Hyundai Sonata Plug-in Hybrid (2017 year). Instruction - part 33

What to do in an emergency

A cold tire means the vehicle has

i

Information

WARNING

been sitting for 3 hours and driven for

less than 1 mile (1.6 km) in that 3

This device complies with Part 15 of

Tampering with, modifying, or

the FCC rules.

hour period.

disabling the Tire Pressure

Allow the tire to cool before measur-

Operation is subject to the following

Monitoring System

(TPMS)

ing the inflation pressure. Always be

three conditions:

components may interfere with

sure the tire is cold before inflating to

1. This device may not cause harmful

the system's ability to warn the

the recommended pressure.

interference, and

driver of low tire pressure con-

ditions and/or TPMS malfunc-

2. This device must accept any inter-

tions. Tampering with, modify-

ference received, including interfer-

WARNING

ing, or disabling the Tire

ence that may cause undesired

Pressure Monitoring System

operation.

• The TPMS cannot alert you to

severe and sudden tire dam-

(TPMS) components may void

3.

Changes or modifications not

age caused by external fac-

the warranty for that portion of

expressly approved by the party

tors such as nails or road

the vehicle.

responsible for compliance could

debris.

void the user’s authority to operate

the equipment.

• If you feel any vehicle instabil-

ity, immediately take your foot

off the accelerator, apply the

brakes gradually with light

force, and slowly move to a

safe position off the road.

6-14

IF YOU HAVE A FLAT TIRE

■ Hybrid

Introduction

CAUTION

One sealant bottle for one tire

When two or more tires are flat,

do not use the tire mobility kit

because the supported one

sealant of Tire Mobility Kit is

only used for one flat tire.

OLFH064014

■ Plug-in hybrid

WARNING

OLF064015

Tire wall

With the Tire Mobility Kit you stay

Do not use the Tire Mobility Kit

mobile even after experiencing a tire

to repair punctures in the tire

puncture.

walls. This can result in an acci-

6

The compressor and sealing com-

dent due to tire failure.

pound system effectively and com-

fortably seals most punctures in a

passenger car tire caused by nails

OLFP065014

WARNING

or similar objects and reinflates the

For safe operation, carefully read

tire.

and follow the instructions in this

Temporary fix

manual before use.

After you ensure that the tire is prop-

Have your tire repaired as soon

erly sealed you can drive cautiously

(1) Compressor

as possible. The tire may lose

on the tire (distance up to 120 miles

(2) Sealant bottle

air pressure at any time after

(200 km)) at a max. speed of (50mph

The Tire Mobility Kit is a temporary fix

inflating with the Tire Mobility

(80 km/h)) in order to reach a service

to the tire and the tire should be

Kit.

station or tire dealer for the tire

inspected by an authorized HYUNDAI

replacement.

dealer as soon as possible.

6-15

Components of the Tire Mobility Kit

9. Hose to connect compressor and

sealant bottle or compressor and

wheel

Connectors, cable and connection

hose are stored in the compressor

housing.

Strictly

follow

the

specified

sequence, otherwise the sealant

may escape under high pressure.

WARNING

Do not use the tire sealant after

the sealant has expired

(i.e.

pasted the expiration date on

the sealant container). This can

6

increase the risk of tire failure.

OEL069020

WARNING

0. Speed restriction label

4. Holder for the sealant bottle

• Keep out of reach of children.

1. Sealant bottle and label with

5. Compressor

speed restriction

• Avoid contact with eyes.

6. ON/OFF switch

• Do not swallow.

2. Filling hose from sealant bottle to

7. Pressure gauge for displaying the

wheel

tire inflation pressure

3. Connectors and cable for power

8. Screw cap for reducing tire infla-

outlet direct connection

tion pressure

6-17

What to do in an emergency

Using the Tire Mobility Kit

1. Detach the speed restriction label

(0) from the sealant bottle (1), and

place it in a highly visible place

inside the vehicle such as on the

steering wheel to remind the driv-

er not to drive too fast.

OLMF064104

OLF064017

2. Screw the connection hose

(9)

4. Unscrew the valve cap from the

onto the connector of the sealant

valve of the flat tire and screw the

bottle.

filling hose (2) of the sealant bottle

onto the valve.

3. Ensure that the screw cap (8) is

closed.

6-18

CAUTION

Securely install the sealant fill-

ing hose to the valve. If not,

sealant may flow backward,

possibly clogging the filling

hose.

