Hyundai Elantra GT (2018 year). Instruction - part 27

Specifications, Consumer information and Reporting safety defects

Light Bulb

Bulb Type

Wattage

Map lamp

W10W

Type A

FESTOON

Room lamp

Type B

LED

Interior

Vanity mirror lamp

FESTOON

Luggage compartment lamp

FESTOON

License plate lamp

W5W

8-4

TIRES AND WHEELS

Inflation pressure

kPa (psi)

Wheel lug nut

Items

Tire Size

Wheel Size

torque kgf•m

Normal Load

Maximum Load

(lbf•ft, N•m)

Front

Rear

Front

Rear

225/45 R17

7.0J X 17

230 (33)

Full size tire

11~13

225/40 R18

7.5J X 18

230 (33)

(79~94,

T125/80 D15

4.0T X 15

420 (60)

107~127)

Compact spare tire

T125/80 D16

4.0T X 16

420 (60)

NOTICE

• It is permissible to add 3 psi to the standard tire pressure specification if colder temperatures are expect-

ed soon.

Tires typically loose 1psi (7kPa) for every 12°F temperature drop. If extreme temperature variations are

expected, recheck your tire pressure as necessary to keep them properly inflated.

• An air pressure generally decreases, as you drive up to a high-altitude area above sea level. Thus, if you

plan to drive a high-altitude area, check the tire pressures in advance. If necessary, inflate them to a prop-

er level. (Air inflation per altitude : +2.4 psi/1 mile)

• Tires get higher strain when driving at high speed than under normal condition, and can cause tire failure.

Therefore, if you are driving at sustained high speed (over 100 mile/h or 160 km/h) with 225/40R18 sized

tires, add 5 psi to the standard tire pressure. However, do not exceed the maximum inflation pressure indi-

cated on the tire sidewall.

CAUTION

When replacing tires, use the same size originally supplied with the vehicle.

Using tires of a different size can damage the related parts or not work properly.

8-5

Specifications, Consumer information and Reporting safety defects

VOLUME AND WEIGHT

Gamma 1.6 T-GDI

Nu 2.0 GDI

Items

M/T

DCT

M/T

A/T

Gross vehicle weight

4,034 (1,830)

4,078 (1,850)

3,924 (1,780)

3,968 (1,800)

lbs. (kg)

Luggage volume (SAE)

24.9 (705)

cu ft (l)

M/T : Manual transmission

A/T : Automatic transmission

DCT : Dual clutch transmission

AIR CONDITIONING SYSTEM

Items

Weight of Volume

Classification

Refrigerant

17.63 (500)

R-1234yf

oz. (g)

Compressor lubricant

3.88±0.35 (110±10)

PAG

oz. (cc)

Contact an authorized HYUNDAI dealer for more details.

8-6

RECOMMENDED LUBRICANTS AND CAPACITIES

To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality.

The correct lubricants also help promote engine efficiency that results in improved fuel economy.

Lubricant

Volume

Classification

Engine oil *1 *2 (drain and refill)

Gamma

4.76 US qt. (4.5 l)

1.6 T-GDI

Recommends

API SM *3 & ILSAC GF-4 (or above)

ACEA A5/B5 *4

Nu 2.0 GDI

4.23 US qt. (4.0 l)

HK SYN MTF 70W (SK)

Gamma

SPIRAX S6 GHME 70W MTF (H.K.SHELL)

Manual transmission fluid

1.6 T-GDI/

1.8~1.9 US qt. (1.7 ~ 1.8 l)

GS MTF HD 70W (GS CALTEX)

Nu 2.0 GDI

(API GL-4, SAE 70W TGO-9)

MICHANG ATF SP-IV, SK ATF SP-IV,

NOCA ATF SP-IV, HYUNDAI genuine ATF

Automatic transmission fluid

Nu 2.0 GDI

7.08 US qt. (6.7 l)

SP-IV or other brands meeting the above

specification approved by HYUNDAI Motor

Co.

