Maintenance

Waxing

CAUTION

A good coat of wax is a barrier

between your paint and contaminate.

•

Do not use strong soap,

Keeping a good coat of wax on your

chemical detergents or hot

vehicle will help protect it.

water, and do not wash the

vehicle in direct sunlight or

Wax the vehicle when water will no

when the body of the vehicle

longer bead on the paint.

is warm.

Always wash and dry the vehicle

•

Be careful when washing the

before waxing. Use a good quality

side windows of your vehicle.

liquid or paste wax, and follow the

manufacturer’s instructions. Wax all

Especially, with high-pressure

OLMB073082

metal trim to protect it and to main-

water, water may leak through

tain its luster.

the windows and wet the inte-

CAUTION

Removing oil, tar, and similar materi-

rior.

als with a spot remover will usually

•

To prevent damage to the

•

Water washing in the engine

strip the wax from the finish. Be sure

plastic parts, do not clean

compartment including high

to re-wax these areas even if the rest

with chemical solvents or

pressure water washing may

of the vehicle does not yet need wax-

strong detergents.

cause the failure of electrical

ing.

circuits located in the engine

compartment.

•

Never allow water or other liq-

uids to come in contact with

electrical/electronic compo-

nents inside the vehicle as

this may damage them.

7-78

Finish damage repair

Bright-metal maintenance

CAUTION

Deep scratches or stone chips in the

• To remove road tar and insects,

painted surface must be repaired

use a tar remover, not a scraper or

•

Wiping dust or dirt off the

promptly. Exposed metal will quickly

other sharp object.

body with a dry cloth will

rust and may develop into a major

• To protect the surfaces of bright-

scratch the finish.

repair expense.

metal parts from corrosion, apply a

•

Do not use steel wool, abra-

coating of wax or chrome preser-

sive cleaners, or strong deter-

NOTICE

vative and rub to a high luster.

gents containing highly alka-

line or caustic agents on

• During winter weather or in coastal

If your vehicle is damaged and

chrome-plated or anodized

areas, cover the bright metal parts

requires any metal repair or

aluminum parts. This may

with a heavier coating of wax or

replacement, be sure the body

result in damage to the pro-

preservative. If necessary, coat the

shop applies anti-corrosion mate-

tective coating and cause dis-

parts with non-corrosive petroleum

rials to the parts repaired or

coloration or paint deteriora-

jelly or other protective compound.

replaced.

tion.

Underbody maintenance

Corrosive materials used for ice and

snow removal and dust control may

collect on the underbody. If these

materials are not removed, acceler-

ated rusting can occur on underbody

parts such as the fuel lines, frame,

floor pan and exhaust system, even

though they have been treated with

rust protection.

7-79

Maintenance

Thoroughly flush the vehicle under-

Aluminum wheel maintenance

Corrosion protection

body and wheel openings with luke-

The aluminum wheels are coated with

Protecting your vehicle from corro-

warm or cold water once a month,

a clear protective finish.

sion

after off-road driving and at the end

By using the most advanced design

of each winter. Pay special attention

CAUTION

and construction practices to combat

to these areas because it is difficult

corrosion, HYUNDAI produces cars

to see all the mud and dirt. It will do

•

Do not use abrasive cleaner,

of the highest quality. However, this is

more harm than good to wet down

polishing compound, solvent,

only part of the job. To achieve the

the road grime without removing it.

or wire brushes on aluminum

long-term corrosion resistance your

The lower edges of doors, rocker

wheels.

vehicle can deliver, the owner’s

panels, and frame members have

cooperation and assistance is also

drain holes that should not be

•

Clean the wheel when it has

required.

allowed to clog with dirt; trapped

cooled.

water in these areas can cause rust-

•

Use only a mild soap or neu-

ing.

tral detergent, and rinse thor-

Common causes of corrosion

oughly with water. Also, clean

The most common causes of corro-

the wheels after driving on

sion on your vehicle are:

WARNING

salted roads.