OLMF064105

OLF064019N

5. Insert the sealant bottle into the

7. Plug the compressor power cord

housing (4) of the compressor so

(3) into the vehicle power outlet.

that the bottle is upright.

8. With the ignition switch in the ON

6. Ensure that the compressor is

position, switch on the compres-

switched off, position 0.

sor and let it run for approximately

6

OHY015012

5~7 minutes to fill the sealant up

to proper pressure. (refer to the

Tire and Wheels, chapter 8). The

inflation pressure of the tire after

filling is unimportant and will be

checked/corrected later.

Be careful not to overinflate the

tire and stay away from the tire

when filling it.

6-19

What to do in an emergency

Distributing the sealant

CAUTION

11. Immediately drive approximately

4~6miles (7~10km or about 10

Do not attempt to drive your

minutes) to evenly distribute the

vehicle if the tire pressure is

sealant in the tire.

below

29 psi

(200kpa). This

could result in an accident due

Do not exceed a speed of 50 mph

to sudden tire failure.

(80 km/h). If possible, do not fall

below a speed of 12 mph (20 km/h).

While driving, if you experience any

9. Switch off the compressor.

unusual vibration, ride disturbance or

10. Detach the hoses from the

noise, reduce your speed and drive

OLF064020

sealant bottle connector and

with caution until you can safely pull

from the tire valve.

off of the side of the road.

Checking the tire inflation pres-

sure

Return the Tire Mobility Kit to its stor-

age location in the vehicle.

1. After

driving

approximately

CAUTION

4~6miles

(7~10km or about

10 minutes), stop at a safe loca-

WARNING

Never use a puncture-repairing

tion.

agent not approved by HYUNDAI

Do not leave your vehicle run-

dealer to repair and/or inflate a

2. Connect hose (9) of the compres-

ning in a poorly ventilated area

low pressure tire. Tire sealant

sor directly to the tire valve.

for extended periods of time.

not approved by HYUNDAI deal-

3. Plug the compressor power cord

Carbon monoxide poisoning

er may damage the tire pressure

into the vehicle power outlet.

and suffocation can occur.

sensor.

6-20

4. Adjust the tire inflation pressure to

CAUTION

the recommended tire inflation.

With the ignition switched on, pro-

When you use the Tire Mobility

ceed as follows.

Kit including sealant not

- To increase the inflation pres-

approved by HYUNDAI, the tire

sure:

pressure sensors may be dam-

Switch on the compressor, posi-

aged by sealant. The sealant on

tion to [I]. To check the current

the tire pressure sensor and

inflation pressure setting, briefly

wheel should be removed when

switch off the compressor.

you replace the tire with a new

one and inspect the tire pres-

- To reduce the inflation pres-

sure sensors at an authorized

sure:

dealer.

Loosen the screw cap (8) on the

compressor hose.

i

Information

6

The pressure gauge may show higher

than actual reading when the com-

pressor is running. To get an accurate

tire pressure, the compressor needs to

be turned off.

6-21

What to do in an emergency

TOWING

Towing service

It is acceptable to tow the vehicle

with the rear wheels on the ground

A

(without dollies) and the front wheels

off the ground.

If any of the loaded wheels or sus-

pension components are damaged

or the vehicle is being towed with the

front wheels on the ground, use a

B

towing dolly under the front wheels.

OLF064023

When being towed by a commercial

tow truck and wheel dollies are not

used, the front of the vehicle should

C

always be lifted, not the rear.

Dolly

OLF064021N

OLF064022

If emergency towing is necessary,

we recommend having it done by an

authorized HYUNDAI dealer or a

CAUTION

commercial tow-truck service.

• Do not tow the vehicle with

Proper lifting and towing procedures

the front wheels on the

are necessary to prevent damage to

ground as this may cause

the vehicle. The use of wheel dollies

damage to the vehicle.

or flatbed is recommended.

• Do not tow with sling-type

equipment. Use wheel lift or

flatbed equipment.

6-22

When towing your vehicle in an

Removable towing hook

emergency without wheel dollies :

■ Hybrid

1. Place the Engine Start/Stop but-

ton in the ACC position.

2. Place the shift lever in N (Neutral).

3. Release the parking brake.

CAUTION

Failure to place the transmis-

sion shift lever in N (Neutral)

OLFH064025

OLFH064024

may cause internal damage to

■ Plug-in hybrid

2. Open the cover by pressing the

the transmission.

lower part on the front bumper.

3. Install the towing hook by rotating

it in a clock-wise direction until it is

securely installed.

6

4. After use, remove the towing hook

and close the cover.

