manual.

eling at the gas station, preventing

the escape of fuel vapors into the

atmosphere.)

7 83

Maintenance

Canister

3. Exhaust emission control

Engine exhaust gas precautions

system

(carbon monoxide)

Fuel vapors generated inside the fuel

tank are absorbed and stored in the

•

Carbon monoxide can be present

The Exhaust Emission Control

onboard canister. When the engine is

System is a highly effective system

with other exhaust fumes.

running, the fuel vapors absorbed in

Therefore, if you smell exhaust

which controls exhaust emissions

the canister are drawn into the surge

while maintaining good vehicle per-

fumes of any kind inside your vehi-

tank through the purge control sole-

cle, have it inspected and repaired

formance.

noid valve.

immediately. If you ever suspect

exhaust fumes are coming into

Vehicle modifications

your vehicle, drive it only with all

Purge Control Solenoid Valve

(PCSV)

This vehicle should not be modified.

the windows fully open. Have your

Modification of your vehicle could

vehicle checked and repaired

The purge control solenoid valve is

affect its performance, safety or

immediately.

controlled by the Engine Control

durability and may even violate gov-

•

Do not operate the engine in con-

Module

(ECM); when the engine

ernmental safety and emissions reg-

coolant temperature is low during

fined or closed areas

(such as

ulations.

garages) any more than what is

idling, the PCSV closes so that evap-

orated fuel is not taken into the

In addition, damage or performance

necessary to move the vehicle in or

problems resulting from any modifi-

out of the area.

engine. After the engine warms-up

during ordinary driving, the PCSV

cation may not be covered under

•

When the vehicle is stopped in an

opens to introduce evaporated fuel to

warranty.

open area for more than a short

the engine.

• If you use unauthorized electronic

time with the engine running,

devices, it may cause the vehicle to

adjust the ventilation system

(as

operate abnormally, wire damage,

needed) to draw outside air into the

battery discharge and fire. For your

vehicle.

safety, do not use unauthorized

•

Never sit in a parked or stopped

electronic devices.

vehicle for any extended time with

the engine running.

7 84

Maintenance

• When the engine stalls or fails to

Operating precautions for catalytic

start, excessive attempts to restart

CALIFORNIA PROPO-

converters (if equipped)

the engine may cause damage to

SITION 65 WARNING

the emission control system.

Engine exhaust and a wide vari-

WARNING - Fire

ety of automobile components

•

A hot exhaust system can

and parts, including compo-

WARNING - Exhaust

ignite flammable items under

nents found in the interior fur-

Engine exhaust gases contain

your vehicle. Do not park,

nishings in a vehicle, contain or

carbon monoxide (CO). Though

idle, or drive the vehicle over

emit chemicals known to the

colorless and odorless, it is

or near flammable objects,

State of California to cause can-

dangerous and could be lethal if

such as grass, vegetation,

cer and birth defects and repro-

inhaled. Follow the instructions

paper, leaves, etc.

ductive harm. In addition, cer-

on this page to avoid CO poi-

tain fluids contained in vehicles

•

The exhaust system and cat-

soning.

and certain products of compo-

alytic system are very hot

nent wear contain or emit chem-

while the engine is running or

icals known to the State of

immediately after the engine is

California to cause cancer and

turned off. Keep away from the

birth defects or other reproduc-

exhaust system and catalytic,

tive harm.

you may get burned.

Also, do not remove the heat

sink around the exhaust sys-

tem, do not seal the bottom of

the vehicle or do not coat the

vehicle for corrosion control.

It may present a fire risk under

certain conditions.

7 85

Maintenance

CALIFORNIA PERCHLORATE

Your vehicle is equipped with a cat-

• Avoid driving with a very low fuel

NOTICE

alytic converter emission control

level. If you run out of gasoline, it

Perchlorate Material-special handling

device.

could cause the engine to misfire

may apply, See www.dtsc.ca.gov/

Therefore, the following precautions

and result in excessive loading of

hazardouswaste/perchlorate.

the catalytic converter.

must be observed:

Failure to observe these precautions

•

Use only UNLEADED FUEL for

Notice to California Vehicle

could result in damage to the catalyt-

gasoline engines.

Dismantlers :

ic converter and to your vehicle.

•

Do not operate the vehicle when

Perchlorate containing materials,

Additionally, such actions could void

there are signs of engine malfunc-

such as air bag inflators, seatbelt

your warranties.

tion, such as misfire or a noticeable

pretensioners and keyless remote

loss of performance.

entry batteries, must be disposed of

•

Do not misuse or abuse the

according to Title 22 California Code

engine. Examples of misuse are

of Regulations Section 67384.10 (a).

coasting with the ignition off and

descending steep grades in gear

with the ignition off.

•

Do not operate the engine at high

idle speed for extended periods (5

minutes or more).

•

Do not modify or tamper with any

part of the engine or emission con-

trol system. All inspections and

adjustments must be made by an

authorized HYUNDAI dealer.

7 86

Hyundai Genesis Coupe (2016 year). Instruction - part 26
