Auto up/down window

Automatic reverse (if equipped)

i

Information

(if equipped)

The automatic reverse feature is only

Pressing or pulling up the power win-

active when the “Auto Up” feature is

dow switch momentarily to the sec-

used by fully pulling up the switch to

ond detent position

(6) completely

the second detent.

lowers or lifts the window even when

the switch is released. To stop the

window at the desired position while

WARNING

the window is in operation, pull up or

press down and release the switch.

Make sure body parts or other

objects are safely out of the way

before closing the windows to

To reset the power windows

avoid injuries or vehicle damage.

OLF044032

If the power windows do not operate

Objects less than 0.16 inch (4 mm)

normally, the automatic power win-

If a window senses any obstacle while

in diameter caught between the

dow system must be reset as follows:

it is closing automatically, it will stop

window glass and the upper win-

1. Place the ignition switch to the ON

and lower approximately 12 inches (30

dow channel may not be detected

position.

cm) to allow the object to be cleared.

by the automatic reverse window

2. Close the window and continue

If the window detects the resistance

and the window will not stop and

while the power window switch is

reverse direction.

pulling up on the power window

switch for at least one second.

pulled up continuously, the window

will stop upward movement then

If the power windows do not operate

lower approximately 1 inch (2.5 cm).

properly after resetting, have the

system checked by an authorized

If the power window switch is pulled

HYUNDAI dealer.

up continuously again within 5 sec-

onds after the window is lowered by

the automatic window reversal fea-

ture, the automatic window reversal

will not operate.

3-46

Power window lock switch

NOTICE

WARNING

•

To prevent possible damage to

Do not allow children to play

the power window system, do

with the power windows. Keep

not open or close two windows

the driver’s door power window

or more at the same time. This

lock switch in the LOCK posi-

will also ensure the longevity of

tion. Serious injury or death can

the fuse.

3

result from unintentional win-

•

Never try to operate the main

dow operation by a child.

switch on the driver’s door and

the individual door window

switch in opposite directions at

the same time. If this is done, the

OLF044033

window will stop and cannot be

opened or closed.

The driver can disable the power

window switches on the rear passen-

gers’ doors by pressing the power

window lock switch.

When the power window lock switch

is pressed:

• The driver’s master control can

operate all the power windows.

• The front passenger’s control can

operate the front passenger’s

power window.

• The rear passenger’s control can-

not operate the rear passengers’

power window.

3-47

Convenient features of your vehicle

SUNROOF (IF EQUIPPED)

Sunroof opening and closing

Sliding the sunroof

Pressing the sunroof control lever

backward or forward momentarily to

the second detent position completely

opens or closes the sunroof even

when the switch is released. To stop

the sunroof at the desired position

while the sunroof is in operation, press

the sunroof control lever backward or

forward and release the switch.

OLFC044034CN

i

Information

If your vehicle is equipped with a

OLFC044036CN

To minimize wind noise while driving,

sunroof, you can slide or tilt your

To open:

it is recommended that you drive with

sunroof with the sunroof control

the sunroof slightly closed (stop the

switch located on the overhead con-

Press the sunroof control lever back-

sunroof about 2 inch (5 cm) before the

sole.

ward to the first detent position.

maximum slide open position).

The sunroof can only be opened,

Release the switch when you want

closed, or tilted when the ignition

the sunroof to stop.

NOTICE

switch is in the ON position.

To close:

Press the sunroof control lever back-

To prevent damage to the sunroof

ward to the first detent position.

and the motor, do not continue to

Release the switch when you want

press the sunroof control lever

the sunroof to stop.

after the sunroof is in the fully

open, closed or tilt position(s).

3-48

Automatic reversal

Tilting the sunroof

WARNING

•

Make sure heads, other body

parts or other objects are

safely out of the way before

closing the sunroof to avoid

injuries or vehicle damage.

3

•

Never adjust the sunroof or

sunshade while driving. This

may cause loss of vehicle con-

trol resulting in an accident.

•

To avoid serious injury or

OLFC044035CN

OLFC044037CN

death, do not extend your

If the sunroof senses an obstacle

Tilt the sunroof open:

head, arms or body outside

while it is closing automatically, it

the sunroof while driving.

Push the sunroof control lever

should reverse direction and stop to

upward until the sunroof moves to

allow the object to be cleared.

the desired position.

To close the sunroof:

Pull the sunroof lever downward until

the sunroof moves to the desired

position.