OLFP065024

1. Open the trunk, and take the tow-

ing hooks out from the tool case.

6-23

What to do in an emergency

Emergency Towing

If towing service is not available in an

Always follow these emergency tow-

(if equipped)

emergency, your vehicle may be

ing precautions:

temporarily towed using a cable or

•

Place the Engine Start/Stop button

■ Front

chain secured to the emergency tow-

in the ACC position so the steering

ing hook at the rear of the vehicle.

wheel is not locked.

Use extreme caution when towing

•

Place the shift lever in N (Neutral).

the vehicle with a cable or chain. A

•

Release the parking brake.

driver must be in the vehicle to steer

it and operate the brakes.

•

Depress the brake pedal with more

force than normal since you will

Towing should be done only on a

have reduced braking perform-

solid ground for a short distance and

ance.

at a low speed.

•

More steering effort will be

OLFH064026N

Also, the wheels, axles, power train,

■ Rear

required because the power steer-

steering and brakes must all be in

ing system will be disabled.

good condition.

•

Use a vehicle heavier than your

own to tow your vehicle.

•

The drivers of both vehicles should

communicate with each other fre-

quently.

•

Before emergency towing, check

that the hook is not broken or dam-

aged.

OLFH064027

•

Fasten the towing cable or chain

If towing is necessary, we recom-

securely to the hook.

mend you to have it done by an

authorized HYUNDAI dealer or a

•

Do not jerk the hook. Apply steady

commercial tow truck service.

and even force.

6-24

CAUTION

To avoid damage to your vehicle

and vehicle components when

towing:

•

Always pull straight ahead

when using the towing hooks.

Do not pull from the side or at

a vertical angle.

•

Do not use the towing hooks

ODH063025

to pull a vehicle out of mud,

sand or other conditions from

•

Use a towing cable or chain less

which the vehicle cannot be

than 16 feet (5 m) long. Attach a

driven out under its own

white or red cloth (about 12 inches

power.

(30 cm) wide) in the middle of the

cable or chain for easy visibility.

•

Limit the vehicle speed to 10

mph (15 km/h) and drive less

6

•

Drive carefully so the towing cable

than 1 mile (1.5 km) when tow-

or chain remains tight during tow-

ing to avoid serious damage

ing.

to the automatic transmis-

•

Before towing, check the automat-

sion.

ic transmission for fluid leaks under

your vehicle. If the automatic trans-

mission fluid is leaking, flatbed

equipment or a towing dolly must

be used.

6-25

What to do in an emergency

IF AN ACCIDENT OCCURS

WARNING

(Continued)

WARNING

• When the vehicle is severely

•

For your safety, do not touch

damaged, remain a safe dis-

When a submersion in water

high voltage cables, connec-

tance of 50 feet (15 meter) or

occurs:

tors and package modules.

more between your vehicle

When your vehicle is flooded in

High voltage components are

and other vehicles/flamma-

water, a high-voltage battery

orange in color.

bles.

may cause shock or may catch

•

Exposed cables or wires may

on fire. Thus, turn the hybrid

be visible inside or outside of

system OFF, take the key in

the vehicle. Never touch the

WARNING

your possession and move to a

wires or cables, because an

safe place. Never attempt phys-

electrical shock, an injury, or a

If a fire occurs :

ical contact with your flooded

death may occur.

vehicle. Immediately contact an

Upon witnessing any sparks,

•

Any gas or electrolyte leakage

authorized HYUNDAI dealer and

gases, flames, or fuel leakage of

from your vehicle is not only

advise them that a hybrid vehi-

your vehicle, immediately call

poisonous but also flammable.

cle is involved.

911 or contact an authorized

Upon witnessing one of those,

HYNDAI dealer. Also, advise

open the windows, and remain

them that a hybrid vehicle is

a safe distance from the vehi-

involved.

cle out of the road. Immediately

contact an authorized Hyundai

dealer and advise them that a

hybrid vehicle is involved.

•

If you need towing, refer to

"Towing" in the previous pages.

