REAR VIEW CAMERA

BLUE LINK® (IF EQUIPPED)

(if equipped)

Hyundai aims to offer differentiated

customer values through a

‘Connected Car Life’, which is to pro-

•

The system has been equipped

vide consumers with fast and reliable

Hyundai Motor plans to achieve this

by realizing a terminal platform flexi-

with a rear view camera for user

IT technology. As consumers’ lifestyles

safety by allowing a wider rear

become more and more mobile in

ble to changes in IT technology,

cooperating with global IT compa-

range of vision.

thanks to remarkable advances in

smart phones, tablet PCs and overall

nies, creating an eco-system and

•

The rear view camera will automat-

providing the latest contents & servic-

wireless telecommunication, new

ically operate when the ignition key

lifestyle patterns demand seamless

es based on an open environment.

is turned ON and the shift lever is

connection between one’s office,

set to R (Reverse).

home, outdoors and automobiles.

•

The rear view camera will automat-

Automobile companies are now faced

ically stop operating when shift

with the task of shifting their paradigm

lever is set to different position.

from vehicle-centered services to cus-

tomer value-centered services, with

CAUTION

the ultimate goal of securing global

leadership in the field of vehicle IT and

The rear view camera has been

telematics.

equipped with an optical lens to

provide a wider range of vision

and may appear different from

the actual distance. For safety,

directly check the rear and

left/right sides.

4-54

Using the Room Mirror Key

➁

(Blue Link® for POI)

Information

Selecting the room mirror key will

• Blue Link® for Voice command

The Turn by Turn (TBT) feature sup-

allow you to make service required

Starts Blue Link® voice command.

ports the store of ten (10) destinations

inquiries, POI info searches, and

in the TBT destinations directory.

Voice receiving voice guidance,

emergency rescues by connecting to

shortly press the button to convert to

the Blue Link® Center.

voice command mode. Press and

3. Route Preview

Such features can be used only after

hold the button to end voice com-

“Route Preview” VR command allows

subscribing to the Blue Link® service.

mand.

the user to preview the route instruc-

tions

(upcoming maneuver instruc-

• TBT VR Commands

tions) at any time during the route

1. Navigate to

guidance.

“Navigate to” voice command is used

to request the download of route

4. Destinations List

data for a new destination, saved

“Destinations List” VR command

destinations, daily routes and previ-

allows the user to preview and delete

ous destinations.

the stored destinations with their

associated voice tags in the Turn by

2. Save Destination

Turn destinations directory.

➀

(Blue Link® Center)

“Save Destination” VR command is

Makes requests for Blue Link® serv-

used to assign a voice tag to the last

5. Voice Guidance

ice related inquiries and consulta-

downloaded destination and store it

“Voice Guidance” VR command allows

tions.

in a destination directory.

the user to mute/unmute the Turn by

A call is connected to the Blue Link®

Turn(TBT) direction announcements.

service center employee.

Re-pressing the key will end the call.

This feature does not operate when

you are on a Bluetooth® phone call.

4-55

Multimedia System

6. Suspend Route

Information

"Suspend Route" VR command

•

You cannot talk simultaneously on

allows the user to suspend and

the Bluetooth® phone and Blue

pause Turn by Turn(TBT) route guid-

Link® phone.

ance while in the guidance mode.

•

While on a Bluetooth® call, pressing

the

key or

key will dis-

7. Resume Route

play a message indicating that you

"Resume Route" VR command

are currently on a call.

allows the user to resume Turn by

•

A message will be displayed if you

Turn(TBT) route guidance.

receive a Bluetooth® Bluetooth®

Wireless Technology call while already

on a Blue Link® call. At this time,

➂

(Blue Link® for SOS)

press the

key on the steering

In the case of an emergency,

wheel remote controller to accept the

requests for help to the Blue Link®

call. The phone bell will not ring.

center.

Call is connected to the Blue Link®

emergency rescue center. Re-press-

ing the key will end the call.

If already on a Bluetooth® phone call,

the call will end to connect you to the

Blue Link® Emergency Rescue

Center.

4-56

Turn by Turn

4.Next Street name

The Turn by Turn feature can be used

5.Distance to destination

through Blue Link®.

6.Expected Time Arrival

7. Current Street name

❈ For information on specific

Blue Link® operations, please refer

to a separate manual.

1.Direction Indicator Image

2.Remaining distance until next point

3.The Count bar is divided into a

total of 9 levels.

9 Level

0.5mi

8 Level

0.4mi

7 Level

0.3mi

6 Level

0.2mi

5 Level

0.1mi

4 Level

400ft

3 Level

300ft

2 Level

200ft

1 Level

100ft

4-57