3-49

Convenient features of your vehicle

NOTICE

Sunshade

Resetting the sunroof

Sunroof needs to be reset if the fol-

• Periodically remove any dirt that

lowing occurs :

may accumulate on the sunroof

guide rail or between the sun-

- Battery is discharged or discon-

roof and roof panel which can

nected or the related fuse has been

make a noise.

replaced or disconnected

• Do not try to open the sunroof

- The one-touch sliding function of

when the temperature is below

the sunroof does not normally oper-

freezing or when the sunroof is

ate

covered with snow or ice as the

motor could be damaged.

Reset procedure :

OLFC044038CN

1. Place the ignition switch to the ON

i

Information

position or start the engine. It is

The sunshade will open automatical-

After washing the vehicle or after a

recommended to reset the sunroof

ly with the sunroof when the glass

rain, be sure to wipe off the water on

while the engine is running.

panel moves. If you want it closed,

the sunroof before operating the sun-

2. Push the control lever forward. The

move the sunshade manually.

roof.

sunroof will close completely or tilt

depending on the condition of the

NOTICE

sunroof.

The sunroof is made to slide

3. Release the control lever until the

together with the sunshade. Do

sunroof does not move.

not leave the sunshade closed

while the sunroof is open.

3-50

Convenient features of your vehicle

PANORAMIC SUNROOF (IF EQUIPPED)

Sunshade

WARNING

Never adjust the sunroof or sun-

shade while driving. This could

result in loss of vehicle control

resulting in an accident.

WARNING

• Make sure heads, other body

OLF044034

parts or objects are out of the

The ignition switch must be in the ON

way before using the sunroof.

OLF044035

position before you can open or

• Do not leave the engine run-

• To open the sunshade, press the

close the sunroof.

ning and the key in your vehi-

sunshade control switch (1).

cle with unsupervised children.

• To close the sunshade, press the

i

Information

Unattended children could

sunshade control switch (2). If you

operate the sunroof, which

In cold and wet climates, the sunroof

press the switch when the sunroof

could result in serious injury.

may not work properly due to freezing

glass is opened, the sunroof glass

conditions.

will close then the sunshade will

NOTICE

close.

To prevent damage to the sunroof

To stop the sliding at any point, press

the sunshade control switch momen-

and the motor, do not continue to

press the sunroof control lever

tarily.

after the sunroof is in the fully

open, closed or tilt position(s).

3-52

Sliding the Sunroof

When the sunshade is opened

Tilting the Sunroof

When the sunshade is closed

If you pull the sunroof control lever

When the sunshade is closed

backward, the sunroof glass will slide

all the way open. To stop the sunroof

movement at any point, pull or push

the sunroof control lever momentarily.

3

i

Information

Only the front glass of the panoramic

sunroof opens and closes.

OLF044036

OLF044037

If you pull the sunroof control lever

If you push the sunroof control lever

backward, the sunshade will slide all

upward, the sunshade will slide open

the way open then the sunroof glass

then the sunroof glass will tilt.

will slide all the way open. To stop the

To stop the sunroof movement at any

sunroof movement at any point, pull

point, pull or push the sunroof control

or push the sunroof control lever

lever momentarily.

momentarily.

When the sunshade is opened

If you push the sunroof control lever

upward, the sunroof glass will tilt.

To stop the sunroof movement at any

point, pull or push the sunroof control

lever momentarily.

3-53

Convenient features of your vehicle

Closing the Sunroof

Automatic reverse

WARNING

•

Make sure heads, other body

parts or other objects are

safely out of the way before

closing the sunroof to avoid

injuries or vehicle damage.

Objects that are small caught

between the sunroof glass

and the front glass channel

may not be detected by the

automatic reverse glass and

OLF044038

ODH043039

the glass will not stop and

reverse direction.

Press the sunshade CLOSE button.

If the sunroof senses any obstacle

The sunroof glass will close then the

while it is closing automatically, it will

•

To avoid serious injury or

sunshade will close. To stop the sun-

reverse direction then stop to allow

death, do not extend your

roof movement at any point, press

the object to be cleared.

head, arms or body outside

the sunshade control switch momen-

the sunroof while driving.

tarily.

•

A panoramic sunroof is made

of glass, therefore it may break

in an accident. If you do not

have your seat belt on, you

may stick out of the broken

glass and get injured or killed.

For all passengers safety, have

an appropriate protection on

(ex. seat belt, child restraint

system, etc.).