(Continued)

6-26

Maintenance

Engine compartment

7-3

Parking brake

7-34

Maintenance services

7-4

Checking the parking brake

7-34

Owner's responsibility

7-4

Air cleaner

7-35

Owner maintenance precautions

7-4

Filter replacement

7-35

Owner maintenance

7-5

Climate control air filter

7-37

Owner maintenance schedule

7-6

Filter inspection

7-37

Scheduled maintenance services

7-8

Wiper blades

7-39

Normal maintenance schedule

7-9

Blade inspection

7-39

Maintenance under severe usage conditions

7-22

Blade replacement

7-39

Explanation of scheduled maintenance

Battery

7-41

items

7-24

For best battery service

7-42

Engine oil

7-27

Battery recharging

7-42

Checking the engine oil level

7-27

Reset features

7-43

Checking the engine oil and filter

7-28

Tires and wheels

7-44

Engine coolant/inverter coolant

7-29

Tire care

7-44

Checking the engine/inverter coolant level

7-29

Recommended cold tire inflation pressures

7-45

Changing engine coolant

7-32

Check tire inflation pressure

7-46

Tire rotation

7-47

Hybrid starter & generator (HSG) belt

7-32

Wheel alignment and tire balance

7-48

Checking the hybrid starter &

7

Tire replacement

7-48

generator (HSG) belt

7-32

Wheel replacement

7-49

Brake fluid

7-33

Tire traction

7-49

Checking the brake fluid level

7-33

Tire maintenance

7-50

Washer fluid

7-34

Tire sidewall labeling

7-50

Checking the washer fluid level

7-34

Tire terminology and definitions

7-54

All season tires

7-57

Emission control system

7-102

Summer tires

7-57

Crankcase emission control system

7-102

Snow tires

7-57

Evaporative emission control system including

Radial-ply tires

7-58

onboard refueling vapor recovery (ORVR)

7-102

Low aspect ratio tires

7-58

Exhaust emission control system

7-103

Fuses

7-60

California perchlorate notice

7-106

Instrument panel fuse replacement

7-61

Engine compartment panel fuse replacement

7-62

Fuse/relay panel description

7-64

Light bulbs

7-80

Headlamp, parking lamp, turn signal lamp and

side marker light bulb replacement

7-81

Side repeater lamp replacement

7-86

Rear combination light bulb replacement

7-87

Back-up lamp

7-91

High mounted stop lamp

7-92

License plate light bulb replacement

7-92

Interior light bulb replacement

7-92

Appearance care

7-94

7

Exterior care

7-94

Interior care

7-99

ENGINE COMPARTMENT

1. Engine oil filler cap

2. Engine oil dipstick

3. Radiator cap

4. Engine coolant reservoir

5. Brake fluid reservoir

6. Air cleaner

7. Inverter coolant reservoir

8. Windshield washer fluid reservoir

9. Fuse box

The actual engine compartment the vehicle

may differ from the illustration.

7

OLFH014005K

7-3

Maintenance

MAINTENANCE SERVICES

You should exercise the utmost care

Detailed warranty information is pro-

Certain modifications may also be in

to prevent damage to your vehicle

vided in your Owner’s Handbook &

violation of regulations established

and injury to yourself whenever per-

Warranty Information booklet.

by the U.S. Department of

forming any maintenance or inspec-

Transportation and other federal or

Repairs and adjustments required as

tion procedures.

state agencies.

a result of improper maintenance or

Have your vehicle maintained and

a lack of required maintenance are

repaired by an authorized HYUNDAI

not covered.

NOTICE

dealer. An authorized HYUNDAI

Improper owner maintenance dur-

dealer meets HYUNDAI’s high serv-

Owner maintenance precau-

ing the warranty period may affect

ice quality standards and receives

tions

warranty coverage. For details,

technical support from HYUNDAI in

read the separate Owner’s

order to provide you with a high level

Inadequate, incomplete or insuffi-

Handbook & Warranty Information

of service satisfaction.

cient servicing may result in opera-

booklet provided with the vehicle.

tional problems with your vehicle that

If you’re unsure about any service

could lead to vehicle damage, an

Owner's responsibility

or maintenance procedure, have it

accident, or personal injury. This

done by an authorized HYUNDAI

Maintenance service and record

chapter provides instructions only for

dealer.

retention are the owner’s responsibil-

the maintenance items that are easy

ity.

to perform. Several procedures can

be done only by an authorized

You should retain documents that

show proper maintenance has been

HYUNDAI dealer with special tools.

performed on your vehicle in accor-

Your vehicle should not be modified

dance with the scheduled mainte-

in any way. Such modifications may

nance service charts shown on the

adversely affect the performance,

following pages. You need this infor-

safety or durability of your vehicle

mation to establish your compliance

and may, in addition, violate condi-

with the servicing and maintenance

tions of the limited warranties cover-

requirements of your vehicle war-

ing the vehicle.

ranties.

7-4

Content   ..  31  32  33  34   ..