HK SYN DCTF 70W (SK)

SPIRAX S6 GHME 70W DCTF

Gamma

Dual clutch transmission fluid

2.01~2.11 US qt. (1.9~2.0 l)

(H.K.SHELL)

1.6 T-GDI

GS DCTF HD 70W (GS CALTEX)

(API GL-4, SAE 70W)

8-7

Specifications, Consumer information and Reporting safety defects

Lubricant

Volume

Classification

Gamma

M/T

6.55 US qt. (6.2 l)

1.6 T-GDI

Mixture of antifreeze and water

DCT

Coolant

(Phosphate-based Ethylene glycol coolant for

M/T

6.23 US qt. (5.9 l)

aluminum radiator)

Nu 2.0 GDI

A/T

6.12 US qt. (5.8 l)

0.74~0.85 US qt.

Brake/Clutch fluid

FMVSS116 DOT-3 or DOT-4

(0.7 ~ 0.8 l)

Refer to "Fuel requirements" in the Foreword

Fuel

14.0 US gal. (53 l)

chapter.

*1 : Refer to the recommended SAE viscosity numbers on the next page.

*2 : Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel econ-

omy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure

in everyday driving, but in a year's time, they can offer significant cost and energy savings.

*3 : If the API service SM engine oil is not available in your country, you are able to use API service SL.

*4 : If the ACEA A5 engine oil is not available in your country, you are able to use ILSAC GF-3 (or above) or ACEA A3 (or above).

8-8

Recommended SAE viscosity

Engine oil viscosity (thickness) has an effect on fuel economy and cold

number

weather operating (engine start and engine oil flowability). Lower viscosity

engine oils can provide better fuel economy and cold weather performance,

however, higher viscosity engine oils are required for satisfactory lubrication

CAUTION

in hot weather.

Always be sure to clean the area

Using oils of any viscosity other than those recommended could result in

around any filler plug, drain

engine damage.

plug, or dipstick before check-

When choosing an oil, consider the range of temperature your vehicle will be

ing or draining any lubricant.

operated in before the next oil change. Proceed to select the recommended

This is especially important in

oil viscosity from the chart.

dusty or sandy areas and when

the vehicle is used on unpaved

Temperature Range for SAE Viscosity Numbers

roads. Cleaning the plug and

°C

-30

-20

-10

dipstick areas will prevent dirt

Temperature

(°F)

-10

100

120

and grit from entering the

20W-50

engine and other mechanisms

that could be damaged.

Gamma

15W-40

1.6 T-GDI *1

10W-30

Engine

5W-30, 5W-40

Oil

Nu 2.0

10W-30

GDI *2

5W-20, 5W-30

*1 :For better fuel economy, it is recommended to use the engine oil

of a viscosity grade 5W-30 (ACEA A5 or above). However, if the

engine oil is not available in your country, select the proper

engine oil using the engine oil viscosity chart.

*2 :For better fuel economy, it is recommended to use the engine oil

of a viscosity grade SAE

5W-20 (API SM / ILSAC GF-4).

However, if the engine oil is not available in your country, select

the proper engine oil using the engine oil viscosity chart.

8-9

Specifications, Consumer information and Reporting safety defects

VEHICLE IDENTIFICATION NUMBER (VIN)

VEHICLE CERTIFICATION

■ Frame number

■ VIN label

LABEL

OPD086001

OPD086002

The vehicle identification number

The VIN is also on a plate attached

OPDE086007

(VIN) is the number used in register-

to the top of the dashboard. The

The vehicle certification label attached

ing your car and in all legal matters

number on the plate can easily be

on the driver's side center pillar gives

pertaining to its ownership, etc.

seen through the windshield from

the Vehicle Identification Number

outside.

The number is punched on the floor

(VIN).

under the passenger seat. To check

the number, open the cover.

8-10

TIRE SPECIFICATION AND

ENGINE NUMBER

REFRIGERANT LABEL

PRESSURE LABEL

■ Gamma 1.6 T-GDI

(IF EQUIPPED)

OPD086005

■ Nu 2.0 GDI

OPD086007

OPDE086008

The tires supplied on your new vehi-

The refrigerant label provides infor-

cle are chosen to provide the best

mation such as refrigerant type and

performance for normal driving.

amount.

The tire label located on the driver’s

The label is located on the underside

side center pillar gives the tire pres-

of the hood.

sures recommended for your car.

OPD087012L

The engine number is stamped on

the engine block as shown in the

drawing.

8-11