3-54

NOTICE

To Reset the Sunroof

3. Push the sunroof control lever for-

ward in the direction of close

• Periodically remove any dirt that

(about 10 seconds) until the sun-

may accumulate on the sunroof

roof slightly moves. Then, release

guide rail or between the sun-

the lever.

roof and roof panel.

4. Push the sunroof control lever for-

• Do not try to open the sunroof

ward in the direction of close until

when the temperature is below

the sunroof operates as follows:

3

freezing or when the sunroof is

covered with snow or ice, the

Sunshade Open → Glass Tilt Open

motor could be damaged.

→ Glass Slide Open → Glass Slide

Close → Sunshade Close

i

Information

OLF044040

After the vehicle is washed or in a

Sunroof needs to be reset if the fol-

Then, release the control lever.

rainstorm, be sure to wipe off any

lowing occurs :

water that is on the sunroof before

operating it.

- Battery is discharged or discon-

When this is complete, the sunroof

nected or the related fuse has been

system is reset.

replaced or disconnected

- The one-touch sliding function of

For more information, contact an

the sunroof does not normally oper-

authorized HYUNDAI dealer.

ate

i

Information

1. Turn the engine on and close the

If you do not reset the sunroof, it may

sunroof glass and sunshade com-

not work properly.

pletely.

2. Release the control lever.

3-55

Convenient features of your vehicle

EXTERIOR FEATURES

Hood

Closing the hood

Opening the hood

1. Before closing the hood, check the

following:

• All filler caps in engine compart-

ment must be correctly installed.

• Gloves, rags or any other com-

bustible material must be

removed from the engine com-

partment.

2. Lower the hood halfway

(lifted

OLF044042N

approximately

30cm from the

closed position) and push down to

3. Raise the hood slightly, push the

securely lock in place. Then dou-

secondary latch up (1) inside of

OLF044041

ble check to be sure the hood is

the hood center and lift the hood

secure.

1. Park the vehicle and set the park-

(2). After it has been raised about

ing brake.

halfway, it will raise completely by

2. Pull the release lever to unlatch

itself.

the hood. The hood should pop

open slightly.

3-56

Trunk

■ Inside

WARNING

Opening the trunk

•

Before closing the hood,

■ Outside

ensure all obstructions are

removed from around hood

opening.

•

Always double check to be

3

sure that the hood is firmly

latched before driving away.

Check there is no hood open

warning light or message dis-

OLF044044

played on the instrument clus-

- Use the trunk release button.

ter. Driving with the hood

opened may cause a total loss

OLF044043

3. Lift the trunk lid up.

of visibility, which might

1. Make sure the shift lever is in P

result in an accident.

(Park).

•

Do not move the vehicle with

2. Then do one of the following :

the hood in the raised posi-

- Press the Remote key or Smart

tion, as vision is obstructed,

Key Trunk Unlock button for more

which might result in an acci-

than one second.

dent, and the hood could fall

or be damaged.

- Press the button on the trunk

itself with the Smart Key in your

possession.

- Use the mechanical key.

3-57

Convenient features of your vehicle

Closing the trunk

NOTICE

Emergency trunk safety release

Lower the trunk lid and press down

To prevent damage to the trunk lift

until it locks.

cylinders and the attached hard-

ware, always close the trunk

WARNING

before driving.

Always keep the trunk lid com-

i

Information

pletely closed while the vehicle is

in motion. If it is left open or ajar,

In cold and wet climates, trunk lock

poisonous exhaust gases con-

and trunk mechanisms may not

taining carbon monoxide (CO)

work properly due to freezing con-

may enter the vehicle and seri-

ditions.

ous illness or death may result.

OLF044045

Your vehicle is equipped with an

Emergency Trunk Safety Release

WARNING

lever located inside the trunk. When

someone is inadvertently locked in

Make sure there are no people

the trunk, the trunk can be opened by

or objects around the trunk

moving the lever in the direction of the

before opening or closing the

arrow and pushing the trunk open.

Power Trunk. Wait until the trunk

is open fully and stopped

before loading or unloading

cargo from the vehicle.

3-58

Trunk lid control switch

WARNING

(Continued)

•

Your vehicle should be kept

•

You and your passengers

locked and the Smart Key

must be aware of the location

should be kept out of the reach

of the Emergency Trunk

of children. Parents should

Safety Release lever in this

teach their children about the

vehicle and how to open the

dangers of playing in trunks.