• Road salt, dirt and moisture that is

After washing the vehicle, test

•

Do not wash the wheels with

allowed to accumulate underneath

the brakes while driving slowly

high-speed car wash brushes.

the vehicle.

to see if they have been affected

•

Do not use any cleaners con-

• Removal of paint or protective

by water. If braking performance

taining acid or alkaline deter-

coatings by stones, gravel, abra-

is impaired, dry the brakes by

gents.

sion or minor scrapes and dents

applying them lightly while

which leave unprotected metal

maintaining a slow forward

exposed to corrosion.

speed.

7-80

High-corrosion areas

Moisture breeds corrosion

To help prevent corrosion

If you live in an area where your vehi-

Moisture creates the conditions in

Keep your car clean

cle is regularly exposed to corrosive

which corrosion is most likely to

The best way to prevent corrosion is

materials, corrosion protection is

occur. For example, corrosion is

to keep your vehicle clean and free

particularly important. Some of the

accelerated by high humidity, partic-

of corrosive materials. Attention to

common causes of accelerated cor-

ularly when temperatures are just

the underside of the vehicle is partic-

rosion are road salts, dust control

above freezing. In such conditions,

ularly important.

chemicals, ocean air and industrial

the corrosive material is kept in con-

pollution.

tact with the car surfaces by moisture

that is slow to evaporate.

• If you live in a high-corrosion area

— where road salts are used, near

Mud is particularly corrosive

the ocean, areas with industrial

because it is slow to dry and holds

pollution, acid rain, etc.—, you

moisture in contact with the vehicle.

should take extra care to prevent

Although the mud appears to be dry,

corrosion. In winter, hose off the

it can still retain the moisture and

underside of your vehicle at least

promote corrosion.

once a month and be sure to clean

High temperatures can also acceler-

the underside thoroughly when

ate corrosion of parts that are not

winter is over.

properly ventilated so the moisture

can be dispersed. For all these rea-

sons, it is particularly important to

keep your vehicle clean and free of

mud or accumulations of other mate-

rials. This applies not only to the vis-

ible surfaces but particularly to the

underside of the vehicle.

7-81

Maintenance

• When cleaning underneath the

Keep your garage dry

Interior Care

vehicle, pay particular attention to

Don’t park your car in a damp, poor-

Interior general precautions

the components under the fenders

ly ventilated garage. This creates a

and other areas that are hidden

Prevent caustic solutions such as

favorable environment for corrosion.

from view. Do a thorough job; just

perfume and cosmetic oil, from con-

This is particularly true if you wash

dampening the accumulated mud

tacting the interior parts because

your vehicle in the garage or drive it

rather than washing it away will

they may cause damage or discol-

into the garage when it is still wet or

accelerate corrosion rather than

oration. If they do contact the interior

covered with snow, ice or mud. Even

prevent it. Water under high pres-

parts, wipe them off immediately.

a heated garage can contribute to

sure and steam are particularly

See the instructions for the proper

corrosion unless it is well ventilated

effective in removing accumulated

way to clean vinyl.

so moisture is dispersed.

mud and corrosive materials.

• When cleaning lower door panels,

CAUTION

Keep paint and trim in good condition

rocker panels and frame members,

be sure that drain holes are kept

Scratches or chips in the finish

•

Never allow water or other liq-

open so that moisture can escape

should be covered with "touch-up"

uids to come in contact with

and not be trapped inside to accel-

paint as soon as possible to reduce

electrical/electronic compo-

erate corrosion.

the possibility of corrosion. If bare

nents inside the vehicle as

metal is showing through, the atten-

this may damage them.

tion of a qualified body and paint

•

When cleaning leather prod-

shop is recommended.

ucts

(steering wheel, seats

Bird droppings are highly corrosive

etc.), use neutral detergents

and may damage painted surfaces in

or low alcohol content solu-

just a few hours. Always remove bird

tions. If you use high alcohol

droppings as soon as possible.

content solutions or acid/

alkaline detergents, the color

of the leather may fade or the

surface may get stripped off.