3

trunk in case you are acciden-

•

Use the release lever for

tally locked in the trunk.

emergencies only.

•

NEVER allow anyone to occu-

py the trunk of the vehicle at

any time. If the trunk is par-

tially or totally latched and the

OLF044004

person is unable to get out,

The trunk lid control switch is used to

serious injury or death could

prevent unauthorized access to the

occur due to lack of ventila-

trunk.

tion, exhaust fumes and rapid

• When the trunk lid control switch is

heat build-up, or because of

in the UNLOCK position (

), the

exposure to cold weather con-

trunk can be unlocked with the

ditions. The trunk is also a

trunk release button and the

highly dangerous location in

remote key or smart key.

the event of a crash because it

is not a protected occupant

• When the trunk lid control switch is

space but is a part of the vehi-

in the LOCK position (

), the trunk

cle’s crush zone.

can be unlocked with the mechani-

cal key of the remote key or smart

(Continued)

key.

3-59

Convenient features of your vehicle

Smart Trunk (if equipped)

How to use the Smart Trunk

The trunk can be opened with no-

touch activation satisfying all the

conditions below.

• After

15 seconds when all doors

are closed and locked

• Positioned in the detecting area for

more than 3 seconds.

i

Information

OLF054450N

• The Smart Trunk does not operate

when:

1. Setting

OLF044046

- The smart key is detected within

To activate the Smart Trunk, go to

On a vehicle equipped with a smart

15 seconds after the doors are

User Settings Mode and select

key, the trunk can be opened using

closed and locked, and is continu-

Smart Trunk on the LCD display.

the Smart Trunk system.

ously detected.

- The smart key is detected within

For more information, refer to the

15 seconds after the doors are

"LCD Display" section in this

closed and locked, and within 60

chapter.

inches (1.5 m) from the front door

handles.

(for vehicles equipped

with Welcome Light)

- A door is not locked or closed.

- The smart key is in the vehicle.

3-60

WARNING

•

Make sure you close the trunk

before driving your vehicle.

•

Make sure there are no people

or objects around the trunk

before opening or closing the

3

trunk.

•

Make sure objects in the trunk

do not come out when open-

OLF044047N

OLF044048

ing the trunk on a slope. It

may cause serious injury.

2. Detect and Alert

3. Automatic opening

•

Make sure to deactivate the

If you are positioned in the detecting

The hazard warning lights will blink

Smart Trunk when washing

area

(20~40 inches

(50

~100 cm)

and chime will sound 2 times and

your vehicle. Otherwise, the

behind the vehicle) carrying a smart

then the trunk will open.

trunk may open inadvertently.

key, the hazard warning lights will blink

and chime will sound for about 3 sec-

•

The key should be kept out of

onds to alert you the smart key has

reach of children. Children

been detected and the trunk will open.

may inadvertently open the

Smart Trunk while playing

i

Information

around the rear area of the

vehicle.

Do not approach the detecting area if

you do not want the trunk to open. If

you have unintentionally entered the

detecting area and the hazard warn-

ing lights and chime starts to operate,

leave the detecting area with the

smart key. The trunk will stay closed.

3-61

Convenient features of your vehicle

How to deactivate the Smart

Detecting area

i

Information

Trunk function using the smart

•

If you press the door unlock button

key

(2), the Smart Trunk function will

be deactivated temporarily. But, if

you do not open any door for 30 sec-

onds, the smart trunk function will

be activated again.

•

If you press the trunk open button

(3) for more than

1 second, the

trunk opens.

•

If you press the door lock button (1)

or trunk open button (3) when the

OLF044050N

Smart Trunk function is not in the

Detect and Alert stage, the smart

•

The Smart Trunk operates with a

OLF044006

trunk function will not be deactivated.

welcome alert if the smart key is

detected within

20~40 inches

1. Door lock

3. Trunk open

•

In case you have deactivated the

(50~100 cm) from the trunk.

Smart Trunk function by pressing

2. Door unlock

4. Panic

the smart key button and opened a

•

The alert stops at once if the smart

If you press any button of the smart

door, the smart trunk function can

key is positioned outside the

key during the Detect and Alert

be activated again by closing and

detecting area during the Detect

stage, the Smart Trunk function will

locking all doors.

and Alert stage.

be deactivated.

Make sure to be aware of how to

deactivate the Smart Trunk function

for emergency situations.

3-62

Content   ..  6  7  8  9   ..
